iHome HiH66 User manual

Model HiH66
The Hotel System
For Your iPod®
Questions? Visit www.hoteltech.com
Music
Photos
Extras
Settings
Shuffle Songs
Backlight
NOTE: THIS UNIT WILL NOT CONTROL OR CHARGE 3G iPod

Table of Contents
Quick Set Up .....................................................................................................................................................................1
Controls and Indicators / HiH66 Display........................................................................................................................2
Using the HiH66 ............................................................................................................................................................3-4
Replacing HiH66 Backup Batteries .................................................................................................................................4
Install/Replace Backup Battery
Batteries information
A Consumer Guide to Product Safety............................................................................................................................5
Troubleshooting............................................................................................................................................................6-7
This equipment complies with the limits for a Class B digital device as specified in Part 15 of FCC Rules. These limits
provide reasonable protection against radio and TV interference in a residential area.
However, your equipment might cause TV or radio interference even when it is operating properly. To eliminate interference
you can try one or more of the following corrective measures:
• Reorient or relocate the receiving antenna.
• Increase the distance between the equipment and the radio or TV.
• Use outlets on different electrical circuits for the equipment and the radio or TV.
Consult your dealer or an experienced radio/television technician if the problem still exists.
Modifying or tampering with your system’s internal components can cause a malfunction and might invalidate the system’s
warranty and void your FCC authorization to operate it.
This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this
device does not cause harmful interference.
A Consumer Guide to Product Safety
Maintenance
• Place the unit on a level surface away from sources of direct sunlight or excessive heat.
• Protect your furniture when placing your unit on a natural wood and lacquered finish. A cloth or other protective material should
be placed between it and the furniture.
• Clean your unit with a soft cloth moistened only with mild soap and water. Stronger cleaning agents, such as Benzine, thinner
or similar materials can damage the surface of the unit.

1
quick set up
Attach AC adaptor cable to
jack on back of the HiH66 and
plug the other end into a
wall socket.
1:power
• Press & hold the Time Zone
button on back until display
flashes
• Turn the Set Wheel to select
your time zone
• Press the Time Zone
button again
• Leave the DST switch on back
of unit on Auto for automatic
daylight savings time changes
3:time
2:rear cover
5:security
Press the Radio button to select
FM radio mode.Turn the Set
Wheel to tune in a station. Press
and hold a pre-set button
(1, 2,3 or 4) to save the station
as a preset.
4:radio presets NOTE: When not in use,
attached line-in cord plug
must be stored in plug
holder on rear of unit to
avoid improper operation
Unit is preset to Eastern time.
If you need to change the time,
turn thumbscrew to remove the
Rear Cover to access Time Zone,
Clock Adjust and DST (Daylight
Savings Time) controls. Replace
Rear Cover after adjusting
settings.
Attach security tether to bottom
of the HiH66 and secure the
other end to a wall or other
permanent surface.

2
Controls and Indicators
iH66 Display
Snooze/Dimmer Button 
Alarm On/Off Button 
Alarm Set Button 
iPod Button 
Volume Wheel 
Radio Button 
Dock 
Preset Buttons 
 Dock Adjust Switch
Alarm Indicator
Daylight Saving Time
Indicator
Battery Low Indicator
Time Display PM Indicator
Radio Frequency / Alarm Time/AUX Display
iPod Indicator
Alarm Time PM Indicator
Wake To Indicator:
iPod, Radio, Buzzer,
FM Indicator
Power Button
 Wake-to Button
Set Wheel
AC Adaptor Jack Time Zone Button 
 DST switch
 Clock Adjust Button
 Line-in Cord
 FM Antenna
Rear Cover

