Impulse D2 User manual

OPERATORS MANUAL
IMPULSE D2D50 AUGER DRIVES

3
TABLE OF CONTENTS
01 CRITICAL INFORMATION  SERVICE INTERVALS 4
02 TO THE PURCHASER 5
03 SERVICE & PREPARATION FOR USE 6
04 SERVICE & PREPARATION FOR USE 7
05 SAFETY PRECAUTIONS  GENERAL INFORMATION 8
06 SAFETY  WORKING WITH THE ATTACHMENT 13
07 BEFORE USE 16
08 COMMISSIONING PROCEDURE 17
09 OPERATING INSTRUCTIONS  COLD WEATHER STARTUP 20
10 MAINTENANCE  OIL CHANGE 25
11 WARRANTY 29

4 5
01 CRITICAL INFORMATION  SERVICE INTERVALS
ATTENTION!
Critical – do not connect or operate your drive unit without rst having read and
understood this statement.
Your Impulse Planetary Drive Gearbox is a high performance attachment that is designed for
Drilling, Screw Anchoring (Pier) installation, Core Barreling and other extreme applications where
it is seeing high levels of torque. To avoid premature wear and failure, and to fulll your terms of
warranty please read this statement.
All IMPULSE PLANETARY DRIVES must have a first oil change within the first 30hrs (extreme use)
or 50hrs (Moderate use) or 3mths of use (which ever comes first) to ensure the bed-in of the drive
unit.
If the first oil change is not performed within this period,excessive wear within the gearbox will
occur that will cause premature failure. All warranty will be void.
Oil must then be changed thereafter every 300/500hrs and a full service every 12mths must be
performed by an authorized service agent to ensure Warranty requirements are met.
In the event of a failure under the warranty period:
•Contact NEXGEN Attachments Inc. immediately, DO-NOT DISASSEMBLE YOUR DRIVE
without first obtaining written permission and instructions from NEXGEN Attachments Inc.
•Proof of service must be provided in hard copy form of both operational and service history
(including serial number of gearbox and hydraulic motor). Service must be performed by an
authorized Impulse service agent.
02 TO THE PURCHASER
THANK YOU
Congratulations on the purchase of your new High Performance Impulse Planetary Drive. This
product was carefully designed and manufactured to give you years of dependable service. It
is mandatory that oil changes are performed at the specified intervalsto keep it in top working
condition (maintenance – chapter 10).
The complete manual must be read and understood before connecting and operating. Be sure to
observe all safety precautions and maintenance procedures as described in this manual.
Optional Extras are available for special applications or extreme conditions: these are noted
throughout the manual. Contact your Impulse dealer for any further information pertaining to
this product or for further information on other products available in the Impulse range.
ABOUT THIS MANUAL
This manual has been designed to help you do a better, safer job. Read this manual carefully and
become familiar with its contents before connecting and operating.
Remember; never let anyone operate this unit without reading the “Safety Precautions”and
“Operating Instructions”sections of this manual. Unless noted otherwise, right and left sides are
determined from the position of the machine operator when facing forward.
SAFETY ALERT SYMBOL!
This is the“Safety Alert Symbol” used by this industry. This symbol is used to warn
of possible injury. Be sure to read all warnings carefully. They are included for your
safety and for the safety of others working with you.

6 7
04 SERVICE & PREPARATION FOR USE
To avoid any inconvenience before operation, please check that you have received the
following items that you have ordered. Items may differ depending on type of machine the
drive unit is to be fitted to.
2
1
4
3
5
 Description Q-ty
1Drilling unit 1
2Hoses kit 2
3Adapter pin 1
4Auger pin 1
5Manual (hardcopy or digital)1
03 SERVICE & PREPARATION FOR USE
Your Impulse Auger Drive is a user non-serviceable part. Unauthorized disassembly will void
your warranty.
All service and warranty must be performed by an authorized Impulse service agent. Contact your
local Impulse dealer for details.
To facilitate warranty or service, record the model and serial number of your unit in the space
provided on this page. This information may be obtained from the identification plate located on
the product.
MODEL _________________________________________________________________________
SERIAL NUMBER __________________________________________________________________
DATE PURCHASED ________________________________________________________________
The parts department needs this information to ensure accurate parts can be sent
to the authorized service agent.
Drilling unit model Output shaft Auger series
D2–D5 65 mm / 2.55 in S4
D6–D10 75mm² / 0.11 in² S5
D12–D25 75mm² / 0.11in² S6
D30–D50 100 mm² / 0.15in² For D30 S6; For D50 PA/PR

