Immergas MAGIS COMBO PLUS V2 Series Operating instructions

Instructionsandrecommendations
Installer
User
Maintenancetechnician
*1.045258ENG*

IE MAGISCOMBO
469
PLUS V2

2

3
INDEX
Dear Customer.................................................................................. 4
Safety symbols used.......................................................................... 6
Personal protective equipment ....................................................... 6
1 Installing the indoor unit............................................... 7
1.1 Description of the product.................................................... 7
1.2 Installation warnings.............................................................. 7
1.3 Main dimensions.................................................................. 11
1.4 Minimum installation distances......................................... 11
1.5 Antifreeze protection ........................................................... 12
1.6 Installation inside the recessed frame (Optional)............ 13
1.7 Indoor unit connection unit ............................................... 14
1.8 Hydraulic connection .......................................................... 14
1.9 Connecting the chiller line.................................................. 15
1.10 Electrical connection ........................................................... 16
1.11 Room chrono-thermostats (Optional) .............................. 20
1.12 MODBUS temperature and humidity room probes
(Optional).............................................................................. 20
1.13 Remote zone control (Optional) ........................................ 21
1.14 Dominus (Optional) ............................................................ 21
1.15 Humidistat ON/OFF (Optional) ........................................ 21
1.16 External temperature probe (Optional) ............................ 21
1.17 Temperature control setting................................................ 22
1.18 Immergas ue systems......................................................... 23
1.19 Tables of resistance factors and equivalent lengths of
“Green Range” ue system components............................ 25
1.20 Outdoor installation in partially protected area............... 27
1.21 Internal installation using a recessed frame with
direct air intake..................................................................... 29
1.22 Concentric horizontal kit installation................................ 30
1.23 Concentric vertical kit installation..................................... 31
1.24 Separator kit installation ..................................................... 33
1.25 C9 adaptor kit installation................................................... 34
1.26 Ducting of ues or technical slots...................................... 36
1.27 Conguration type B, open chamber and fan assisted
for indoors............................................................................. 36
1.28 Flue exhaust to ue/chimney. ............................................. 37
1.29 Flues, chimneys and chimney caps. ................................... 37
1.30 Water treatment plant lling............................................... 38
1.31 System lling......................................................................... 39
1.32 Filling the condensate drain trap........................................ 39
1.33 Gas system start-up. ............................................................. 39
1.34 Operating limits.................................................................... 39
1.35 Commissioning the indoor unit (Ignition, only when
paired with an outdoor unit) .............................................. 40
1.36 Circulation pump ................................................................. 41
1.37 Kits available on request ...................................................... 42
1.38 Main components................................................................. 43
2 Instructions for use and maintenance ......................... 44
2.1 General recommendations.................................................. 44
2.2 Cleaning and maintenance.................................................. 46
2.3 Control panel ........................................................................ 46
2.4 System use ............................................................................. 47
2.5 Fault and anomaly signals ................................................... 50
2.6 Parameters and information menu .................................... 58
2.7 Indoor unit shutdown.......................................................... 62
2.8 Restore central heating system pressure............................ 62
2.9 Draining the system ............................................................. 62
2.10 Antifreeze protection ........................................................... 62
2.11 Cleaning the case.................................................................. 62
2.12 Permanent shutdown........................................................... 62
2.13 Use of the remote zone panel (Optional) .......................... 62
3 Instructions for maintenance and initial check...........63
3.1 General recommendations.................................................. 63
3.2 Initial check........................................................................... 63
3.3 Yearly appliance check and maintenance .......................... 64
3.4 Hydraulic diagram................................................................ 66
3.5 Wiring diagram..................................................................... 67
3.6 Storage tank unit................................................................... 73
3.7 System lter........................................................................... 73
3.8 Troubleshooting.................................................................... 74
3.9 Gas valve................................................................................ 75
3.10 Converting the heat generator to other types of gas........ 75
3.11 Fan speed calibration ........................................................... 76
3.12 Adjustment of the air-gas ratio........................................... 76
3.13 P.C.B. programming............................................................. 77
3.14 "Chimney sweep” function.................................................. 84
3.15 Pump anti-block function................................................... 84
3.16 ree-way anti-block system .............................................. 84
3.17 Radiators antifreeze function.............................................. 84
3.18 Photovoltaic function........................................................... 84
3.19 Outdoor unit disable function............................................ 84
3.20 Preheating function.............................................................. 85
3.21 Diverter valve management (summer / winter)............... 85
3.22 Automatic venting function................................................ 85
3.23 Screed heater function......................................................... 85
3.24 Dehumidication function ................................................. 86
3.25 Outdoor Unit Testmode Function ..................................... 86
3.26 Outdoor Unit Pump Down Function................................ 86
3.27 Puer in preheating function.............................................. 86
3.28 Night mode function............................................................ 86
3.29 System setpoint correction function.................................. 86
3.30 Generator management....................................................... 87
3.31 Casing removal ..................................................................... 88
4 Technical data............................................................... 90
4.1 Variable heat output ............................................................. 90
4.2 Magis Combo 4 Plus V2 product che (in compliance
with Regulation 811/2013).................................................. 92
4.3 Magis Combo 6 Plus V2 product che (in compliance
with Regulation 811/2013).................................................. 94
4.4 Magis Combo 9 Plus V2 product che (in compliance
with Regulation 811/2013).................................................. 96
4.5 Parameters for lling in the package che ........................ 98

