This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety. Children should be supervised to ensure
that they do not play with the appliance.

ENGLISH 4
General Safety
instructions:

•When the appliance is empty for long period, switch it o,
defrost, clean, dry and leave the door open to prevent
mould from developing within the appliance.
•Do not store explosive substances such as aerosol cans with
a ammable propellant in this appliance.
•If the supply cord is damaged, it must be replaced by the
manufacturer, its Authorised Service Centre or similarly
qualied persons in order to avoid a hazard.
ENGLISH 5
Safety instructions
Installation
Warning! Only a qualied person
must install this appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Do not use the appliance before installing
it in the built-in structure due to safety
manner.
• Follow the installation instructions
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use safety
gloves and enclosed footwear.
• Make sure the air can circulate around
the appliance.
• At rst installation or after reversing the
door wait at least 4 hours before
connecting the appliance to the power
supply. This is to allow the oil to ow back
in the compressor.
• Before carrying out any operations on the
appliance (e.g. reversing the door),
remove the plug from the power socket.
• Do not install the appliance close to
radiators or cookers, ovens or hobs.
• Do not expose the appliance to the rain.
• Do not install the appliance where there is
direct sunlight.
• Do not install this appliance in areas that
are too humid or too cold.
•When you move the appliance, lift it by
the front edge to avoid scratching the
floor.
Electrical connection
Warning! Risk of re and electric
shock.
Warning! When positioning the
appliance, ensure the supply cord
is not trapped or damaged.
Warning! Do not use multi-plug
adapters and extension cables.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed shockproof
socket.
• Make sure not to cause damage to the
electrical components (e.g. mains plug,
mains cable, compressor). Please refer to
www.IKEA.com/au
and contact our local store for local store
phone numbers and opening times or
have an electrician to change the electrical
components.
• The mains cable must stay below the level
of the mains plug.

ENGLISH 6
• Connect the mains plug to the mains
socket only at the end of the installation.
Make sure that there is access to the
mains plug after the installation.
• Do not pull the mains cable to disconnect
the appliance. Always pull the mains plug.
Use
Warning! Risk of injury, burns,
electric shock or re.
The appliance contains ammable
gas, isobutane (R600a), a natural gas with a
high level of environmental compatibility. Be
careful not to cause damage to the
refrigerant circuit containing isobutane.
• Do not change the specication of this
appliance.
• Do not put electrical appliances (e.g. ice
cream makers) in the appliance unless
they are stated applicable by the
manufacturer.
• If damage occurs to the refrigerant
circuit, make sure that there are no
ames and sources of ignition in the
room. Ventilate the room.
• Do not let hot items to touch the plastic
parts of the appliance.
• Do not put soft drinks in the freezer
compartment. This will create pressure on
the drink container.
• Do not store ammable gas and liquid in
the appliance.
• Do not put ammable products or items
that are wet with ammable products in,
near or on the appliance.
• Do not touch the compressor or the
condenser. They are hot.
• Do not remove or touch items from the
freezer compartment if your hands are
wet or damp.
• Do not freeze again food that has been
thawed.
• Follow the storage instructions on the
packaging of frozen food.
• Wrap the food in any food contact
material before putting it in the freezer
compartment.
Internal lighting
Warning! Risk of electric shock.
• Concerning the lamp(s) inside this
product and spare part lamps sold
separately: These lamps are intended to
withstand extreme physical conditions in
household appliances, such as
temperature, vibration, humidity, or are
intended to signal information about the
operational status of the appliance. They
are not intended to be used in other
applications and are not suitable for
household room illumination.
Care and cleaning
Warning! Risk of injury or
damage to the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains plug
from the mains socket.
• This appliance contains hydrocarbons in
the cooling unit. Only a qualied person
must do the maintenance and the
recharging of the unit.
• Regularly examine the drain of the
appliance and if necessary, clean it. If the
drain is blocked, defrosted water collects
in the bottom of the appliance.
• The IKEA after sales customer service
center will assist you on the phone with
basic trouble-shooting for your
appliances at the time of service call
request. Please refer to
www.IKEA.com/au
and select your local store for local store
phone numbers and opening times.
How to reach us if you need our
service

XXX.XXX.XX
Serial No.: xxxxxxxxxxxxxxx

speci ed
range.
Electrical connection
quali ied
observed.
Ventilation requirements
air low
su icient.
5 cm min.
200 cm2
min.
200 cm2
Caution!
Door reversibility
reversal.
Caution!
9ENGLISH
Cleaning the interior
Caution!
Caution!

