IMR EX610 User manual

R2.1
Environmental Equipment, Inc.
IMR EX610 Portable SMART Sensor Gas Detector
User Manual
Read this manual carefully before using this device.
[phone] / (800)RING-IMR • Fax: [phone]
www.imrusa.com • email: inf[email protected]om

®
Environmental Equipment, Inc.
IMR EX610 User Manual
3632 Central Ave. St. Petersburg, FL 33711 –Phone: [phone] / 800-RING-IMR –Fax: [phone] –E-mail: [e-mail] –Web: www.imrusa.com
THE PRIDE OF THE COMPANY –MADE IN THE USA
Page 2of 27
Table of Contents
Table of Contents.................................................................................................................................................... 2
Safety Information.................................................................................................................................................. 4
1. Brief Introduction ............................................................................................................................................ 5
2. Main Function and Specification..................................................................................................................... 5
2.1 Main Function and Features..................................................................................................................... 5
2.2 Technical Specification............................................................................................................................ 6
3. Configuration and function.............................................................................................................................. 7
3.1 Appearance............................................................................................................................................... 7
3.2 Display information.................................................................................................................................. 8
3.3 Buttons ..................................................................................................................................................... 9
4. Operation ....................................................................................................................................................... 10
4.1 Power on................................................................................................................................................. 10
4.2 Power off................................................................................................................................................ 11
4.3 Bump Test.............................................................................................................................................. 12
4.4 Settings Menu......................................................................................................................................... 12
4.5 Alarm information.................................................................................................................................. 14
4.6 Status Checking...................................................................................................................................... 15
4.7 Zero Point Adjustment........................................................................................................................... 16
4.8 Calibration and alarm adjustment .......................................................................................................... 16
4.8.1 Calibration and Alarm Levels......................................................................................................... 16
4.8.2 Warming Up.................................................................................................................................... 17
4.8.3 Zero Point Calibration..................................................................................................................... 17
4.8.4 SPAN Calibration Setup................................................................................................................. 18
4.8.5 SPAN Calibration ........................................................................................................................... 18
4.8.6 Low Alarm Level Setting (L-Alarm).............................................................................................. 19
4.8.7 High Alarm Level Setting (H-Alarm)............................................................................................. 19
5. Data Uploading (If Equipped)....................................................................................................................... 20
6. Using and Replacement of sensors................................................................................................................ 20
7. Trouble Shooting Guidance........................................................................................................................... 20

®
Environmental Equipment, Inc.
IMR EX610 User Manual
3632 Central Ave. St. Petersburg, FL 33711 –Phone: [phone] / 800-RING-IMR –Fax: [phone] –E-mail: [e-mail] –Web: www.imrusa.com
THE PRIDE OF THE COMPANY –MADE IN THE USA
Page 3of 27
8. WARNINGS.................................................................................................................................................. 21
9. Chart 1 - Gas List........................................................................................................................................... 22
10. WARRANTY ............................................................................................................................................ 23
11. Contact Information................................................................................................................................... 24