8 9
05 SAFETY PRECAUTIONS  GENERAL INFORMATION
TAKE NOTE! THIS SAFETY ALERT SYMBOL FOUND THROUGHOUT THIS MANUAL IS USED TO CALL
YOUR ATTENTION TO INSTRUCTIONS INVOLVING YOUR PERSONAL SAFETY OR OTHERS. FAILURE
TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN INJURY OR DEATH.
THIS SYMBOL MEANS:
ATTENTION!
BECOME ALERT!
YOUR SAFETY IS INVOLVED!
SIGNAL WORDS: Note the use of signal words DANGER, WARNING, and CAUTION with the safety
messages. The appropriate signal word for each has been selected using the following guidelines:
DANGER: Indicates an imminently hazardous situation, which if not avoided, will result in death
or serious injury. This signal word is to be limited to the most extreme situations, typically for
machine components which, for functional purposes, cannot be guarded.
WARNING: Indicates a potentially hazardous situation, which if not avoided, could result in death
or serious injury, and includes hazards that are exposed when guards are removed. It may also be
used to alert against unsafe practices and indicate potential failure or damage to equipment.
CAUTION: Indicates a potentially hazardous situation, which if not avoided, may result in minor or
moderate injury. It may also be used to alert against unsafe practices.
This section is composed of various warnings and safety tips. Read and learn all the information in
this section before you attempt to use your attachment. Also read your machines owner’s manual
before using your equipment. This knowledge will help you operate your unit safely. Do not take
this information lightly, it is presented for your benet and for the benet of others working
around you.
The “Safety Alert Symbol” will be used throughout this manual. It will appear with the word
DANGER, WARNING, or CAUTION, and a safety message pertaining to the specic topic being
covered. Take the time to read these messages as you come across them.
EXPOSURE TO RESPIRABLE CRYSTALLINE SILICA DUST ALONG WITH OTHER
HAZARDOUS DUSTS MAY CAUSE SERIOUS OR FATAL RESPIRATORY DISEASE.
It is recommended to use dust suppression, dust collection and if necessary
personal protective equipment during the operation of any attachment that may
cause high levels of dust.
REMOVE PAINT BEFORE WELDING OR HEATING
Hazardous fumes/dust can be generated when paint is heated by welding,
soldering or using a torch. Do all work outside or in a well ventilated area and
dispose of paint and solvent properly. Remove paint before welding or heating.
When sanding or grinding paint, avoid breathing the dust. Wear an approved
respirator. If you use solvent or paint stripper, remove stripper with soap and water
before welding. Remove solvent or paint stripper containers and other flammable
material from the area. Allow fumes to disperse at least 15 minutes before
welding or heating.
END OF LIFE DISPOSAL
At the completion of the useful life of the unit, drain all fluids and dismantle by
separating the different materials (rubber, steel, plastic, etc.). Follow all federal,
state and local regulations for recycling and disposal of the fluid and components.
STORAGE OF THE PLANETARY DRIVE
•Seal hydraulic couplers from contaminants and secure all hydraulic hoses off the
ground to help prevent damage.
• Clean the unit thoroughly, removing all mud, dirt, and grease.
•Inspect for visible signs of wear, breakage, or damage. Order any parts required
and make the necessary repairs to avoid delays upon removal from storage.
• Check that the drive unit motor and hoses are full of clean oil and planetary is
full.
•Coat the output shaft and collar, extension shaft and collar,
and all connecting pins liberally with grease to prevent rust and reduce wear.
• Tighten loose nuts, capscrews and hydraulic connections.
• Replace decals that are damaged or in unreadable condition.
•Store unit in a dry and protected place. Leaving the unit outside will drastically
shorten its life.

10 11
OPERATING THE PLANETARY DRIVE
•An operator must not use drugs or alcohol, which can change his or her alertness
or coordination. An operator taking prescription or over-the-counter drugs
should seek medical advice on whether or not he or she can safely operate
equipment.
•All bystanders should be kept a minimum of 6 meters (20 feet) away from the
working area of the drive.
•Do not allow Site workers to climb or ride on a drill mast, Planetary Drive, Auger
or Auger Extension at any time, including while stationary, in operation or being
moved or rotated.
• Operate only from the operator’s station.
•
•
Avoid steep hillside operation which could cause the machine to
overturn. Consult your machines'operator’s and safety manuals for
maximum incline allowable.
Reduce speed when driving over rough terrain, on a slope, or turning, to avoid
overturning the vehicle.
•Travel only with the planetary drive in a safe transport position to prevent
uncontrolled movement. Drive slowly over rough ground and on slopes.
•Tether any auger, anchor or extensions connected to the drive with a chain if
necessary, to prevent uncontrolled swinging of the attachments when moving
from position to position.
• Do not drive close to ditches, excavations, etc., it could result in a cave in.
•Before exiting the machine, lower the attachment to the ground, apply the
parking brakes, turn off the engine, and remove the key.
•Flow and pressure gauges, fittings, and hoses must have a continuous operating
pressure rating of at least 25% higher than highest pressures of the system.
•Do not smoke when refueling the machine. Allow room in the fuel tank for
expansion. Wipe up any spilled fuel. Secure cap tightly when done.
•Remove the auger drive from the machine before transporting to and from the
job site.
•Planetary Drives shall be used only for their designed intent and shall not be
loaded beyond their rated capacity. Overloading or exceeding the manufacturers
specifications will void all warranty.
•Drill stem rotation must be stopped before adding or removing sections, or
making adjustments to the drill stem or sampling equipment.
•
•
Augers shall be cleaned only when the rotating mechanism is in neutral and the
auger stopped; long-handled shovels shall be used to move cuttings from the
auger. Materials heavier than 10kgs (22lbs) must be moved mechanically or by
using at least two people.
Drilling operations must be stopped in the event of local thunderstorms,
or lightning activity. During operation, weather conditions shall be
monitored: operations shall cease during electrical storms or when electrical
storms are imminent.
• Open bore holes must be capped and flagged.
GROUND PERSONNEL AND BYSTANDERS
•Be aware of others in the work area. Be sure others know when and where
you will be working. Make sure no one is behind equipment or within 6 metres
(20 feet) of it operating.
•Loose fitting clothing, long hair, jewelery and equipment which might become
entangled in moving equipment are prohibited while working near Auger Drills
or Anchoring equipment.
•Operators, helpers, and other personnel working near Auger Drills or Anchoring
equipment must wear steel-toe safety shoes, safety glasses, and hard hats.
Hearing protection, respirators, and personal protective clothing will be
specified in the site-specific Health and Safety Plan.
MAINTAINING THE PLANETARY DRIVE
• Before performing maintenance, lower the attachment to the ground, apply the
parking brakes, turn o the engine, and remove the key.
• Drill rigs must be shut down and properly locked-out and tagged before repairs
or maintenance is performed. Only properly trained and qualied individuals are
permitted to perform repairs and maintenance.
• Never adjust a relief valve for pressure higher than recommended by the
machine’s manufacturer.
TRANSPORTING
Follow all local government regulations that may apply along with recommended
tie down points and any equipment safety precautions at the front of
this manual when transporting your attachment.
TIE DOWN POINTS
•Tie down points are identified by tie down decals where required. Securing to
trailer at other points is unsafe and can damage the attachment.
•Do not attach tie down accessories around cylinders or in any way that may
damage hoses or hydraulic components.
•Attach tie down accessories to unit as recommended.
• Check unit stability before transporting.
Verify that all tie down accessories (chains, slings, ropes, shackles etc.) are capable
of maintaining attachment stability during transporting and are attached in such
a way to prevent unintended disengagement or shifting of the unit. Failure to do
so could result in serious personal injury or death.

