Indel B TB13 User manual

Dimensions: HxWxD=360x225x535mm
Power: 35W
Voltage: DC12/24
Weight: 10 g
Volume: 13L
TB13
VAN CONVERSIONS MINIBUSES BUS & COACHES
Designed for
COMPRESSORS
NEW POWERFUL COMPRESSOR FRIDGE
Indel B SpA—Via Sarsinate 27 - I-47866 S.Agata Feltria (RN), Italy. Tel. [phone]
16
16
Ph Davide Camporesi
30

1 2
3 4
5
212mm
35mm
423mm
For installing the fridge inside the vehicle, the metal
plate is to be fixed with screws both to the floor as
well as to the fridge.
On the metal plate you find many holes which you can
use for fixing it to the floor of the vehicle. If the
position of the holes is not suitable for your vehicle
you can drill other hoses.
On the left and right sides close to the bottom the
fridge has has 4 holes with screws inside (2 for each
side) conresponding to 4 slots where to insert the
brackets of the metal plate. Unscrew and remove the
screws from the fridge.
Use the screws you have removed from the fridge for
fixing the fridge to the brackets.
Sit the fridge on the fixing plate and make sure that
the brackets slip into the slots.
6
Make sure that the position of the holes of the fridge
and the of the brakets correnspond perfectly.
For more information contact:
Gabriele Morbidelli
[e-mail]
Indel B SpA—Via Sarsinate 27 - I-47866 S.Agata Feltria (RN), Italy. Tel. [phone]
Ph Davide Camporesi
423mm
212mm
FAST, EASY AND SAFE INSTALLATION