4
DearCustomer
Congratulations forhavingchosena top-quality Immergas product, ableto assure well-being and safety for a long period of time.AsanIm-
mergascustomeryoucan alsocount ona Qualied AuthorisedAer-SalesTechnicalAssistanceCentre,prepared andupdated toguarantee
con stant ecienc y of your appliance. Read the following pages caref ully: you w ill be able to draw useful tips on the proper use of the device,
co m pl i an c e w i t h wh i c h w i l l c o n  r m yo u r sa t i s f a c ti o n w it h th e Im m e r g a s p ro d u c t .
For assistance and routine maintenance, contact Authorised Technical Service Centres: they have original spare parts and are specically
traineddirectlyby themanufacturer.
ermal systems must undergo periodic maintenance and scheduled checks of the energy eciency in compliance with national,
regionalor localprovisionsin force.
e company IMMERGASS.p.A., with registered oce in via Cisa Ligure 95 42041 Brescello (RE), declares that the design, manufac-
turing and aer-sales assistanceprocesses complywith therequirements ofstandard UNIENISO9001:2015.
For further details on the product CE marking, request a copy of the Declaration of Conformity from the manufacturer, specifying the
appliance model andthe languageofthe country.
e manufacturer declines all liability due to printing or transcription errors, reserving the right to make any modications to its tech-
nicalandcommercial documents withoutforewarning.

5
GENERALRECOMMENDATIONS
isbook contains importantinformationforthe:
Installer(section 1);
User (section 2);
MaintenanceTechnician(section 3).
• eusermust carefully readthe instructionsin thespecic section (section2).
• eusermust limit operationsontheappliance only tothose explicitlyallowed in thespecic section.
• Every operation carried out on the heat pump (e.g. set up, inspection, installation and commissioning), must mandatorily be
performedbyauthorisedpersonnelaloneandin possession ofatechnicalengineeringorprofessionaldegreequalifyingthemto
perform these tasks. ey must also have attended a refresher course acknowledged by competent authorities. is particularly
applies to personal specialised in C.H. and air-conditioning systems and qualied electricians who, due to their specialised
training, skills and experience are experts in the correct installation and maintenance of C.H., cooling and air-conditioning
systems.
• eappliancemust beinstalled byqualied and professionallytrainedpersonnel.
• e instruction booklet is an integral and essential part of the product and must be given to the new user in the case of transfer or suc-
cession of ownership.
• Itmustbe storedwithcareandconsultedcarefully,as all ofthewarnings provide importantsafety indicationsforinstallation, useand
maintenance stages.
• In compliance with the legislation in force, the systems must be designed by qualied professionals, within the dimensional limits es-
tablished by the Law. Installation and maintenance must be performed in compliance with the regulations in force, according to the
manufacturer's instructions and by professionally qualied sta, meaning sta with specic technical skills in the plant sector, as
provided for by Law.
• Improper installation or assembly of the Immergas device and/or components, accessories, kits and devices can cause unexpected
problemsforpeople, animalsandobjects. Readtheinstructionsprovided with theproduct carefullytoensureproperinstallation.
• isinstructions manualprovidestechnical informationforinstalling Immergas products.As fortheother issuesrelated to theinstal-
lation ofproducts(e.g. safety at theworkplace,environmentalprotection,accident prevention), itisnecessary tocomplywith the pro-
visionsofthestandardsinforceand theprinciplesofgood practice.
• All Immergas productsareprotected withsuitabletransportpackaging.
• ematerialmustbe storedina dryplace protected fromtheweather.
• Damagedproductsmustnotbe installed.
• Maintenance must be carried out by skilled technical sta. For example, the Authorised Service Centre that represents a guarantee of
qualications andprofessionalism.
• eappliance mustonlybedestinedfortheuseforwhich ithas been expresslydeclared.Anyother usewillbeconsideredimproperand
thereforepotentially dangerous.
• If errors occur during installation, operation and maintenance, due to non-compliance with technical laws in force, standards or in-
structions contained in this booklet (or however supplied by the manufacturer), the manufacturer is excluded from any contractual
andextra-contractual liability foranydamages andthedevicewarranty is invalidated.
• In theeventofmalfunctions, faults orincorrectoperation,turn theappliance oandcontact anauthorised company (e.g. theAuthor-
ised TechnicalAssistance Centre, which hasspecicallytrained sta and original spare parts).Do not attempt to modify orrepair the
appliancealone.