12 13
TO THE OPERATOR
The primary responsibility for safety with this equipment falls to the operator. Make sure that
the equipment is operated only by trained individuals that have read and understood this
manual. Don’t hurry the learning process or take the unit for granted.
It is the skill, care, common sense, and good judgment of the operator that will determine how
efficiently and safely the job is performed. Know your equipment before you start. Know
its capabilities and how to operate all the controls.
Visually inspect your equipment before you start, ensure correct assembly and installation of the
attachment and never operate equipment that is not in proper working order.
Practice the operation of your new attachment and become familiar with the controls and the
way it handles on your machine. If there is any portion of this manual or function you do not
understand, contact your local authorized dealer or the manufacturer.
1. Never operate the attachment without first reading and understanding the entire operator’s
manual.
2. Do not paint over, remove or deface any safety signs or warning decals on your equipment.
3. Follow all safety decals. Keep them clean and replace them if they become worn, damaged or
illegible.
4. Know your equipment inside and out. Know how to operate all controls and know emergency
shut down procedures.
5. Keep all stepping surfaces, pedals, and controls free from dirt, grease and oil. Keep equipment
clean to help avoid injury from slipping or a fall when getting on or off equipment.
6. Operate the attachment only in daylight or with sufficient artificial light.
7. Always carry loads close to the ground. Do not step off the machine platform with load raised.
8. Turn off the engine before performing maintenance. All maintenance should be performed
with the machine arms lowered. If the lift arms must be left raised for any reason, use a
positive lift arm lock to secure the arms in place. Serious damage or personal injury could
result from lift arms accidentally lowering.
9. Do not exceed rated operating capacity of the host machine, as the machine may become
unstable, resulting in loss of control.
10. Always lower the loader arms or machine boom to the ground, shut off the engine and
remove the key before getting off the unit.
11. Never use the Drive Unit on a machine that is not equipped with a cab or ROPS, FOPS
and operator restraints (seat belts or equivalent devices).
06 SAFETY  WORKING WITH THE ATTACHMENT
TAKE EXTREME CARE WHEN DEALING WITH HYDRAULICS, WHILST ASSEM-
BLING, OPERATING, MAINTAINING OR PERFORMING ANY WORK ON OR NEAR
THIS PRODUCT.
•Hydraulic fluid under pressure can penetrate the skin and may develop gangrene
or other permanent disabilities. Hydraulic leaks under pressure may not be
visible!
• If any fluid penetrates the skin, SEEK IMMEDIATE MEDICAL ATTENTION!!
•Wear safety glasses, protective clothing, and use a solid piece of cardboard or
wood when searching for hydraulic leaks. DO NOT USE YOUR HANDS!
•Before connecting or disconnecting hydraulic hoses, read your machine
or power unit’s operator’s manual for detailed instructions on connecting
and disconnecting hydraulic attachments.
•Make certain that all parts meet the specifications for this product when installing
or replacing hydraulic hoses or fittings.
•After connecting hydraulic lines:
•Slowly and carefully raise the loaders arm/s and cycle the rollback / dump
cylinders to check hose clearances and to check for any interference.
•Operate the hydraulics on this product to ascertain forward and reverse.
•Make certain that the hoses cannot interfere with or actuate the quick-attach
mechanism.
•Make certain that hoses will not be pinched, or get tangled, in any equipment.
•Do not lock the auxiliary hydraulics of your power unit in the “ON” position.
•Refer to your power unit’s operator’s manual and this manual for procedures and
intervals, then inspect and maintain the entire hydraulic system to insure that
the fluid remains clean, that all devices function properly, and that there are no
fluid leaks.
WHEN MOUNTING THIS PRODUCT TO YOUR MACHINE
•Refer to the operator’s manual of your machine, and your quick-attach for
special or detailed mounting instructions.
•This product should fit onto the quick-attach Frame or Hitch (Machine Mount).
•If this product does not fit properly, contact your Impulse Dealer before operating.
•Never place any part of your body into the mounting plate, frame, hitch or loader
holes. A slight movement of the power unit and this product could cause serious
injury.
•Where‘Dead Man’connections are connected or installed it is illegal to disengage,
tamper with or remove them.