3
Using the HiH66
Connect HiH66 to Power Source
a) Plug the AC adaptor cable into the AC Adaptor Jack and the other end into a standard 120v wall socket. The HiH66 does
not operate on batteries.
Setting the Clock
a) Press and hold the  Time Zone Button until the display flashes.
b) Turn the Set Wheel to select your time zone.
c) Press the Time Zone Button again. The clock will display the current time in your time zone.
d) DST (Daylight Saving Time):This unit ships with the  DST Switch set to AUTO and will automatically adjust for daylight savings
time in that position. In a non-DST zone, set the switch to OFF. To set DST manually, set to +1 to advance the time 1 hour. Slide
to OFF to turn the clock back 1 hour.
To Set Clock Manually
a) Press and hold the  Clock Adjust Button. The clock display will flash.
b) Turn the  Set Wheel until the current time is displayed (a PM indicator appears when time is set to PM; there is no AM indicator).
c) Press the Clock Adjust Button to accept the time. The year display will flash.
d) Turn the Set Wheel to adjust the year and press the Clock Adjust Button. The date display will flash.
e) Turn the Set Wheel to adjust the date and press the Clock Adjust Button. Two beeps will indicate clock setting is complete.
Using the Alarm
Setting the Alarms
a) Press and hold the  Alarm Set Button until the alarm time flashes and the unit beeps.
b) Turn the Set Wheel to set the alarm time (a PM indicator appears when time is set to PM; there is no AM indicator).
c) Press the Alarm Set Button again. Alarm is now armed, indicated by the alarm icon and alarm source icon.
d) Press the Wake To Button at any time to select iPod, radio or buzzer as your alarm source.You cannot wake to shuffle.
Arming and Disarming Alarm (Turn Alarm Function ON and OFF)
a) Press the Alarm On/Off Button to arm or disarm alarm functions. When armed, the related alarm icon appears in display.
One Day Alarm
a) Once the alarm sounds it will be disamerd and must be set again to come on the following day.This prevents waking to unwanted
alarms.
Snooze
a) Press the  Snooze/Dimmer Button after the alarm sounds. The alarm will be silenced and come on again 9 minutes later. Snooze
can be pressed several times during the 1 hour alarm cycle.
Sure Alarm
The HiH66 has a sure alarm feature so the buzzer alarm will still sound in the event of power failure, if backup batteries are installed.
iPod
Playing and charging your iPod
a) Set Dock Adjust Switch to match your iPod, then gently dock iPod. iPod should be firmly in place in the dock. When docked,
iPod will charge until fully charged. Unit will not overcharge iPod. Note: The HiH66 will not control or charge 3G iPod
models.
b) Press the iPod Button to play iPod, and again to pause.
c) Turn Volume Wheel to adjust HiH66 volume up or down
d) Press
Power Button to turn HiH66 and iPod off.
Note: If you dock an iPod with a drained battery, it may take up to 6 minutes of charging before the iPod will respond.

Install/Replace Backup Battery
The HiH66 uses a backup battery system to provide continuous alarm operation and clock settings in the event of a power
failure. If the Battery Low Icon located on the left of the display is flashing, it is time to replace the
backup batteries.
Please make sure the AC adaptor is connected, otherwise all settings may be lost
during battery replacement.
Open the battery compartment cover located on the bottom of the unit. Insert 2 “AA” batteries
as indicated. We recommend the use of alkaline batteries for longer life.
Batteries information:
• Do not mix old and new batteries.
• Do not mix alkaline, standard (carbon -zinc) or rechargeable (nickel-cadmium) batteries.
Replacing HiH66 Backup Batteries
4
Using the HiH66
Radio
Setting up Antenna
a) Extend the FM Antenna (on back of unit) fully for best reception. Do not strip, alter or attach to other antennas.
Tuning and Playing the Radio
a) Press the Radio Button to select FM radio.
b) Turn the Set Wheel to tune radio to a desired station.
c) To memorize the current station as a preset, press and hold  Preset Button 1,2,3 or 4. Repeat steps a,b,and c to preset up
to 4 FM stations. To listen to a preset station at any time, simply press the desired preset button.
d) Turn the Volume Wheel to adjust HiH66 volume up or down.
e) Press
Power Button to turn HiH66 off.
Using the Line-in Cord
a) An audio line-in cord comes with the HiH66. Use it to play nondocking iPods or other audio devices through the HiH66. Make
sure there is no iPod docked in the HiH66 when using the line-in cord. Press the iPod Button until AUX appears on the display.
Store the audio line-in cord properly in provided plug holder when not in use to avoid static charge which can interfere with proper
operation.
Using Dimmer
a) Press the  Snooze/Dimmer Button during normal operation to adjust brightness of LCD display.

