IMRELAX IM-WL6403 User manual

LED BAR
64pcs 1.5W RGB 3-in-1 LED
er1.0

1
Table of contents
1. Preface ················································································ 2
1.1 Packing list····················································· 2
1.2 Unpacking instructions································ 2
1.3 AC Power······················································ 2
1.4 Safety instructions·························································· 2
2. Introduction··········································································3
2.1 Features ························································ 3
2.2 quick start ·················································· 4
3. Setup ····················································································· 5
3.1 Fixture linking·············································· 4
Data connect ················································ 5
Cable wire sadapter ··········································· 5
3.2 Setting up aDMX serial data link···································· 5
3.3 Setup················································································· 6
4. Operating instructions ·························································6
4.1 Menu configure ··············································· 6
4.2Menu structure and comments ························ 6
4.3 User configurations······································· 8
4.4 DMX channel values······································ 8
5. Technical specifications······················································· 9

2
1. Preface
1.1 Packing list
Product name quantity
LED Par Light 1 pc
Power -cable 1 base
User manual 1 pc
1.2 Unpacking instructions
When you getthis product, please takeit from carton carefully tomakesurewhether all the
accessoriesareinand damagedor not.When you find thatthereareanypartsor wrong sign
with thecarton, or non-operation, please inform us and tokeep thecarton and shippingbill
completely.
1.3 AC Power
Please check the manual book beforeyou operatethe light. Therating currentofthe light
listedwhich shows the average current-consume under the normal circumstances.
All thelightsmustbe offeredshoot-through circuit, it couldntbeconnecteddimmer circuit,
although the dimmer channelsare completely for 1-100% switch.
1.4 Safety instructions
Before thelight s working, please confirm the correct voltage.
Please confirm there is no flammable material around the light.
The lightmustbe setup theventilating place. The distance is 51cm around approach
material. To checkthe air passage is ok atany time.
The Maximum temperature is ≤40℃(104℉).
When the lightshasproblems, please stoptousetoseektheprofessionalcounseling or
manufacturer.
Please turn off the power before maintenance, modification is prohibited.
Don tlook thebulbfor along time,so asnottoaffectvision when thelightisworking to
avoid any hurt.
2. Introduction
2.1 Features
*Voltage: AC100/240V, 50/60Hz
*Power consumption:117w
*Light source: 64*1.5W RGB 3 IN 1 LED
*Color mixing:RGB
*Beam angle:45 degree
*Strobe:0-16Hz, from slow to fast, adjusting

3
*Electronicdimmer from 0 to 100%
*Control mode: Auto, Sound ,DMX512
*DMXchannels:2/3/4/7/14/26
*LED digital display
*Data out/in:3 pin XLR-connection sockets
*Size:1050*75*120mm
*Net weight:3.5kg
2.2 quick start
ØOperatingmode switch and Settings
nThe main menu, the display ofeach menu item, are "external controlmode"
uDefault is "DMX512console control", only toreceivestandardDMX512 signal, 1
decimalpointwill shine. Otherwise please checkwhether itisrighttoconnect to
the console
lIf you wanttomodifythe DMX address code, please press "MENU"button
untilyou see continuous "dxxx", press "UP" and"DOWN" toadjustaddress
code, press "ENTER"key to save
lIf you wanttoselect DMX channel mode, please continuous press "MENU"
button untilyou seethe"SET", press "ENTER"button toENTERsubmenu
"ChNd" to choose from 11 ch / 5 ch
lTherearefivekindsofadjustable speedoflight(decidedtomovelightsoft
degrees) tochoose from (" SET "menu"LinE "andconsole mode under 11
channels)
uIf you wanttouse"master-slavemachine control", please setalampsand
lanterns tothe model, and the other without anysetoflampsandlanterns, will
automatically identifythe hostsignal source, the lampsandlanterns showfrom
the machine will automatically jump "dxxx" menu,the decimal point 1 will shine
uMustensurethatthe one andonly onecontrol source (a hostor acontrol table) :
if therearemultiplesignal sourcein thesame line, thesignal will disturb each
other, result in unable to correctly receive datafrom the machine
n"Static model", please enter the RGBW menu (to be automatic intothe host state)
n"The pattern" enter "CCxx/CPxx/DExx" menu (to be automatic intothe host state)
n"Acousticmodel", please enter the SoUd menu (to be automatic intothe host state)
3. Setup
3.1 Fixture linking
When you control the light smaster/slaveor DMX 512 signal agreement, thelightscan be
connected bysignal wirewhich the distance is ≤500m,The maximum connect lightsare32pcs
moreor less, and adaptDMX lightpairtosegregatethesignal zoomequipment, in order to
protect thelight ssignal won tbe interruptedbyother signal. Moreover,it wontaffectbythe
signal wire s length
Data connect
Datacable is connectedbyDMX datawire, and XLR.Please use hi-qualitydatacable signal wire,