6
SAFETYSYMBOLSUSED
GENERICHAZARD
Strictly follow all of the indications next to the pictogram. Failure to follow the indications can generate hazard situations
re su lt i ng i n p o s s i bl e h a r m to t he h e a lt h of t he o p e r ato r a nd u s e r i n ge ner a l , a n d /or pr op er t y d a m a ge .
ELECTRICALHAZARD
Strictly followalloftheindicationsnext to thepictogram. esymbolindicates theappliance’selectrical componentsor,in
this manual, identiesactions thatcan cause an electrical hazard.
WARNINGFORINSTALLER
Read the instructionbookletcarefully beforeinstalling theproduct.
LOWFLAMMABILITYMATERIAL
esymbolindicates thattheappliancecontains lowammability material.
WAR NI NGS
Strictly follow all of the indications next to the pictogram. Failure to follow the indications can generate hazard situations
re su lt i ng i n p o s s i bl e m i nor i nju r i e s t o t he he a lt h of b ot h t h e op er a t or a nd t h e u s er i n g en e r a l, a nd /or sl i g ht m at er i a l d a m a g e .
ATTENTION
Read and understand the instructions of the appliance before carrying out any operation, carefully following the instruc-
tions given. Failure to observe the instructionsmayresultin malfunctionoftheunit.
INFORMATION
Indicatesusefultipsoradditionalinformation.
EARTHTERMINALCONNECTION
esymbolidenties the appliance’searthterminalconnectionpoint.
DISPOSAL WARNING
e user must not dispose of the appliance at the end of its service life as municipal waste, but send it to appropriate
collectioncentres.
PERSONALPROTECTIVEEQUIPMENT
SAFETYGLOVES
EYEPROTECTION
SAFETYFOOTWEAR

7
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
1INSTALLINGTHEINDOORUNIT
1.1 DESCRIPTIONOFTHEPRODUCT.
Magis Combo4-6-9Plus V2is a hybrid heat pumpconsistingof:
- Magis ComboPlusV2indoorunit;
- AudaxPro 4-6-9V2outdoorcondensingunit.
Magis Combo 4-6-9 Plus V2 is perfectly operational only if the
twounits arecorrectly poweredandinterconnected.
e Magis Combo Plus V2 indoor unit was designed solely for
wallmountedinstallationforheatingand airconditioning and to
produce domestic hot water for domestic use and similar purpos-
es (ifpaired withanoutdoorstorage tank).
For normal operation is must be paired with the following out-
door units:
- AudaxPro 4V2outdoorcondensingunit;
- AudaxPro 6V2outdoorcondensingunit;
- AudaxPro 9V2outdoorcondensingunit;
Accordingly it is necessary to comply with all of the rules regard-
ing safety andthe use of bothappliances.
1.2 INSTALLATIONWARNINGS
Operatorswhoinstallandservicetheap-
pliance must wear the personal protec-
tive equipment required by applicable
law.
e place of installation of the appliance and relative
Im me r ga s ac c e ss or i e s mus t have su it a ble feat u re s (te ch-
nical and structural), such as to allow for (always in safe,
ecientandcomfortableconditions):
- installation (according to the provisions of technical
legislationandtechnical regulations);
- maintenance operations (including scheduled, peri-
odic,routineandspecial maintenance);
- removal (to outdoors in the place for loading and
transporting the appliances and components) as well
as the eventual replacement of those with appliances
and/orequivalentcomponents.
By varying the type of installation the classication of
theindoorunitalso varies, precisely:
- Type B23 o B53 indoor unit if installed using the rele-
vant terminal for air intake directly from the room in
which theboilerhas beeninstalled.
- Type Cindoorunitifinstalled using concentric pipes
orothertypesofpipesenvisionedforthesealedcham-
berboilerforintakeofair andexpulsion ofuegas.
Only a professionally enabled company is authorised to
install Immergasappliances.
e wall surface must be smooth, without any protru-
sions or recesses enabling access to the rear part. ey
are not designed to be installed on plinths or oors
(Fig. 1).
Installation must be carried out according to regulation
standards, current legislation and in compliance with
local technical regulations and the required technical
procedures.
It is forbidden to install appliances removed from other
systems.
e manufacturer declines all liability in the event of
damage caused by appliances removed from other sys-
tems or forany non-conformitieswithsuch equipment.
OK
1

