in3138hd
Professional Full 3D 1080p Projector
www.infocus.com

Impressive image quality
With up to 4000 lumens, high contrast, 1920
x 1080 resolution, six-segment color wheel,
and BrilliantColor™ DLP imaging, the
IN3138HD projects big, bright, colorful HD
images with the lights on and the blinds open.
3D
The IN3138HD supports multiple forms
of 3D – including HDMI, Blu-Ray, 3D
broadcasting, video games and NVIDIA
3DTV PC connectivity – in 1080p Full-
HD for your maximum viewing pleasure.
Compatible with 144Hz DLP Link™
3D glasses.
3D Triple Flash
The IN3138HD uses the latest Texas
Instruments DLP® Dark Chip 3 technology
and drivers (DLP 0.65” 1080P s600 DC3)
and incorporates 3D Triple Flash technology.
3D Triple Flash triples the normal 3D frame
rate of 48 Hz (24 for the right eye and 24 for the left) to 144
Hz, which gives you a deeper, more immersive 3D experience.
True High Definition 1080p
comes to the Office or Classroom
HD is moving out of the house and into a conference
room or classroom near you. The IN3138HD beams today’s
high definition content with 4000 lumens of brightness at
work or school.
1080p resolution is THE standard for high quality media and movies.
The InFocus IN3138HD 1080p projector displays today’s true high definition
content and its high resolution is the perfect match for today’s 16:9 notebooks.
Professional Full 3D
1080p Projector
IN3138HD – FULL 3D 1080p
• Native full HD 1080p (1920 x 1080) resolution
• 4000 ANSI lumens
• 5000:1 contrast ratio
• NVIDIA 3DTV Play, 144Hz 3D triple flash
• 3D support for Blu-ray, cable boxes and more
• HDMI 1.4, DisplayPort, VGA inputs and more
• RJ45 network connection
• Screen trigger
• VGA and variable audio out
Audio
The IN3138HD features a 10W on-board speaker that
can fill most meeting or class rooms. No additional audio
equipment is required.
Portable or installed
The IN3138HD projector’s light weight, high brightness,
strong audio, and numerous connectivity options means it
will be ready for any situation. The same features, including
its RJ45 networking port, make it a strong candidate for
installation too.

Connectivity
VGA x 2 RS232
HDMI 1.4 3.5mm audio in
DisplayPort RCA stereo audio in
S-Video 3.5mm audio out
Composite video Monitor Out (VGA)
RJ45 12v trigger
Distance Chart
Diagonal Screen Size
(16:9 screen) Projection Distance
Inches Metres
Inches Metres Min Max Min Max
77 1.9558 106.04 128.85 2.69 3.27
82 2.0828 112.92 137.22 2.87 3.49
92 2.3368 126.69 153.96 3.22 3.91
100 2.54 137.71 167.34 3.5 4.25
106 2.6924 145.97 177.38 3.71 4.51
110 2.794 151.48 184.08 3.85 4.68
119 3.0226 163.87 199.14 4.16 5.06
133 3.3782 183.15 222.57 4.65 5.65
159 4.0386 218.96 266.07 5.56 6.76
Connect to the latest devices
This projector is loaded with connectivity options, including HDMI and DisplayPort. Project from PCs, Macs, video sources,
tablets and smartphones. The IN3138HD with native 1080p resolution projects high definition video and widescreen
notebooks at full resolution without scaling.
DisplayPort provides the fastest refresh rates, the deepest color depths and the highest fidelity with near zero latency.
Plus, it not only connects backwards to older technologies, it is designed to accommodate future advances too.
Networked support
With the IN3138HD, your IT manager and tech team can manage and control the projector the same way as a printer—remotely.
That cuts time and cost for routine tasks such as troubleshooting and maintenance. And when presenters need tech support,
they can get it instantly through the network.
Digital control
Connect to and control your IN3138HD projector via your IT network with Crestron Roomview and AMX Device
Discovery. Roomview enables instant, intuitive operation of your projector with no need for a control
processor or custom programming.
You can also use an AMX controller to detect your IN3138HD projector dynamically and configure it with
the correct driver for remote control.
D
E
V
I
C
E
D
I
S
C
O
V
E
R
Y

