iLive ITTB751 User manual
Turntable with Stereo Speakers
User’s Guide for Model ITTB751 v2743-01
For the most up-to-date version of this User’s Guide, go to www.iliveelectronics.com
2 3
Safety Instructions & Warnings
Important Safety Instructions
• Read these Instructions.
• Keep these Instructions.
• Heed all Warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with a dry cloth.
• Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers)
that produce heat.
• Do not defeat the safety purpose of the polarized or
grounding - type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. When the provided
plug does not t into your outlet, consult an electrician for
replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
• Only use attachments/accessories specied by the
manufacturer.
• Unplug this apparatus during lightning storms or when
unused for long periods of time.
• Refer all servicing to qualied service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
• Use only with a cart, stand, tripod, bracket,
or table specied by the manufacturer, or
sold with the apparatus. When a cart is
used, use caution when moving the cart/
apparatus combination to avoid injury from
tip-over.
FCC Warnings
Warning: Changes or modications to this unit not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o
and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
Additional Warnings and Precautions
• CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH
WIDE BLADE OF PLUG TO WIDE SLOT, FULLY
INSERT.
• Mains plug is used as disconnect device and it should remain
readily operable during intended use. In order to disconnect
the apparatus from the mains completely, the mains plug
should be disconnected from the mains socket outlet
completely.
• CAUTION: Use of controls or adjustments or performance
of procedures other than those specied may result in
hazardous radiation exposure.
• WARNING: Changes or modications to this unit not
expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
• WARNING: Use of this unit near uorescent lighting may
cause interference regarding use of the remote. If the unit is
displaying erratic behavior move away from any uorescent
lighting, as it may be the cause.
• WARNING: Shock hazard - Do Not Open.
• Caution and marking information is located at the rear or
bottom of the apparatus.
• WARNING: To reduce the risk of re or electric shock,
do not expose this apparatus to rain, moisture, dripping, or
splashing.
• Objects lled with liquids, such as vases, shall not be placed
on the apparatus.
WARNING: To reduce the risk of electric
shock, do not remove cover (or back). No
user-serviceable parts inside. Refer servicing
to qualied service personnel.
ATTENTION
RISQUE D' ÉLECTROCUTION
NE PAS OUVRIR
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation point within an equilateral
triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
This symbol indicates that this product
incorporates double insulation between
hazardous mains voltage and user accessible
parts.
The lightning ash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of “dangerous
voltage” within the product’s enclosure that
may be of sucient magnitude to constitute a
risk of electric shock to persons.
This product utilizes a Class 1 laser to read
Compact Discs. This laser Compact Disc
Player is equipped with safety switches to
avoid exposure when the CD door is open and
the safety interlocks are defeated. Invisible
laser radiation is present when the CD Player’s
lid is open and the system’s interlock has failed
or been defeated. It is very important that you
avoid direct exposure to the laser beam at
all times. Please do not attempt to defeat or
bypass the safety switches.
WARNING: This product can expose you to
chemicals including lead, which is known to
the State of California to cause cancer. For
more information go to: www.P65Warnings.
ca.gov This product meets and complies with
all Federal regulations.
4 5
SetupTable of Contents
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Includes
Power
Orientation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Features & Controls
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Connecting to Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Pairing Bluetooth and Playing Audio Wirelessly
Connecting the Speakers
Using the Aux Out
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Playing a Record
Recording (USB)
Customer Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Contact Information
Warranty
International Support
Includes
• RCA stereo audio cable
• User's Guide
Power
Plug the built in AC power cord into a standard wall outlet.
6 7
Orientation
Tone Arm
& Stylus
Turntable
Aux Out
USB
Insert USB drive
to record audio
from turntable.
Speaker Inputs
Tone Arm
Lift Switch
Features & Controls
Controls
Counterweight
Adjustment
Turn to adjust the
weight of the stylus
onto the record. Note:
3 grams of weight is
recommended
Anti-Skating Adjustment
Use to stop the stylus
from sliding toward the
center of the record.
Pitch Adj.
Use to fine tune the speed of the turntable.
78/45/30
Press to select playback speed of a record.
Volume
Power
Press to power ON/OFF.
Rec. Stop
Press to stop recording music to a USB.
Recording
Press to start recording music to a USB drive.
Pair
Press and hold to begin pairing to a Bluetooth device.
Playback Switch
Select Line If your
speaker system
(amplifier) does not have
phono inputs.
Select Phono if your
stereo system (amplifier)
has Phono inputs
connect your turntable
to the phono inputs on
your stereo system to
play music out loud.
