Ikan Lightstar LSKT-001 User manual

CHECKED BY
LSKT-001
Quick Start Guide
ON THE GO-01 3PT Tungsten Fresnel Light Kit (Lightstar)
www.ikancorp.com | 1.713.272.8822 | [email protected] because we’re filmmakers too
What’s Included
1 x 150W Tungsten Fresnel
1 x 300W Tungsten Fresnel
1 x 650W Tungsten Fresnel
1 x Scrim Set for 150W
1 x Scrim Set for 300W
1 x Scrim Set for 650W
1 x Gel Frame 150W
1 x Gel Frame 300W
1 x Gel Frame 650W
1 x Set of 3 Light Stands
1 x Carrying Case w/ Wheels
1 x FDV Lamp (150W)
1 x FKW Lamp (300W)
1 x FRK Lamp (650W)

www.ikancorp.com | 1.713.272.8822 | [email protected] because we’re filmmakers too
Getting to know your LIGHTSTAR Light
The Lightstar LSW-010 (150 Watt) LSW-001 (300 Watt) LSW-002 (650 Watt) fixtures are intended for professional applications, and are only to be operated
by qualified persons. Please read the following operating instructions very carefully before using these fixtures. They contain important information on the
operation of Lightstar lighting.
For your own safety, please follow all safety instructions and warnings. Please follow the operating instructions of the lamp manufacturers. Please keep
these operating instructions for you and subsequent users to reference in the future.
CAUTION: These fixtures use high voltage, before replacing the lamp; disconnect the fixture from its power supply. Warning! Lamp
may be hot! Allow the lamp to cool down sufficiently before replacing it. Do not switch on the Fixture without a lamp inserted. Do not
switch on the fixture without a Fresnel lens, safety mesh and reflector in place. Warning! The housing of the fixture can achieve very
high temperatures. Do not cover any ventilation slots. Always keep the mains cables away from the hot housing. A risk of overheating
or fire can occur if misused. Do not overtax the fixture cables for transport or suspension of fixture. Always remove the lamp from the
fixture for transport. Do not operate the fixture if it shows any visible damage.
Mounting the Fixture
Loosen the thumb screw on the yoke. Bring the fixture to the desired position. Tighten thumb screws until it locks in place. Check to ensure the fixture is
securely fastened.
If the fixture is being used in a hanging position, be sure to secure the fixture with a safety cable from the mounting pipe or truss. Accessories, not secured
with a safety rope must be secured with a safety cable as well. The carrying capacity of the safety rope must be rated at a minimum of 10 times the
weight of the fixture system including accessories. Stands must be set up in a stable position and capable of carrying the weight of the fixture including
accessories and cables.
Getting the Fixture Operational
Inserting the Lamp
Before replacing the lamp, the fixture must be disconnected from the power supply. Before inserting, visually check the lamp for functionality. Damaged
lamps must not be operated. Ensure the lamp is firmly fastened in its socket and the lamp must match the fixtures voltage. Connect the lamp head
connector to the power source, and put the cable switch to the ON position.
For the LSW-010 (150 Watt) fixture, loosen the small black screw at the rear of the fixture and pull out the carriage which accommodates the lamp holder
and reflector. Pull out the lamp carefully into the lamp holder. Push the lamp carriage back and fasten the small black head screw.
For the LSW-001 (300 Watt) and LSW-002 (650 Watt) press gently against the top cover to open the cover lock and lift the cover. Turn the focus knob
to move the lamp carefully with a cloth or glove. WARNING! The contact pins of the lamps have different diameters and have to be matched to the right
contact point of the lamp holder. Insert the lamp carefully as far as possible into the lamp holder. Close the top cover and gently press it down until you
hear it lock in the cover lock.
Ikan is the exclusive distributor of Lightstar products in the United States.