2

12ENGLISH
Daily use
Freezing calendar
1-2
10 -12
3-4
10 -12
3-6
10 -12
3-6
10 -12
3-6
• The symbols show dierent types of frozen
goods.
• The numbers indicate storage times in
months for the appropriate types of frozen
goods. Whether the upper or lower value of
the indicated storage time is valid depends
on the quality of the foods and treating
before freezing.
Freezing fresh food
• The freezer compartment is suitable for
freezing fresh food and storing frozen and
deep-frozen food for a long time.
• The freezing process lasts 24 hours: during
this period do not add other food to be
frozen.
Storage of frozen food
• When rst starting-up or after a period out
of use, before putting the products in the
compartment let the appliance run at least
2 hours on the colder setting.
• Successful freezing depends on the correct
packaging. When you close and seal the
package you must not allow air or moisture
in or out. If you do, you could have food
odour and taste transfer throughout the
refrigerator, and also dry out frozen food.
•Note: Never put bottled food or drinks in
the freezer compartment.
• For best performance, leave enough space
in the freezer and refrigerator compartment
for air to circulate around the packages.
Also let enough room at the front so the
door can close tightly.
Warning! In the event of accidental
defrosting, for example due to a power
failure, the defrosted food must be
consumed quickly or cooked immediately,
cooled and then re-frozen.
Thawing
Deep-frozen or frozen food, prior to being used,
can be thawed in the refrigerator compartment
or at room temperature, depending on the time
available for this operation.
Small pieces may even be cooked still frozen,
directly from the freezer: in this case, cooking
will take longer.
Storage of food in the refrigerator
compartmen
• Cover or wrap the food, particularly if it has
a strong avour.
• Position the food so that air can circulate
freely around it.
Positioning the door balconies
Picture for reference only
• To permit storage of food packages of
various sizes, the door balconies can be
placed at dierent heights.
• Carefully remove a door balcony from the
support, then reposition it as desired.

13ENGLISH
Movable shelves
Picture for reference only
• The walls of the refrigerator are equipped
with a series of runners so that the safety
glass shelves can be positioned as desired.
Caution! Do not move the glass shelf above
the vegetable drawer to ensure correct air
circulation.
Vegetable drawer
Picture for reference only
• The drawers can be pulled out for cleaning.
• The drawer is suitable for storing fruit and
vegetables.
• The drawer can be pulled out for cleaning.
Hints and tips
Normal operating sounds
The following sounds are normal during
operation:
• A faint gurgling and bubbling sound from
coils sound when refrigerant is pumped.
• A whirring and pulsating sound from the
compressor when refrigerant is pumped.
• A sudden cracking noise from inside
appliance caused by thermic dilatation
(a natural and not dangerous physical
phenomenon).
Hints for energy saving
• Do not open the door frequently or leave it
open longer than absolutely necessary.
• If the ambient temperature is high and very
low internal temperature is set and the
appliance is fully loaded, the compressor
may run continuously, causing frost or ice
on the evaporator. If this happens, set the
internal temperature toward warmer one to
allow automatic defrosting and so a saving
in electricity consumption.
Hints for fresh food refrigeration
• Do not store warm food or evaporating
liquids in the refrigerator.
• Cover or wrap the food, particularly if it has
a strong avour.
• Position food so that air can circulate freely
around it.
Hints for refrigeration
Useful hints:
• Meat (all types): wrap in a suitable
packaging and place it on the glass shelf
above the vegetable drawer. Store meat for
at most 1-2 days.
• Cooked foods, cold dishes: cover and place
on any shelf.
• Fruit and vegetables: clean thoroughly and
place in a special drawer. Bananas, potatoes,
onions and garlic must not be kept in the
refrigerator if not packed.
• Butter and cheese: place in a special airtight
container or wrap in an aluminium foil or
a polythene bag to exclude as much air as
possible.
• Bottles: close with a cap and place on the
door bottle shelf, or (if available) on the
bottle rack.
Cautions for Use
• The more food stu put in or the more and
the longer for once the door is opened, the
more it needs electric consumption, which
even leads malfunction.
• Re-plug in the power plug at the interval of
over ten minutes.
• Do not store bottled drink in the freezer,