8
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
e appliance operates with R32 refrig-
erantgas.
isgasisODOURLESS.
Paytheutmostattention
Strictlyfollowtheinstructionhandbook
oftheUE Audax Pro outdoor unitbefore
installationandanytypeofoperationon
thechillerline.
R32 refrigerant gas belongs to the low
ammability refrigerant category: class
A2L according to standard ISO 817. It
guarantees high performance with low
environmental impact. e new gas re-
duces the potential environmental im-
pact by one third compared to R410A,
having less eect on global warning
(GWP 675).
Check the environmental operating conditions of all
partsrelevantto installation,referring to thisbooklet.
Beforeinstallingthe appliance, ensure thatit is delivered
in perfect condition; if in doubt, contact the supplier
immediately.
Packing materials (staples, nails, plastic bags, polysty-
renefoam,etc.)constitutea hazardandmust be kept out
ofthereach of children.
If the appliance is installed inside or between cabinets,
ensure sucient space for routine servicing; for mini-
muminstallationdistances,seeFig. 3.
If installing a kitorservicing theappliance,always emp-
ty the system’s circuit rst so as not to compromise the
appliance’selectricalsafety (Parag. 2.9).
Always disconnect the appliance from voltage and, de-
pending on the type of operation, decrease the pressure
and/orbringitto zero inthegasandDHW circuits.
Keep allammableobjects awayfromtheappliance (pa-
per,rags, plastic, polystyrene,etc.).
Do not put household appliances under the indoor unit
as theycouldbe damagedifthesafetyvalve tripsorifthe
hydraulic ttings leak. Otherwise, the manufacturer
cannot be held liable for any damage to the household
appliances.
For the aforementioned reasons, we recommend not
placing furnishings, furniture, etc. under the indoor
unit.
Any modication to the appliance that is not explicitly
indicatedinthissectionofthebookletisforbidden.
In the event of malfunctions, faults or incorrect opera-
tion, turn the appliance o and contact an authorised
company (e.g. the Authorised Technical Assistance
Centre, which has specically trained sta and original
spare parts).
Donotattempttomodifyorrepairtheappliance alone.

9
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
Installationstandards
is indoor unit can be installed outdoors in a partially
protected area.
Apartially protectedareais onein whichtheindoorunit
is not exposed to the direct action of the weather (rain,
snow, hail, etc.).
is type of installation is possible when permitted by
the laws in force in the appliance's country of destina-
tion.
Installation of gas appliances, ue ex-
haust pipes and combustion air intake
pipes is forbidden in places with a re
risk (for example: garages, closed park-
ing stalls), and in potentially dangerous
places.
Do not install on the vertical projection
ofhobs.
Do not install in places/rooms that con-
stitute public areas of apartment build-
ings, internal stairways or other escape
routes (e.g. oor landings, entrance
halls,etc.).
Installation is also forbidden in places/
rooms that constitute public areas of
apartment buildings such as cellars, en-
trance halls, attics, los, etc., unless oth-
erwise provided for by local regulations
inforce.
Inany congurationdonoinstallthein-
door unit and outdoor unit at altitudes
above2000m.
To prevent electrocution, re or injury,
always switch o the unit, disable the
protective switch and, if smoke escapes
or if the unit is extremely noisy, contact
the Authorised Aer-Sales Technical
AssistanceCentre.
Pay attention not to generate sparks as
follows:
– Do not remove the fuses while the unit
ison.
– Donotunplugtheunitwhileitison.
It is recommended to install the outlet
high up. Lay the cables in such a way that
theydonotgettangled.
Wa l l mou nt i ng of t he i ndo or u n it mu st g u a r a nte e st able
andecientsupportforthegenerator.
e plugs (standard supply) are only to be used to x the indoor
unitto the wall; they onlyensureadequatesupport ifinserted cor-
rectly (according to technical standards) in walls made of solid or
semi-hollow brick or block. In the case of walls made from hollow
brick or block, partitions with limited static properties, or in any
case walls other than those indicated, a static test must be carried
outtoensureadequate mount.
is indoor unit is used to heat water to below boiling
temperaturein atmospheric pressure.

10
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
e storage tank unit must also be installed in an envi-
ronment in which the temperature cannot fall below
0°C.
“Anti-Legionella” heat treatment of the Immergas stor-
age tank (function enabled when the system is provided
with temperature control).
During this phase, the temperature of the water inside
thetankexceeds60°Cwiththesubsequentriskofburns.
Keep this domestic hot water treatment under control
(and inform the users) to prevent unforeseeable damage
topeople, animals,things.
If required install a thermostatic valve on the domestic
hotwateroutlettopreventscalding.
e appliance is built to also operate in
coolingmode.
If cold water production, during sum-
mer,couldinterfereanddamagethecen-
tral heating onlysystems, necessary pre-
cautions must be ta ken to prevent t hat a n
unintentional production of cold water
enterstheheatingonlysystem.
Failure to comply with the above implies
personal responsibility and invalidates
thewarranty.