4
it won t be interrupted by magnetic.
Cable wire sadapter:
The twosidesofsignal cablewireis consistedof1pair female and male 3XLR plug,which is
correspond the lights or DMX controller,
3.2 Setting up aDMX signal connect
As following picturesshow,please connect the firstlighttothe signalcable which is with XLR
by DMX controller, then, connectlightin series.
3.3 Setup
The lightmustbesetuptheventilatingplace. Toconfirmthereis nothing tohinder theheat
dissipation place. When the light is hanged, please choose a safety wire.
4. Operating instructions
4.1 Menu configure
Thereare4buttons locatedin the bottomofthe LED digital displaywhen you check themenu
configure of the bottom of light. Show as follow:
Note: Please choose ”ENTER”return tothe mainmenu tosavethe address code or mode
after you setup. When thelightislighting,thedisplayoftheaddress code or mode is same
as the lasttime when you operated.
4.2 Menu structure and comments
Addr A001-A512 512 address setting
CHnd
3CH 3 channel setting
7CH 7 channel setting
24CH 24channelsetting
28CH 28channelsetting
SLnd
Auto masterauto
Soun mastersound model
SL1 DMX
SL2 Slave
SH** 0-15
masterselectofauto
recommend channel 15）
SP** 0-100 Speed of auto
MENU UP DOWN ENTER

5
SN** 0-100 Sound sensitivity
r*** 0-255 red dimming
G*** 0-255 green dimming
b*** 0-255 blue dimming
LEd OFF
After 5seconds the screen
isoff
ON Thescreen is always open
4.3 User configurations
Set-up 1pcs light`s menu mode (Auto-running)
.Press the MENU, such as thepicture 4.2 shows the menu function
.Use theUP/DOWN buttons tochoose the right one to confirm.
To set Master-slave mode
.Press the MENU, same as picture 4.2 shows the menu function
Master: Set any one of lightsto auto、sound or strobe control mode
Slave: Setthem to DMX mode and their address code to1.
Notes：Each Master-slavegroup can be one and only lightin master,ensurelightsunder this
group without connection with any DMX controller.
To set DMX mode
The lightcan connect tothe DMX controller toreceiveitssignal indication, which control by
DMX controller. DMX valueis referenced by“4.4 DMX channel values”.
4.4 DMX channel values
DMX channels
2channels
functions specification
1 nofunction 0-8
auto 9-127 Recommendeffect15 121-127））
sound 128-255 Recommendeffect15 247-255））
2 speed/sensitivity 0-255
Button Function
<ENTER> Each operation to be confirmed
<DOWN-<UP> Down-Up
<MENU> menu option

6
3channels
functions specification
1 red brightnessadjust 0-255
2 green brightness adjust 0-255
3 blue brightness adjust0-255
4channels
functions specification
1 general brightnessadjust 0-255
2 strobe0-255
3 nofunction 0-8
auto 9-127 Recommendeffect15 121-127））
sound 128-255 Recommendeffect15 247-255））
4 speed/sensitivity 0-255
7channels
functions specification
1 general brightnessadjust 0-255
2 strobe0-255
3 nofunction 0-8
auto 9-127 Recommendeffect15 121-127））
sound 128-255 Recommendeffect15 247-255））
4 speed/sensitivity 0-255
5 red brightnessadjust 0-255
6 green brightness adjust 0-255
7 blue brightness adjust0-255
14channel
s functions specification
1 general brightnessadjust 0-255
2 strobe0-255
3 the 1st/2nd group red bright 0-255
4 the 1st/2nd group green bright
0-255
5 the 1st/2nd group bluebright
0-255
4 the 3rd\4th group red bright 0-255
6 the 3rd\4th group green bright
0-255

7
7 the 3rd\4th group bluebright
0-255
……………………………………………
……………………………
12 the 7th\8th group red bright 0-255
13 the 7th\8th group green bright 0-255
14 the 7th\8th group bluebright 0-255
26chann
els functions specification
1 general brightnessadjust 0-255
2 strobe0-255
3 the first group red bright 0-255
4 the first group green bright 0-255
5 the first group blue bright 0-255
6 the secondgroup red bright 0-255
7 the secondgroup greenbright 0-255
8 the secondgroup blue bright 0-255
……………………………………………
……………………………
24 the eighthgroup red bright 0-255
25 the eighthgroup greenbright 0-255
26 the eighthgroup blue bright 0-255
5. Specification
Voltage AC100V -240V/50Hz/60Hz
Control mode Auto, master-slave,DMX512 signal
Max temperature 104°F(40°C)
Data input/output 3pin XLR-connection、anode socket
Lamp resource 64pcs 1.5W RGB 3-in-1 LED
Outside size 1050*75*120mm
N.W 3.5kg