14ENGLISH
so as to prevent from being broken and
damaging the refrigerator.
• Open the door as less as possible during
power-cut.
• When defrosting, never use any sharp or
metallic objects to remove the frost on the
surface of the evaporator as it will damage
the evaporator.
• Do not touch foods and containers in the
freezing compartment with your wet hands
so as to prevent from being frostbitten.
Hints for freezing
To help you make the most of the freezing
process, here are some important hints:
• The freezing process takes 24 hours. No
further food to be frozen should be added
during this period.
• Freeze only top quality, fresh and
thoroughly cleaned, foodstus.
• Prepare food in small portions to enable it
to be rapidly and completely frozen and to
make it possible subsequently to thaw only
the quantity required.
• Wrap up the food in aluminium foil or
polythene and make sure that the packages
are airtight.
• Do not allow fresh, unfrozen food to touch
food which is already frozen, thus avoiding a
rise in temperature of the latter.
• Lean foods store better and longer than
fatty ones; salt reduces the storage life of
food.
• Water ices, if consumed immediately after
removal from the freezer compartment, can
possibly cause the skin to be freeze burnt.
• It is advisable to show the freezing in date
on each individual pack to enable you to
keep tab of the storage time.
Hints for storage of frozen food
To obtain the best performance from this
appliance, you should:
• Make sure that the commercially frozen
foodstus were adequately stored by the
retailer.
• Make sure that frozen foodstus are
transferred from the food store to the
freezer in the shortest possible time.
• Do not open the door frequently or leave it
open longer than absolutely necessary.
• Once defrosted, food deteriorates rapidly
and cannot be refrozen.
• Do not exceed the storage period indicated
by the food manufacturer.
Care and cleaning
Warning! Refer to Safety chapters.
General warnings
Caution! Unplug the appliance before
carrying out any maintenance operation.
This appliance contains hydrocarbons in its
cooling unit; maintenance and recharging
must therefore only be carried out by
authorized technicians.
The accessories and parts of the
appliance are not suitable for washing in a
dishwasher.
Cleaning the interior
Before using the appliance for the rst time, the
interior and all internal accessories should be
washed with lukewarm water and some neutral
soap to remove the typical smell of a brand-new
product, then dried thoroughly.
Caution! Do not use detergents or
abrasive powders, as these will damage
the nish.
Initial power on
Caution! Before inserting the power
plug in to the outlet and switching on
the cabinet for the rst time, leave the
appliance standing upright for at least
4 hours. This will assure a sucient
amount of time for the oil to return to the
compressor. Otherwise the compressor
or electronic components may sustain
damage.
Periodic cleaning
Caution! Do not pull, move or damage any
pipes and/or cables inside the cabinet.

15ENGLISH
Caution! Do not damage the cooling
system.
Caution! When moving the cabinet, lift it
by the front edge to avoid scratching the
oor.
The equipment has to be cleaned regularly:
1. Clean the inside and accessories with
lukewarm water and some neutral soap.
2. Regularly check the door seals and wipe
clean to ensure they are clean and free from
debris.
3. Rinse and dry thoroughly.
4. If accessible, clean the condenser and the
compressor at the back of the appliance
with a brush. This operation will improve
the performance of the appliance and save
electricity consumption.
Periods of non-operation
When the appliance is not in use for long
periods, take the following precautions:
1. Disconnect the appliance from electricity
supply.
2. Remove all food.
3. Defrost (if necessary) and clean the
appliance and all accessories.
4. Clean the appliance and all accessories.
5. Leave the door/doors open to prevent
unpleasant smells.
Caution! If you want to keep the appliance
switched on, ask somebody to check it
once in a while to prevent the food inside
from spoiling in case of a power failure.
Defrosting refrigerator compartment
Frost is automatically eliminated from the
evaporator of the refrigerator compartment
every time the motor compressor stops,
during normal use. The defrost water drains
out through a trough into a special container
at the back of the appliance, over the motor
compressor, where it evaporates.
It is important to periodically clean the defrost
water drain hole at the back of the refrigerator
compartment to prevent the water overowing
and dripping onto the food inside.
For this purpose use the tube cleaner provided
in the accessory bag.
Defrosting freezer compartment
The freezer compartment has automatic
defrosting function.
Due to seasonal changes, a thick layer of frost
may form. To defrost manually, observe the
followings.
• Disconnect the appliance from the power
supply, and leave open the freezer door.
• Remove all foods, ice cube tray and shelf or
transfer to refrigerator compartment.
• Clean and wipe out the melted frost with a
cloth.
• After defrosting, connect the appliance to
the power supply.
Caution! To avoid damaging the freezer
compartment wall, do not use any sharp
objects to remove the frost or separate the
frozen food.
Troubleshooting
Warning! Refer to Safety chapters.
What to do if...
Problem Possible Cause Solution
The appliance does not operate.
The appliance is switched o. Switch on the appliance.
The mains plug is not connected to the
mains socket correctly
Connect the mains plug to the
mains socket correctly. Refer to
"Electrical connection" section of
the safety chapter.
There is no voltage in the mains socket.
Connect a dierent electrical
appliance to the mains socket.
Contact a qualied electrician.