11
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
1.3 MAIN DIMENSIONS
2
Key (Fig. 2):
V - Electric connection
G - Gassupply
LP - Chillerline - liquid phase
GP - Chillerline - gaseousphase
RU - Storage tank unit return
MU - Storagetank unitow
RR - Systemlling
SC - Condensate drain (minimum internal
diameter Ø 13mm)
R - Systemreturn
M - Systemow
Height
(mm)
Width
(mm)
Depth
(mm)
787 440 400
CONNECTIONS
LINE
CHILLERLINE GAS
DOMESTIC
HOT
WATER
SYSTEM
LP GP G RR MU - RU
SAE 1/4” SAE 5/8” 3/4” 1/2” 3/4”
1.4 MINIMUM INSTALLATIONDISTANCES
3
Key (Fig. 3):
A - 450 mm
B - 350 mm
C - 30 mm
D - 30 mm
E - 350mm

12
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
1.5 ANTIFREEZEPROTECTION
Minimumtemperature -5°C
e i ndo or u n it comes st a nda rd w it h a n a nt i-f re e z e f u nc t ion t h at
activates the outdoor unit when the temperature of the water in-
sideofitfalls below4°C.
In these conditions, the indoor unit is protected against
freezingupto anambienttemperatureof-5.
Minimumtemperature-15°C
If the indoor unit is installed in a place where the tem-
perature dropsbelow-5°C, the appliance can freeze.
Topreventthe risk offreezingfollowtheinstructionsbelow:
- protect the central heating circuit from freezing by inserting a
go od - q u a l it y a nt i f r e e z e l iq u id i nt o t h i s c i r c u it , w h i c h i s s p e c i a l-
lysuited forcentralheatingsystems andwhich ismanufacturer
guaranteed not to cause damage to the heat exchanger or other
components of the indoor unit. e antifreeze liquid must not
be harmful to one's health. e instructions of the manufactur-
er of this liquid must be strictly followed regarding the neces-
sary percentage with respect to the minimum temperature at
whichthesystemmust be kept.
- e materials used for the central heating circuit of Immergas
indoor unit resist ethylene and propylene glycol based anti-
freezeliquids (if themixturesarepreparedperfectly).
- An aqueous solution must be made with potential pollution
classof water2(EN 1717:2002or localstandardsinforce).
e excessive use of glycol could jeopardise the proper
functioningoftheappliance.
For life and possible disposal, follow the
supplier'sinstructions.
- Protect the domestic hot water circuit against freezing by using
an accessory that is supplied on request (antifreeze kit) com-
prising two electric heating elements, the relevant wiring and a
control thermostat (carefully read the installation instructions
containedintheaccessory kit pack).
In these conditions, the indoor unit is protected against
freezinguptoa temperatureof-15°C.
Indoor unit anti-freeze protection (both -5°C and -15°C) is only
ensuredif:
- indoor unit and outdoor unit are properly connected to each
otherandtotheelectrical powersupplycircuits;
- theunits arecontinuouslypowered;
- theindoorunitis notin“o” mode;
- theunits arenotin anomaly (Parag. 2.5);
- the antifreeze unit and/or kit essential components are not
faulty.
e warranty does not cover damage due to interruption of the
electrical power supply and failure to comply with that stated on
theprevious page.
If the indoor unitis installed inplaceswherethe temper-
ature drops below 0°C, the domestic hot water connec-
t io n p i p e s mu s t b e i n s u l at e d .
e water in the storage tank unit is not protected
againstfreezing whenthe indoorunit is switchedo.
eantifreeze systemsdescribedinthischapter areonly
to protect the indoor unit. e presence of these func-
tions and devices does not exclude the possibility of
parts of the circuits outside the indoor unit from freez-
ing.