www.ikancorp.com | 1.713.272.8822 | [email protected] because we’re filmmakers too
Internal Care Instructions
Please clean the reflector and lens regularly with a customary glass cleaning agent. Please check that the reflector shows no kind of corrosion or damage.
Keep the contact surfaces of the electrical connections and lamp holder clean.
Lightstar Disclaimer
The manufacturer disclaims liability for any damage to persons or property caused by inappropriate or misuse of the fixture. Damage of this kind is
responsibility of the operator.
Optional Accessories
Some other products that work well include:
ROLLR-STND10
SW-04
KCP-703
2-Stage Roller Stand 10ft 6 in
Safety Wire
Stage Clamp with 16mm Stud
LSKT Kit Specs
Shipping Dimensions 36 x 16 x 16 in.
Shipping Weight 44.8 lbs
Inserting Accessories
Inserting and exchanging accessories must be carried out from a stable position. On the LSW-010, lift the top latch and turn it by 90° to the left. On the
LSW-001 and LSW-002 press the pin on the side of the holding bracket to release the spring. Insert accessories e.g. barn door, or scrim into the bracket.
Lift the top latch and turn it back into original position. Make sure the accessories are securely locked.
WARNING! Do NOT operate the fixture with closed barn doors! The risk of overheating can occur.

www.ikancorp.com | 1.713.272.8822 | [email protected] because we’re filmmakers too
LSW-010 Photometrics
No Lens Distance 2.5m 3.5m 4.5m Beam Angle
Spot Luminance 11080 5653 3420 12°
Beam Diameter 0.5m 0.7m 0.9m
Flood Luminance 2040 1041 630 52°
Beam Diameter 2.4m 3.4m 4.4m
LSW-010 Specs
Head Type 3200K
Rating AC Volts 120 v ac, 50-60Hrz
Light Source 1-150 Watt Bulb
Power Supply 6 ft Power Cable
Dimming N/A
Control Focusing Knob
Lens 1.9 In. Fresnel Lens
Focusing Rotating Rear Knob
Beam Angle 11-55º
Cooling System Air Cooled
Yoke Cast Aluminum w/ 11/8” Pin
Fixture Size 7 x 6 x 9 In.
Fixture Weight 3 lbs
Build Material Aluminum
Shipping Dimensions 12 x 8 x 8 In.
Shipping Weight 4 lbs

www.ikancorp.com | 1.713.272.8822 | [email protected] because we’re filmmakers too
LSW-001 Photometrics
No Lens Distance 2.5m 3.5m 4.5m Beam Angle
Spot Luminance 17730 4433 1970 14°
Beam Diameter 0.2m 0.5m 0.7m
Flood Luminance 3870 968 430 53°
Beam Diameter 1m 2.0m 3.0m
LSW-001 Specs
Head Type 3200K
Rating AC Volts 120V AC, 50-60Hrz
Light Source 1-300 Watt Bulb
Power Supply 6 ft Power Cable
Dimming N/A
Control Focusing Knob
Lens 3.1 In. Fresnel Lens
Focusing Rotating Rear Knob
Beam Angle 14-53º
Cooling System Air Cooled
Yoke Cast Aluminum w/ 11/8” Pin
Fixture Size 6 x 6 x8 In.
Fixture Weight 5.5 lbs
Build Material Aluminum
Shipping Dimensions 7 x 10 x 9 In.
Shipping Weight 6 lbs

www.ikancorp.com | 1.713.272.8822 | [email protected] because we’re filmmakers too
LSW-002 Photometrics
No Lens Distance 2.5m 3.5m 4.5m Beam Angle
Spot Luminance 11080 5653 3420 12°
Beam Diameter 0.5m 0.7m 0.9m
Flood Luminance 2040 1041 630 52°
Beam Diameter 2.4m 3.4m 4.4m
LSW-002 Specs
Head Type 3200K
Rating AC Volts 120 v ac, 50-60Hrz
Light Source 1-650 Watt Bulb
Power Supply 6ft Power Cable
Dimming N/A
Control Focusing Knob
Lens 4.4 In. Fresnel Lens
Focusing Rotating Rear Knob
Beam Angle 11-55º
Cooling System Air Cooled
Yoke Cast Aluminum w/ 11/8” Pin
Fixture Size 7 x 8 x 9 In.
Fixture Weight 7 lbs
Build Material Aluminum
Shipping Dimensions 9 x 11 x 11 In.
Shipping Weight 8 lbs

Learn More
More dynamic information at official website: www.ikancorp.com
Support
Contact email: [email protected]
