INISOL NEO 2.1 Manual

EN
Flat solar panels
NEO 2.1 / SUN 211
Installation and
Service Manual
Roof-integral
Installation
17° to 65°
mechanical tiles
300024195-001-02

Contents
1 Introduction ................................................................................................4
1.1 Symbols used .......................................................4
1.2 General ..................................................................5
1.2.1 Manufacturer’s liability .............................................5
1.2.2 Installer’s liability .....................................................5
1.2.3 User’s liability ..........................................................5
2Safety instructions and recommendations ..............................................7
2.1 Safety instructions ...............................................7
2.2 Recommendations ................................................7
3Technical description ................................................................................8
3.1 Operating principle ...............................................8
3.2 Technical specifications ......................................8
3.2.1 Solar collectors ........................................................8
3.2.2 Load loss curve .......................................................9
4Installation ................................................................................................10
4.1 Regulations governing installation ...................10
4.2 Package list .........................................................11
4.3 Main dimensions .................................................14
4.4 Installation diagrams ..........................................15
4.4.1 Vertical assembly, juxtaposed ...............................15
4.4.2 Example of an installation .....................................16
4.5 Assembling the solar collectors .......................17
4.5.1 Warning .................................................................17
4.5.2 Tools required .......................................................18
4.5.3 Dimensions ...........................................................19
4.5.4 Clearance to allow for ...........................................20
4.5.5 Fitting the battens ..................................................21
4.5.6 Mounting for an installation with 2 collectors .........22
4.5.7 Mounting for a system with up to 5 collectors .......37
4.5.8 Mounting for an installation with 1 collector ..........55
4.5.9 Put the tiles in place ..............................................66
4.6 Hydraulic connections .......................................67
4.6.1 Connection dimensions .........................................67
4.6.2 Connecting ............................................................67
4.6.3 Pipe insulation .......................................................68
120/02/2013 - 300024195-001-02

4.7 Filling the system ...............................................68
5 Commissioning ........................................................................................70
5.1 Check points before commissioning ................70
5.2 Commissioning ...................................................70
6 Checking and maintenance .....................................................................71
6.1 General instructions ...........................................71
7 Spare parts ................................................................................................72
7.1 General ................................................................72
7.2 Spare parts ..........................................................72
Contents
220/02/2013 - 300024195-001-02

320/02/2013 - 300024195-001-02

1 Introduction
1.1 Symbols used
In these instructions, various danger levels are employed to draw the
user’s attention to particular information. In so doing, we wish to
safeguard the user’s safety, obviate hazards and guarantee correct
operation of the appliance.
DANGER
Risk of a dangerous situation causing serious physical
injury.
WARNING
Risk of a dangerous situation causing slight physical
injury.
CAUTION
Risk of material damage.
Signals important information.
¼Signals a referral to other instructions or other pages in the
instructions.
Caution: Risk of being burnt.
Zone susceptible to snow.
Zone susceptible to windy conditions.
NEO 2.1 / SUN 211 1. Introduction
20/02/2013 - 300024195-001-02 4

1.2 General
1.2.1. Manufacturer’s liability
Our products are manufactured in compliance with the requirements
of the various applicable European Directives. They are therefore
delivered with [ marking and all relevant documentation.
In the interest of customers, we are continuously endeavouring to
make improvements in product quality. All the specifications stated in
this document are therefore subject to change without notice.
Our liability as the manufacturer may not be invoked in the following
cases:
4Failure to abide by the instructions on using the appliance.
4Faulty or insufficient maintenance of the appliance.
4Failure to abide by the instructions on installing the appliance.
1.2.2. Installer’s liability
The installer is responsible for the installation and inital start up of the
appliance. The installer must respect the following instructions:
4Read and follow the instructions given in the manuals provided
with the appliance.
4Carry out installation in compliance with the prevailing legislation
and standards.
4Perform the initial start up and carry out any checks necessary.
4Explain the installation to the user.
4If a maintenance is necessary, warn the user of the obligation to
check the appliance and maintain it in good working order.
4Give all the instruction manuals to the user.
1.2.3. User’s liability
To guarantee optimum operation of the appliance, the user must
respect the following instructions:
4Read and follow the instructions given in the manuals provided
with the appliance.
4Call on qualified professionals to carry out installation and initial
start up.
4Get your installer to explain your installation to you.
4Have the required checks and services done.
4Keep the instruction manuals in good condition close to the
appliance.
1. Introduction NEO 2.1 / SUN 211
520/02/2013 - 300024195-001-02

This appliance is not intended to be used by persons (including
children) whose physcial, sensory or mental capacity is impaired or
persons with no experience or knowledge, unless they have the
benefit, through the intermediary of a person responsible for their
safety, of supervision or prior instructions regarding use of the
appliance. Care should be taken to ensure that children do not play
with the appliance.
To prevent hazardous situations from arising, if the mains lead is
damaged it must be replaced by the original manufacturer, the
manufacturer’s dealer or another suitably skilled person.
NEO 2.1 / SUN 211 1. Introduction
20/02/2013 - 300024195-001-02 6

