Inder P-204 Operator's manual

HAND PIPE BENDER INSTRUCTION MANUAL
INTRODUCTION
Manual operated for long radius conduit, brass, copper, aluminium & furniture bending
upto 180°.
SAFETY INSTRUCTIONS
WARNING : When using tools, the following safety instructions must be observed to reduce
the risk of personal injury and property damage.
Please read and observe the following instructions before use.
1. Keep work area clean : An untidy and cluttered work area increases the risk of accidents
2. Use eye protection : Always use safety glasses or goggles. A face mask should also be worn
when dust is generated.
3. Wear suitable work clothes : Don't wear loose fitting clothes or jewellery. They can be caught
in moving parts and may cause injury. For outdoor work rubber gloves and non-stick footwear
are advised. Wear a protective hair net to contain long hair.
4. Guard against electric shock : Avoid any body contact with grounded surfaces e.g. bars, iron
sheet, radiators, stoves, and refrigerator enclosures.
6. Keep children away : Children should be kept away from the work area. Do not permit them to
handle the tool or tool cable.
7. Secure the work pieces : Use clamps or a vice to hold work. This will free up both hands to
operate the tool, which is safer.
8. Don't overreach when working : Keep a balanced footing at all times.Avoid abnormal stances
and awkward body positioning.
9. Do not overload or force tools : Tools operate better in the specified performance ranges.
Forcing the tool may cause damage.
10. Check for damage : Before further use always check the protection guards carefully to ensure
proper operation and performance. Check for alignment of moving parts, binding of moving
parts, breakage of parts, mountings and any other condition that may effect the tools operation.
An authorised service dealer should properly repair all damaged parts unless otherwise
indicated elsewhere in the instruction manual. Do not use the tool if the switch does not turn it on
and off.
11. Pull out power plug : When changing accessories or when the tool is not in use.
12. Avoid unintentional starting : Do not carry tools by the switch. Always check that the switch is
in the off position before connecting to power source.
13. Storage : When not in use your tools machine should be stored in a dry area, which is not
accessible to children.
14. Stay alert : Do not use the tool when you are tired. Use common sense and watch what you are
doing.
15. Remove keys and spanners : Do not forget to remove any adjustment keys, spanners and
wrenches before storing the tool.
16. Recommended use : Please note the use of tools other than those described in instruction
manuals or in the product catalogues can result in a risk of personal injury.
SINCE 1958
Page #3 M:204
HAND PIPE BENDER
User’s Instruction Manual
Model : P-204
Note : Before using this Hand Pipe bender carefully read through this
INSTRUCTIONS MANUAL to ensure efficient, safe operation. It is
recommended that these INSTRUCTIONS be kept readily available as an
important reference when using this Pipe Bender.

WARRANTY CERTIFICATE
Product : HAND PIPE BENDER
Identification : Type Designation : P-204
LIMITED ONE YEAR WARRANTY AGAINST MANUFACTURING DEFECT.
Makes every effort to assure that its Hand Pipe Bender meet high quality
and durability standards and warrants to the original purchaser that the product is free from
defects in material and workmanship for the period of one year form the date of purchase.
This warranty does not apply to damage due directly or indirectly to misuse, abuse,
negligence or accidental repairs or alteration outside our laclliles, or to lack or indignance.
We shall in no event be liable for death, injuries to person or property or for incidental
contingent, special or consequential damages arising from the use of our product. Some
states don't allow the exclusion or limitation of incidental or consequential dames, so the
above limitation of exclusion may not apply to you.
To take advantages of this warranty, the product or part must be returned to us with
transportation charges pre-paid. Proof of purchase date and an explanation of the
complaint must accompany the merchandise. If our inspection very the defect, we will
either repair or replace the product all elecllore or we may elect to refund the purchase
price if we cannot readily and quickly provide you with replacement. We well return
repaired products all our expense, but if we determine there is no defect, or that the defect
resulted from caused no within the scope of our warranty, then you must bear the cost of
returning the product.
This warranty gives you specific legal right and you may also have other rights which vary
from state to state.
12576
49
o
N*
Accredited
by the RvA
SINCE 1958
Page #1 M:204
FEATURES
Prod. No. 204A 204B 204C 204D 204E
Size (Inch.) ½ - ¾ ¾ - 1 ½ - 1 ½ - 1.¼ as per
(Standard Former for gauge 16 pipe) customer
Specification
Manual operated for long radius conduit, brass, copper, aluminium & furniture bending
upto 180°.
PART DIAGRAM PROD. NO. 204A, B, C, D
PART DIAGRAM AND LIST
#1
#2 #3
#4
#5
#6
S.No. S.No.Parts Desc. Parts Desc.
1.
2.
3.
Bending Former
Sliding Bar
Bending Roller
4.
5.
6.
Adjustment Screw
Sliding
Base Plate
Page #2 M:204
PART DIAGRAM PROD. NO. 204E
#1 Bending Former
#3 Clamping Die
#4 Adjustment Screw
#5 Rotating Arm
#6 Base Plate
#7 Clamp
#8 Clamping Base
#2 Sliding Bar
#3 Clamping Die
#1 Bending Former
