IKA®CBC 5 control

CBC 5 basic_112016

Operating instructions EN

2

Item Designation

1 Wireless Controller (WiCo)

2 Filling opening lid

3 Front cover

4 Handle

5 Venting grid

6 Mains switch

7 Power socket

8 Cable clip

9Pump connection IN

10 Pump connection OUT

11 RS 232 interface

12 USB interface

13 External temperature sensor socket

14 Multifunction interface

Device setup

Fig. 1

11

RS 232

13

ext

Pt 100

12

Micro USB

1

2

3

5

4

611

12

13

14

7

9

10

4

8

14

Multi I/O

5

3

Contents

EN

Source language: German

Page

Device setup................................................................................................................................................. 2

Declaration of Conformity............................................................................................................................ 4

Note for USA (FCC)....................................................................................................................................... 4

Note for Canada (IC)..................................................................................................................................... 4

Explication of warning symbols ................................................................................................................... 4

Safety instructions ....................................................................................................................................... 5

General information ��5

Fluids��6

Battery pack RB 1 (for WiCo) ��6

Correct use................................................................................................................................................... 7

Use ��7

Range of use (indoor use only)��7

Wireless remote control��7

Unpacking.................................................................................................................................................... 8

Unpacking��8

Delivery scope ��8

Preparations................................................................................................................................................. 8

Setting up ��8

Connecting the tubings ��8

Inserting battery into the WiCo��9

Mounting the WiCo to the station��9

Filling and draining ��9

Fluid (Standard information for IKA®fluid)��10

Moving the device��11

Charging the Battery Pack RB 1 (rechargeable battery) ��11

Changing battery to WiCo��11

WiCo – holder WH 10 ��11

Operator panel and display ........................................................................................................................ 12

station��12

WiCo��12

Setting the safety temperature .................................................................................................................. 13

Commissioning........................................................................................................................................... 13

Useful information ..................................................................................................................................... 14

Working with WiCo.................................................................................................................................... 15

Working screen at the time of delivery��15

Explanation of symbols on the working screen��15

Menu navigation and structure��16

Menu (Details)��18

Interface and output .................................................................................................................................. 23

Maintenance and cleaning ......................................................................................................................... 26

Error codes................................................................................................................................................. 27

Accessories................................................................................................................................................. 28

Technical data ............................................................................................................................................ 29

Warranty .................................................................................................................................................... 31

Pump performance curve ........................................................................................................................... 31

4

Declaration of Conformity

We declare under our sole responsibility that this product corresponds to the regulations 2014/35/EU, 2014/30/EU,

2014/53/EU

and 2011/65/EU and conforms with the standards or standardized documents: EN 61010-1, EN 61010-2-010, EN 61010-2-051,

EN 61326-1 and DIN 12876-1�

Bluetooth®module:

Directive: 2014/53/EU Standards: EN 300328, EN 301489-17, EN 301489-1, EN 60950-1

Note for USA (FCC)

This equipment complies with Part 15 of the FCC rules� Any changes or modiﬁcations not expressly approved by the Manu-

facturer could void the user's authority to operate the equipment� This device complies with Part 15 of the FCC rules subject

to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept all interference received, including interference that may cause undesired operation�

NOTE:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the

FCC Rules� These limits are designed to provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment�

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with

the instruction manual, may cause harmful interference to radio communications� Operation of this equipment in a resi-

dential area is likely to cause harmful interference in which case the user will be required to correct the interference at his

own expense�

Note for Canada (IC)

This device complies with Industry Canada license-exempt RSS standard(s)� Operation is subject to the following two condi-

tions:

(1) This device may not cause interference

(2) This device must accept any interference, including interference that may cause undesired operation of the device�

This device complies with Health Canada’s Safety Code 6/IC RSS-210� The installer of this device should ensure that RF radiation

is not emitted in excess of the Health Canada’s requirement�

Explication of warning symbols

Indicates an (extremly) hazardous situation, which, if not avoided, will result in death,

serious injury�

Indicates a hazardous situation, which, if not avoided, can result in death, serious injury�

Indicates a potentially hazardous situation, which, if not avoided, can result in injury�

Indicates practices which, if not avoided, can result in equipment damage�

Indicates a hazardous situation that cause from a hot surface!

CAUTION

WARNING

CAUTION

NOTICE

DANGER

5

Safety instructions

General information:

• Read the operating instructions completely before

starting up and follow the safety instructions.