®
Environmental Equipment, Inc.
IMR EX610 User Manual
3632 Central Ave. St. Petersburg, FL 33711 –Phone: [phone] / 800-RING-IMR –Fax: [phone] –E-mail: [e-mail] –Web: www.imrusa.com
THE PRIDE OF THE COMPANY –MADE IN THE USA
Page 4of 27
Safety Information
Please read the following information before using the detector:
Do not use a damaged gas detector. Before using the detector. Check for cracks or missing parts. If the
detector is damaged or incomplete, please contact IMR.
It is highly recommend to do a "bump test" to ensure proper performance of the detector (refer to section
4.3 for more information). Calibrate the device if the test value is beyond detection range (refer to
section 4.8 for more information).
Do "bump tests" periodically to confirm sensor is responding to gas. Verify that the audio, visual, and
vibration alarms are working properly during the test.
Use only accessories specially designed for EX610 or accessories approved by IMR.
Use only the charger supplied with the detector. Do not charge the detector in hazardous area.
Detectors with catalytic or semiconductor sensor: Exposing the sensor to gas concentrations beyond its
detection range for a prolonged period of time can adversely affect the cell and possibly lead to damage.
Detectors with catalytic or semiconductor sensor: Will be damaged if exposed to environments
containing: lean chromate, sulfur compounds, phosphorus compounds, or silicon. Do not use the
detector in these environments.
Do not expose the device to environments that consist of hydrogen sulfide, halogenated hydrocarbon, or
highly corrosive gases for extended periods of time. Doing so will reduce the response of the sensor and
there for its accuracy. If the device needs to be used in environments preform a Bump Test before and
after to ensure functionality of the sensors (see section 4.3).
Do not expose the device to environments that have the potential for electric shock, strong magnetic
fields, or intense continuous mechanic vibration.
This device uses a lithium-ion battery. Follow all local environmental and governmental regulations
when disposing of the battery.
Any unauthorized disassembly, modification or repair of the gas detector will void the warranty.
Avoid dropping the detector from high elevations or exposing it to extreme vibrations.
For any issues not covered in this manual. Contact IMR for more information.

®
Environmental Equipment, Inc.
IMR EX610 User Manual
3632 Central Ave. St. Petersburg, FL 33711 –Phone: [phone] / 800-RING-IMR –Fax: [phone] –E-mail: [e-mail] –Web: www.imrusa.com
THE PRIDE OF THE COMPANY –MADE IN THE USA
Page 5of 27
1. Brief Introduction
IMR EX610 portable single gas detector is an intrinsically safe instrument which continuously detects
combustible and toxic gases. It is suitable for combustible and toxic gas leakage detection in underground pipes
or mines. It keeps workers safe and helps prevent facilities from being damaged.
The detector uses high-quality sensors and detects gases via the natural diffusion method. It also has high
sensitivity and repeatability. The detector uses an embedded MCU controller making it easy to operate.
The shell uses special high strength material and anti-slip rubber. It is also water-proof and dust-proof.
2. Main Function and Specification
2.1 Main Function and Features
Advanced 16-digit MCU controller with low power consumption
Wide view LCD screen
Adjustable high alarm and low alarm setting
Adjustable calibrating level for easy calibration
Devices with LEL range have a high-concentration protection function
Self-tests combustible gas sensors
Low-voltage alert
Real time clock display
Smart Sensor module design for easy maintenance and replacement
Self-adjustment function to reduce detection errors
Audio, visual, and vibration alarms
Upload data to a PC
STEL and TWA alarming for toxic gases
Self-test at power on with advanced fault diagnosis and auto reset
Password management to avoid improper operation or configuration
Intrinsically safe design

®
Environmental Equipment, Inc.
IMR EX610 User Manual
3632 Central Ave. St. Petersburg, FL 33711 –Phone: [phone] / 800-RING-IMR –Fax: [phone] –E-mail: [e-mail] –Web: www.imrusa.com
THE PRIDE OF THE COMPANY –MADE IN THE USA
Page 6of 27
2.2 Technical Specification
Ranges: See attached table 1.
Gases Detected: combustible gas, toxic gas, oxygen
Response time:
oSemiconductor, Catalytic, Thermal conductivity t90<30s
oOxygen, Carbon monoxide, hydrogen sulfide t90<30s
Indication method:
oLCD displays the real time data and status
oAlarm method: Audio, video and vibration alarm
Working Temperature:
oCombustible Gas: -40℃～70℃
oToxic Gas -20℃～50℃
Working humidity:≤95%RH no condensation
Power source: DC3.7V (Lithium battery 1800mAh)
Charging time: 4～6 hours
Continuous working time:
o≥8 hours (for combustible gas)
o≥300 hours (for toxic gas under temperature of 20℃)
Protection Grade: IP66
Weight: about. 191g (with battery)
Dimensions: 108.4mm×61mm×36mm (L × W × H)

