IMMAX NEO Soil Sensor User manual
USER MANUAL
Manufacturer and importer:
IMMAX, Pohoří 703, 742 85 Vřesina, EU | www.immaxneo.cz | www.immaxneo.com
Made in P.R.C.
TECHNICAL SPECIFICATIONS
Communication with indoor unit: RF signal 433 MHz, distance 60 meters
Humidity measuring range: 0-100%
Indicates humidity level: 20%, 40%, 60%, 80%, 100%
Temperature measuring range: -10 ° C to 60 ° C
Degree of protection: IP65
Working temperature: -10 ° C to 60 ° C
Power supply: 3x AAA batteries (not included)
Dimensions: 135x138x110mm
Weight: 260g
IMMAX NEO PRO APPLICATION
Download the Immax NEO PRO app from Google Play or the Apple store.
OPERATING
After connected our Wi-Fi water timer with APP, click the Water Timer icon,
switch to “Sensor” interface.
“Sensor” interface will show Soil sensor icon and Rain sensor icon. The switch
button is in gray color, it means the sensor haven’t connect yet.
Screw off the sensor battery door and install the batteries to the soil sensor
near our Wi-Fi water timer. After installing the batteries, the GREEN LED light
will turn on for few seconds.
After the green LED light turn off, please press and hold the button at the
back of the sensor for ve seconds until the RED LED light turn on, it means
the sensor is ready for connecting.
When the RED light turn on, please tap the soil sensor button at the App,it
will automatically search and connect the sensor, it will take around 10
seconds. After connected, the soil sensor icon will turn to green color and
show the battery power level in APP. Switch to “Parameter” interface, user
will see the soil data.
After conrm connected, screw the battery door, insert into the earth where
you needed. The distance between Soil Sensor and Wi Water Time must
within 60 meters in open area.
SETTING SOIL SENSOR
Left key is to set humidity level
Right key is conrm button/ test now button
After nishing connection, press and hold the two buttons for 5 seconds,
user can wake up the program, the LED light will show the current Soil
moisture level. 5 LED lights indicate 5 levels of soil moisture levels: 20%, 40%,
60% 80% and 100% (Volume Water Content).
When wake up the LED light, press the Left button, user can set the “Stop
Watering Soil Moisture Level”, default humidity is at 60%. After setting, press
Right button or wait for 20 seconds to conrm.
When wake up the LED light, press the Right button, user can check the cur-
rent soil moisture level. (User can view the accurate data through our APP).
AUTO RUNNING
After setting the“Stop Watering Soil Moisture Level” and pair successfully,
the Wi-Fi water timer will automatically stop watering plan once the Soil
moisture reach the setting level.