• Keep the operating instructions in a place where it can be

accessed by everyone�

• Ensure that only trained staff work with the device�

• Follow the safety instructions, guidelines, occupational

health, safety and accident prevention regulations�

• Set up the device in a spacious area on an even, stable,

clean, non-slip, dry and ﬁreproof surface�

• Do not operate the device in explosive atmospheres,

with

hazardous substances�

• Protect the device and accessories from bumping and im-

pacting�

• Check the device and accessories for damage before each

use� Do not use damaged components�

• Safe operation is only guaranteed with the accessories de-

scribed in the ”Accessories” section�

• The device must only be operated with the original mains

cord�

• The socket for the mains cord must be easily accessible�

• Socket must be earthed (protective ground contact)�

• The voltage stated on the type plate must correspond to

the mains voltage�

•

The device can only be disconnected from the mains sup-

ply by pulling out the mains plug or the connector plug�

• Disconnect the mains plug before attaching or changing

any accessories�

• Disconnect the mains plug before cleaning, maintenance

or moving the device�

•

The device must only be opened by trained specialists,

even during repair� The device must be unplugged from

the power supply before opening� Live parts inside the

device may still be live for some time after unplugging

from the power supply�

Coverings or parts that can be re-

moved from the device must be put

back on the device again to ensure

safe operation, for example to keep foreign objects and

liquids, etc� from getting into the device�

• The device must only be used as prescribed and as de-

scribed in the operating instructions� This includes opera-

tion by instructed specialist personnel�

• When using critical or hazardous materials in your pro-

cesses, IKA®recommends to use additional appropriate

measures to ensure safety in the experiment� For exam-

ple, users can implement measures that inhibit ﬁre or ex-

plosions or comprehensive monitoring equipment�

• Process pathogenic material only in closed vessels under a

suitable fume hood� Please contact IKA®application sup-

port if you have any question�

If the mains switch is not within

reach when device is operating, an

EMERGENCY STOP switch that

can be easily accessed must be installed in the work area�

• A laboratory circulator heats/refrigerates and circulates ﬂu-

id according to speciﬁed parameters� This involves hazards

due to high temperatures, ﬁre and general hazards due to

the device of electrical energy� The user safety can not be

ensured simply with design requirements on the part of

the device� Further hazard sources may arise due to the

type of tempering ﬂuid, e�g� by exceeding or undercutting

certain temperature thresholds or by the breakage of the

container and reaction with the carrier ﬂuid� It is not pos-

sible to consider all eventualities� They remain largely sub-

ject to the judgment and responsibility of the operator� For

this reason, it may become necessary for user to take other

precautionary safety measures�

• Insucient ventilation may result in the formation of ex-

plosive mixtures� Only use the device in well ventilated

areas�

The safety circuit (safe temperature)

must be adjusted so that the maxi-

mum permissible temperature can-

not be exceeded even in the event of a fault� Check the

safe temperature circuit on a regular basis (see section

"Setting the safety temperature")�

• When device is used for external circulation, extra pre-

caution must be taken for hot/cold liquid leakage due to

damaged hose:

- Use suitable hoses for connection�

- Secure hoses and tubes against slippage and avoid kinks�

- Check hoses, tubes and bath at regular intervals for pos-

sible material fatigue (cracks/leaks)�

• Mains cable should not get in contact with hot parts and

ﬂuids�

Do not start up the device if:

- It is damaged or leaking

-

Cable (not only mains cable) is damaged�

• Be careful when reﬁlling a hot bath�

At high operating temperature, the

temperature of housing parts, sur-

faces and tubes can exceed 70 ° C�

It is dangerous to touch the heater�

The temperature of the heater can

be very high�

CAUTION

NOTICE

WARNING

CAUTION

6

Battery pack RB 1 (for WiCo):

If during operation the battery pack

RB 1 (rechargeable battery) be-

comes fully discharged, the device

(Station) will continue to run or is shut down depending on

the value settings for “Time Out”, “Safe Speed” and “Safe

Temperature”� If the device is set so that it continues to run

when the battery of the WiCo is fully discharged, the only

means of switching the station off are the “safe STOP”,

“ON/OFF” key and the “Mains switch”!

Please note the following safe-

ty instructions for the battery

pack RB 1 (rechargeable bat-

tery):

•

Keep the battery pack out of reach of children at all times�

• Store the battery pack in a cool, dry place�

•

Never throw the battery pack into a ﬁre� Keep it away

from direct sunlight and temperatures above 60 °C� High

temperatures will damage the battery pack and render

it unusable� Temperatures above 100 °C may cause it to

explode�

• Never throw the battery pack into water or expose it to

moisture� Water may lead to a short-circuit, causing the

battery pack to explode�

•

Do not deform or crush the battery pack or damage it in

any other way� This can cause battery ﬂuid to leak and/or

the battery pack to explode�

• When not in use, keep battery packs away from pa-

perclips, coins, keys, nails, screws or other small metal

objects which could cause the contacts to be bridged�

Short-circuiting may result in an explosion�

• After a power failure during operation, the device may

start automatically (depending on operating mode)�

• Transport the device with care�

• Do not transport or empty the bath while it is still hot/

cold� This may result in accidents, especially scalding inju-

ries or frostbite�

Because of the heavy weight of the

device, at least two persons are

needed for carrying the device�

CAUTION

Risk of burning caused by vapor or

hot water at the outlet of the cool-

ing coil�

Don’t use following ﬂuids:

- Untreated tap water

- Acids or bases

- Solutions with halides: chlorides, ﬂuorides, bromides,

iodides or sulfur

- Bleach (Sodium Hypochlorite)

- Solution with chromates or chromium salts

- Glycerine

- Ferrous water�

When changing the bath ﬂuid, re-

move the remaining water from the

complete system (including hoses

and external devices)� When doing this, also open the

stopper and union nuts caps of the pump outputs and

inputs and blow compressed air through all the pump

outputs and inputs! Beware of the risk of burning due to

delay in boiling!

Fluids:

Beware of the risk of burning due

to delay in boiling!

