TECHNOLOGY,PERFORMANCE,DESIGN.
Groundbreaking new technologies,
revolutionary new materials
and advanced manufacturing
techniques – for nearly 40 years,
Infinity has set new standards
for performance, simplicity and
style. Now, Infinity’s unchallenged
leadership in loudspeaker design
extends from our critically
acclaimed Infinity Cascade
™Series
to the stylish new Total Solutions™
loudspeaker systems inspired by
the award-winning Cascade.
INFH1363-TSS Lit-rev5-23 6/6/06 4:48 PM Page 1

INFH1363-TSS Lit-rev5-23 6/6/06 4:49 PM Page 4

TSS – COMPLETE MOVIE AND MUSIC
LOUDSPEAKER SYSTEMS WITH
POWERED SUBWOOFERS
Realistic surround sound, deep,
powerful bass and clean dialogue
reproduction will entice you into
enjoying your favorite movies and
music again and again – or even
contending with your adversaries
in your favorite video game! TSS
systems are designed for almost
any size space, so filling your
room with great sound is easy.
The most demanding digital media
are handled with ease through the
voice-matched center channel, wall-
mountable satellite speakers and
powerful, amplified subwoofer. With
attention to detail, a sleek, sculpted
design and the choice of a charcoal
or platinum finish,TSS systems will
blend seamlessly with today’s flat-
panel televisions and your décor.
The science of superior sound and
the art of distinctive styling come
together in three innovative systems
that will transport you to a new level
of listening enjoyment.
NEW METAL MATRIX
DIAPHRAGM™(MMD®)
DRIVER TECHNOLOGY
Derived from our
patented CMMD®
(patent nos. 6,327,372 and
6,404,897) technology, the
TSS-800 and TSS-1200 employ
Infinity’s new Metal Matrix
Diaphragms.
™MMD®continues
the Infinity®tradition of using
advanced materials to improve
cone performance, with signifi-
cantly less distortion, outper-
forming commonly used cones
made of paper, polypropylene
and Kevlar.
®What does that
mean to you? It means that
Infinity’s Total Solutions systems
sound great.
ROOM-FRIENDLY
All Total Solutions speaker systems
utilize an acoustical waveguide to
deliver a wider, more even high-
frequency response.This ensures
that no matter where in the room you
sit, you won’t miss any of the action.
And remember, unlike many
systems, the TSS-500,TSS-800
and TSS-1200 are engineered to
sound as exceptional with music
as they do with your favorite movies.
Pure, realistic sound to please
discriminating ears in systems
that are a feast for the eyes –
Infinity Total Solutions.
INFH1363-TSS Lit-rev5-23 6/6/06 4:49 PM Page 5

TSS-1200
TSS-1200
Filling Even the Largest Spaces
With Great Sound
•Extruded-aluminum satellite
and center channel enclosures
•MMD®drivers
•Four two-way satellites and
a two-way center channel with
dual 3-1/2" woofers and
3/4" tweeter
•12," 250-Watt powered sub
•Satellites and center are
magnetically shielded
•Includes center channel base
•Gold-plated binding posts
•Available in platinum or
charcoal
•Includes adjustable- and fixed-
mount wall brackets for the
satellites and center channel
INFH1363-TSS Lit-rev5-23 6/6/06 4:49 PM Page 6

TSS-800
TSS-800
Exceptional Home Theater and
Music Reproduction
•Extruded-aluminum satellite and
center channel enclosures
•MMD®drivers
•Four two-way satellites with
3-1/2" woofer and 3/4" tweeter
•Two-way center channel with
dual 3-1/2" woofers and
3/4" tweeter
•10," 150-Watt powered sub
•Satellites and center are
magnetically shielded
•Includes center channel base
•Gold-plated binding posts
•Available in platinum or
charcoal
•Includes adjustable- and fixed-
mount wall brackets for the
satellites and center channel
INFH1363-TSS Lit-rev5-23 6/6/06 4:49 PM Page 7

TSS-500
TSS-500
A Most Dramatic Improvement in
Television Sound
•Four two-way satellites with
2-1/2" woofer and 3/4" tweeter
•Two-way center channel with
dual 2-1/2" woofers and
3/4" tweeter
•8," 100-Watt powered sub
•High-impact polystyrene
enclosures
•Satellites and center are
magnetically shielded
•Includes center channel base
•Available in platinum or
charcoal
•Includes adjustable-mount
wall brackets for the satellites
and center channel
INFH1363-TSS Lit-rev5-23 6/6/06 4:49 PM Page 8

