Control Algorithm Tuning Parameters
Intellipak™ Rooftop Units
General Service Bulletin
ATTENTION: Warnings, Cautions and Notices appear at appropriate sections throughout this literature. Read these
carefully:
WARNING Indicates a potentially hazardous situation which, if not avoided, could result in death or
serious injury.
CAUTIONsIndicates a potentially hazardous situation which, if not avoided, could result in minor or
moderate injury. It could also be used to alert against unsafe practices.
NOTICE: Indicates a situation that could result in equipment or property-damage only accidents
RT-SVB98B-EN
March 2016

2RT-SVB98B-EN
Copyright
This document and the information in it are the property of
Trane, and may not be used or reproduced in whole or in
part without written permission. Trane reserves the right
to revise this publication at any time, and to make changes
to its content without obligation to notify any person of
such revision or change.
Trademarks
All trademarks referenced in this document are the
trademarks of their respective owners.
Revision History
Added Factory Preset List (Table 1, p. 9).
Introduction
The purpose of this service bulletin is to provide
information for verification of correct values for certain
factory-preset tuning parameters.
The action described in this bulletin is not being
taken to address a safety concern.
Affected Units
All Intellipak™ units.
Discussion
Rooftop units with Intellipak controls (S-HF 20 through 75
Tons and S-HG 90 through 130 Tons units) contain
parameters - adjustable through the human interface
module - that ‘tune’ the control loops.
Values for these parameters are downloaded at the
factory. If the values are wrong, poor temperature or
pressure control can result. In particular, the following
symptoms have been observed:
• Even with a call for cooling, the economizer seems
stuck at some position between minimum and 100%.
• With a call for cooling, compressors are not operating.
• On a VAV unit, the supply air temperature is offset 6 to
10ºF above setpoint.
Some units with serial numbers between J93K and J94D
have one or more incorrect preset values for these
parameters.
Corrective Action
1. Press the SETUP key on the Human Interface module.
Using the NEXT or PREVIOUS key, scroll to this
display:
2. Press the ENTER key. Then, as you press the NEXT key
repeatedly, you will see a series of displays that show
the values of Control Algorithm Tuning Parameters.
3. Figure 1 represents the entire list of displays, showing
the correct factory-preset values. Any particular unit
will contain only a portion of this list of displays.
WARNING
Personal Protective Equipment (PPE)
Required!
Failure to wear proper PPE for the job being undertaken
could result in death or serious injury. Technicians, in
order to protect themselves from potential electrical,
mechanical, and chemical hazards, MUST follow
precautions in this manual and on the tags, stickers,
and labels, as well as the instructions below:
• Before installing/servicing this unit, technicians
MUST put on all PPE required for the work being
undertaken (Examples; cut resistant gloves/sleeves,
butyl gloves, safety glasses, hard hat/bump cap, fall
protection, electrical PPE and arc flash clothing).
ALWAYS refer to appropriate Material Safety Data
Sheets (MSDS)/Safety Data Sheets (SDS) and OSHA
guidelines for proper PPE.
• When working with or around hazardous chemicals,
ALWAYS refer to the appropriate MSDS/SDS and
OSHA/GHS (Global Harmonized System of
Classification and Labelling of Chemicals) guidelines
for information on allowable personal exposure
levels, proper respiratory protection and handling
instructions.
• If there is a risk of energized electrical contact, arc, or
flash, technicians MUST put on all PPE in accordance
with OSHA, NFPA 70E, or other country-specific
requirements for arc flash protection, PRIOR to
servicing the unit. NEVER PERFORM ANY
SWITCHING, DISCONNECTING, OR VOLTAGE
TESTING WITHOUT PROPER ELECTRICAL PPE AND
ARC FLASH CLOTHING. ENSURE ELECTRICAL
METERS AND EQUIPMENT ARE PROPERLY RATED
FOR INTENDED VOLTAGE.
WARNING
Proper Field Wiring and Grounding
Required!
All field wiring MUST be performed by qualified
personnel. Improperly installed and grounded field
wiring poses FIRE and ELECTROCUTION hazards. To
avoid these hazards, you MUST follow requirements for
field wiring installation and grounding as described in
NEC and your local/state electrical codes. Failure to
follow code could result in death or serious injury. Control Algorithm Tuning Parameters
Press Enter to View or Adjust