16ENGLISH
Problem Possible Cause Solution
The appliance is noisy. The appliance is not placed stably. Check if the appliance stands
stable.
The lamp does not work. The lamp is defective. Refer to “Replacing the lamp”.
The compressor operates
continually.
Temperature is set incorrectly. Refer to “Operation” chapter.
Many food products were inserted at the
same time.
Wait some hours and then check
the temperature again.
The room temperature is too high. Refer to climate class chart on the
rating plate.
Food products placed in the appliance
were too warm.
Allow food products to cool to
room temperature before storing.
The door is not closed correctly. Refer to “Closing the door”.
The temperature in the appliance
is too low/too high.
The temperature is not set correctly. Set a higher/lower temperature.
The door is not closed correctly. Refer to “Closing the door”.
The food products temperature is too
high.
Let the food products temperature
decrease to room temperature
before storage.
Many food products are inserted at the
same time.
Insert less food products at the
same time.
The thickness of the frost is greater than
0.16"-0.20". Defrost the appliance.
The door has been opened often. Open the door only if necessary.
There is no cold air circulation in the
appliance.
Make sure that there is cold air
circulation in the appliance.
There is too much condensed
water on the rear wall of the
refrigerator.
Door was opened too frequently. Open the door only when
necessary.
Door was not closed completely. Make sure the door is closed
completely.
Stored food was not wrapped. Wrap food in suitable packaging
before storing it in the appliance.
refrigerator.
The drain hole at the back of the
appliance is clogged.
Clean the drain hole with a piece
of wire.
Food products prevent water from Make sure that food products do
not touch the rear plate.
The door is not closed well.
Refer to "Closing the door", or
refer to the troubleshooting item
below ("The door does not close
completely").
The drip pan cracks.
The IKEA after sales customer
service center will assist you on the
phone at the time of service call
request.Please refer to
www.IKEA.com/au
and select your local store for local
store phone numbers and opening
times.
The defrost water drain is clogged. Clean the drain hole with a piece
of wire.

1ENGLISH
Problem Possible Cause Solution
The door does not close
completely.
The shelves are out of position.
Make sure the shelves are in
correct position. Refer to "Movable
shelves".
The gaskets are dirty. Clean the gaskets. Refer to "Care
and cleaning".
The appliance is not level. Make sure the appliances is
installed in level.
Malfunction alarm
If the appliance malfunctions, a LED indicatior
• Temperature sensor failure of the
refrigerator chamber
• Defrosting sensor failure of the
refrigerator chamber
• Defrosting sensor failure of the
Refrigerator-Freezer
freezer chamber
• Failure of ambient temperature
sensor
If your appliance still is not working
properly after making the above checks,
the IKEA after sales customer service center
will assist you on the phone at the time of
service call request.
Please refer to
www.IKEA.com/au
and select your local store for local store
phone numbers and opening times.
Product type
Installation type
Closing the door
1. Clean the door gaskets.
2. If necessary, adjust the door. Refer to the
separate Assembly Instructions.
3. If necessary, replace the defective door
gaskets. Contact the After Sales Service.
interior lighting.
device.
Please reach out to IKEA, referring to
www.IKEA.com/au
and select your store for local store phone
numbers and opening times.

ENGLISH 8
Fridge Auto
Freezer Auto
Energy consumption 303 kWh/y
Energy class MEPS 3 stars
Voltage 220 - 240 V
Frequency 50 Hz
Pictur e for reference only
Article Nu mb er
(8-d igitco de)
Ser ial Num ber (sta rt
with SN, 22-d igit co de )
The article number and the serial number
are situated in the rating plate on the
internal left side of the appliance.
Recycle materials with the symbol
packaging in relevant containers to recycle it.
Help protect the environment and human health
by recycling waste of electrical and electronic
appliances. Do not dispose of this product
with the household waste. Return the product
to your local recycling facility or contact your
. Put the
Net volume
XXX.XXX.XX
Serial No.: xxxxxxxxxxxxxxx

