Ikegami VCM-901 User manual

VCM-901
9-Inch Color Monitor
■Description
■Features
The VCM-901 is a 9-inch Color Monitor with 300 TV Lines Resolution. It is suitable for industrial CCTV
surveillance applications. The VCM-901 can be used in desktop or dual rack mounted, using an optional
rack mount kit (RMK-901).
■ 9-inch in-line gun, semi-tinted CRT that
produces 300 lines of Horizontal resolution
■ Accepts both NTSC and PAL
■ Accepts Y/C signal
■ Two Video IN connectors
■ Two Audio IN/OUT connectors
and a built-in speaker
■ Durable metal cabinet
■ Adjustable Tint, Color, Contrast
Brightness and Audio volume
■ Ideal for multiple professional
applications such as FCC, cUL,DHHS,
CE and ISO9001
■ Two units fit side by side in a standard EIA rack.
RMK-901 rack mount kit is Optional.

VCM-901
■Specifications
IKEGAMI ELECTRONICS (U.S.A.), INC.
HEADQUARTERS 37 BROOK AVENUE, MAYWOOD, NJ 07607
Phone: [phone] Fax: [phone]
WEST COAST OFFICE 2631 MANHATTAN BEACH BLVD., REDONDO BEACH, CA 90278 Phone: [phone] Fax [phone]
SOUTHWEST OFFICE 526 BLUEBIRD LANE, RED OAK, TX 75154 Phone: [phone] Fax: [phone]
MIDWEST OFFICE 747 CHURCH ROAD, UNIT C1, ELMHURST, IL 60126 Phone: [phone] Fax: [phone]
SOUTHEAST OFFICE 5200 N.W. 33RD AVENUE, SUITE 111 FORT LAUDERDALE, FL 33309 Phone: [phone] Fax: [phone]
■ URL http://www.ikegami.com
General
Color System NTSC/PAL
Input/Output Connections Video IN: BNC x2, Y/C x1
Video OUT: BNC x2
Audio IN: RCA x2
Audio OUT: RCA x2
Picture Tube 9" In-Line Gun,
Semi-tinted CRT,
90°Deflection
Resolution 300TV Lines at center
Power Source AC 100 ~ 240V, 50/60Hz
Power Consumption Approx. 45W
Linearity Horizontal: 10%
Vertical:10%
Position Horizontal: ± 8mm
Vertical: ± 8mm
Operating Temperature 0°C ~ 40°C (32°F ~ 104°F)
Operating Humidity 35% ~ 80% (non-condensing)
Net Weight Approx. 7.5kg (16.7 lbs)
Dimensions(WHD) 220 x 223 x 317mm
(8.66 x 8.78 x 12.48 inches)
Enclosure Metal
Video
Input level: 1.0 ± 0.2Vp-p, 75 ohms
Control & Switches
Mechanical Push Button: Power
Soft Touch Button: Tint, (NTSC only)
Color, Brightness,
Contrast, Volume Up,
Volume Down, Video Selector
(Video1, Video2, Y/C)
Indicators Green LED's for Power,
Video1, Video2, Y/C
Accessories Power Cord, Owner's Manual
Approvals FCC Class A, cUL, DHHS,
CE, ISO9001
*These specifications are subject to change without notice.