13
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
1.6 INSTALLATIONINSIDETHERECESSED
FRAMEOPTIONAL
e M a g i s C om b o P l u s i nd o or u n it i s s e t- u p for i n s t a l l at ion i n s i de
thefollowing optional kits:
- SolarContainerCombo
- SuperTrioContainer
- DomusContainer Supertrio
e necessary parts for this type of installation (brackets) must
also bepurchasedseparately as optionalkit.
e images referring to the procedure are relative to the
SolarContainerCombokitbuttheillustratedprocedure
is also identical for Container Super Trio and Domus
ContainerSuperTrio.
Toinstall proceedas follows:
1. Install the bracket (2) inside the recessed frame xing it with
thescrews(3)in thepre-drilledholes(Fig. 4);
2. Hangtheindoor unit(4)fromthe bracket (2)(Fig. 5);
3. e indoor unit (4) is thus installed inside the recessed frame
(1)(Fig. 6).
1
2
3
3
4
1
2
2
4
5
1
4
6

14
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
1.7 INDOORUNITCONNECTIONUNIT
- e hyd r au l ic c onnect ion unit is standard supplie d w it h Ma g is
Combo Plus V2. Make the hydraulic connection as shown be-
low, making sure to protect the system ow and return pipes
withtheirsuppliedinsulatingsheaths.
- e R32 circuit wall connection unit is supplied as an extra kit.
Connect the circuit, following the instructions provided in the
outdoorunitinstructionsbooklet.
1.8 HYDRAULICCONNECTION
In order not to void the warranty, before making indoor
unit connections, carefully clean the heating system
(pipes,radiators,etc.)withspecialpicklingorde-scaling
products to remove any deposits that could jeopardise
proper hydronic moduleoperation.
7
1
2
3
LP GP
G
RR
SC
R
M
LP GP
GR
M
MU
RU
SC
V
RU MU
RR
8
ehydraulicconnectionkit includes(Fig. 7):
2 - Adjustableexpansion bolts
2 - indoorunit supporthooks
1 - 1/2” system llingpipe (RR)
1 - 3/4”storagetankunitowpipe (MU)
1 - 3/4”storage tankunit returnpipe (RU)
1 - 1/2”ball valve (RR)
1 - 3/4”systemreturnpipe (R)
1 - 3/4”systemow pipe (M)
1 - 3/4”ball valve(M)
3 - Insulating sheathforsystem pipes (R - M)
1 - Telescopictting3/4” (MU)
1 - x3/4”telescopictting(RU)
Gaskets, screws andsealO-Ring
e R32circuit wallconnectionkit (optional)includes:
1 - SAE1/4”liquid phase chiller linepipe (LP)
1 - SAE5/8”gaseous phasechiller line pipe(GP)
Alreadyinstalledon the module:
1 - Gascock
1 - System shut-ocock with3/4”lter(R)
Key (Fig. 8):
V - Electric connection
G - Gassupply
RU - Storage tank unit return
MU - Storagetank unitow
RR - Systemlling
SC - Condensate drain (minimum internaldiameter Ø 13mm)
R - Systemreturn
M - Systemow
LP - Chillerline - liquid phase
GP - Chillerline - gaseousphase
1 - System llingcock
2 - Systemdrainingvalve
3 - Storage tank unit bypass pipe, to be used only in case of heat
generator operating in room heatingmodeonly

15
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
3barsafetyvalve
edrain ofthesafetyvalvemust alwaysbeproperlyconveyedto a
draining funnel; consequently, in case of valve operation, the
leaked uidwillendupinthesewersystem.
Condensatedrain
Todrainthecondensate producedby the appliance,itis necessary
toconnect to thedrainagesystemby means ofacid condensate re-
si s t a nt pip e s , w it h a n i nte r na l Ø of a t l e a s t 13 m m .
esystem connecting theappliance to thedrainagesystemmust
be carriedoutinsuch a wayas topreventocclusionand freezingof
theliquidcontainedinit.
Before appliance ignition, ensure that the condensate can be cor-
rectly removed. Aer rst ignition, check that the drain trap is
lled withcondensate.
Also, comply with national and local regulations on discharging
wastewaters.
In the event condensate is not discharged into the wastewater
drainage system, a condensate neutraliser must be installed to
ensurecompliancewiththeparameters established bythelegisla-
tioninforce.
A treatment of the heating and water system water is required, in
compliance with the technical standards in force, in order to pro-
tect the system and the appliance from deposits (e.g. scale), slurry
orotherhazardousdeposits.
In ordernotto void the heat exchangerwarranty,youarerequired
tocomplywith what hasbeenprescribed (Par. 1.30).
Water connections must be made in a rational way using the cou-
plingson the indoor unittemplate.
e manufacturer declines all liability in the event of
d a m a ge c a u s e d by t he i ns t a l la t ion o f a n aut om at i c  l l i n g
system.
In order to meet the system requirements established by EN 1717
in terms of pollution of drinking water, we recommend installing
t h e I M M E RG A S a nt i-b ac k  o w k i t t o b e u s e d u ps t r e a m of t he c ol d
water inlet connection of the indoor unit. We also recommend
using category 2 heat transfer uid (ex: water+glycol) in the boil-
er'sprimarycircuit(C.H. circuit), asdened instandardEN1717.
Topreserve the durationof appliance eciency features,
in the presence of water whose features can lead to the
deposit of lime scale, installation of the “polyphosphate
dispenser” kitis recommended.
If youareusing oneor more boosterpumpsitisessential
to install a hydraulic separator (not supplied by Immer-
gas)downstreamof the indoorunit.
1.9 CONNECTINGTHECHILLERLINE
As far as connecting the cooling line is concerned, all the instruc-
tions contained in the outdoor unit instructions booklet must be
followed.
Make the connections directly on the indoor unit couplings, or
use therearoutletkit(optional).
c
c
d
2
1
a
b
a
a
a
1
1
1
9