ENGLISH 19
IKEA GUARANTEE
How long is the IKEA guarantee valid?
This guarantee is valid for ve (5) years from
the original date of purchase of your
appliance at IKEA. The original sales receipt
is required as proof of purchase. If service
work is carried out under guarantee, this will
not extend the guarantee period for the
appliance.
Who will execute the service?
IKEA service provider will provide the service
through its own service operations or
authorized service partner network.
What does this guarantee cover?
The guarantee covers faults of the appliance,
which have been caused by faulty
construction or material faults from the date
of purchase from IKEA. This guarantee
applies to domestic use only. The exceptions
are specied under the headline “What is not
covered under this guarantee?” Within the
guarantee period, the costs to remedy the
fault e.g. repairs, parts, labour and travel will
be covered, provided that the appliance is
accessible for repair without special
expenditure. On these conditions the
respective local regulations are applicable.
Replaced parts become the property of IKEA.
The guarantee exists only if the appliance
complies and is installed in accordance with:
• The technical specifications.
• The Assembly Instructions and
usermanual Safety Information.
IKEA’s guarantee is subject to Australian
Consumer Law - see Schedule 2 to
Competition and Consumer Act, 2010. This
guarantee is in addition to (and does not
exclude, restrict or modify in any way) any
non-excludable statutory warranties in
Australia.
• Normal wear and tear.
• Deliberate or negligent damage,
damage caused by failure to observe
operating instructions, incorrect
installation or by connection to the
wrong voltage, damage caused by
chemical or electro-chemical reaction,
rust, corrosion or water damage
including but not limited to damage
caused by excessive lime in the water
supply, damage caused by abnormal
environmental conditions.
•Consumable parts including batteries
and lamps.
•Non-functional and decorative parts
which do not affect normal use of the
appliance, including any scratches and
possible color differences.
•Accidental damage caused by foreign
objects or substances and cleaning or
unblocking of filters, drainage systems
or soap drawers.
•Damage to the following parts:
ceramic glass, accessories, crockery
and cutlery baskets, feed and drainage
pipes, seals, lamps and lamp covers,
screens, knobs, casings and parts of
casings. Unless such damages can be
proved to have been caused by
production faults.
•Cases where no fault could be found
during a technician’s visit.
What will IKEA do to correct the problem?
IKEA appointed Service Provider will examine
the product and decide, at its sole discretion,
if it is covered under this guarantee. If
considered covered, IKEA Service Provider or
its authorized service partner through its
own service operations, will then, at its sole
discretion, either repair the defective
product or replace it with the same or a
comparable product.
What is not covered under this
guarantee?

ENGLISH 20
•Repairs not carried out by our appointed
service providers and/or an authorized
service contractual partner or where non-
original parts have been used.
•Repairs caused by installation which is
faulty or not according to specification.
•The use of the appliance in a non-domestic
environment i.e. professional use.
•Transportation damages. If a customer
transports the product to his home or
another address, IKEA is not liable for any
damage that may occur during transport.
However, if IKEA delivers the product to
the customer’s delivery address, then
damage to the product that occurs during
this delivery will be covered by IKEA.
•Cost for carrying out the initial installation
of the IKEA appliance.
•However, if an IKEA appointed Service
Provider or its authorized service partner
repairs or replaces the appliance under the
terms of this guarantee, the appointed
Service Provider or its authorized service
partner will reinstall the repaired appliance
or install the replacement, if necessary.
•Problems caused by incorrect or
inadequate venting of the appliance.
• All plumbing and electrical installation, are
not the responsibility of IKEA, and
customer must complete these work
before the execution work.
•The benefits conferred by this express
guarantess are in addition to all other
conditions, warranties, guarantees, rights
and remedies expressed or implied by the
Trade Practices Act and similar State and
Territory laws and all other obligations
and liabilities on the part of the
manufacturer or supplier and nothing
contained herein shall restrict or modify
such rights, remedies, obligations or
liabilities.
How country law applies
The IKEA guarantee gives you specific
legal rights, which cover or exceed all the
local legal demands. However these
conditions do not limit in any way
consumer rights described in the local
legislation.
Our goods come with guarantees that
cannot be excluded under the Australian
Consumer Law (ACL).
You are entitled to a replacement or
refund for a major failure and for
compensation for any other reasonably
foreseeable loss or damage.
You are also entitled to have the goods
repaired or replaced if the goods fail to be
of acceptable quality and the failure does
not amount to a major failure.
This guarantee is not intended in any way
to limit or exclude such rights and
remedies that you may have under law.
You can find out more information about
the Australian Consumer Law on the ACCC
website: www.accc.gov.au
Area of validity
The IKEA guarantee applies only to
products purchased and installed in
AUSTRALIA . The services will be provided
in the framework of the guarantee
conditions. An obligation to carry out
services in the framework of the
guarantee exists only if the appliance
complies and is installed in accordance
with:
•the technical specifications of the
country in which the guarantee claim is
made;
•the Assembly Instructions and User
Manual Safety Information;