14 15
WHEN ADJUSTING, SERVICING OR REPAIRING THIS PRODUCT
•
•
Make no modifications to your Drive Unit.
When doing repairs use only authorized Impulse service agents, use only
genuine parts for the gearbox. For fasteners, hydraulic hoses, or hydraulic ttings,
use only properly rated parts.
• Replacement parts must also have safety signs attached.
The key feature of your Impulse Auger Drive is that it is low maintenance, only regular oil
changes are required. It contains no user serviceable parts, unauthorized disassembly will
void warranty. WRITTEN PERMISSION FROM NEXGEN ATTACHMENTS INC. MUST BE OBTAINED
before performing any disassembly.
SAFETY FIRST!
READ AND UNDERSTAND THE SAFETY INSTRUCTIONS BEFORE BEGINNING ANY
DRIVE UNIT MAINTENANCE.
BEFORE FIRST USE
• Inspect the attachment for shipping damage. If damage does exist, do not operate until the
damaged parts have been replaced or repaired.
BEFORE EACH USE
• Make sure that all nuts and bolts are in place and properly tightened.
• Make sure that all other fasteners are in place and are performing their specified function.
•Make sure that all hydraulic fittings are tightened and that there are no leaks in any fittings or
hoses.
•Make sure that all safety signs are in place, are clean, and are legible (SEE THE SAFETY SIGN
SECTION).
• Check for any oil leaks, wear and tear on pins, linkages, clips, bushings and hood.
• Ensure any damage or excessively worn parts are replaced.
• Always wear safety goggles or glasses when inspecting equipment.
WARNING!
If injured by ejected fluid, see a doctor at once. If your doctor is not familiar
with this type of injury, ask them to research it immediately to determine
proper treatment.
CARDBOARD
HYDRAULIC HOSE
OR FITTING
MAGNIFYING GLASS
Escaping uid under pressure can have sucient force to penetrate the skin causing serious
personal injury. Fluid escaping from a very small hole can be almost invisible. Use a piece of
cardboard or wood, rather than hands to search for suspected leaks. Keep unprotected body
parts, such as face, eyes, and arms as far away as possible from a suspected leak. Flesh injected
with hydraulic uid may develop gangrene or other permanent disabilities.

16 17
07 BEFORE USE
OPERATING PARAMETERS – HP (KW) POWER RATINGS
The hydraulic motor of your auger drive unit has a maximum power rating. Maximum Pressure &
Max Flow cannot be achieved at the same time. Ensure you know and understand the maximum
flow, pressure and power ratings of your auger drive and machine and never exceed the
maximum ratings listed below. The following chart indicatesthe maximum capacities of the
drive unit.
Drilling units D12-D50 are basically complete with PRV valve.
MAX POWER MAXIMUM
FLOW
MAXIMUM
PRESSURE
MODEL **PRV **ECV Case
Drain HP Kw LPM @ BAR/PSI BAR/PSI @ LPM
Impulse D2 Opt Opt Opt 34 25 115 130/1885 240/3480 60
Impulse D3 Opt Opt Opt 34 25 115 130/1885 60
Impulse D4 Opt Opt Opt 34 25 115 60
Impulse D5 Opt Opt Opt 34 25 115 60
Impulse D6 Opt Opt Opt 34 25 115 60
Impulse D7 Opt Opt Opt 34 25 115 60
Impulse D8 Opt Opt Opt 34 25 115 60
Impulse D10 Opt Opt Opt 34 25 115 60
Impulse D12 Opt Opt Opt 67 50 230 130
Impulse D15 Opt Opt Opt 67 50 210 145/2103 130
Impulse D20 Opt Opt Opt 67 50 230 130
Impulse D30 Opt Opt Opt 67 50 230 130
Impulse D50 Opt Opt Opt 67 50 230 130
08 COMMISSIONING PROCEDURE
WARNING!
NOTE: BEFORE THE DRIVE UNIT IS EVEN CONNECTED TO THE MACHINE ENSURE
THAT THE DRIVE IS FULL OF HYDRAULIC OIL AND THE GEARBOX IS FULL OF GEAR
OIL.
All Impulse planetary drive units are dispatched from the factory full of fluids (hydraulic and
gearbox oil) unless the drive unit is shipped by plane.
1. Once you have determined if the drive unit has gearbox oil in it or requires oil, ensure that the
correct grade and quantity of oil is used. DO NOT RUN THE DRIVE UNIT WITHOUT GEARBOX OIL.
Connect the hydraulic hoses.
WARNING!
NOTE: IF REQUIRED, ENSURE THAT THE CASE DRAIN HOSE IS CONNECTED TO THE
RESERVOIR OF THE MACHINE. IT IS IMPORTANT THAT THE PRESSURE IN THE CASE
DRAIN HOSE IS NOT READING MORE THAN 690KPA (100PSI) WHILST OPERATING
AND THAT A CONSISTENT TRICKLE OF HYDRAULIC OIL IS BEING RETURNED TO
THE EXCAVATOR RESERVOIR. INTERMITTENT AND SPURTS OF FLOW FROM THE
CASE DRAIN HOSE ARE NOT STANDARD DESIGN SYMPTOMS. PLEASE CONSULT A
IMPULSE DEALER IF THIS OCCURS.
WARNING!
NOTE: TO ENSURE THE BEST MOTOR LIFE, RUN MOTOR FOR APPROXIMATELY
ONE HOUR AT 30% OF RATED PRESSURE BEFORE APPLICATION TO FULL LOAD.
BE SURE THAT THE MOTOR AND GEARBOX ARE FULL OF FLUIDS PRIOR TO ANY
LOAD APPLICATION.
240/3480
130/1885
130/1885
130/1885
130/1885
130/1885
130/1885
130/1885
130/1885
130/1885
130/1885
240/3480
240/3480
240/3480
240/3480
240/3480
240/3480
240/3480
240/3480
240/3480
240/3480
240/3480