TSS-500 Satellites Center Channel
Frequency Range (±3dB) 150Hz – 25,000Hz 150Hz – 25,000Hz
Recommended 10 – 100 Watts 10 – 100 Watts
Amplifier Power Range
Sensitivity 86dB 87dB
(2.83V @1 Meter)
Nominal Impedance 8 Ohms 8 Ohms
Crossover Frequency 7,000Hz 7,000Hz
Midrange Driver(s) 2-1/2" (64mm), Dual 2-1/2" (64mm),
magnetically shielded magnetically shielded
High-Frequency Driver 3/4" (19mm), 3/4" (19mm),
magnetically shielded magnetically shielded
Dimensions (H x W x D) 7-11/16" x 3-1/2" x 2-3/4" 3-1/2" x 12" x 2-3/4"
(195mm x 89mm x 70mm) (89mm x 305mm x 70mm)
Weight 1.2 lb (0.5kg) 2 lb (0.9kg)
Powered Subwoofer
Frequency 39Hz – 150Hz
Range (±3dB)
Amplifier Output 100 Watts RMS
Low-Frequency Driver 8" (200mm)
Crossover 120Hz,24dB/octave
Frequency (LFE/Normal switch
in Normal position)
Dimensions 15-7/8" x 13-5/8" x 14-5/8"
(H x W x D) (403mm x 346mm x 371mm)
Weight 31.7 lb (14.4kg)
TSS-800 Satellites Center Channel
Frequency Range (±3dB) 120Hz – 30,000Hz 120Hz – 30,000Hz
Recommended 10 – 100 Watts 10 – 125 Watts
Amplifier Power Range
Sensitivity 88dB 89dB
(2.83V @1 Meter)
Nominal Impedance 8 Ohms 8 Ohms
Crossover Frequency 3,500Hz; 24dB/octave 3,500Hz; 24dB/octave
Midrange Driver(s) 3-1/2" (89mm) MMD,
®Dual 3-1/2" (89mm) MMD, ®
magnetically shielded magnetically shielded
High-Frequency Driver 3/4" (19mm) MMD, 3/4" (19mm) MMD,
magnetically shielded magnetically shielded
Dimensions (H x W x D) 9-1/8" x 3-3/4" x 2-3/4" 3-3/4" x 13" x 2-3/4"
(232mm x 95mm x 70mm) (95mm x 330mm x 70mm)
Weight 2.5 lb (1.1kg) 4.5 lb (2kg)
Powered Subwoofer
Frequency 34Hz – 150Hz
Range (±3dB)
Amplifier Output 150 Watts RMS
Low-Frequency Driver 10" (250mm)
Crossover 50Hz – 150Hz,
Frequency 24dB/octave,
continuously
variable
Dimensions 15-3/4" x 14" x 15"
(H x W x D) (400mm x 356mm x 381mm)
Weight 34.6 lb (15.7kg)
TOTAL SOLUTIONS™SPECIFICATIONS
TSS-1200 Satellites Center Channel
Frequency Range (±3dB) 120Hz – 30,000Hz 120Hz – 30,000Hz
Recommended 10 – 125 Watts 10 – 125 Watts
Amplifier Power Range
Sensitivity 89dB 89dB
(2.83V @1 Meter)
Nominal Impedance 8 Ohms 8 Ohms
Crossover Frequency 3,500Hz; 24dB/octave 3,500Hz; 24dB/octave
Midrange Driver(s) Dual 3-1/2" (89mm) MMD,
®Dual 3-1/2" (89mm) MMD, ®
magnetically shielded magnetically shielded
High-Frequency Driver 3/4" (19mm) MMD, 3/4" (19mm) MMD,
magnetically shielded magnetically shielded
Dimensions (H x W x D) 12-15/16" x 3-15/16" x 3" 3-15/16" x 13-3/16" x 3"
(329mm x 100mm x 75mm) (100mm x 335mm x 75mm)
Weight 3.9 lb (1.8kg) 3.9 lb (1.8kg)
Powered Subwoofer
Frequency 29Hz – 150Hz
Range (±3dB)
Amplifier Output 250 Watts RMS
Low-Frequency Driver 12" (300mm) MMD®
Crossover 50Hz – 150Hz,
Frequency 24dB/octave,
continuously
variable
Dimensions 18-1/2" x 12-3/4" x 18-1/2"
(H x W x D) (470mm x 324mm x 470mm)
Weight 44 lb (20kg)
250 Crossways Park Drive,Woodbury, NY 11797 USA 516.674.4INF (4463) Fax [phone] www.infinitysystems.com
© 2006 Harman International Industries, Incorporated. All rights reserved. Printed 5/06
Part No.TSSLIT5/06 Designed, edited and digitally produced by Harman Consumer Group Marketing & Design Center, Woodbury, NY.
Infinity, Harman International, CMMD and MMD are registered trademarks, and Infinity Cascade, Metal Matrix Diaphragm and Total Solutions
are trademarks, of Harman International Industries, Incorporated.
Kevlar is a registered trademark of E.I. du Pont de Nemours and Company.
Infinity continually strives to update and improve existing products, as well as create new ones.The specifications and construction
details herein are therefore subject to change without notice.
Optional satellite
stand available.
Optional Accessories
TSS-STAND500 ForTSS-500 satellites
TSS-STAND1200 ForTSS-800 andTSS-1200 satellites
TSS-SAT500 Individual satellite for upgrading to
6 or 7 channels
TSS-SAT800 Individual satellite for upgrading to
6 or 7 channels
TSS-SAT1200 Individual satellite for upgrading to
6 or 7 channels