2 Safety instructions and
recommendations
2.1 Safety instructions
DANGER
The permissible roof load of the building must not at any
time be exceeded. If necessary, a structural engineer
should be consulted before commencing work.
WARNING
Only a qualified professional may carry out the installation
in conformity with in force legislation and standards.
CAUTION
Do not neglect to service the appliance. Contact a qualified
professional or take out a maintenance contract for the
annual servicing of the appliance.
2.2 Recommendations
WARNING
4Any operation on the installation must be performed
by a qualified technician respecting professional
regulations and in accordance with this document.
4When making the connections, it is imperative that
the standards and corresponding local directives are
respected.
4The flat solar panels and fittings should be handled carefully during
transportation and storage. If the packing has nevertheless been
damaged during transit, the damage must be reported
immediately to and claimed against the carrier.
4The contents of the assembly kit must be checked before
installation against the list which accompnaies each kit.
4When installing the panels, take note of the safety instructions in
this document.
4The packing material should be properly disposed of after
installation.
4Insulate the pipes in rooms that are not heated (cellars and lofts).
4Check regularly that the installation contains water and is
pressurised.
4Service the appliance regularly to ensure that it operates correctly.
2. Safety instructions and recommendations NEO 2.1 / SUN 211
720/02/2013 - 300024195-001-02

3 Technical description
3.1 Operating principle
The short-wave solar radiation (sunlight) striking the solar panel is
converted into heat by the selective coating on the absorber. From
there it is transferred by heat conduction to the absorber pipe and
carried by the heat-transporting fluid to the calorifier. The solar-panel
fluid heats the calorifier by means of the energy absorbed from the
sun and cools down itself in the process. The cooled heat-transporting
fluid then flows back to the solar panel in order to collect more solar
energy. An intelligent control system ensures that the circulation
system is only active when there is sufficient solar radiation, thus
optimising the collection of solar energy.
3.2 Technical specifications
3.2.1. Solar collectors
Length mm 1960
Width mm 1060
Height mm 70
Weight kg 34,45
Gross collector area AGm22,1
Inlet surface Aa m21,88
Absorber surface AAm21,90
Water content litres 1,2
Maximum operating pressure bar 10
Testing pressure bar 15
Optical efficiency ηo 0,773
Loss rating a1W/m2.K 3,676
Loss rating a2W/m2.K 0,0143
Stagnation temperature °C 180
Hydraulic connections mm 12
Pressure drop mbar See below
Fitted tilt angle
minimum/maximum
° 17 to 65
NEO 2.1 / SUN 211 3. Technical description
20/02/2013 - 300024195-001-02 8

3.2.2. Load loss curve
APressure drop (mbar)
ZMass flow (Kg/h)
0
50
100
150
200
250
300
350
400
0 50 100 150 200 250 300
1
2M002031-A
3. Technical description NEO 2.1 / SUN 211
920/02/2013 - 300024195-001-02

4 Installation
4.1 Regulations governing installation
CAUTION
The installation must be equipped with a protective plastic
film (roof underlay film).
CAUTION
4The installation must comply in all matters to the
standards and rules which govern the work and
interventions in individual and collective homes, and
other constructions.
4The installation and maintenance of the appliance
must be carried out by a qualified professional in
compliance with the statutory texts of the codes of
conduct in force.
4Before installation, make sure that the framework is
solid and strong enough to comply with the static
requirements.
4Solar installations must be earthed to protect them
against lightning.
4Protection of the environment: Place a container of
sufficient volume under the drain pipe and the valve
discharge pipe.
4The roof mounting pack makes it possible to install
the solar collectors on roofs with structures
presenting a minimum incline of 17°.
4The roof-integral installation set is designed specifically as a
mounting system for the NEO 2.1 flat solar panels and may only
be used in accordance with their building regulations approval.
4The mounting kit is designed for roof coverings in standard
mechanical roman roof tiles for the South of France.
4The water drainage channels on the membrane should run into
the eaves (roof gutter).
4The installation should therefore not be flushed or filled when the
collectors are hot (in strong sunshine).
4The solar system must at all times be filled with heat transporting
fluid.
M001788-A
M002132-A
NEO 2.1 / SUN 211 4. Installation
20/02/2013 - 300024195-001-02 10

4.2 Package list
M001801-B
ER45 ER193
(5x)
(5x)
(2x)
(2x)
M001802-B
ER194 ER195
(10x)
(10x)
(4x)
(4x)
(5x)
(5x)
(2x)
(2x)
4. Installation NEO 2.1 / SUN 211
11 20/02/2013 - 300024195-001-02