RT-SVB98B-EN 3
4. Referring to Figure 1, if a value other than the factory
preset is shown, place the cursor beneath that value
and press the + and - keys to adjust it to the factory
preset value. Then press the ENTER key to set the
change. The display will prompt you to enter a
password.
The password is “+ + - +”. After entering the password,
press the ENTER key again. It won’t be necessary to
enter the password again for the next 15 minutes.
Important: The factory-preset values have been chosen
to provide stable but responsive control
loops. These values MUST NOT be further
adjusted from the factory presets.
Figure 1. Control algorithm tuning parameter setup
submenu screens
Screen always shown
Control Algorithm Tuning Parameters
Press ENTER to Review or Adjust
Screen shown only for units with Dehumidification Installed
SA Reheat Control Gains
Proportional XX.X %/F Reset Time XXX Sec
└─┬─┘ └─┬─┘
Range 0.2-20.0 Range 5-600
Default 3.3 Default 50
Note: “XXX Sec” field becomes “DISABLE” if > 3600 seconds
Screen shown only for VAV or SZVAV units
V
AV Cooling Control Gains
Proportional XX.X %/F Reset Time XXX Sec
└─┬─┘ └─┬─┘
Range 0.2-20.0 Range 5-600
Default 3.3 Default 50
Note: “XXX Sec” field becomes “DISABLE” if > 3600 seconds
Screen shown only for IntelliPak II VAV or SZVAV units with Electric heat installed
V
AV Heating Control Gains
Proportional XX.X %/F Reset Time XXX Sec
└─┬─┘ └─┬─┘
Range 0.2-20.0 Range 5-600
Default 3.3 Default 50
Note: “XXX Sec” field becomes “DISABLE” if > 3600 seconds
Screen shown only for units with Air Economizer installed
Range 0.2-20.0
Default 2.0
┌─┴─┐
Econ SA Cntl Gain: Proportional XX.X %/F
Reset Time XXX Sec Rate Time XXX Sec
└─┬─┘ └─┬─┘
Range 5-600 Range 0-100
Default 75 Default 0
NOTE: Referred to as “VAV Occ Econ Ctrl Gains” in IPC documentation

4RT-SVB98B-EN
Screen shown only for units with Hydronic Heat or Modulating Gas Heat installed
Range 0.2-20.0
Default 2.0
┌─┴─┐
M
od Heat Gains Proportional XX.X %/F
Reset Time XXX Sec Rate Time XXX Sec
└─┬─┘ └─┬─┘
Range 5-600 Range 0-100
Default 90 Default 0
Screen shown only for CV units
Zone Control Occupied Cooling Gains
Proportional XX.X %/F Reset Time XXX Sec
└─┬─┘ └─┬─┘
Range 2.0-200.0 Range 90-3600
Default 90 Default 1800
Note: “XXX Sec” field becomes “DISABLE” if > 3600 seconds
Screen shown only for CV units
Zone Control Occupied Cooling Gains
Proport Bias XXX %
M
ax Cy Rate X.X CPH
└─┬─┘ └─┬─┘
Range 0-400 Range 1.5-6.0
Default 0 Default 3.0
Screen shown only for CV units with Air Economizer, or SZVAV installed
CV Air Economizer Control Gains
When CV
SZVAV Cooling Control Gains
When SZVAV
┌──────────────────┴────────────────────┐
XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX
Proportional XX.X %/F Reset Time XXX Sec
└─┬─┘ └─┬─┘
Range 0.2-50.0 Range 90-3600
Default
CV Air: 10.0
SZVAV: 6
Default
CV Air: Disable
SZVAV: 1200
Note: “XXX Sec” field becomes “DISABLE” if > 3600 seconds