®
Environmental Equipment, Inc.
IMR EX610 User Manual
3632 Central Ave. St. Petersburg, FL 33711 –Phone: [phone] / 800-RING-IMR –Fax: [phone] –E-mail: [e-mail] –Web: www.imrusa.com
THE PRIDE OF THE COMPANY –MADE IN THE USA
Page 7of 27
3. Configuration and function
3.1 Appearance
#
Description
1
Alarm light
2
LCD Screen
3
Buzzer port
4
Sensor Port
5
Button
6
Buckle

®
Environmental Equipment, Inc.
IMR EX610 User Manual
3632 Central Ave. St. Petersburg, FL 33711 –Phone: [phone] / 800-RING-IMR –Fax: [phone] –E-mail: [e-mail] –Web: www.imrusa.com
THE PRIDE OF THE COMPANY –MADE IN THE USA
Page 8of 27
3.2 Display information
#
Function
1
Battery Status
2
Lock on or Password
3
Buzzer Status
4
Vibration Status
5
Alarm Information
6
Warning or Max Value
7
Gas Concentration
8
Error
9
Record
10
Clock Icon
11
Zero Calibration
12
Calibration Point or Calibration Status
13
Communication icon ①
14
Data Setting
15
Engineering Unit
Note: ①only appears when the device is uploading data.

®
Environmental Equipment, Inc.
IMR EX610 User Manual
3632 Central Ave. St. Petersburg, FL 33711 –Phone: [phone] / 800-RING-IMR –Fax: [phone] –E-mail: [e-mail] –Web: www.imrusa.com
THE PRIDE OF THE COMPANY –MADE IN THE USA
Page 9of 27
3.3 Buttons
Button
Function
Press and hold for more than 3 seconds to turn on the device.
Press to cancel configuration setting.
When powered off. Press and for more than 5 seconds to calibrating the device.
Hold for a few seconds to turn off the device.
Press to adjust a value
Press to enter the setup menu for the selected item
Press and for more than 3 seconds to access the configuration menu.
Press and to review temperature, time, STEL , TWA①and Max Value ②
Press to check setup
Press to save a setting.
If the alarm is active. Press to cancel an audible alarm and vibration.
Notice:①Only available for toxic gas detector
②Oxygen has Max/Min exposer value

®
Environmental Equipment, Inc.
IMR EX610 User Manual
3632 Central Ave. St. Petersburg, FL 33711 –Phone: [phone] / 800-RING-IMR –Fax: [phone] –E-mail: [e-mail] –Web: www.imrusa.com
THE PRIDE OF THE COMPANY –MADE IN THE USA
Page 10 of 27
4. Operation
4.1 Power on
With the device powered off. Hold for more than 3 seconds and the device will start up. The device then
starts a self-test as follows:
1. All the data and figures displayed; back light on
2. Buzzer sounds
3. All alarm functions
4. Version number displayed
5. Date & Time display
Year Date Time
6. Gas type
7. L-alarm and H-alarm
L-alarm H-alarm

®
Environmental Equipment, Inc.
IMR EX610 User Manual
3632 Central Ave. St. Petersburg, FL 33711 –Phone: [phone] / 800-RING-IMR –Fax: [phone] –E-mail: [e-mail] –Web: www.imrusa.com
THE PRIDE OF THE COMPANY –MADE IN THE USA
Page 11 of 27
8. Display STEL and TWA levels:
STEL TWA
Note: Only available for Toxic gas.
9. Self-test pass
After the self-test; the device starts a short warm-up countdown (3-30 seconds). After the warm-up; the screen
below is display indicating the device has finished startup.
Note: If the self-test fails, it will display error information. Refer to "Time fault alarm" and "Storage fault
alarm" in section 4.5. If self-test passed without error then the detector will automatically select a warm up time
from 3s~30s based on the sensor.
4.2 Power off
With the device powered on. When the device is not in detection mode, hold and the screen displays the
following:

®
Environmental Equipment, Inc.
IMR EX610 User Manual
3632 Central Ave. St. Petersburg, FL 33711 –Phone: [phone] / 800-RING-IMR –Fax: [phone] –E-mail: [e-mail] –Web: www.imrusa.com
THE PRIDE OF THE COMPANY –MADE IN THE USA
Page 12 of 27
The buzzer will beep. After 3 seconds. When the screen displays the following release and the detector will
turn off.
Note: When the device is not in the detection interface. Press again and again until the device exits to the
detection interface.
4.3 Bump Test
Perform a “Bump Test” before use each day to ensure that the detector is functioning properly.
Method: After powering on the device. Expose the device to gas with a concentration that is higher than the H-
alarm level with standard test gas. If the device is working normally then the device can be used. If the response
on the screen is beyond the error range refer to section 4.8 to re-calibrate the device. If the device does not
respond or displays unexpected output, contact IMR.
4.4 Settings Menu
This menu includes the following:
Zero translation
Date and time
Vibration on / off
Keytone on/off
Communication mode①
Password
Note: ①only available when the purchased instrument is supplied with USB communication cable.

®
Environmental Equipment, Inc.
IMR EX610 User Manual
3632 Central Ave. St. Petersburg, FL 33711 –Phone: [phone] / 800-RING-IMR –Fax: [phone] –E-mail: [e-mail] –Web: www.imrusa.com
THE PRIDE OF THE COMPANY –MADE IN THE USA
Page 13 of 27
In normal detection mode press both and the screen displays the following. After 1 second it will enter
the settings menu.
Use to navigate between selections. Use to enter the current selection. The following covers what each
menu contains.
Display
Function
Sets a new zero point
Sets date and time
Toggles the buzzer on / off
Toggles vibration on / off
①
Starts communication mode with a PC①
Change the password (initial passwords is 0000)
Note: ①only available when the purchased instrument is supplied with USB communication cable.

®
Environmental Equipment, Inc.
IMR EX610 User Manual
3632 Central Ave. St. Petersburg, FL 33711 –Phone: [phone] / 800-RING-IMR –Fax: [phone] –E-mail: [e-mail] –Web: www.imrusa.com
THE PRIDE OF THE COMPANY –MADE IN THE USA
Page 14 of 27
Press to change the currently selected item. Press to confirm the changes or press to exit the
selected item without saving the change. Below is a description the items
Display
Description
Turns off the function
Turns on the function
4.5 Alarm information
Alarm Type
Display
L-alarm:
Slow and hi alarm sound
Flickering alarm lights
Vibration ①
H-alarm:
Fast and hi alarm sound
Flickering alarm lights
Vibration ①
High concentration protection: ②
Slow and hi alarm sound
Flickering alarm light
Sensor fault alert:
Fast and hi alarm sound
STEL Alert:
Slow and hi alarm sound
Flickering alarm lights
Vibration ①

®
Environmental Equipment, Inc.
IMR EX610 User Manual
3632 Central Ave. St. Petersburg, FL 33711 –Phone: [phone] / 800-RING-IMR –Fax: [phone] –E-mail: [e-mail] –Web: www.imrusa.com
THE PRIDE OF THE COMPANY –MADE IN THE USA
Page 15 of 27
TWA Alert：
Slow and hi alarm sound
Flickering alarm lights
Vibration ①
Over range Alert:
Slow and hi alarm sound
Alarm LED flickering
Time fault:
The device will attempt to solve this problem automatically. If successful the device
will enter into the time setting after power on. The time can then be set.
If the device is unable to resolve the issue it will power off. Contact IMR.
Storage fault:
The device will attempt to solve this problem automatically. If successful the device
will enter into the calibration mode after power on. Refer to section 4.7 for the
procedure. If failed, the device will turn off automatically.
If the device is unable to resolve the issue it will power off. Contact IMR.
Low voltage alert:
Hi alarm sound once every 1 minute.
With very low-voltage the device can work for up to 15 minutes. Charge the
device in a non-hazardous area. Otherwise, it will turn off automatically.
Note: ①Only available when vibration function is on.
②Only available for Combustible Gas detector.
When the alarm is continuously sounding press to stop audio alarm, and vibration. The and icon
on the screen will flicker indicating that the alarm status is currently suppressed.
4.6 Status Checking
In detection mode press the device will then cycle through temperature, time, Max. Value, Min Value②,
STEL Value①, TWA Value②, etc.
Note: ①Only available for toxic gas detector
②Only available for Oxygen detector