8 9
Connecting the Speakers
1. Connect each speaker to the speaker inputs on the back of the unit.
2. Set the Playback Switch to Line mode. The Line button will turn white.
3. Audio played through the turntable should now be heard through the connected speakers.
Connecting to Devices
Pairing Bluetooth and Playing Audio Wirelessly
1. Power on the unit. Enter into Bluetooth mode by pressing the Source button, the pair button will begin quickly
flashing blue. When pairing, remain within 3 feet of the unit.
2. Using the controls on your Bluetooth device, search for and select ITTB751 in your Bluetooth settings to pair.
If need be, refer to the user’s manual for your specific device for instructions on pairing and connecting Bluetooth
devices.
3. When successfully paired and connected, a voice prompt will sound and the Pair button will turn solid.
After initial pairing, the unit will stay paired unless unpaired manually by the user or erased due to a reset of the
device. If your device should become unpaired or you find it is unable to connect, repeat these steps.
4. Use the controls on your connected Bluetooth Device to select and begin playing audio. Play, pause or skip
a selected track using the controls on the connected Bluetooth Device. Change volume level using both
connected device and turntable.
After initial pairing, the unit will automatically connect to the last Bluetooth device used whenever it is powered on. If
you would like to connect to a different device, turn off Bluetooth on the unwanted device and use the above steps to
connect to a different device.
Using the Aux Out
Requires RCA audio cable (included).
1. Plug the included RCA audio cable into the Aux Out on the turntable and your amplifier.
2. Set the Playback Switch to Phono mode, the backlighting will turn white.
3. Audio from the record will now be heard through the connected amplifier/speakers.
Belt Plate
Belt
Step 1
Place the Belt plate onto the main
unit as seen below.
Step 2
Pull the Belt of the Belt Plate around the
Roller as shown below.
Step 3
Place the Plate Cover over the Belt Plate as shown
below. You may now load a record onto the turntable.
Roller
Plate Cover Note: Select Phono on the Playback Switch if your stereo system (amplifier) has Phono inputs connect your
turntable to the phono inputs on your stereo system to play music out loud.
If your stereo system (amplifier) does not have Phono inputs set the Playback Switch to Line.
Assembly
Preamp
Speaker
s
10 11
Operation
Playing a Record
It is recommended that you use extreme care when manipulating the tone arm, stylus, and other components of this
turntable. These parts are very sensitive and can easily break or become damaged if they are carelessly handled.
1. Enter into Turntable mode by pressing the Source button.
2. Remove the shroud that protects the stylus and release the lock that holds the Tone Arm in place.
3. Use the Tone Arm Lift Switch to raise the Tone Arm from its catch.
4. Using your hand, gently swing the Tone Arm into the desired location over the record. The turntable will start
spinning as the Tone Arm is moved into position.
5. Use the Tone Arm Lift Switch to safely lower the stylus onto the record.
Using the Lift Switch instead of your hand will reduce the chance of accidentally damaging the record or the stylus.
6. When not in use, secure and lock the Tone Arm in its resting position and replace the protective shroud over the
stylus. This will minimize the risk of accidental damage to these sensitive parts.
Lock Unlock
Stylus
Recording (USB)
Note: This unit can record playback from a record onto a USB drive to be saved via MP3 format.
Please Check to make sure Bluetooth is OFF.
1. Insert a USB drive into the rear of the unit.
2. Press the Recording button to begin recording the audio of the record being played. When recording the
backlighting will turn red.
3. To pause recording, press the Rec. Stop button. The red backlighting will begin flashing slowly.
4. When the recording is finished or you want to stop it, press and hold the Recording button for 5 seconds, the
red backlighting will turn off and the unit will exit recording mode.
12
Protect for Today
Sustain for Tomorrow
Made
Green
International Support
To download this User’s Guide in English, Spanish, and French, or to get answers to frequently asked questions, visit
the support section at: www.iliveelectronics.com
Para descargar este Manual del Usuario en inglés, español y francés, o para obtener respuestas a preguntas frecuentes,
visite la sección de apoyo en: www.iliveelectronics.com
Pour télécharger ce guide de l’utilisateur en anglais, espagnol ou français, ou pour obtenir des réponses à des
questions fréquemment posées, consultez la rubrique d’assistance sur: www.iliveelectronics.com
Contact Information
Website: www.iliveelectronics.com
Phone Support: 1-888-999-4215
Warranty
For Warranty Information and the most up-to-date version of this User’s Guide, go to:
www.iliveelectronics.com
Customer Support
Copyright © 2021 Digital Products International (DPI, Inc.). All other trademarks appearing herein are the property of
their respective owners. Specifications are subject to change without notice.
Table of contents
Other iLive Turntable manuals