18 19
All D-series planetary gear drive units listed in this manual use ISO EP 320 (mineral oil) gearbox oil
for operating in tropical ambient temperatures. See maintenance section in the operators manual
on gearbox oil level checking as well as the gearbox oils recommended for cold climate
conditions. Technopark Impulse produces many drive units with many different gear set ratios
and as a result don’t list every possible gearbox option and gearbox oil quantity required. See
the maintenance section (page 48) for gearbox oil volume and checking/topping up the
gearbox oil. The gearbox oil quantity is also on the serial tag located between the ears of the
hood.
WARNING!
NOTE: WHEN PROCURING ANY HOSE ASSEMBLIES FOR USE ON YOUR IMPULSE
PLANETARY DRIVE UNIT ENSURE THAT THE MAX OPERATING PRESSURE OF THE
HOSES IS ALWAYS HIGHER THAN WHAT THE EXCAVATOR OR MACHINE (WHICH
THE PLANETARY DRIVE UNIT WILL BE USED ON) CAN PRODUCE.
INSTALLING YOUR HIGH PERFORMANCE PLANETARY DRIVE
1. Remove the shipping banding from around the attachment.
2. ENSURE YOU HAVE READ THE SERIAL TAG ON THE DRIVE UNIT TO OBTAIN THE MAX FLOW AND
PRESSURE RATINGS. Ensure your machine ow and pressure settings are aligned with the
requirements of the drive unit. NEVER EXCEED THE MAX FLOW AND PRESSURE RATINGS AS
WARRANTY WILL BE VOID.
3. Following all standard safety practices and the instructions for installing an attachment as
shown in your machine operator’s manual.
4. Lower the unit to the ground and remove any attachments from the front of the host machine.
5. Attach the quick attach mounting frame or hitch to the host machine as per the machine
manufacturers specications. Ensure the locking mechanisms on the machine are engaged &
the attachment is secure.
WARNING!
NOTE: IT IS IMPORTANT TO MAKE SURE THE LOCKING MECHANISM ON YOUR
QUICK ATTACH IS ENGAGED, THEREFORE LOCKING THE ATTACHMENT ONTO THE
MACHINE.
6. Relieve any pressure from the auxiliary hydraulic system and after making sure there is no
foreign matter on the hydraulic couplers, connect the power and return couplers to the auxiliary
hydraulic system of your machine. The list below shows the most common places to “tap” into
the hydraulic system on various types of machines.
• SKID STEER LOADERS – Auxiliary hydraulic outlets.
• BACKHOES & EXCAVATORS – Auxiliary hydraulic outlets or bucket curl cylinder circuit.
• WHEEL LOADERS – Auxiliary hydraulic outlets or bucket tilt (dump) cylinder circuit.
7. If applicable connect the case drain coupler to the case drain on your machine. If your machine
has a case tap, ensure the case tap is open. Failure to connect the case drain will severely damage
the motor and void all warranty. Case drain hose is already fitted to the units hydraulic motor
and must be unraveled. This case drain hose must return directly to the hydraulic oil
reservoir on the host machine. There can be no valving or restrictions in the line and the
hose must be minimum ½” ID. The loose end of this case drain line must have a fitting fitted to
match the fitting on the host machine.
WARNING!
WARNING: ENSURE THAT THERE ARE NO QUICK RELEASE COUPLERS IN THE CASE
DRAIN LINE OR THE T-CONNECTORS. OPERATION WITHOUT CASE DRAIN WILL
CAUSE MOTOR FAILURE
8. VARIABLE FOOT CONTROL – Excavators used to power drive units must have their auxiliary
circuit controlled with a variable foot control. This foot control gives the operator the ability to
ease the power on and off avoiding shock loading which will cause potential expensive damage
to the hydraulic motor and gearbox.
9. FILTRATION/CONTAMINATION – These units are fitted with a hydraulic motor, therefore require
the oil to be of suitable cleanliness. Ensure hoses are clear of any contamination during
connecting/disconnecting to prevent contaminants entering the hydraulic motor.
10. With the unit lying horizontally on the ground,connect the auger, screw anchor or
extension or core barrel. ENSURE THE AUGER PIN AND SAFETY CLIP ARE INSTALLED
CORRECTLY. The machine is now ready for use.
11. If auguring, check the auger teeth and pilots are not worn. Ensure all worn parts are
replaced. Worn parts will become ineffective and severely diminish the overall
performance of the planetary drive and auger.
PLEASE NOTE: ALTERING,TAMPERING OR DISMANTLING ANY PART OFTHE IMPULSE UNIT
WITHOUT WRITTEN PERMISSION FROM NEXGEN ATTACHMENTS INC. WILL VOID ANY WARRANTY.