M002133-C
ER190 ER191
(7x) (7x)
(10x)
(10x)
(10x)
(12x)
(2x)
(1x)
(2x)
(20x)
(12x)
(1x)
M002134-C
ER192
(1x)
(2x)
(2x)
(1x)
(1x)
(2x)
(2x)
(2x)
(1x)
30
ER236
C003463-C
NEO 2.1 / SUN 211 4. Installation
20/02/2013 - 300024195-001-02 12

Pack no. Article no. Description Packages needed to construct the installation depending
on the number of solar collectors
1 2 3 4 5
ER 45 100013471 Solar collector 1 2 3 4 5
ER 193 100017965 Mounting kit 1 panel 1
ER 194 100017966 Mounting kit for 2 collectors 1 1 1 1
ER 195 100017967 Mounting kit for extension 123
ER 190 100015204 Sheet metal plate kit for 1 collector 1
ER 191 100015205 Sheet metal plate kit for 2 collectors 1 1 1 1
ER 192 100015206 Sheet metal plate kit for extension 123
ER 235 100017997 Waterproofing kit for integration of 1
collectors
1
ER 236 100017998 Waterproofing kit for integration of 2
collectors
1 2 3 4
ER 67 100013503 Hydraulic connection kit 1 1 1 1 1
ER 68 100013504 Hydraulic connection kit: Bridge 180°
DN12 230 mm
1 2 3 4
ER235
C003478-D
M001805-A
ER67 ER68
4. Installation NEO 2.1 / SUN 211
13 20/02/2013 - 300024195-001-02

4.3 Main dimensions
ASolar collector inlet
ZSolar collector outlet
ESolar sensor probe
M001740-A
1060
113,5 113,5
175,5
371960
70
321 2 31
NEO 2.1 / SUN 211 4. Installation
20/02/2013 - 300024195-001-02 14

4.4 Installation diagrams
It is permitted to assemble a maximum of 5 interlinked
collectors.
4.4.1. Vertical assembly, juxtaposed
4Connection for 1 to 5 collectors.
CAUTION
Place the collector sensor on the flow side of the solar
circuit (flow from the hottest collector).
A: Solar sensor probe.
CAUTION
Recommended mounting: Sensor A located at the top of
the collector.
CAUTION
If sensor A is located at the bottom of the collector, it is
necessary to use a batten from your delivery of a max.
height of 45 mm (¼ "Dimensions", page 19).
M001754-B
A
M001775-B
A
4. Installation NEO 2.1 / SUN 211
15 20/02/2013 - 300024195-001-02

4.4.2. Example of an installation
4Pressure gauge
17 Drain cock
57 Domestic hot water outlet
61 Thermometer
84 Stop valve with releasable non-return valve
85 Primary solar circuit pump
87 6-bar calibrated safety valve (primary solar)
88 Expansion vessel
89 Heat transfer fluid container
109 Domestic hot water thermostatic mixing valve
112a Solar sensor probe
112b Domestic hot water sensor
114 Solar circuit drainage valve
126 Solar regulator
129 Duo-Tube
130 Manual bleed degasser
131 Flat or tubular solar panel
M001806-C
109
130
89
230V
50Hz
114
61
88
61 61
87
85
4
84
114
NEO 2.1 / SUN 211 4. Installation
20/02/2013 - 300024195-001-02 16

4.5 Assembling the solar collectors
4.5.1. Warning
M001748-A
4. Installation NEO 2.1 / SUN 211
17 20/02/2013 - 300024195-001-02

4.5.2. Tools required
M001719-B
10 10
NEO 2.1 / SUN 211 4. Installation
20/02/2013 - 300024195-001-02 18

4.5.3. Dimensions
AExisting batten
ZStarting batten to be laid, not provided (Width: 45 mm)
EFastening batten to be fitted supplied
RFixing lugs to be put in place on the starting batten
TProtective tarpaulin
Number of panels 1 2 3 4 5
Size A1147 2210 3273 4336 5400
M002135-D
4
4 4 4 4
370
430 1980
2410
A
400 66066016580
10 10
17-65°
550
3
5
2
1
4. Installation NEO 2.1 / SUN 211
19 20/02/2013 - 300024195-001-02
Table of contents
Popular Solar Panel manuals by other brands

Goalo
Goalo escape 30M reference guide

moovo
moovo KSM001 Installation and use instructions and warnings

Atlantic
Atlantic Solar Plan 500V INSTALLATION AND UTILISATION MANUAL

Gasolarxy
Gasolarxy PG-GSP150W quick start guide

ESDEC
ESDEC CLICKFIT BASIC manual

MHG Heating
MHG Heating SolarMat FL/K 420 Installation and operating manual

Viessmann
Viessmann VITOSOL-F installation instructions

Thermo King
Thermo King ThermoLite installation guide

Thunderbolt Magnum Solar
Thunderbolt Magnum Solar 57970 Owner's manual & safety instructions

Xantrex
Xantrex 781-0110 installation guide

REC
REC REC235 Series installation manual

Xstream
Xstream Flat Plate Collector Mounting Installation Instructions
