Infinea® BluePad 2.0
User Manual
For Apple®/ Android®/ Windows®8

Infinea BluePad 2.0 User Manual
2
Contact Information
Mobility Sales/ Technical Support Center
Innite Peripherals, Inc.
17681 Mitchell N
Irvine, CA 92614
Toll-Free: [phone]
Ofce: [phone]
Website: ipcmobile.com
Headquarters/ Main Warehouse
Innite Peripherals, Inc.
2312 Touhy Avenue
Elk Grove Village, IL 60007
Toll-Free: [phone]
Ofce: [phone]
Fax: [phone]
Compatible Devices
Legal Notice
“Made for iPhone” means that an electronic accessory has been designed to connect specically to an Apple mobile device and has been
certied by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance
with safety and regulatory standards.
• iPod, iPhone, iPad
• Android O/S 2.1 and higher
• Window Phone 8
Trademarks
Innite Peripherals, Mobilize Your Enterprise, Linea Pro, Innea, Innea Tab, and Innea Omni are trademarks of Innite Peripherals, Inc.
All other trademarks are the property of their respective owners.

Infinea BluePad 2.0 User Manual
3
Table of Contents
Compatible Devices 2
Trademarks 2
Overview 4
Features 4
Accessories 4
Develop Applications 4
Technical Specifications 5
Before Using Your Infinea BluePad 2.0 6
Getting Started 6
Product Description 7
Developing Applications 8
Turn On the BluePad 2.0 8
Charge the Infinea BluePad 2.0 8
Set-up Service Mode 9
Service Mode Options 9
Application Download Mode 9
Installing SIM/SAM Cards 10
Touchscreen Display 10
Magnetic Card Reader 11
Smartcard Reader 11
Contactless Credit or Debit Cards 11
Pairing BluePad 2.0 12
Scan to Pair BluePad 2.0 12
Troubleshooting 13
Blank Display 13
Keyboard Not Responding 13
Failure to Process Transactions 13
Warranty 13
Disclaimer 13
Symbols 14
Product Returns and Servicing 14
Federal Communications Commission 14

Infinea BluePad 2.0 User Manual
4
Visit our website, https://ipcmobile.com or contact your
Innite Peripherals account representative for additional
information about our current and future product
accessories.
Overview
The Innea BluePad 2.0 is a hand-held PIN pad with an integrated smart card reader, near-eld communication (NFC) contactless card
reader, and magnetic stripe card reader. This low-energy Bluetooth interface simplies the pairing process to any smart phone by scanning
to pair. The optional Wi-Fi or 3G connectivity enables the unit as a standalone terminal. In addition, a tamper detection circuitry resists
unauthorized intrusions and supports a broad spectrum of hardware and software security features.
Features
Battery
• Rechargeable Lithium-ion polymer battery
• USB communication cable is included
Magnetic Card Reader
• 3-track read-head
• ISO 7810 / 7811 / 7813
Bluetooth
• 3.0
• Serial Port Proles (SPP)
Accessories
(Optional) Smart Card Reader
EMV Level 1 and Level 2
Keypad
• On/Off
• Up/down arrows
• Red X to close
• Right arrow
• Green check mark
Develop Applications
Software is not provided with your Innea BluePad
2.0. Please contact Innite Peripherals for Third-Party
software solutions. Integrating the Innea BluePad 2.0 into
your software application requires the use of the Innite
Peripherals Universal SDK. The SDK incorporates an API
specically for developing applications to read smart cards
and perform other functionality with the Innea BluePad 2.0.
For additional details about the Innite Peripheral Universal
SDK, refer to the SDKs documentation. For the latest Innite
Peripheral Universal SDK, visit our developer portal, https://
developer.ipcmobile.com.