20 21
09 OPERATING INSTRUCTIONS  COLD WEATHER STARTUP
COLD WEATHER STARTUP INFORMATION
The information that is contained on this page is an aid to the operation and maintenance of your
Impulse planetary Drive Unit in cold weather. When you operate the host machine in temperatures
from 9 °C (48 °F) to −40 °C (−40 °F) refer to the Operation and Maintenance Manual of your machine. It is
dicult to outline the operation and maintenance of a machine that is used in freezing temperatures for
a general publication.The diculty in outlining the requirements is caused by the following conditions:
• The unlimited dierences in weather conditions
• Applications and ground conditions
• And the supplies that are available in your area
In order to provide the best possible guidelines, use the information in this document and
the following criteria: varying factors, recommendations from your machinery dealer, and past
proven practices.
Hints for cold weather
Make sure that you read the information for selecting the correct oils for use in cold
weather. Refer to page 25for details. Prepare the machine for the weather conditions as
instructed in your machines operator manuals.
Procedure for startup in cold weather
• Your Impulse Planetary Drive System is designed to operate within ambient temperatures of 5°C
(41°F) and 30°C (86°F).
• For temperatures below 5°C (48°F) it is recommended to slowly start the drive under no load, at
minimum speed. This will allow warm hydraulic oil from your host machine to circulate through
the hydraulic motor of your drive and slowly bring it to the minimum recommended operating
temperature of of 5°C (48°F).
•Once the minimum temperature has been reached, it is recommended to slowly introduce load
to the output of the drive unit, which in turn will increase the internal gear oil temperature.
Note - The host machines'cooling system and the lubrication system for the engine do not lose
heat immediately upon shutdown. The transmission and the hydraulic system lose heat more
rapidly because of more exposed areas. The Planetary Gearbox & Motor cases cool rapidly, since
the cases do not operate as warm as other compartments. Therefore, after any period of down
time on the machine, ensure you achieve full operating temperature.
OPERATING PROCEDURES – AUGERING
WARNING!
YOUR IMPULSE HIGH PERFORMANCE PLANETARY DRIVE IS SPECIFICALLY DESIGNED
FOR DRILLING AND ROTATIONAL OPERATION ONLY, IT IS NOT A LIFTING DEVICE!
Intended use
This unit is designed for drilling vertical or horizontal holes or rotating piers into the ground. Use
in any other way is considered contrary to the intended use.
After all installation instructions have been completed, safety information read and understood,
and the rest of this operator’s manual has been reviewed, your Impulse Auger Drive is now ready
for use.
1. With the auger raised off the ground and the vehicle engine set at a low RPM, activate the host
machines drive control valve to determine which position the control valve lever must be in to
turn auger in a forward (clockwise) rotation. This is the “digging” position.
2. Before beginning to dig, experiment with auger speed to determine a suitable auger RPM.
Generally in light and sandy soil a high RPM is desirable. In hard, rocky, or frozen soils a slower
RPM is desirable. To increase auger RPM, increase vehicle engine RPM. To decrease auger RPM,
decrease vehicle engine RPM.
3. Raise the Auger Drive so the auger hangs vertically and the drive is clear of the cradle, then
lower the auger into the starting position.
4. Ensure the cradle on your machine is forward and not back. This will keep the Drive clear of
the cradle and allow the auger to move freely from side to side and forward and back. The
pendulum action must not be hindered,otherwise damage / bending of the shaft or auger may
occur. Lower the auger into the ground,ensuring the auger drive does not stall and remains in a
vertical position, start rotation of the auger.
5. As the auger starts to load up with soil, stop the rotation whilst still in the hole and raise the
auger vertically. Move away from the hole, rotate the auger & stop in the forward direction to
remove the soil. DO NOT rapidly engage forward/reverse action to remove soil.
WARNING!
DO NOT RAPIDLY ENGAGE FORWARD REVERSE OPERATIONTO REMOVE SOIL FROM
THE AUGER, THIS CREATES EXCESSIVE PRESSURE SPIKES WHICH WILL ADVERSELY
EFFECT PERFORMANCE AND LONGEVITY OF THE MOTOR.
6. Do not remove the auger at an angle out of the hole, as you will run the increased risk of
bending the auger or shaft.
7. If trying to remove the auger full of material and you experience strong resistance, reverse
the auger slowly whilst raising the auger vertically to assist with removal. Do not pull with the
machine as you may run the risk of shaft damage to the drive.
8. Do not flick the dirt (especially mud or clay) from the auger, as you may run the increased risk
of bending the auger shaft.
9. Keep clearing the auger hole regularly as you drill deeper. This will help prolong the life of the
auger and the wear parts.
*Note: In rock it is recommended to add a slow stream of water to help the performance and life
of the rock teeth.

22 23
Excavators – Apply the greatest amount of down force from the main boom. Be aware that the
boom moves in an arc and to maintain a vertical drilling position, you will need
to compensate for this movement by adjusting the dipper arm or moving your
machine backwards or forwards to ensure you are drilling straight. You must
take extreme care when doing this to prevent the auger or screw pile from
bending or pulling flights against the inside of the hole.
All other machines – Ensure the vertical position is maintained when drilling.
DO NOT drill with the Cradle resting against the Drive Unit –This will
damage your Drive unit & Auger
The correct drilling operation is with the Cradle positioned up and
away from the Drive Unit allowing the Drive and Auger to swing
freely left, right, forward & back.
For manoeuvring around the job site the Cradle is positioned so the
Drive unit is resting against the Cradle arm & the loader arms are not
obstructing visibility.
EXTENSIONS & TELESCOPIC AUGER EXTENSIONS – OPERATING PROCEDURE
1. Once you have obtained the maximum depth with the extension & auger you have, raise the
auger out of the hole & clear the soil from the auger. Place the auger back into the hole ensuring
the auger is bottomed out in the hole & the hub of the extension is clear & easily accessible,
remove the auger pin to disengage the auger drive from the auger.
Note - Ensure personal safety at all times, determine if access to the auger hub, once
the auger is in the hole, is safe, if not safe for persons assisting, place boards or covers
across the hole before attempting to reach across to the hub.
Install the additional extension onto the auger drive with pin & safety clip, lower the extension
& attach to the auger with second pin & safety clip. Always ensure people assisting are clear &
visible to the operator at all times.
2. Recommencedrilling. Onceyouhavereachedthemaximumdepth, raisetheauger andextension
out of the hole until the eyelets of the extension are visible & just above the hole. Slide the two
support bars through the two heavy duty eyelets or U brackets welded to the outer extension.
Then remove the pin & section of extension and place away from the hole. Then re-pin back
to the bottom section, take the weight of the rest of the extension & auger on the machine &
remove the support bars. Clear the auger & then keep repeating these steps.
3. For telescopic extensions, use the same method as above, but slide the inner extension back
into the auger & pin.
NEXGEN ATTACHMENTS INC. DOES NOT ACCEPT ANY LIABILITY FOR INJURY OR DAMAGE
RESULTING FROM THE OPERATOR USING THE EXTENSION(S) OUTSIDE THE DESIGNED OPERATING
PROCEDURE
OPERATING PROCEDURES – SCREW ANCHORING (PILE/PIER)
1. Installation is to be performed by a trained and/or certified installer.
2. Connect the manufacturer’s approved adapters to the Planetary Drive head,install the pile in
one continuous motion until the desired depth and torque is achieved.
3. Install pile/pier with a continuous motion.The rate should match the pitch on the pile. Make sure
to apply just enough downward pressure to help the advancement of the pile into the ground,
but not toomuch that you are driving or drilling the pile into the ground. Always maintain
a vertical line so that you do not bend the pile.
All 2 Stage reduction D-series Model drives (D15–D50) specified for anchoring applications must
be fitted with an ECV – Energy Contol Valve (Patented). During the screw anchoring process,
energy builds up in the pile/pier, when the operator stops installation as torque is reached,
the pile/pier temporarily ‘flicks’ back or rotates back forcing energy up the pile/pier, back up
through the gear sets and into the motor, momentarily turning the motor into a pump. The ECV
is designed to protect the motor from this action and essentially grabs the oil and gently bleeds it
back down the hydraulic lines. The sound it makes is a gentle ‘swoosh’, this is how you know the
valve is working.
Note - Inefficiencies occur with machinery that can reduce the torque output, such as heat, cold,
age of machine etc. It is therefore highly recommended that torque monitoring equipment to
keep record of the torque and pressure is installed. Contact Technopark Impulse or your local
Impulse Dealer for further information regarding torque monitoring options.
WARNING!
IT IS THE RESPONSIBILITY OF THE INSTALLER TO CORRECTLY CALCULATE,
PLAN AND EXECUTE THE INSTALLATION OF THE PIERS TO THE NOMINAL
TORQUES REQUIRED. TECHNOPARK IMPULSE DOES NOT ACCEPT ANY
LIABILITY OR CONSEQUENTIAL LOSS THAT IS INCURRED FROM INCORRECT
INSTALLATION, OVER TORQUING OR UNDER TORQUING OF PILES