Only use ﬂuids, which fulﬁll the re-

quirements for safety, health and

device compatibility� Be aware of

the chemical hazards that may be associated with the bath

ﬂuid used� Observe all safety warnings for the ﬂuids�

• Depending on the bath ﬂuid used and the type of opera-

tion, toxic or ﬂammable vapors can arise� Ensure suitable

extraction�

• Do not use any ﬂuid which may cause dangerous reac-

tions during processing�

• Only use recommended bath ﬂuid� Only use non-acid and

non corroding ﬂuid�

Only process and heat up any ﬂuid

that has a ﬂash point higher than

the adjusted safe temperature limit

that has been set� The safe temperature limit must always

be set to at least 25 ºC lower than the ﬂash point of the

ﬂuid used� Examine regularly the function of the safety

temperature limiter�

Never operate the device without

sucient heat carrier ﬂuid! Check

the ﬂuid level detection at a regular

basis (see the chapter “Filling and draining”)�

• Continuous monitoring of the bath and the ﬁlling level of

the bath ﬂuid is required, especially at high temperatures�

• To ensure a sucient ﬂuid circulation, the viscosity of the

bath ﬂuid at the lowest operating temperature must not

exceed a value of 50 mm2/s�

If water is used at higher tempera-

ture, there is heavy loss of ﬂuid due

to the evaporation of the steam�

•

Untreated tap water is not recommended� It is recom-

mended to use distilled water or high purity water (ion ex-

changers) and add 0�1 g soda (sodium carbonate Na2CO3)

/liter, to reduce corrosive properties�

CAUTION

WARNING

NOTICE

CAUTION

7

Disposal instructions:

• When disposing of the IKA®battery pack, please tape over

the contacts with adhesive tape to prevent short-circuiting

due to moisture or contact with metal components� Short-

circuiting may result in an explosion�

• Do not throw used battery packs into your household

waste� Dispose of them properly in accordance with statu-

tory regulations�

End users are obliged by law to return all used dis-

posable and rechargeable batteries� Throwing them

into the household waste is prohibited� Disposable/

rechargeable batteries containing harmful substances are

marked with this symbol to indicate that they may not be

disposed of as household waste�

• You can return used disposable and rechargeable batteries

free of charge to your local authority collection site or to any

battery retailer� In doing so you will be complying with statu-

tory regulations and helping to protect the environment�

• Batteries must be disposed of in accordance with local

and national regulations�

• Explosion of a battery pack may release battery ﬂuid and

cause a ﬁre�

• The lithium polymer battery pack must only be used and

charged in IKA®products designed for use with this bat-

tery pack�

• When the battery pack is inserted it should slide in easily

and without resistance� Do not force it�

• If the battery pack is removed for an extended period of

time, store it in a sealed plastic bag to prevent short-circu-

iting due to moisture or contact with metal components�

• The operating temperature range of the battery pack is

from 0 °C to + 45 °C� Note that the battery pack capacity

will be reduced at temperatures below 20 °C�

•

Only the rechargeable battery types recommended in the

technical data may be used in the device!

Do not charge batteries that have leaked or that are

discolored, deformed or damaged in any other way�

Correct use

• Use:

Use CBC (Combined refrigerating and heating Bath Circu-

lators)

for heating

/refrigerating

and circulating ﬂuids�

Intended Use: Tabletop device

• Range of use (indoor use only):

- Laboratories -Schools

- Pharmacies - Universities

• Wireless remote control:

Before using the wireless link between the WiCo and the

laboratory device, ﬁrst check whether your region is in-

cluded in the radio communication approval for the de-

vice� If it is not, remote control can also be performed

using a USB cable�

This device is suitable for use in all areas except:

- Residential areas

- Areas that are connected directly to a low-voltage supply

network that also supplies residential areas�

The safety of the user cannot be guaranteed:

- If the device is operated with accessories that are not sup-

plied or recommended by the IKA®�

- If the device is operated improperly or in contrary to the

IKA®speciﬁcations�

- If the device or the printed circuit board are modiﬁed by

third parties�

8

Unpacking

• Unpacking:

- Please unpack the device carefully�

- In the case of any damage a detailed report must be

sent immediately (post, rail or forwarder)�

Transport safety:

Open the filling open lid (2) and

remove the protection under the

buoyage�

• Delivery scope:

- CBC 5 control station with WiCo

- Mains cables

- Hose olive NW 12 (2 pieces) see Fig� 2

- Screwdriver (use for safety circuit) see Fig� 3

- WiCo holder WH 10

- OS 1�0 power supply (for WiCo) see Fig� 4

- Temperature sensor Pt 100�30

- USB 2�0 cable micro A – micro B

- USB 2�0 cabel A – micro B

- User guide

- Warranty card�

Adapter

England

Adapter

Australia

Adapter

Europe, Switzerland

Fig. 4

Adapter

USA, China

Preparations

• Setting up:

- Place the unit on an even, stable, clean, nonslip, dry

and ﬁreproof surface�

- Keep at least 20 cm of open space on the front and rear

side�

- The place for installation should be large enough and

provide sucient air ventilation to ensure the room

does not warm up excessively because of the heat

from device radiates to the environment�

- Do not set up the device in the immediate vicinity of

heat sources and do not expose to sun light�

- Cooling machine, pump motor and electronics produce

intrinsic heat that is dissipated via the venting grids (5)!

Never cover these venting grids!