16
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
1.10 ELECTRICALCONNECTION
Disconnect power to the indoor unit be-
foremakinganyelectricalconnection.
eappliance has anIPX4D degreeofprotection;electricalsafety
of the appliance is achieved only when it is properly connected to
an ecient earthing system, as specied by current safety stand-
ards.
e manufacturer declines any responsibility for dam-
age or physical injury caused by failure to connect the
indoor unit to an ecient earthing system or failure to
complywith the IEC referencestandards.
Connectioncablesmust respect theprearranged routes.
Use 3 clips (c) (not supplied) to group the individual cables (max.
1.5 mm2intothelowerterminal board.
Use the specic fairleads (d) on the le side, making sure to put at
most 2 multi-polar cables(max 3 x 1 mm2)in each fairlead.
e gure 9 shows cables in a hypothetical connection. To make
theconnectionsbasedonyourown requirements, seetheinstruc-
tionsbelow.
Openthecontrol panelconnectionscompartment(Fig. 9).
To carry out electrical connections, all you have to do is open the
connectionscompartment as follows.
1. Removethefront panel.
2. Disassemble thecover.
3. Loosen thescrews(a).
4. Removethecover(b)from thecontrol panel(c).
Atthis point,youcan access theterminalboard.
Also ensure that the electrical installation corresponds to maxi-
mum absorbed power specications as shown on the indoor unit
data-plate.
Indoor units are supplied complete with a “Y” type power cable
withoutplug.
e power supply cable must be connect-
ed to a 230V ±10% / 50Hz mains supply
respecting L-N polarity and earth con-
nection; this network must also have a
multi-pole circuit breaker with class III
overvoltage category in compliance with
installationregulations.
To protect from possible dispersions of
DC voltage, it is necessary to provide a
typeAdierentialsafetydevice.

17
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
If the power cable is damaged, contact a
qualied company (e.g. the Authorised
Technical Assistance Centre) for its re-
placementtoavoidahazard.
epowercablemustfollowthe prescribed route(Par. 1.8);avoid-
ing contact withthesideoftheframe.
If the fuses on the circuitboardsneedtobe replaced,thismustalso
be done by qualied personnel: use a F3.15A H250V fuse on the
P.C.B.
For the main power supply to the appliance, never use adapters,
multiplesocketsorextensionleads.
Make the various electrical connections according to your needs
(Fig. 10,11):
Connect the relative terminals 37 and 38 to electrically
connect the indoor unit and the storage tank unit, re-
moving heatingelementR8 intheinstrument(Fig. 10):
Outdoorunitelectricalconnection
e i n d o or u n i t mu s t b e c oupl e d t o a n o u td o o r u n it b y c o n ne c t i ng
terminalsF1andF2 as shown in thewiringdiagram (Fig. 11). e
outdoorunitis poweredat230 V,regardlessofthe indoorunit.
Congure the indoor unit parameters as indicated in paragraph
(Parag. 3.13).
Photovoltaic systeminstallation
Connecting the product to a photovoltaic system enhances use of
theoutdoorunitwhen the photovoltaic panelsareoperating. Car-
ryouttheconnectionasindicated(Fig. 10).
Dehumidiers
Carry out the connection as indicated (Fig. 11). To complete the
connection operations,insertthe 2-relayBoardoptional kit.
It is compulsory to set up separate lines
with dierent power supply voltages,
particularly it is essential to separate the
very low voltage connections from the
230Vones.
No product pipes must ever be used to
earth the electric system or telephone
lines.
Ensure elimination of this risk before
making the indoor unit electrical con-
nections.
e indoor unit can be electrically con-
nected to outdoor units with very low
voltagesafety circuits (SELV)

18
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
Lowvoltageelectricalconnectiondiagram.
1
23
1
1
4
5
6
10
Termina l 87
0V Close Winter
230V Open Summerwithcooling
Key (Fig. 10):
1 - Open/Close
2 - Close
3 - Open
4 - Valvewith springreturn
5 - valve with2points
6 - Auxiliaries
M10-1 - Zone1pump (optional)
M10-2 - Zone2 circulator pump (optional)
M10-3 - Zone3circulatorpump (optional)
M31-2 - Zone 2 mixingvalve(optional)
M52 - Hotcoldthree-way(optional)
S39 - Solarinlet
S41 - Outdoorunitdeactivation
A 3rd zone (mixed) can also be managed on the system by means
ofthecongurablerelayinterface kit(optional).
In this case, the zone 3 pump must be connected according to dia-
gram (M10-3).
e zone 3 dehumidier, if any, will be managed by means of the
congurable relay interface kit, which the zone 3 mixer will also
beconnectedto.