Infinea BluePad 2.0 User Manual
5
Technical Specifications
Mechanical
Compatibility Any iPod, iPhone, iPad mobile device
Android, Window Phone 8
Weight without mobile device 180g (6.35oz)
Dimensions 133mm x 71mm x 1835mm (5.24” x 2.80” x 72.2”)
Display • LCD
• Capacitive touchscreen for signatures
• 65K colours
• 2.4”/40 x 320 pixels resolution
• 10 numeric keys
• 5 functional keys
Buttons • On/Off
• Up/Down arrows
• Red X
• Right arrow
• Green check mark
Electrical
Battery Capacity 3.7 1180mAH
Smart Card Reader Level 1 and Level 2 certified
Magnetic Card Reader • 3-track, bi-directional reading
• ISO 7810, 7811, 7813
Contactless Card Reader EMV Level 1 certified
Connectivity • Wi-Fi module 802.11 b/g/n
• Wireless mobile GSM (900 / 1800 MHZ / UMT (900 / 2100 MHZ)
• Tray for Nano SIM / SAM cards
Power Input DC 5V through USB-C, charging station, or docking station
Port USB-C
Certifications
CE, FCC, EMV Level 1, Level 2, Contactless, PCI, PTS 4.x SRED
Environment
Temperature Operation -10 C to +40 C (14 F to 104 F)
Storage -15 C to +50 C (5 F to 122 F)
Relative Humidity Operation/Storage 5% to 90%

Infinea BluePad 2.0 User Manual
6
Innea BluePad 2.0 (1) USB Type–C Cable (1)
Note
Box contents and SKUs vary based on your order conguration.
Getting Started
What to do Where to find the information
The BluePad 2.0 is shipped with 30% of full charge approximately.
Ensure the battery is fully charged before first use.
Charging the Battery
Software is required on your mobile device for operation of the smartcard
reader, touchscreen signatures, and LEDs.
Developing Applications
Processing Transactions with payment cards. • Smartcard Reader
• Contactless Card Reader
• Magnetic Stripe Reader
Before Using Your Infinea BluePad 2.0
Remove the BluePad 2.0 and any included accessories from the shipping carton, and then verify the contents against your packing list.
Important
Retain all the packing materials, invoice, and bill of lading. These items may be required if you need to return the unit for servicing later.
Inspect the packaging and contents carefully for any signs of damage, and verify the packaging is intact. If there are sign of damage, do not
attempt to use the unit. Notify your account executive or contact Innite Peripherals Support: https://ipcmobile.com/support

Infinea BluePad 2.0 User Manual
7
Product Description
This illustrates the key features of the BluePad 2.0.
1. Contactless LED status indicators
2. LCD display touchscreen
3. Keypad
4. Charging pads
5. Chip card reader
6. USB-C connector
7. SIM/SAM card tray
8. Docking station charging pads/UART communications
9. Magnetic stripe reader

Infinea BluePad 2.0 User Manual
8
Developing Applications
Software is not provided with your BluePad 2.0. Contact
Innite Peripherals for Third Party software solutions.
Integrating the Innea BluePad 2.0 with a mobile device
requires the Innite Peripherals Universal Software
Development Kit (SDK). This SDK incorporates an API for
developing applications for specic functionality specically
for the BluePad 2.0.
For additional details on using the SDK, refer to the
documentation and information at
https://developer.ipcmobile.com
Charge the Infinea BluePad 2.0
Before rst use, the Lithium Ion rechargeable battery must be
charged for at least four hours and 30 minutes.
Note
To prevent electrical damage to the unit, only use the included
USB cable and power adapter.
1. Press the On/Off button.
2. Plug the USB-C connector into an AC wall adapter.
3. Conrm the battery status. See below.
Battery Status Display Indicators
These indicate the battery status on the BluePad 2.0 menu.
Display Description
Battery is discharged.
Battery is fully charged.
USB cable plug for external power.
Flashing indicates battery is charging
from the USB cable or power supply.
USB connection.
Bluetooth connection is active.
Note
Contact Innite Peripherals before attempting to open your
BluePad 2.0 as disassembling a SRED encrypted unit renders
it unusable and impacts your warranty.
For help, contact https://ipcmobile.com/support.
Turn On the BluePad 2.0
1. To turn on the BluePad 2.0, press the Power button on the top,
right corner of the keypad.
2. Once powered on, the name and version of the secure boot
loader and the rmware are displayed.
Note
To prevent the risk of shock or damage, do not use the
BluePad 2.0 near water or with wet hands.