®
Environmental Equipment, Inc.
IMR EX610 User Manual
3632 Central Ave. St. Petersburg, FL 33711 –Phone: [phone] / 800-RING-IMR –Fax: [phone] –E-mail: [e-mail] –Web: www.imrusa.com
THE PRIDE OF THE COMPANY –MADE IN THE USA
Page 16 of 27
4.7 Zero Point Adjustment
If the device in the clean air and is not zeroing then follow the steps below to adjust the zero point.
In detection mode hold both and for more than 1 second until the configuration screen is displayed.
Status
Display
When holding both and the display will show this screen. After 1 second it
will then enter the configuration menu.
Once this screen is seen the configuration menu has been accessed. Press cycle
through the available options.
When the zero point is being set this screen will be displayed. The Zero calibration
process will complete in 5s and then it will return to detection mode.
Note: Zero Point Adjustment must be done in the clean air. Otherwise the accuracy will be affected.
Oxygen detectors use a concentration of 20.9％VOL in fresh air for the above process.
4.8 Calibration and alarm adjustment
If the detector needs to be re-calibrated or the alarm level adjusted follow the below steps.
4.8.1 Calibration and Alarm Levels
With the device powered off hold both and for 3 seconds. The detector then self-tests then after a short
delay it will require the password. The following will be displayed:
Input the password to enter into calibration mode.
Note: Improper configuration of the settings in this menu can endanger the end user; take extreme care with the
information entered. The detector will power off automatically if there is no input within 5s after accessing the
password menu or the input password is incorrect. If the password is lost or forgotten contact IMR.

®
Environmental Equipment, Inc.
IMR EX610 User Manual
3632 Central Ave. St. Petersburg, FL 33711 –Phone: [phone] / 800-RING-IMR –Fax: [phone] –E-mail: [e-mail] –Web: www.imrusa.com
THE PRIDE OF THE COMPANY –MADE IN THE USA
Page 17 of 27
4.8.2 Warming Up
After inputting the password the device will start a countdown to warm up the gas sensor. The countdown time
will be different depending on the sensor (30s～90s).
Note: During this countdown can be pressed to skip the calibration procedure and enter into the Alarm
Level Setting (see sections 4.8.6, 4.8.7).
4.8.3 Zero Point Calibration
The detector will now display the current output form the sensor. A screen similar to below will be shown.
If there is no input within 1 minute the last displayed value will be set as the zero point. Next the device enters
into SPAN Calibration mode.
During this mode if is pressed the AD value will be displayed. Then can be pressed to return to the
display of the current gas concentration.
Note: During this countdown can be pressed to skip the calibration procedure and enter into the Alarm
Level Setting (see sections 4.8.6, 4.8.7).
Warning: This operation should be carried out in clean air.
Failure to do so will affect the accuracy of the detector. When advancing to the next mode an Ewill be
displayed if the air is not clean or the sensor is damaged. Move to another location for adjustment or replace the
sensor as needed.