24 25
OPTIONAL EXTRA – CRADLE HITCH
If you have purchased a Cradle Hitch please ensure you read and understand the following
operational procedures
AVOID PILE
INSTALLATION
WHEN HITCH IS
FULLY DOWN
AVOID PILE
INSTALLATION
WHEN HITCH IS
FULLY UP
The correct drilling
operation is with the
cradle positioned up
and away from the
drive unit.
Resting the drive unit on
the cradle will stop it from
swinging around while
manoeuvring over
uneven terrain.
The cradle allows the operator to angle
the drive up to 90 degrees for easy
connection to augers and anchors.
10 MAINTENANCE  OIL CHANGE
WARNING!
IMPORTANT: OIL CHANGE SCHEDULE.
THE GEARBOX OIL CAPACITY IS ENGRAVED ONTO THE SERIAL TAG LOCATED ON THE TOP OF
THE HOOD.
Initial (Bed-in) oil change:
• The rst oil change must be carried out within the rst 50 hours of use under MODERATE
OPERATING CONDITIONS. Thereafter, every 500 hours.
• Change the gear oil after the rst 30 hours of SEVERE OPERATING CONDITIONS*. (i.e. severe
ambient temperature conditions of +40°C or below 0°C, when augering, screw piling or core
barrelling in hard ground.) Thereafter, every 300 hours.
MODERATE OPERATING
CONDITIONS
SEVERE OPERATING
CONDITIONS*
IMPULSE
(DIRECT DRIVE
ONLY)
FIRST OIL CHANGE Within 3 months OR
initial 50 hours of use
Within the rst
30 hours of use Within the rst year
2ND OIL CHANGE
PLUS SUBSEQUENT
OIL CHANGES
After 500 hours or 12
months of use
After 300 hours of
use thereafter (Drive
requires a major
stripdown, inspection
and rebuild)
Every 3 years
thereafter
GEARBOX OIL:- ISO 320 (MINERAL OIL) AUST/UK –
Impulse D2 to Impulse D50
Oil Capacity 0.25L
(250ml)
*SEVERE OPERATING CONDITIONS:- AMBIENT TEMPERATURES BELOW 0° (32°F) & ABOVE 40°C
(104°F). WORKING IN HARD GROUND. EXTENDED AND CONTINUOUS HOURS OF OPERATION.
MINIMUM AND MAXIMUM GEAR OIL OPERATING TEMPERATURE FOR GEARBOXES
°C
0 50 100 150-50-100
120°C (248°F)(16°F) -9°C
D2 TO D50 – ISO EP320 (MINERAL OIL)
INSTRUCTIONS ON HOW TO WARM UP A DRIVE IF OPERATING BELOW 5° C CAN BE FOUND
ON PAGE 20. PLEASE READ AND UNDERSTAND THESE INSTRUCTIONS.