Infinea BluePad 2.0 User Manual
9
Set-up Service Mode
Service technicians can access service mode to add or delete
data encryption algorithm (DEA) keys. In addition, the
keyboard, magnetic strip reader, smartcard reader, and display
may be tested.
1. To enter service mode, press the Down button and On button at
the same time.
2. When the display is visible, you will see the secure boot loader/
rmware name and version.
3. To navigate the options, use these keys.
* Up – moves up one position in the list.
* Down – moves down one position in the list.
* OK – select the active option.
* C – return to the previous level or exit.
Service Mode Options
Option Description
Info version Displays serial number and versions of the program
modules.
Info
hardware
Information about the status of the hardware:
battery voltage, external power supply used, and
battery charging.
Info keys Version of the Acquire Initial Key (AIK) key version.
Test Display To perform a display test:
• Press OK once on a blank screen.
• Press OK again to show the check mate
background.
• Press the Up and Down buttons to change the
contrast.
• Press C to exit.
Test
keyboard
To remove a key symbol from the display, press the
specic key for the symbol to remove it.
Test MSR To show data, swipe a magnetic strip card correctly.
Test SCR To Return to Answer to Reset (ATR), insert a
smartcard, and press RESET.
Keys
download
To exchange secure information through the RS-232
interface using proprietary communication protocol
securely, download AIK with the PIN pad to set Keys
Download Mode.
Application Download Mode
The BluePad memory may be corrupted if the application
download process is interrupted before completion. The
application integrity checking fails during boot up.
Note
If this occurs, you must repeat the application download
process.
1. Press and hold the Up button and the On button at the same
time.
2. When you hear a sound, the BluePad is in the application
download mode and the name and version of the Secure Boot
Loader is displayed.
3. Verify the message
* MODE: FW/APR
4. The progress percentage complete is displayed once the
download begins.
5. Once completed successfully, do one of the following:
* Press C
* Press the Off button

Infinea BluePad 2.0 User Manual
10
Installing SIM/SAM Cards
The SIM/SAM tray only supports Nano SIM cards, which all
iOS device models after iPhone 5 use. These cards are smaller
and thinner than the micro SIM standard and mini SIM cards.
1. Insert a paper clip into the opening beside the tray on the left-
hand side.
2. Slide open the tray.
3. Place the card into the tray.
4. Close the tray gently.
Touchscreen Display
To use the touchscreen display, ensure the software is loaded.
Refer to Developing Applications for details or visit our
Development Portal at https://developer.ipcmobile.com
Once the touchscreen is installed, customers can use
a ngertip to write their signatures after verifying the
transaction is complete.

Infinea BluePad 2.0 User Manual
11
Contactless Credit or Debit Cards
1. Place a contactless card on the contactless logo.
2. Keep the card in place until you see the transaction is complete
on the display.
Smartcard Reader
To avoid a canceled transaction, leave the card in the reader
until the transaction is complete.
1. Place the smartcard with the gold contacts facing upward.
2. Insert the card into the bottom reader slot in a smooth,
continuous motion unit you feel it seat rmly with a click.
3. Give the BluePad to the customer for PIN entry or signature.
4. Remove the card once you see the transaction is complete on
the display.
Processing Transactions
Magnetic Card Reader
The BluePad 2.0 can be used with a built-in personal digital
assistant (PDA) such as a magnetic card reader.
1. Hold the card with the stripe facing downward.
2. Insert the card into the card reader slot and swipe it through
swiftly.
3. Hand the BluePad to the customer for signature or PIN entry.

Infinea BluePad 2.0 User Manual
12
Pairing BluePad 2.0
You can pair the BluePad to your iOS device using of two
methods.
Method one, pair the BluePad 2.0 to Bluetooth 3.0 only.
1. Press and hold down the On/Off button for two seconds
approximately.
2. After a few seconds, the unit is ready and you can access the iOS
Settings > BlueTooth option to locate the device to pair.
Note
This process can only be done once.
3. Run the iOS application.
Scan to Pair BluePad 2.0
Method two, scan to pair the BluePad 2.0 to your iOS device
via BLE.
1. Press and hold down the On/Off button for two seconds
approximately.
2. After a few seconds, the unit is ready and you can access the iOS
Settings > Scan Barcode.
3. Once the camera phone is activated, scan the serial number on
the back of the BluePad using the phone camera. The Bluetooth
Pairing Request is displayed on both screens.
4. Conrm the passkey is the same on both, and then tap Pair.