®
Environmental Equipment, Inc.
IMR EX610 User Manual
3632 Central Ave. St. Petersburg, FL 33711 –Phone: [phone] / 800-RING-IMR –Fax: [phone] –E-mail: [e-mail] –Web: www.imrusa.com
THE PRIDE OF THE COMPANY –MADE IN THE USA
Page 18 of 27
4.8.4 SPAN Calibration Setup
In this mode the screen will display a set of flickering figures. Press or to modify these figures.
Then the Standard sample gas concentration recommended to calibrate the detector will be shown. See the
image below:
If there is no input is made within 10 minutes the detector will then display a Calibration Error and advance to
the Alarm Level Setting mode (see section 4.8.6 and 4.8.7).
If gas input is applied within 10 minutes the detector will use the figure shown on the display as the
concentration of the calibration gas. It will then enter into the SPAN Calibration mode.
Note: See Chart 1 in section 9 for the available adjustable range of the calibration gas concentration.
4.8.5 SPAN Calibration
The detector will display the currently detected concentration of gas from the sensor. See the image below:
Next fit the calibration cover to the detector and apply the calibration gas. If the calibration gas is detected
within 30 seconds the detector will start the automatic calibration process. The detector will make automatic
adjustments until it reached the optimal calibration point. It then saves this information and exits sensor
calibration.
Next the detector advances to L-alarm setup.
Note: In this mode avoid touching any buttons. Failure to do so will affect the accuracy of the detector.
If half of the SPAN calibration point is not reached within 30 seconds or the gas concentration is beyond the
maximum range of the sensor. An Eicon will be displayed. This indicates that the test gas is unusable for
calibration of this sensor or that the sensor is defective. Replace the gas or gas sensor.
O2 calibration will skip step 4.8.3. and 4.8.4.

®
Environmental Equipment, Inc.
IMR EX610 User Manual
3632 Central Ave. St. Petersburg, FL 33711 –Phone: [phone] / 800-RING-IMR –Fax: [phone] –E-mail: [e-mail] –Web: www.imrusa.com
THE PRIDE OF THE COMPANY –MADE IN THE USA
Page 19 of 27
4.8.6 Low Alarm Level Setting (L-Alarm)
In this mode the L-alarm level can be adjusted. The display will show the following flickering figure.
Press or to adjust the flickering figure as needed. Then press to save the figure and complete the
set up. The detector then advances to H-alarm set up.
If you don’t need to adjust the setting press to skip the L-Alarm setting and enter into H-Alarm setting.
4.8.7 High Alarm Level Setting (H-Alarm)
In this mode the H-alarm level can be adjusted. The display will show the following flickering figure.
Press or to adjust the flickering figure as needed. Then press to save the figure and complete the
set up. The device will then power off automatically.
Note: For the available ranges of the alarm settings see Chart 1 in section 9.

®
Environmental Equipment, Inc.
IMR EX610 User Manual
3632 Central Ave. St. Petersburg, FL 33711 –Phone: [phone] / 800-RING-IMR –Fax: [phone] –E-mail: [e-mail] –Web: www.imrusa.com
THE PRIDE OF THE COMPANY –MADE IN THE USA
Page 20 of 27
5. Data Uploading (If Equipped)
Connect the detector to a PC with a USB cable. Then open the data software.
Note: This function will be available only if the product that was purchased is capable of communication with a
PC.
6. Using and Replacement of sensors
It is important to be aware of the life span of equipped sensors. When they are beyond their expected life they
should be replaced. Approximately every half year calibration should be checked for accuracy in order to ensure
safety of the end user.
Sensor replacement should only be done by IMR or an authorized repair center. Only authorized parts should be
used. Contact IMR if any additional information is needed.
7. Trouble Shooting Guidance
Trouble
Possible Reasons
Solutions
Unable to turn on the detector
Battery voltage is low
Charge the detector
Detector is defective
Contact the IMR
PCB fault
Contact the IMR
No response to gas
Warm up has not finished
Wait longer for it to finish
PCB fault
Contact the IMR
Gas response inaccurate
Sensor replacement overdue
Replace the sensor
Calibration overdue
Calibrate the detector
Date/Time is incorrect
Battery needs replacement
Replace battery and set
date/time
Electromagnetic interference
Set the date/time
Unable to set a new Zero calibration
Excessive sensor drift
Calibrate or replace the sensor
Display shows “-0”
Excessive sensor drift
Calibrate or replace the sensor
If the display shows
Sensor fault
Replace the sensor