RT-SVB98B-EN 5
Screen shown only for CV units with Air Economizer, or SZVAV installed
CV
CV Air Econ Control Rate Time
SZVAV
SZVAV Cooling Control Rate Time Default 0
┌─────────────────┴───────────────────┐┌─┴─┐
XXXXXXXXXXXXXXXXXXXXXX XXXXXXXXX XXX Sec
Proport Bias XX °F
└─┬─┘
Range 0-40
Default 5
Screen shown only for units with Staged Gas or Electric Heat installed
Zone Control Occupied Heating Gains
Proportional XX.X %/F Reset Time XXX Sec
└─┬─┘ └─┬─┘
Range 2.0-200.0 Range 90-3600
Default 30.0 Default 1800
Note 1 : “XXX Sec” field becomes “DISABLE” if > 3600 seconds
Note 2: The Proportional Gain parameter depends on the number of configured heat stages for proper algorithm
performance. The HI will automatically adjust this parameter to the proper setting defined below if it detects the
incorrect value for the number of configured heat stages. If heat stages are not configured it will place 30 %/F in the
field as a default until heat stages are configured. This will happen once at power up if needed and applies to all units.
Product Staged Heat Type Number of
Sta
g
es
Proportional Gain
IPak I Gas 2 30.0 %/F
IPak I Electric 3 45.0 %/F
IPak II Gas 2 30.0 %/F
IPak II Electric - 90 kw 3 45.0 %/F
IPak II Electric – 140 kw 4 60.0 %/F
IPak II Electric – 265 kw 5 75.0 %/F
Ipak II Electric - 300 kw 5 75.0 %/F
Screen shown only for units with Staged Gas or Electric Heat installed
Zone Control Occupied Heating Gains
Proport Bias XXX %
M
ax Cy Rate X.X CPH
└─┬─┘ └─┬─┘
Range 0-400 Range 1.5-6.0
Default 0 Default 5.0
Zone Control Modulating Heat Gain When CV
SZVAV Heating Control Gains When SZVAV
┌──────────────────┴────────────────────┐
XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX
Proportional XX.X %/F Reset Time XXX Sec
└─┬─┘ └─┬─┘
Range 0.2-50.0 Range 90-3600
Default 8.0 Default 1200
Note: “XXX Sec” field becomes “DISABLE” if > 3600 seconds

6RT-SVB98B-EN
Screen shown only for units with Modulating Gas or Hydronic Heat installed
Zone Control Modulating Heat
When CV
SZVAV Heating Control Gains
When SZVAV
┌──────────────────┴────────────────────┐
XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX
Proport Bias XXX °F Rate Time XXX Sec
└─┬─┘ └─┬─┘
Range 0-40 Range 0-100
Default 0 Default 0
Screen shown only for units with Modulating Gas or Hydronic Heat installed
Zone Control Modulating Heat
Supply Air Temp High Limit XX.X °F
└─┬─┘
Range 80-140
Default 120
Screen shown only for VAV units
Supply Air Pressure Gain
Proportional XX.X %/IWC Reset Time XXX Sec
└─┬─┘ └─┬─┘
Range 0.2-20.0 Range 1-60
Default 3.3 Default 5
Screen shown only for IntelliPak II units with Return Fan VFD installed
Return Plenum Pressure Gain
Proportional XX.X %/F Reset Time XX Sec
└──┬──┘ └─┬─┘
Range 0.2-20.0 Range 1.0-60.0
Default 3.3 Default 5.0
Link
Screen shown only for units with VCM installed
Range 20-2000
Default 100
┌─┴─┐
M
in OA Flow Gain: Proportion XXXXX %/CFM
Reset Time XXX Sec Rate Time XXX Sec
└─┬─┘ └─┬─┘
Range 0-600 Range 0-100
Default 10 Default 0

RT-SVB98B-EN 7
Screen shown only for units with Power Exhaust with Statitrac installed and Reset Time set to DISABLE
Space Pressure Control
Integral Gain XX.X %/IWC
└─┬─┘
Range 0.5-60.0
Default 6.0
or
Screen shown only on units with Power Exhaust or Return Fan with Statitrac installed
(with IntelliPak II RTM, ECEM and HI)
Range 0.2-20.0
Default 0.5
┌─┴─┐
Space Press Control: Prop: XX.X %/IWC
Reset Time XXXXXXX Feedforward XXX %
└───┬───┘ └─┬─┘
Range 1-1000 s
Range 0-100
Default 17 s
Default 80
Note: “XXXXs” field becomes “DISABLE” and “Prop:” and “Feedforward:” items are not shown if Reset Time > 1000 s
on Ipak 1 units only
Screen shown only for RT or RT AH units with DX Cooling
Low Ambient Fan Control Gain
Proportional XX.X %/F Reset Time XXX Sec
└─┬─┘ └─┬─┘
Range 0.2-20.0
Range 5-600
Default 2.0
Default 90
Screen shown only for RT or RT AH units with DX Cooling
Low Ambient Fan Control Gain
Rate Time XXX Sec
└─┬─┘
Range 0.0-50.0
Default 0
Screen shown only for units with Energy Recovery Installed
Exhaust Air Bypass Damper Control Gain
Proportional XX.X %/F Reset Time XXX Sec
└─┬─┘ └─┬─┘
Range 0.2-20.0
Range 1-200
Default 5.0
Default 5