Infinea BluePad 2.0 User Manual
13
Troubleshooting
To assist you in installing and conguring your BluePad 2.0
successfully, refer to these guidelines.
Note
If problems persist, which are not addressed here, contact
https://ipcmobile.com/support
Blank Display
• Ensure the battery is fully charged.
• If the screen is not completely blank, refer to Failure to Process
Transactions.
Keyboard Not Responding
• Verify the screen is not blank, and then refer to Failure to
Process Transactions.
• If the screen is blank, contact https://ipcmobile.com/support
Failure to Process Transactions
Magnetic Card Reader
• Verify the issue is not a defective card by testing the transaction
using one or more different magnetic stripe cards.
• Ensure you are swiping the card correctly.
Smartcard Reader
• Test transactions with different smart cards to ensure the
problems are not a defective card.
• Ensure the card is inserted correctly.
Warranty
Innite Peripherals does not warrant, and is not responsible
for, any damage to the Innea BluePad 2.0 (“Product”) or the
assembled iOS device as a result of liquid or solid particle
intrusion into the Product, or damaged caused by dropping
the Product with the assembled iOS device. If a material
or workmanship defect arises with regard to any Innite
Peripherals product, and a valid claim is received within the
Warranty Period, Innite Peripherals (at our sole discretion)
will repair the Product using new or refurbished parts, or
replace the Product with a new or refurbished Product.
For purposes of this limited warranty, “refurbished” means
a product or part that has been substantially returned to its
original specications. In the event of a defect, these are your
exclusive remedies.
Disclaimer
NO WARRANTY. This technical documentation is provided
AS-IS. Further, the documentation does not represent a
commitment on the part of. Innite Peripherals, Inc does
not warrant that it is accurate, complete or error free. Any
use of the technical documentation is at the risk of the user.
Innite Peripherals, Inc reserves the right to make changes
in specications and other information contained in this
document without prior notice, and the reader should in all
cases consult Innite Peripherals, Inc to determine whether
any such changes have been made. Innite Peripherals, Inc
shall not be liable for technical or editorial errors or omissions
contained herein; nor for incidental or consequential
damages resulting from the furnishing, performance, or use
of this material. Innite Peripherals, Inc does not assume
any product liability arising out of or in connection with the
application or use of any product or application described
herein.

Infinea BluePad 2.0 User Manual
14
Symbol Description
Refer to the instructions before using
this product
Manufacturer
Manufacture Date
Caution
Serial Number
P/N Part Number
Waste Electrical and Electric Equipment
Complies with part 15 of the FCC rules
Symbols
Federal Communications
Commission
Federal Communications Commission (FCC)
Statement
15.21
You are cautioned that changes or modications not expressly
approved by the part responsible for compliance could void
the user’s authority to operate the equipment.
15.105(b)
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15
of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help
.
Operation is subject to the following two conditions:
1. This device may not cause interference and
2. This device must accept any interference, including interference
that may cause undesired operation of the device.
FCC RF Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits
set forth for an uncontrolled environment. End users must
follow the specic operating instructions for satisfying RF
exposure compliance. This transmitter must not be co-
located or operating in conjunction with any other antenna or
transmitter.
Product Returns and Servicing
Use the link in step 1 to create an account and gain access to
our Knowledge Base and online support services. Through our
online support center, you’ll be able to download les, open a
Support Ticket, manage your RMAs, view your account Prole
and subscribe to Alerts.
To request a RMA
1. Create a user account in the RMA Support Portal at http://
ipcmobile.com/support/rma/
2. Login to your user account, and then click Create RMA Request.
3. Read the instructions provided and complete the online request
form.
4. Note the assigned RMA number and write it clearly on your
shipping carton.
5. Ship your equipment back to us using the address provided.