Note: After setting up the device, wait at least one hour be-

fore starting the operation to avoid the damage to the cool-

ing system�

• Connecting the tubings:

-

Unscrew the union nuts and stoppers using a wrench

(SW19) from the pump connection IN (9) and OUT (10)�

- Connect the hoses for circulating the external system to

the pump connection M 16 x 1 for IN and OUT directly

or with the olives�

- Screw the hose olives to the pump connection IN and

OUT with union nuts� Slide the hoses (NW 12) onto the

olives� The hoses must be secured with suitable clamps�

Note: Please note the permissible temperature range of

hoses� For hot ﬂuids we recommend the IKA®LT 5�20

hoses�

When the external system is not necessary, please seal

the pump connection IN and OUT with the existing union

nuts and stoppers�

Fig. 3Fig. 2

Hose olive

Union nut

Fig. 6

Stopper

Union nut

Fig. 5

NOTICE

9

• Filling and draining:

- Before ﬁlling the ﬂuid into the bath, open the front

cover as indicated in following ﬁgure�

- Check and make sure that the drain valve is closed (Ro-

tate clockwise to the stop position, see Fig� 10)�

Note: Please note information in section “Commissioning”�

- Connect the mains plug and turn on the device with

mains switch (6)�

- The low level icon ( ) appears on the display of the

WiCo�

- Open the ﬁlling lid (2) and ﬁll ﬂuid to the bath�

Note:

Pay attention to the ﬂuid level information!:

Fig. 9

Fig. 10

Drain valve Drain port

Fig. 11

(see “Fluid level” in section “ Working with WiCo”)�

— Low level

— High level

Warning: Do not empty the bath while it is still hot/cold,

there is a risk of burning/freezing�

- To drain the ﬂuid from the bath, connect a hose to the

drain port and turn the drain valve in counter clockwise

direction with a straight screwdriver�

• Inserting battery into the WiCo:

Model:WiCo CBC 5

LPS

IP40



Model:WiCo CBC 5

LPS

IP40



Model:WiCo CBC 5

LPS

IP40

Model:WiCo CBC 5

LPS

IP40



Note: notch upward!

• Mounting the WiCo to the station:

IKA

®

CBC 5 control

High

Low

Fluid level

R

Note:

If the WiCo need be permanently attached to the

station, we strictly recommend to fasten the unlocking but-

ton with the integrated screw (turn counter clock wise)�



Model: WiCo CBC 5

LPS

IP 40

Fig. 7

Fig. 8

10

• Fluid (Standard information for IKA®ﬂuid):

IKA®Designation

Operating temperature

range for open bath

application

(°C)

Operating temperature

range for closed bath

applications

(°C)

Safety temperature

(°C)

Flash point

(°C)

CF�EG28�N10�80�8

-10 �� 80 -10 … 80 90 115

CF�EG39�N20�80�16

-20 … 80 -20 … 80 90 115

CF�EG44�N25�80�19

-25 … 80 -25 … 80 90 115

CF�EG48�N30�80�22

-30 … 80 -30 … 80 90 115

UF�Si�N30�150�10LV

-30 … 130 -30 … 150 145 >170

HF�Si�20�200�50

20 … 200 20 … 200 255 >280

HF�Si�20�250�50A

20 … 200 20 … 250 255 >280

H

2

O (Water) 

5 … 95 5 … 95 - -

Customized 1



Customized 2



Check the suitability of the fluid according to your application�

(1) Classiﬁcation:

HF: Heating Fluid

CF: Cooling Fluid

UF: Universal Fluid

(2) Chemical composition:

Si: Silicone oil

EG: Ethylene Glycol

(3) Temperature range: (

Minimum temperature� Maximum temperature)

N: Negative Temperature

(4) Viscosiy:

Viscosiy at 25 °C for Heating Fluid (HF)

Viscosity at -20 °C for Cooling Fluid (CF)

Viscosity at 25 °C for Universal Fluid (UF)

Dynamic viscosity [mPa•s] is a product of kinematic viscosity [mm²/s] and density [kg/m³] of the ﬂuid divided by 1000�

(5) Additional information:

A: Oil Additives

LV: Low Viscosity



Note: for open bath application!



Note: Tap water may be unsuitable for operation because the calcium carbonate content may cause calcification�

High purity water (from icon exchangers) and distilled or bi-distilled water are unsuitable for operation due to corrosive

properties of these media� High purity water and distillates are suitable as a medium after adding 0�1 g soda (Na2CO3,

sodium carbonate) per liter of water�

Note: The limits can be adjusted according to the ﬂuid used�

Nomenclature for IKA®fluid:

CF�EG28�N10�80�8 --

(5) Addition information

(4) Kinematic viscosity (8

mm²/s

)

(3) Temperature range (- 10–80 °C)

(2) Chemical composition (Ethylene Glycol 28 %)

(1) Classiﬁcation (Cooling ﬂuid)

11

• Charging the Battery Pack RB 1 (rechargeable battery):

The battery pack in the WiCo can be charged by any of the following means:

- On the station

- Via a USB cable at the PC or station

- Via an OS 1�0 power supply unit�

1



•

Changing battery to WiCo:

Note: Please comply with the relevant safety instructions in the "Safety instructions" section for the RB 1 battery pack!

Fig. 13

•

WiCo – holder WH 10:

WiCo – holder WH 10

WiCo –holder WH 10

Fig. 14

WiCo –holder WH 10

H 44 Boss head clamp

H 38 Holding rod

IKA

®

CBC 5 control

IKA

®

CBC 5 control

IKA

®

CBC 5 control

max. 10 ˚

• Moving the device:

Empty all ﬂuid in the bath before moving device from one

place to other place�

The device must be lifted by two persons with the upper

handles� For this purpose, take off the front cover (3)�

It can also be moved on ﬂat surface by lifting and pushing

the front of the device� It is easy to move the device with

the help of the wheels�

The angle of inclination should never be more than 10 º

at any direction when move the device!

