iLive ITTB757B User manual

User’s Guide for Model ITTB757B v1828-01
For the most up-to-date version of this User’s Guide, go to www.iliveelectronics.com
Stereo Turntable with Bluetooth
and wired speakers

2
Safety Instructions & Warnings
WARNING: To reduce the risk of electric
shock, do not remove cover (or back). No
user-serviceable parts inside. Refer servicing
to qualied service personnel.
ATTENTION
RISQUE D' ÉLECTROCUTION
NE PAS OUVRIR
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation point within an equilateral
triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
This symbol indicates that this product
incorporates double insulation between
hazardous mains voltage and user accessible
parts.
The lightning ash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of un-insulated
“dangerous voltage” within the product’s
enclosure that may be of sufcient magnitude
to constitute a risk of electric shock to persons.

3
Important Safety Instructions
•Read these Instructions.
•Keep these Instructions.
•Heed all Warnings.
•Follow all instructions.
•Do not use this apparatus near water.
•Clean only with a dry cloth.
•Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
•Do not install near any heat Function swtich s such as
radiators, heat registers, stoves, or other apparatus (including
ampliers) that produce heat.
•Do not defeat the safety purpose of the polarized or
grounding - type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. When the provided
plug does not t into your outlet, consult an electrician for
replacement of the obsolete outlet.
•Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
• Only use attachments/accessories specied by the
manufacturer.
•Unplug this apparatus during lightning storms or when
unused for long periods of time.
• Refer all servicing to qualied service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
•Use only with a cart, stand, tripod, bracket,
or table specied by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
Additional Warnings and Precautions
• CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH
WIDE BLADE OF PLUG TO WIDE SLOT, FULLY
INSERT.
• Mains plug is used as disconnect device and it should remain
readily operable during intended use. In order to disconnect
the apparatus from the mains completely, the mains plug
should be disconnected from the mains socket outlet
completely.
•CAUTION: Use of controls or adjustments or performance
of procedures other than those specied may result in
hazardous radiation exposure.
• WARNING: Changes or modications to this unit not
expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
• WARNING: Use of this unit near uorescent lighting may
cause interference regarding use of the remote. If the unit is
displaying erratic behavior move away from any uorescent
lighting, as it may be the cause.
• WARNING: Shock hazard - Do Not Open.
•Caution and marking information is located at the rear or
bottom of the apparatus.
• WARNING: To reduce the risk of re or electric shock,
do not expose this apparatus to rain, moisture, dripping, or
splashing.
• Objects lled with liquids, such as vases, shall not be placed
on the apparatus.
•WARNING: This product may contain chemicals known
to the State of California to cause birth defects, or other
reproductive harm (California Prop 65). Wash hands after
handling.
•This product meets and complies with all Federal regulations.
FCC Warnings
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference receeived, including interference that may cause
undesired operation.
Warning: Changes or modifications to this unit not expressl
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentandreceiver.
• Connecttheequipmentintoanoutletonacircuitdierent
fromthattowhichthereceiverisconnected.
• Consultthedealeroranexperiencedradio/TVtechnician
forhelp.
This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. This equipment should be
installed and operated with minimum distance 20cm between the
radiator & your body.

4
Table of Contents
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Includes
Power
Speakers
Orientation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Features & Controls
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Playing a Record
Pairing Bluetooth and playing Audio Wirelessly
Using the Aux In (3.5mm Audio Input)
RCA Audio Output
Customer Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Contact Information
Warranty
International Support

5
Setup
AUX IN
AUDIO OUT
AUX IN
AUDIO OUT
AUX IN
AUDIO OUT
Includes
• AC/DC power adapter
• 45 rpm adapter
• Warranty
• User's Guide
Power
Plug the AC/DC power
adapter (included) into the
DC power input on the unit
and a standard power outlet.
Speakers
Connect the speaker wires to the speaker inputs on
the tuntable. Be sure to match the positive (red) and
negative (black) wires to their corresponding inputs.

6
AUX IN
AUDIO OUT
Orientation
Speakers x 2
Features & Controls
Dust Cover
Aux In (3.5mm audio input)
Speaker Output
Connect included
speakers here.
Source Select
Audio Output
Connect to send audio
signal to an external
audio source.

