LIGHT SENSOR (4-20 mA OUTPUT)
User Guide for SRMS-D469-1
Thank you for choosing L-com product. To ensure safe, accurate performance and product longevity, please take a moment to familiarize yourself
with this manual before powering the device. Please keep it handy for future reference. In case of any questions regarding the installation or use of
product, please call us at 800.341.5266.
Reach out to us at [e-mail] and visit our website at www.l-com.com
M_L-com_SRMS-D469-1_11/2022_R1.0
1
Product Description
The SRMS-D469-1 is a sensor that measures ambient light intensity. With a waterproof housing, the SRMS-D469-1 can be used outdoors, as well in
demanding indoor environments such factory floors. The SRMS-D469-1 has a 4  20 mA output and can measure illuminance up to 65,000 lux.
Features
 Monitors ambient light intensity
 12  24 VDC supply
 Up to 65,000 Lux
 4  20 mA output
 Wall mount waterproof housing
Applications
 Greenhouses
 Agriculture
 Solar farms
 Laboratories
 Factory floors
 Manufacturing
 General Environmental monitoring

2
Technical Parameters
Working Voltage 12  24 VDC
Output Mode 4  20 mA
Measuring Range 0~65000 Lux
Long-term Stability (Light Intensity) ±5% / y
Maximum Allowed Error ±7%
Work Environment
Temperature 0~60 °C
Humidity ≤80% RH (No condensation)
Temperature
Storage Environment
-20~65 °C
Humidity 0~100% RH (No condensation)
Mounting Diagram
Vertical wall mount, fixed hole diameter 4 mm, pitch 105 mm
Electrical Diagram
No. Wire Color Definition Function description
1Brown VCC DC 12-24V Power supply
2Blue Vout - Current output negative
3Black GND Power supply negative
4Yellow / Gray Vout + Current output positive
Notes
1. Confirm the polarity and the voltage of the power supply before powering ON the sensor.
2. There are two colors for wire 4, ie. Yellow or gray.