When used in the directed manner, this unit has been designed and manufactured to ensure your personal safety.
However, improper use can result in potential electrical shock or fire hazards. Please read all safety and operating
instructions carefully before installation and use, and keep these instructions handy for future reference. Take special
note of all warnings listed in these instructions and on the unit.
1. Water and Moisture – The unit should not be used near water. For example: near a bathtub, washbowl, kitchen sink,
laundry tub, swimming pool or in a wet basement.
2. Ventilation – The unit should be situated so that its location or position does not interfere with its proper ventilation.
For example, it should not be situated on a bed, sofa, rug or similar surface that may block ventilation openings.
Also, it should not be placed in a built-in installation, such as a bookcase or cabinet, which may impede the flow of
air through the ventilation openings.
3. Heat – The unit should be situated away from heat sources such as radiators, heat registers, stoves or other appliances
(including amplifiers) that produce heat.
4. Power Sources – The unit should be connected to a power supply only of the type described in the operating
instructions or as marked on the appliance.
5. Power-Cable Protection – Power supply cables should be routed so that they are not likely to be walked on or
pinched by items placed upon or against them. It is always best to have a clear area from where the cable exits the
unit to where it is plugged into an AC socket.
6. Cleaning – The unit should be cleaned only as recommended. See the Maintenance section of this manual for
cleaning instructions.
7. Objects and Liquid Entry – Care should be taken so that objects do not fall and liquids are not spilled into any
openings or vents located on the product.
8. Attachments – Do not use attachments not recommended by the product manufacturer.
9. Lightning and Power Surge Protection – Unplug the unit from the wall socket and disconnect the antenna or
cable system during a lightning storm or when it is left unattended and unused for long periods of time. This will
prevent damage to the product due to lightning and power-line surges.
10. Overloading – Do not overload wall sockets, extension cords, or integral convenience receptacles as this can result
in a risk of fire or electric shock.
11. Damage Requiring Service – The unit should be serviced by qualified service personnel when:
A. the power supply cable or plug has been damaged.
B. objects have fallen into or liquid has been spilled into the enclosure.
C. the unit has been exposed to rain.
D. the unit has been dropped or the enclosure damaged.
E. the unit exhibits a marked change in performance or does not operate normally.
12. Antenna – Do not connect an external antenna to the unit (other than that provided).
13. Periods of Nonuse – If the unit is to be left unused for an extended period of time, such as a month or longer, the
power cable should be unplugged from the unit to prevent damage or corrosion.
14. Servicing – The user should not attempt to service the unit beyond those methods described in the user’s operating
instructions. Service methods not covered in the operating instructions should be referred to qualified service
personnel.
Questions? Visit www.hoteltech.com
A Consumer Guide to Product Safety
5

HiH66 does not turn on AC adaptor isn't plugged into a working wall socket
or not plugged into the power supply jack on back
of the unit
Plug the AC adaptor into a working wall socket and plug the
connector into the supply jack on the unit
HiH66 requires a reset If unit is plugged in and doesn't respond, try resetting the unit by following
these steps:
a) remove iPod from dock
b) unplug unit from power source
c) remove back up batteries
d) wait 1 hour, then resume use
iPod does not dock
properly
iPod didn’t install properly Remove your iPod from the dock and check for obstruction on the
connectors in the dock and on your iPod. Then reseat it in the dock.
Battery Low icon always
flashing
Batteries are weak Replace with new batteries
Batteries were not installed properly Check to make sure the polarity ( + and – ends) matches the diagram
in the battery compartment
iPod does not respond
to the unit/iPod is
playing but no sound
comes out
iPod is not installed properly Remove your iPod from the dock and check for obstruction on the
connectors in the dock and on your iPod. Then reseat it in the dock.
Your iPod software is too old Upgrade software on your iPod. For details visit
http://www.apple.com/ipod/download
iPod is locked up/plays but no sound
comes out
Check the volume setting. Make sure your iPod is working properly
before docking into the unit. Please refer to your iPod manual for
details. See above for software upgrade information.
You may need to reset your iPod. To do so:
1. Toggle the Hold switch to hold position, then off.
2. Press and hold the Menu and center Select buttons at the same
time until Apple logo appears. You may need to repeat this
step.
Using 1st or 2nd generation iPod, iPod Shuffle or
other devices.
HiH66 cannot control those iPods or other devices.
iPod didn’t charge up iPod is not installed properly Remove your iPod from the dock and check for obstruction on the
connectors in the dock and on your iPod. Then reseat it in the dock.
iPod is locked up/ frozen
iPod battery has problem
Please make sure your iPod is working properly before docking into the
unit. Please refer to your iPod manual for details.
6
Troubleshooting
Solution
Symptom Possible Problem
No sound from HiH66 Volume is set too low on HiH66 Make sure volume is turned up
Move unit away from potential sources of external interference such as
computers, modems, wireless devices (routers) or fluorescent light
HiH66/iPod performance
is erratic The HiH66 is reacting to external interference
HiH66 doesn’t
respond

Sound is distorted Volume level is set too high Decrease the volume
Sound source is distorted If the iPod original sound source (MP3) is old or of poor quality, distortion
and noise are easily noticed with high-power speakers. Try a different
audio source such as a music CD.
If you are using an external sound source like older generation of iPod
or iPod Shuffle, try reducing the output volume on the device itself. Also
try turning bass boost OFF.
7
Troubleshooting
Solution
Symptom Possible Problem
Unit/adaptor gets warm
after extended play at
high volume
This is normal Turn unit off for awhile or lower volume
The signal from the line out jack needs amplification. Use powered
speakers/monitors or other amplified audio device.
Can't hear
headphones/speakers
attached to line out jack
Line out jack is not meant for headphones.
Speakers need a power source
Clock reset/changed
times
Electrostatic charge from line-in cord Store the end of the line-in cord properly away in provided plug holder
on back of unit when not in use. Adjust clock to proper time.
NOTE: When not in use, attached line-in cord plug must be stored in plug holder on rear of
unit to avoid improper operation.

HiH66USBIB-110206-B Printed in China