19
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
Electricalconnectiondiagram (verylowvoltage).
11
A16-1 and A16-2 dehumidiers can be connected only aer in-
stalling 2-relayboard(optional).
Remove jumper X40-1 before the electrical connection of the
ro om t he r mo s t a t z one 1.
Key (Fig. 11):
A13 - Systemmanager (optional) A16-1 - Zone 1 dehumidier (optional with dehumidier
managementboard)
A16-2 - Zone 2 dehumidier (optional - with dehumidier
managementboard)
A17-1 - Zone 1 humidity sensor(optional) A17-2 - Zone 2 humidity sensor(optional) A17-3 - Zone3humiditysensor (optional) A23 - Externalunit A30 - Dominus
A32-1 - Zone1remotepanel(optional) A32-2 - Zone2remotepanel(optional) A32-3 - Zone 3 remote panel (optional) B2 - Storage tank probe(optional) B3-2 - Zone2owprobe (optional) B3-3 - Zone3owprobe (optional) B4 - Externalprobe (optional) B13 - Central heating probe(optional) E7-2 - Mixed zone 2 safety thermostat(optional) E7-3 - Mixed zone 3 safety thermostat (optional)
R8 - Storagetankresistance S20-1 - Zone1room thermostat(optional) S20-2 - Zone2room thermostat(optional) S20-3 - Zone3room thermostat(optional) S36-1 - Zone 1 humidistat (optional) S36-2 - Zone 2 humidistat (optional) S36-3 - Zone3humidistat (optional) S44 - Heating /Coolingselector X40-1 - Zone 1 roomthermostatjumper

20
INSTALLER
USERMAINTENANCETECHNICIAN
TECHNICALDATA
1.11 ROOM CHRONOTHERMOSTATS
OPTIONAL
e indoor unit is prepared for the application of room
chrono-thermostats or remote controls, which are available as
optional kits(Fig. 12).
A maximum of 2 temperature controllers can be applied directly
totheappliance.
All Immergas chrono-thermostats are connected with 2 wires
only.
Carefully read the user and assembly instructions contained in
theaccessorykit.
Disconnect power to the unit before
makinganyelectricalconnections.
On/O Immergasdigitalchrono-thermostat.
echrono-thermostat allows:
- set two room temperature value: one for day (comfort tempera-
ture)andonefornight(reduced temperature);
- set a weekly programmewithfourdaily switch onandswitcho
times;
- selecting the required function mode from the various possible
alternatives:
• manual mode (with adjustabletemperature);
• automaticmode (withset programme);
• forced automatic operation (momentarily changing the tem-
perature of theautomaticprogram).
echrono-thermostat is powered by two1.5VLR6typealkaline
batteries.
On/O chrono-thermostatelectricalconnection(Optional).
e operations described below must be
performed aer having removed the
voltagefromtheappliance.
On/O ambient thermostat or chrono-thermostat: must be con-
nected to the 40-1 / 41 terminals, eliminating the X40-1 jumper
forzone1 and40-2/41forzone2 and40-3 / 42forzone3.
Make sure that the On/O thermostat contact is of the “clean”
type, i.e. independent of the mains voltage, otherwise the P.C.B.
would be damaged.
e connections must be made on the terminal board inside the
appliance’scontrol panel (Fig. 11).
1.12 MODBUS TEMPERATURE AND
HUMIDITYROOMPROBESOPTIONAL
e temperature and humidity probe is used to detect room hu-
midity and to calculate the relative dew point by regulating the
owtemperatureduringthecoolingphase.
Connect the appliance asshown (Fig. 11);
DIP-Switchcongurationtable
ON
123 4567 8
DIP 1-5 DIP 6-7 DIP 8
DIP1-5
(Address)
ON
123 45
Zone1
(Address
131)
ON
123 45
Zone2
(Address
132)
ON
123 45
Zone3
(Address
133)
DIP6-7
(Type)
ON
67
Modbus 1 - 8
-E-1
DIP8
(Speed)
ON
8
9600 bit/s