Specifications*
©2014 InFocus Corporation. All rights reserved. Specifications are subject to change without further notice. InFocus and InFocus The New Way to Collaborate are either trademarks or registered trademarks
of InFocus Corporation in the United States and other countries. DLP, the DLP logo, and the DLP medallion are trademarks of Texas Instruments. All trademarks are used with permission or are for identification
purposes only and are the property of their respective companies. InFocus_IN3138HD_Datasheet_EN_23JAN14.
Panel / Native Resolution DLP 0.65” 1080P s600 DC3, 1920x1080
Data Processor DDP4422
Brightness 4000 ANSI lumens (3500 ANSI lumens Eco Mode)
Brightness Uniformity (Typical) 80%
Lamp Life** 3,000 hours (Standard Mode), 4,000 hours (Eco Mode)
Contrast Ratio (Typical) 5000:1
Input Connections VGA x 2, HDMI 1.4a, DisplayPort, S-Video, Composite video, RCA stereo audio in (L/R), 3.5mm stereo audio in
Output Connections VGA out, 3.5mm stereo audio out
Control RS-232, 12V screen controller, USB Mini-B (service)
LAN Control Function: Crestron / AMX / TelNet / Extron
Network RJ45
3D Supports all major 3D standards for DLP projectors, including 3D content from Blu-ray, cable boxes,
dish services, PCs and more (over HDMI at 1080p). 144Hz DLP LinkTM 3D glasses required.
Color Wheel 6 segments (RYGCWB)
Color Reproduction Graphic: 30 bit 1 billion true color, Video: 30 bit 1 billion true color
Lens Type Manual Zoom, Manual Focus
Zoom Ratio Digital Zoom ; Optical Zoom: 1.22:1
Projection Distance 25.6 – 300 in (65 – 762 cm)
Projection Screen Size 3.28 - 32.8 ft (1 - 10 m)
Throw Ratio (D/W) 1.58- 1.92
Optical Offset 110% +/- 10%
Aspect Ratio 16:9 (native) & 4:3 / letter box / 2.35:1 (supported)
Keystone Correction +/- 40° (vertical only)
Frequency H-Sync 15, 30-90 KHz
Frequency V-Sync 43-85 Hz (120Hz)
Data Compatibility VGA, SVGA, XGA, SXGA, Macintosh
Video Compatibility NTSC/NTSC 4.43, PAL B/G/H/I/M/N 60, SECAM, 480i/480p/720p/1080p
Acoustic Noise 37 dB (Standard Mode), 35 dB (Eco Mode)
Built-in Speaker 10w mono speaker
Power Supply AC input 100~240 Voltage (auto ranging)
Power Consumption (maximum) 340 W (Standard Mode), 290 W (Eco Mode), <0.5 W (Standby Mode)
Product Dimensions (WxDxH) 11.2 x 10.3 x 4.8 inches / 285 x 261 x 121.8 mm
Product Weight 6.94 lbs / 3.15 kg
Shipping Dimensions 14.5 x 15.4 x 8.2 in / 369 × 392 × 208 mm
Shipping Weight 10.25 lbs / 4.65 kg
Security Features Security lock slot, Security bar
Ships with -- Accessories Power Cord, VGA Cable, Remote Control, Quick Start Guide, CD for User’s Manual
Warranty 2 years (projector), 6 months (lamp), 90 days (accessories)
Menu Languages English, German, French, Spanish, Portuguese, Simplified Chinese, Traditional Chinese, Russian
Approvals FCC, UL/cUL, CE+, TUV-GS, CU-PCT, PSB
in3138hd
* Product specifications, terms, and offerings are subject to change at any time without notice.
** Actual lamp life may vary based on the ambient environment and projector usage. Conditions that may affect lamp life include temperature, altitude, and rapidly switching the projector on and off.
Optional Accessories
Replacement Lamp (SP-LAMP-088)
Universal Ceiling Mount (PRJ-MNT-UNIV)
LiteShow Wireless Adapter (INLITESHOW3)
Carrying Case (CA-SOFTCASE-MTG)
ATA Travel Case (CA-ATA-MTG2)
Extended warranties (PROJ-EW-1YR-MC, PROJ-EW2YR-MC)
Cables and adapters
