CC-130 Pipe Clamp
with Baby Pin
INSTRUCTIONS

Introduction
Thank you for choosing the Impact CC-130 Pipe Clamp with Baby Pin. This
clamp features a baby (5/8 in.) pin that will accommodate an item with a
baby receiver, a long handle for extra torque when tightening the clamp,
and an included safety cable. The CC-130 is ideal for suspending a lighting
xture from an overhead pipe.
Note: When using the safety cable, thread the cable through your lighting
xture and around the pipe from which you are suspending it.
Recommended Equipment and Accessories
• ME-111 Plate Clamp
• ME-128 Right Angle Adapter
• ME-114 3 in. Center Jaw Vise Grip
• ME-108 Monitor Mount Adapter
• LSP-K10 - Pro Light Stand, 10.8 ft., Black
Visit our website at www.ImpactStudioLighting.com for more Impact
equipment and accessories.

Specications
Clamping range: 16 to 50 mm
Pin size: 5/8 in.
Maximum load capacity: 110 lb. (50 kg)
Warnings ⚠
• Please read and follow these instructions, and keep this manual in a
safe place.
• Handle the unit with care.
• Clean the unit with a soft, dry cloth.
• Keep this unit away from children.
• Make sure everything is secure before proceeding.
• Make sure the item is intact and that there are no missing parts.
• Always use the included steel safety cable when suspending a light
xture or other assembly.
• Do not exceed the maximum load capacity.
• Use caution when mounting anything at the maximum load capacity.
• All photos are for illustrative purposes only.

One-Year Limited Warranty
This IMPACT product is warranted to the original purchaser to be free from defects
in materials and workmanship under normal consumer use for a period of one (1) year
from the original purchase date or thirty (30) days af ter replacement, whichever
occurs later. The warranty provider’s responsibility with respect to this limited
warranty shall be limited solely to repair or replacement, at the provider’s discretion,
of any product that fails during normal use of this product in its intended manner and
in its intended environment. Inoperability of the product or part(s) shall be determined
by the warranty provider. If the product has been discontinued, the warranty provider
reserves the right to replace it with a model of equivalent quality and function.
This warranty does not cover damage or defect caused by misuse, neglect, accident,
alteration, abuse, improper installation or maintenance. EXCEPT AS PROVIDED
HEREIN, THE WA RR ANT Y PROVIDER MAKES NEITHER ANY E XPRESS
WARRANTIES NOR ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED
TO ANY IMPLIED WARRANT Y OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. This warranty provides you with specic legal rights, and
you may also have additional rights that vary from state to state.
To obtain warranty coverage, contact the Impact Customer Service Department to
obtain a return merchandise authorization (“RMA”) number, and return the defective
product to Impact along with the RMA number and proof of purchase. Shipment of
the defective product is at the purchaser’s own risk and expense.
For more information or to arrange service, visit www.impactstudiolighting.com or
call Customer Service at 212-594-2353.
Product warranty provided by the Gradus Group.
www.gradusgroup.com
IMPACT is a registered trademark of the Gradus Group.
© 2018 Gradus Group LLC. All Rights Reserved. GG3