8RT-SVB98B-EN
Screen shown only for units with Energy Recovery Installed
Exhaust Air Bypass Damper Control Gain
Rate Time XXX Sec
└─┬─┘
Range 0.0-100.0
Default 0
One of the following two screens will be shown:
Only if Energy Recovery Installed and value is greater than 0.
Range 1-255 and Disable
Default 3 Min
┌─┴─┐
Energy Wheel Off Delay Time: XXX
M
in
Turn Wheel Off When Temp Above Setpoint
“Disable” is displayed when the value is incremented above 255. A selection of “Disable” disables wheel shutoff
changes to screen below and allows continuous wheel operation when conditions permit.
Only if Energy Recovery Installed and value is equal to Disable.
Energy Wheel Off Delay Time: Disable
W
heel Remains On Until Call For Cooling
Screen shown only on units with Rapid Restart or Dehumidification installed
Range 15 - 50
Default 30
┌─┴─┐
Rapid DX Interstage Timing: XXX Sec
Screen shown if in this submenu
End Of Submenu (NEXT) To Enter SETUP

RT-SVB98B-EN 9
Questions
If you have questions and are a Trane Distributor or a
Commercial Sales Office, contact Large Commercial
Technical Support in Clarksville, TN. If you are not a Trane
distributor or a Commercial Sales Office, contact the local
Trane distributor or a commercial sales office.
Table 1. Factory presets list
Adjustable Function Factory Preset Changed To
To adjust
press...
CIPD Sensitivity Parameters
Circuit 1 CIPD Sensitivity 30 ___________ Setup
Circuit 2 CIPD Sensitivity 30 ___________ Setup
Control Algorithm Tuning Parameters (Partial)(a)
VAV Cooling Control Gains
Proportional (w-VSC / wo-VSC) (2.0%/F/3.3%/F) ___________ Setup
Reset Time (w-VSC/wo-VSC) (100 Sec/50 Sec) ___________ Setup
CV Air Economizer Control Gains
Proportional 10.0% F ___________ Setup
Reset Time DISABLE ___________ Setup
Rate Time 0 Sec ___________ Setup
Bias 0 deg F ___________ Setup
SZVAV Cooling Control Gains
Proportional 6.0% F ___________ Setup
Reset Time 1200 Sec ___________ Setup
Rate Time 0 Sec ___________ Setup
Bias 0 deg F ___________ Setup
Zone Control Modulating Heat Gains
Proportional 10.0% F ___________ Setup
Reset Time DISABLE ___________ Setup
Rate Time 0 Sec ___________ Setup
Bias 0 deg F ___________ Setup
SZVAV Heating Control Gains
Proportional 8.0% F ___________ Setup
Reset Time 1200 Sec ___________ Setup
Rate Time 0 Sec ___________ Setup
Bias 0 deg F ___________ Setup
(a) Field replacement of control modules requires proper human interface setup to insure unit performance.

Ingersoll Rand (NYSE:IR) advances the quality of life by creating comfortable, sustainable and efficient environments.
Our people and our family of brands—including Club Car®, Ingersoll Rand®, Thermo King® and Trane®—work together
to enhance the quality and comfort of air in homes and buildings; transport and protect food and perishables; and
increase industrial productivity and efficiency. We are a $13 billion global business committed to a world of sustainable
progress and enduring results. For more information, visit www.ingersollrand.com.
Ingersoll Rand has a policy of continuous product and product data improvement and reserves the right to change design and specifications without notice.
We are committed to using environmentally
conscious print practices that reduce waste.
© 2016 Ingersoll Rand All rights reserved
RT-SVA98B-EN 08 Mar 2016
Supersedes RT-SVB98A-EN (29 Mar 2012)