26 27
PROCEDURE TO CHECK THE GEARBOX OIL LEVEL
Unfortunately, there is no way to make a quick visual inspection of the gearbox oil level. The
gearbox is filled to the correct level at the factory. Unless there are clear signs of gearbox oil
leakage it should not require topping up between scheduled oil changes or services.
PROCEDURE TO DRAIN GEAR BOX OIL
The gearbox oil change interval should be carried out in accordance with the requirements set out
in the table on page 25. It is advisable to replace the output shaft seal at the rst oil change as this
is the most important oil change to prolong the life of bearings and gears. The reasoning behind
this is that whilst bedding in, gearboxes can generate ne metallic contamination. This will nd
its way to the lowest part of the gearbox and collect in the output seal thus allowing an abrasive
paste to wear the output seal and the output shaft. It is advisable that oil changes are performed
by a Impulse authorized service agent, however it is not always possible for many reasons to get
this done by a dealer however what is important is that the oil is changed at the required intervals.
REMEMBER TO CONSIDER THE ENVIRONMENT, STATE/PROVINCIAL AND
FEDERAL LAWS RELATING TO DISPOSAL OF OIL. DUMPING AND SPILLAGE OF
OIL ONTO LAND, STORM WATER OUTLETS AND WATERWAYS IS ILLEGAL. OIL
MUST BE DISPOSED OF BY PROFESSIONAL WASTE DISPOSAL OR RECYCLING
SPECIALIST.
1. Ensure that the gearbox is stable, secure,safe to work on and that the drive unit is vertical.
Also, that there is an appropriate sized drip tray to catch the drained oil.
2. Before commencing to drain any oil, check the serial tag of the unit to determine the quantity
of oil which the gearbox holds. This will indicate the quantity of oil which has to be replaced
into the gearbox and size of bucket needed to contain the oil. Remove the drain plug from the
output housing. This will allow the bulk of the gearbox oil to drain out (this will not drain the
gearbox entirely). The lower section of the output housing, below the plug will still contain
some oil.
3. To drain the remaining oil, lay the drive unit on it’s side with the bung-hole facing down.
4. Once all the oil has been drained follow the procedure on the following page to refill the oil.
PROCEDURE FOR CHANGING OR RE-FILLING GEARBOX OIL LEVEL
WARNING!
NOTE: IF YOUR UNIT IS LEAKING OIL AFTER YOU HAVE PERFORMED THE DAILY
CHECKS,CONSULT YOUR LOCAL AUTHORIZED SERVICE AGENT.
1. Lay the drive unit flat on the ground with the oil fill hole facing up. Usean 8mm Allen key
to remove the bung. To drain the oil, turn the drive until the hole is facing down. Allow to
drain until all the oil has been removed.
60º
2. Rotate the unit until the oil ll hole is sitting between 60º – 70º from horizontal.
60º
3. Once the ller hole is at approx 60º the oil should be sitting at the base of the ller hole thread.
60º
4. If the oil level is too low to reach the thread it should be topped up. Rotate the unit so the filler
hole is sitting at the top and add oil. Repeat steps 2 – 4 until you have achieved the correct level.
Note that the oil takes time to work it’s way through the gearbox. Allow time for it to settle once
it has reached the bung-hole. Then check the level again until all seepage has occurred.

28 29
GEARBOX OIL CAPACITY
DRIVE UNIT OIL CAPACITY IN LITRES RECOMMENDED OIL FOR
GEARBOX
Impulse D2 0.55 ISO EP320 Mineral
Impulse D3 0.55 ISO EP320 Mineral
Impulse D4 0.55 ISO EP320 Mineral
Impulse D5 0.55 ISO EP320 Mineral
Impulse D6 1.45 ISO EP320 Mineral
Impulse D7 1.45 ISO EP320 Mineral
Impulse D8 1.45 ISO EP320 Mineral
Impulse D10 1.45 ISO EP320 Mineral
Impulse D12 1.45 ISO EP320 Mineral
Impulse D15 2.85 ISO EP320 Mineral
Impulse D20 2.85 ISO EP320 Mineral
Impulse D25 2.85 ISO EP320 Mineral
Impulse D30 4.8 ISO EP320 Mineral
Impulse D50 4.8 ISO EP320 Mineral
WARNING!
Please Note: Oil capacity charts are estimated for a gearbox being lled the rst
time. When changing the oil, not all oil will drain out, there will always be some
resididual oil left in the gearbox. Follow the procedure to ll the gearbox, using
the oil capacity charts as a guide only.
11 WARRANTY
Impulse D-series hydraulic auger drill units are high-performance mechanisms designed for
drilling, installing screw piles (supports), coring, as well as some other extreme applications with
high torque level requirements.
NEXGEN Attachments Inc. guarantees the quality of the supplied equipment. The warranty
period is 12 months or 1000 hours of operation, starting from the date the equipment was put
into operation. The warranty covers manufacturing defects and defects in parts supplied by
NEXGEN Attachments Inc. or their authorized dealers. Responsibility for the replacement and
repair of defective parts is determined by NEXGEN Attachments Inc.
Warranty does not apply to:
1. Normal wear and tear of equipment.
2. Equipment failure caused by improper assembly, improper pre-sale preparation or improper
installation.
3. Failure in the operation of the equipment caused by a load exceeding the allowable limits by
the manufacturer
4. Hydraulic hoses or parts directly cutting the ground, such as drill blades, teeth and pilots /
bumps.
5. The cost of delivery of spare parts.
6. Indirect losses of any kind.
Also, warranty is not applicable to damage caused by excess pressure supplied by the hydraulic
system of the vehicle and / or ignoring recommendations for compliance with the
technical requirements and characteristics specified by the manufacturer in this manual.
The equipment supplied by NEXGEN Attachments Inc. should be operated in accordance
with the recommendations and within the parameters specified in the Operators Manual
All warranty claims must be made in writing within 14 days from the date of failure.
Complaints received by NEXGEN Attachments Inc. later than 14 days after the breakdown
may be invalidated.
NEXGEN Attachments Inc. is not responsible and does not reimburse any costs associated with
the work of uninvolved specialists. Only those expenses are accepted for compensation,
including for spare parts, which were authorized in writing by NEXGEN Attachments Inc.
Any delivery costs while returning the products to NEXGEN Attachments Inc. for warranty claims
or for repair are paid by the consumer, unless authorized by NEXGEN Attachments Inc. in writing.

30
NOTES

NEXGEN Attachments Inc.
[email protected]
www.nexgenattachments.ca
1-866-921-0333