Note: The device must not be moved during operation�

After moving the device, you must wait at least one hour

before restarting the unit�

Fig. 12

12

Operator panel and display

• station:

• WiCo:

Fig. 16

Item Designation Function

L On/Off

key

:Switch the WiCo on and off�

M “int/ext” key:

Switch between the internal and external temperature display and control�

N “Timer/Pump” key:

Switch between the timer and pump display�

O Graph key: Display time/temperature graph�

P Rotating/pressing knob: Set the temperature value�

Start/Stop the heating/cooling function�

R Rotating/pressing knob: Navigation, selecting and changing the settings in the menu�

Set the pump speed value�

Start/Stop the pump function�

S Display: Screen�

T “Back”

key

: Return to the previous menu level�

U "Menu"

key

:Press it once: main menu is displayed�

Press it a second time: back to the working screen�

V Lock

key

: Lock/Unlock the knobs and keys�

Item Designation Function

A On/Off key: Switch on/off the station�

B Adjustable safety circuit: Adjust the safety temperature limit with delivered screwdriver�

C LED bar: Display different status of the circulator with different color�

D Contacts: Communicate and charge the WiCo�

E "safe STOP" key: Safe stop the working of the station in emergency�

F Bluetooth®searching key: Search the WiCowhen the Bluetooth®is active�

G Bluetooth®LED: Bluetooth®indicator�

Fig. 15

R

P

L

U

T

V

M

N

OS

A

B

G

E

F

C D

13

Setting the safety temperature

Seting the safety temperature with screwdriver delivered

with the device�

The safety temperature setting will appear on the display�

Factory setting: maximum value

Adjustment range: see “Technical data“�

Note: The safe temperature limit must always be set to at

least 25 ºC lower than the ﬂash point of the ﬂuid used�

Fig. 17

+

-

Commissioning

Note: Before commissioning, make sure that the device

has not been moved in one hour!

Check whether the voltage given on the type plate corre-

sponds to the available mains voltage�

The socket used must be earthed

(ﬁtted with earth contact)�

If these conditions have been met, the machine is ready for

operation when the mains plug is plugged in�

If these conditions are not met, safe operation is not guaran-

teed and the machine could be damaged�

Observe the ambient conditions (temperature, humidity,

etc�) listed under “Technical Data”�

After pressing the mains switch (6) of the station, the screen

of the WiCo displays the device designation and the soft-

ware version after a beep�

IKA®

Circulator

CBC Control

Version 1.2.005

Fig. 18

After several seconds, screen display the information of

WiCo�

Information

Internal Max: 95 °C

Internal Min: 5 °C

External Max: 95 °C

External Min: 5 °C

Fluid: H2O (Water)

Fig. 19

Then the working screen appears and the device is ready

for operation�

A

0.00

int °C

ext °C

int 5.00 1000

set °C Pump rpm

Safe Temp °C

Fig. 20

Change the temperature setting with left knob (P)�

Change the pump speed setting with the right knob (R)�

In standby status, activate the heating/refrigerating func-

tion by pressing the left knob (P)� The device start heating/

refrigerating function� Meanwhile, the pump starts to run

at once�

After pressing the mains switch (6) the start-up of the com-

pressor is delayed (about 3 minutes)�

In working status, press the right knob (R) to stop opera-

tion of the pump� The heating/refrigerating function and

the pump stops�

14

Note: In standby status, press the right knob (R) to start the

pump function, the heating/refrigerating function will not

be activated�

In working status, press the left knob (P) to stop the heat-

ing/refrigerating, the pump keep running�

When the WiCo is switched on without being connected to

the station, the green LED bar (C) and the green Bluetooth®

LED (G) on station lights up�

The control elements of the WiCo allow to be locked by

pressing the lock key (V) about 2 seconds, so no accidental

changes during operation are possible (lock symbol ap-

pears in the display)�

By pressing lock key (V) about 2 seconds again, the control

elements are released (lock symbol disappears from the

display)�

Useful information

The station is controlled via a WiCo� If the WiCo is mounted

on the station, data is exchanged between the station and

WiCo via the contacts (D)� The screen of the WiCo displays

the home icon �

The WiCo is equipped with a USB socket (Universal Serial

Bus) with which the WiCo can be connected with station,

the USB icon appears on the screen�

If the WiCo is not connected with station via a USB cable,

the data exchange between the station and the WiCo via

Bluetooth®� In this case, the Bluetooth®icon is displayed �

Depending on the structure of the building, the WiCo can

be operated at a distance up to 15 m from the station, us-

ing the Bluetooth®connection�

The WiCo could be either installed on the station or put

on a safe place where is accessed easily by the user during

operation�

If the WiCo is mounted on the station, the battery is charged

through the contacts (D)�

The battery could also be charged via the USB port on the

WiCo (See “Charging the Battery Pack RB 1“ in “Prepara-

tions“ section)�

Note: In an emergency, the device function can be turned

off by pressing the “safe STOP” key (E) at the front of sta-

tion� The LED bar (C) changed into red color�

A message appears in the display indicates that the station

was forced off� To restart, press the mains switch (6) or On/

Off key (A) off and on again�

If the Bluetooth®function of the WiCo is activated, the

Bluetooth®icon appears on the screen and the user can

search the WiCo by pressing the searching key (F)� Then, a

beep is heard�

15

AOperating Mode:

This symbol indicates the operating mode currently select-

ed (A, B, C, D)�

USB:

This symbol means the WiCo is communicating or the

battery is charged via a USB cable� The symbol no longer

appears if no USB cable is being used for communicating

with the station�

Home:

This symbol means that the WiCo is connected to the

station and is communicating with the station via the

contacts�

The symbol no longer appears if the WiCo is removed

from the station�

Battery pack:

This symbol indicates the charging status of the RB 1 bat-

tery pack within the WiCo�

The charging symbol appears if the WiCo

- is connected to a PC via a USB cable

- is connected to a station via a USB cable

- is connected to the power supply unit OS 1�0 via a USB cable

-

is connected to the station via the charger contacts�

Heating

This symbol indicates that the heating function is active�

  indicate active heating process�

Refrigerating

This symbol indicates that the refrigerating function is ac-

tive�

indicates active refrigerating process�

Fluid level

This symbol indicates ﬂuid level�

The red symbol means the ﬂuid is above the maximum

ﬂuid level� Excess ﬂuid should be drained out�

The red symbol means the ﬂuid is below the minimum

ﬂuid level� Please add ﬂuid�

Pump:

This symbol indicates that the pump is activated�

Warning:

This symbol indicates that warning is active�

PC PC Control:

This symbol means that either the station or the WiCo is

connected to a computer and is being controlled from

the computer�

PR Program Control:

This symbol indicates that the WiCo is controlled by a pro-

gram (see “PROGRAMS”)�

Working with WiCo

•

Working screen at the time of delivery:

A

0.00

int °C

ext °C

int 5.00 1000

set °C Pump rpm

Safe Temp °C

Fig. 21

Note: The wireless symbol appears only when the sta-

tion is switched on�

•

Explanation of symbols on the working screen:

The symbols displayed change depending on the status

and settings of the WiCo and the station� The screen be-

low shows the most signiﬁcant symbols on the working

screen�

Bluetooth®:

This symbol means the station and the WiCo are commu-

nicating via Bluetooth®�

The symbol no longer appears if no Bluetooth®communi-

cation is being performed�

99 Device number:

This ﬁgure appears when the “Device Number“ is acti-

vated in menu option “Display“�

The ﬁgure can be set from 0 to 99�

See section “Display“ under “Menu (Details)“�

Lock:

This symbol means that the function of the keys and the

rotary knobs for controlling the WiCo are disabled by

pressing lock key about 2 seconds�

The symbol no longer appears if the functions are en-

abled once again by pressing the lock key about 2 sec-

onds again�

Temperature Sensor:

This symbol appears when the external temperature sen-

sor is connected�

Fig. 22

A

99

10.00

int °C

ext °C

int 10.00 1000

set °C Pump rpm

Safe Temp °C

PC

10.00 260

16

• Menu navigation and structure:

Menu navigation:

Press the "Menu" key (U)�

Select the menu by turning the right rotating/pressing knob (R) to the right or

left�

Open the menu item by pressing the right rotating/pressing knob (R)�

Turn the rotating/pressing knob (R) to select the desired menu option and edit

the values or settings�

Press the rotating/pressing knob (R) to get into sub menu items to active/inac-

tive to switch settings or to conﬁrm settings ("OK")�

Press the "Back" key (T) to a setting or cancel to return to the previous menu�

Press the "Menu" key (U) to return directly to the working screen�

Control elements

for menu navigation

Note: If you press the “Menu“ key (U), the system skips directly back to the working screen�

If you press the “Back“ key (T), the system skips back to the previous screen�

Menu

Menu navigation: 

Press the “Menu“ key (U) and rotate rotating/pressing knob (R)



Press the ”Back” key (T) or the ”Menu” key (U)

A

0.00

int °C

ext °C

int 5.00 1000

set °C Pump rpm

Safe Temp °C

TEMPERING

Tempering

Control

Limits

Temperature Sensor

> Tempering

Control

Control Mode

Control Parameters

Fluids

> Tempering > Control

Control Mode

Internal (int)

External (ext)

Menu

Back

MENU

Fig. 23

Fig. 24

Note: When the tempering or pump functions are active, the menu is locked� On the display, the active menu option is high-

lighted in yellow� The active status of a menu item is marked with a check (√)�

Back

R

U

T

17

TEMPERING Control Control Mode

Fluids

Control Parameters

Internal (int) activated

-

activated

95 °C

5°C

100 °C

100 %

± 0.0 K

60.0, 5.0, 0.3, 3, +1.00, -1.00

1.0, 15.0, 0.0, 90, +1.00, -1.00

-

Automatic Accurate

Internal

Internal (Kp, Ti, Td, Ts, Prop_Bp, Prop_Bn)

2 Point Calibration

Fast

Manual

Eternal (ext)

I T (int - ext)I

Power Output

Calibration

Reset Calibration

Heating

Maximum

Minimum

Eternal

Eternal (Kp, Ti, Td, Ts, Prop_Bp, Prop_Bn)

3 Point Calibration

Information (Kp, Ti, Td, Ts, Prop_Bp, Prop_Bn)

Limits

Temperature Sensor

Notiﬁcation Hysteresis

Sound Inﬁnite

Beep

ON

Cooling

CF.EG28.N10.80.8

CF.EG39.N20.80.16

CF.EG44.N25.80.19

CF.EG48.N30.80.22

UF.Si.N30.150.10LV

HF�Si�20�200�50

HF�Si�20�250�50A

H2O (Water)

Customized 1

Customized 2

PUMP Limits Speed

Pressure

Maximum

Minimum

4600 rpm

1000 rpm

0.7 bar

TIMER Set

Display

00:00 [hh:mm]

-

MODE A

C

B

D

-

activated

GRAPH Automatic

Manual Axis Assignment Set Temperature

Actual Internal Temp.