7
Tone Arm & Stylus
Record Speed
Choose 33, 45, or
78, depending on
the type of record
to be played.
Auto Stop
Select ON or OFF.
Tone Arm Lock
Turntable Tone Arm
Lift Switch
45 rpm Record Adapter
Pairing
Indicator
Power
Play/
Pause/Pair
Bluetooth
Stop
Skip Track
Volume

8
Playing a Record
It is recommended that you use extreme care when manipulating the tone arm, stylus, and other components of this
turntable. These parts are very sensitive and can easily break or become damaged if they are carelessly handled.
1. Set the Source swtich to Phono.
2. Lift open the turntable cover and place the record on the turntable. If you are playing a 45 rpm record, use the
included 45 rpm adapter and place it between the turntable and the record.
3. Remove the shroud that protects the stylus and release the lock that holds the Tone Arm in place.
4. Use the Tone Arm Lift Switch to raise the Tone Arm from its catch.
5. Using your hand, gently swing the Tone Arm into the desired location over the record. The turntable will start
spinning as the Tone Arm is moved into position.
6. Use the Tone Arm Lift Switch to safely lower the stylus onto the record.
Using the Lift Switch instead of your hand will reduce the chance of accidentally damaging the record or the stylus.
7. Slide the Auto Stop Switch to ON to enable the Auto Stop feature. When the record is finished playing, it will
automatically stop the turntable. Use the Lift Switch to raise the stylus off of the record, and gently return the
Tone Arm to the catch by hand.
Note: Some records place their Auto Stop area outside of the range of this unit. In these cases, the record will stop
playing before the last track is reached. Set the Auto Stop Switch to OFF and use the Tone Arm Lift Switch to safely
raise the stylus off the record when the end of the record has been reached.
8. When not in use, secure and lock the Tone Arm in its resting position and replace the protective shroud over the
stylus. This will minimize the risk of accidental damage to these sensitive parts.
Operation
Lock Unlock

9
RCA Audio Output
Requires RCA audio cables (red/white, not included). Use to
connect the turntable to an external stereo, television, or
other Function swtich .
1. Connect RCA audio cables to the Audio Output on
the back of the turntable, and to the audio input
of an external stereo system. If need be, adjust the
external stereo system to accept input from the
turntable.
2. Audio played through the turntable should now be
heard through the connected stereo system.
Using the Aux In (3.5mm Audio Input)
Requires 3.5 mm audio input cable (not included).
1. Plug a 3.5 mm audio input cable into the Aux In
on the unit and the headphone jack on an MP3
Player or other audio Function swtich .
2. Set the Source swtich to Aux and use the controls
on your connected device to select and play audio.
3. Audio played through the connected device
should now be heard through the speakers.
AUX IN
AUDIO OUT
AUX IN
AUDIO OUT
Connecting External Devices
Pairing Bluetooth and playing Audio Wirelessly
1. Set the Source swtich to BT and press and hold the Play/Pause/Pair button. The pairing indicator will begin
quickly flashing blue. When pairing, remain within 3 feet of the unit.
2. Using the controls on your Bluetooth device, search for and select ITTB757 in your Bluetooth settings to pair. If
your device requests a password, enter the default password 0 0 0 0 . If need be, refer to the user’s manual for your
specific device for instructions on pairing and connecting Bluetooth devices.
3. When successfully paired and connected, an audible chime will sound and the pairing indicator will turn solid.
After initial pairing, the unit will stay paired unless unpaired manually by the user or erased due to a reset of the
device. If your device should become unpaired or you find it is unable to connect, repeat these steps.
4. Use the controls on your connected Bluetooth Device to select and begin playing audio. Play, pause or skip a
selected track using the controls on the connected Bluetooth Device or the controls on the turntable.
AUX IN
AUDIO OUT
AUX IN
AUDIO OUT

10
Protect for Today
Sustain for Tomorrow
Made
Green
International Support
To download this User’s Guide in English, Spanish, and French, or to get answers to frequently asked questions, visit
the support section at: www.iliveelectronics.com
Para descargar este Manual del Usuario en inglés, español y francés, o para obtener respuestas a preguntas frecuentes,
visite la sección de apoyo en: www.iliveelectronics.com
Pour télécharger ce guide de l’utilisateur en anglais, espagnol ou français, ou pour obtenir des réponses à des
questions fréquemment posées, consultez la rubrique d’assistance sur: www.iliveelectronics.com
Contact Information
Website: www.iliveelectronics.com
Email Support: [email protected]
Email Parts: [email protected]
Phone Support: 1-888-999-4215
Warranty
For Warranty Information and the most up-to-date version of this User’s Guide, go to: www.
iliveelectronics.com
Customer Support
Copyright © 2016 Digital Products International (DPI, Inc.). All other trademarks appearing herein are the property of
their respective owners. Specifications are subject to change without notice.