Actual External Temp.

X - Axis

Y - Axis

15 min

30 min

60 min

120 min

Axis Scaling

Maximum

Minimum

-

activated

95 ºC

5 ºC

PROGRAMS Program 1

...

Program 10

-

MODULES M1 - Valve

M2 - Output

M3 - Input Ext. Standby

Alarm

Switch

Error

Warning

ON

Default Status

Open

Closed

ON

Default Status Open

Higher

Lower

Int > Set Temperature

Start

Closed

Stop

Reﬁll

Temperature (Int)

95 ºC

5 ºC

-

activated

-

Level 2

Level 4

OUTGAS Speed

Interval

1000 rpm

10 s

SAFETY Time out

Password

Safe Temp. Conﬁrmation

Set

Speed

Temperature 30.00 °C

000

-

1000 rpm

00:30 [mm:ss]

DISPLAY Main Screen Pump

Timer

Device number

-

0

activated

Menu structure:

Factory Settings

Menu

SETTING Languages

Display

Sound

Factory Settings

Communication

Information

English

Background

Brightness

Key Tone

Device name

Tempering

Safety

Intro

Bluetooth

Pump

Software

Firemware Update Info

Firmware Update Info

Black

White

Deutsch

... -

activated

Circulator WiCo

-

yes

-

activaed

Standard Mode

Battery Mode

100%

40%

18

• Menu (Details):

TEMPERING:

Control:

Control Mode:

Internal (int): The temperature is regulated according to

the internal temperature sensor�

Extern (ext): The temperature is regulated according to

the external temperature sensor�

Control parameters:

Automatic: The optimal control parameters for PID tem-

perature control are determined automatically� This is the

recommended mode�

Selecting "Automatic" allows you to set the dynamics for

temperature control�

Accurate: precise tempering without overshooting�

Fast: fast tempering with minimal overshooting�

Ts must be adjusted to match the response characteristic

(total of all time constants) of the closed loop controlled

system, so that the control variable can deliver a uniform

and measurable change in the control deviation� Ts val-

ues that are too small or too large can lead to instability

of the controller�

Prop_Bp: Proportional Band Maximum�

Prop_Bn: Proportional Band Minimum�

The Proportional Band is the range below (Prop_Bp) and

above (Prop_Bn) the set value in which the control output

value is calculated via the difference between the actual

and the set value and the PID parameters�

Examples of non-optimal settings:

°C

t

Fig. 25

Manual: The control parameters for PID temperature con-

trol can be set manually�

"Manual" should only be used in the event of special tem-

perature control requirements�

When "Manual" is selected, the following parameters can

be set for "Internal (int)" and "External (ext)" temperature

control:

Kp: Proportional coecient

The proportional coecient Kp is the controller ampliﬁ-

cation and determines how strongly the control deviation

(the difference between the target temperature and ac-

tual temperature) directly affects the control variable (on-

time of the cooling)� Kp-values that are too large can lead

to the controller overshooting�

Ti: Integral time

The integral time Ti (s) is the correction time and deter-

mines how strongly the duration of the control deviation

affects the control variable� Ti compensates for an ex-

isting control deviation� A high Ti means a smaller and

slower effect on the control variable� Ti-values that are

too small can lead to instability of the controller�

Td: Differential time

The differential time Td (s) is the derivative time and de-

termines how strongly the rate of change of the control

deviation affects the control variable� Td compensates for

rapid control deviations� A high Td means a smaller and

slower effect on the control variable� Td-values that are

too large can lead to instability of the controller�

Ts: Sampling time

The sampling time Ts (s) is the time interval over which the

control deviation is determined and the respective control

variable (dependent on Kp, Ti and Td) is calculated�

Fig. 26

°C

t

Kp too high

°C

t

Ti too low

°C

t

Td too high

°C

t

Kp too low

Ti too high

Fluids:

Under the option "Fluids", a variety of ﬂuids can be se-

lected�

The selected ﬂuid limits the setting range of the target

temperature� See table in the section “Fluid (Standard in-

formation for IKA®ﬂuid)“�

The maximum and minimum temperature values of the

selected ﬂuid can be set within these limitations�

Cooling:

This menu option allows you to activate/deactivate the

Cooling function�

(heating curve in "Automatic" mode)

19

Limits:

Under the option "External (ext)", the maximum and min-

imum temperature for external temperature control can

be limited�

Under "l Δ T (int - ext) l", the maximum difference be-

tween the internal and external temperature can be set�

The function limits the absolute temperature difference

between the external system and internal bath during

the heating up and cooling down process� This can pro-

tects sensitive device like the glass reactors from thermal

shock (e�g� glass break)�

Temperature sensor:

Calibration:

The internal and the external temperature measurement can be calibrated and adjusted�

You can select 2-ponit calibration or 3-point calibration for internal and external measurement�

Calibration proceeding (example: 2-point calibration):

Reset Calibration:

By “Reset Calibration”, the calibration value for the internal or the external temperature sensor will be deleted�

Notiﬁcation:

ON:

This menu option allows you to activate/deactivate the

“Notiﬁcation“ function� A green check mark and a beep

informing when the target value (hysteresis) has been

reached�

Hysteresis:

This menu option allows you to set the hysteresis from 0

to ±2�0 K�

Sound:

Inﬁnite: Beep until you press the “Back” key�

Beep: Single beep�

Under “Power Output“, the maximum heating output

can be set as a percentage of nominal heat output�

PUMP

Limits:

In “Limits“ menu option, you are allowed to set the

maximum and minimum speed to the pump, and also

the maximum pressure�

> Tempering

Temperature Sensor

Calibration

Reset Calibration

> Temperature Sensor

Calibration

Internal

External

> Calibration

Internal

2 Point Calibration

3 Point Calibration

> Calibration > Internal

2 Point Calibration

Temperature sensor calibration

at

Step: 1 / 2

5.00 C

OK

> Calibration > Internal

2 Point Calibration

Temperature sensor calibration

at

Step: 1 / 2

30.00 C

OK

> Calibration > Internal

2 Point Calibration

Temperature sensor calibration

at

Step: 1 / 2

30.00 C

OK

> Calibration > Internal

2 Point Calibration

Target Temp: 30.00 C

Actual Temp: 25.00 C

Please wait...

Step: 1 / 2

> Calibration > Internal

2 Point Calibration

Target Temp: 30.00 C

Actual Temp: 30.00 C

Step: 1 / 2

OK

> Calibration > Internal

2 Point Calibration

Step: 1 / 2

Enter the temperature from the

measuring device

5.00 C

OK

> Calibration > Internal

2 Point Calibration

Step: 1 / 2

Enter the temperature from the

measuring device

32.00 C

OK

> Calibration > Internal

2 Point Calibration

Step: 1 / 2

Enter the temperature from the

measuring device

32.00 C

OK

> Calibration > Internal

2 Point Calibration

Sensor calibrated successfully

OK

Fig. 27

20

PROGRAMS

Under programs, 10 user-deﬁned temperature-time pro-

ﬁles can be created� A program can consist of up to 10

segments�

Once a program has been selected, the following options

are available:

Start:

Starts the program upon request of loop mode�

Inﬁnite loop: Upon completion of the last segment, the

program continues with the ﬁrst segment until you end

the program by stopping a device function�

Loop Count: Indicates the total number of loop cycles

until program end�

Note: At the end of the program all device functions are

switched off�

Edit:

Edit/change program parameters�

Seg No�: Segment number�

Ctrl� Sensor (int/ext): Determines whether control is

through the internal (int) or external (ext) temperature

sensor�

Temp�: Target temperature�

Ctrl�Mode (Time / +/- x�x K):In "Ctrl�Mode Time" the tar-

get values and settings of the segment are valid for the

duration indicated in the column "Time hh:mm"�

Afterwards, the next program segment is automatically

executed�

In "Ctrl�Mode +/- x�xx K", the hysteresis (tolerance) of the

actual temperature to the target temperature is set (e�g�

+/- 0�1 K)� The target values and settings of the segment

are valid until the actual temperature reaches the target

temperature +/- hysteresis for the ﬁrst time�

Afterwards, the next program segment is automatically

executed�

Pump rpm: Target speed of pump�

M1 (ON/OFF): MODULES M1-Valve:

OFF: M1 valve in initial state

ON: M1 valve in inverted initial state�

Note: The initial state of the M1 valve is deﬁned in

“MODULES M1-Valve” in “Default Status” as “Open” or

“Closed”�

GRAPH

In this menu, you can set the options for the time-tem-

perature diagram�

Automatic:

The scaling of the temperature axis (Y-axis) is automati-

cally determined, depending on the target temperature

and the actual internal and external temperature�

The time axis (X-axis) is permanently scaled to 30 minutes�

DISPLAY

Main Screen:

In the “Main Screen“ menu option, you can specify what

information will be displayed on the screen�

Device Number:

In the “Device number“ menu option, you are allowed to

edit the device number from 0 to 99 that will be shown

on the main screen�

When using multiple units, it may be helpful to identify

WiCo and station�

Note: Labeling device number to the station�

MODE

Operating Mode A:

After power-on/power failure no automatic restart of

functions�

Operating Mode B:

After power-on/power failure automatic restart of func-

tions, depending on previous settings�

Operating mode C:

Set values (set in A or B) cannot be changed�

After power-on/power failure automatic restart of func-

tions, depending on previous settings�

Operating mode D:

Conﬁrmation request for set value changes, if functions

are active� After power-on/power failure no automatic

restart of functions�

TIMER

Set:

You can set a target time (duration) in this menu option�

When device functions are started normally, this time is

displayed on the working screen� The device functions

stop automatically once this time has expired� The run-

ning time is then displayed again on the display�

Note: To deactivate the target time speciﬁcation, set the

target time to 00:00�

Display:

Activate the timer display on the main display (working

screen)�

Manual:

Axis Assignment:

The temperature values to be displayed can be selected�

Axis scaling:

Scaling of the time (X) and temperature axis (Y) can be

selected or set�

IKA CBC 5 control User manual

Popular Control Unit manuals by other brands
