ESDEC CLICKFIT BASIC User manual

EN
MOUNTING SYSTEM FOR BITUMEN / EPDM
MANUAL
© ESDEC BV 2015
Rev. 10.06.15
mounting system for uninsulated pitched roof
Bitumen / EPDM for solar panels
portrait / landscape setup

Rev. 10.06.15 MANUAL MOUNTING SYSTEM FOR PITCHED ROOF WITH BITUMEN
TABLE OF CONTENT
pag
1. Introduction 1
2. General installation conditions 1
3. Product description 3
4. Parts overview 3
4.1 Exploded-view 3
4.2 Bill of materials 4
5. Mounting preparation 5
5.1 Monitoring tools and accessories 5
5.2 Determining position of solar panels and measuring 6
5.3 Cleaning roof 6
6. Installation 7
6.1 Preinstall suspension sockets on solar panels (only with portrait) 7
6.2 Preinstall connecting strips 7
6.3 Attaching mounting brackets 8
6.4 Attaching mounting rail 9
6.5 Hanging solar panels to mounting rail (only with portrait) 10
6.6 Mounting 1st solar panel on the rail 11
6.7 Mounting other solar panels on the rail 12
6.8 Final assembly / multiple rows under each other 13
7. Annex 14
THIS INSTALLATION MANUAL SHOULD BE RETAINED WELL FOR FUTURE REFERENCE!
For the duration and conditions regarding warranty we recommend contacting your dealer. Furthermore, we refer to our General
Terms and Conditions of the sale which are available on request.
The manufacturer declines all responsibility for damage or injury resulting from failure to strictly follow this installation manual and
failure to observe normal caution in handling, installation and use of the ClickFit mounting system.
As a result of constant efforts to improve it may happen that the product differs in detail from what is described in this manual. For
this reason the given instructions serve only as a guideline for installing the product mentioned in this manual.
This manual has been prepared with all due care, but the manufacturer can not be held responsible for any errors in this manual or
the consequences thereof.
In addition, all rights are reserved and nothin may be reproduced from this manual in any way.

01
Rev. 10.06.15 MANUAL MOUNTING SYSTEM FOR PITCHED ROOF WITH BITUMEN
1. Introduction
This manual describes the installation of the ClickFit mounting system for an uninsulated pitched roof with bitumen / EPDM
(for solar panels in portait / landscape setup).
Read the manual carefully so you are fully informed of the contents of the manual. Follow the instructions in the manual
carefully. Perform the operations in the correct order.
Keep the manual in a safe and dry place. Should the manual get lost then there is the possibility to request a new one from
Esdec BV.
2. General installation conditions
In general
Non-compliance with the requirements mentioned in this document may result in invalidation of all warranty and product liability claims.
The data, comments and opinions in this document are binding and must be checked for completeness and timeliness. Esdec BV
reserves the right to modify this document without notice.
Stability and condition of the roof
The roof should be in good condition and strong enough to bear the weight of the solar panels incl. the additional materials, wind and
snow loads. Check the stability of the roof and adjust the roof / construction where necessary, in in doubt contact a manufacturer. Ensure
that the load reserve of the roof is exceeded not locally or in its entirety.
Safety Warnings
• The installation of the ClickFit system must by default be performed by qualied technical personnel (at least 2 skilled people).
• Adding or removing parts may have an adverse effect on the function and is absolutely not advised!
• For placement of the solar panels to the roof must be clean, dry, at and free from algae etc.
• Avoid mounting with strong winds and a slippery wet roof surface.
• Work on a pitched roof always with fall protection, and if necessary with safety nets and edge protection.
• Be aware !: Never stand in the gutter.
• Wear shoes with reinforced toe and sturdy non-slip soles.
• Always wear proper protective clothing when performing the work.
• Always use a lifting aid / lift installation when moving the equipment (solar panels, etc.).
• Always place a ladder on a rm stable surface.
• Always place the ladder at an angle of about 75º and leave it sticking out above the roof edge for about 1 meter.
• If possible, secure the ladder to the top with a rope or strap.
• Preferably work according to manual “work safely on roofs”.
Scope ClickFit
• Wind zone (1 t/m 3)
• Roof height (3-9m) When your roof is higher you should contact your supplier.
• Type of roong: Bitumen / EPDM
• Roof pitch: Between 10 - 60 degrees (35 degrees is best)
Edge zone
The distance from the solar panels to the ridge and gutter should be at least 30 cm due the wind load. The distance from solar panels to
the side of the roof should be at least 30 cm. There shouldn’t be solar panels in this area, in its entirety nor in part.
Dimensioning
All dimensions and sizes are in cm unless stated otherwise.

Standards, requirement and regulations
Upon installation of the mounting system, it is important to follow the installation instructions and the related standards for
the prevention of accidents. In particular, observe the following standards, requirements and regulations:
• Building Decree Construction
• PPE Personal Protective Equipment
• KEMA Testing of Electrotechnical Materials
• DIN 1055 Design loads for buildings
• DIN 18299 General rules for all construction sectors
• DIN 18451 Scaffolds
Removal and disassembly
Remove the product according to local laws and regulations. At the end of the life span all materials are recyclable.
Warranty
Warranty according to warranty conditions and terms of Esdec BV. These can be found on the website www.esdec.nl.
Liability
The manufacturer accepts no liability for damage or injury caused by not (strictly) observing the safety regulations and
instructions in this manual or by carelessness during installation of the product mentioned in this document and any related
accessories.
• subject to misprints
02
Rev. 10.06.15 MANUAL MOUNTING SYSTEM FOR PITCHED ROOF WITH BITUMEN

3. Product Description
The ClickFit mounting system consists of mounting brackets, mounting rails and the necessary installation materials to
mount the solar panels in portrait or landscape setup on the roof. The ClickFit mounting system for bitumen / EPDM can be
used for all types of bitumen / EPDM.
Mounting system
The mounting brackets are secured to the bitumen roof using chipboard screws. Because the mounting brackets are
attached to the roof boarding, one can determine freely the location of the solar panels on the roof. Differences in height in
the roof can easily be lled by means of a special increment block (optional). In order to prevent leakage, at the bottom of
the mounting brackets a layer of Tixophalte kit is applied. In an EPDM roof at the bottom of the mounting brackets it is an
option to use as a water stop a self-adhesive sealing tape EPDM instead of the Tixophalte kit layer.
Attachment of the mounting rail
The mounting rail is attached to the mounting brackets by means of a snap connection. For this purpose, no further
materials or tools are needed.
Attachment of the panels
The handy assembly aid contributes to the quick and safe installation and also serves as sliding protection for the solar
panels. The solar panels are attached by means of universal module clamping plates, end clamps and mounting screws.
The mounting screws are screwed directly to the mounting rail in which is a special thread installed.
4. Parts overview
432
1
8
5
6
7
12
11
15
14
13
10
9
16
17
4.1 Exploded-view
03
Rev. 10.06.15 MANUAL MOUNTING SYSTEM FOR PITCHED ROOF WITH BITUMEN

1. Solar panel
2. RVS Hex bolt M6 x 20
Article nr: 100-0620
3. Nylon suspension socket
Article nr: 100-9001
4. RVS Hexagon nut M6
Article nr: 100-0600
5. Mounting rail
Article nr: 100-1001
6. Connection strip pro
Article nr: 100-3040
11. End clamp
End clamp CFA
Article nr: 100-3003
End clamp CFB
Article nr: 100-3004
For type see annex ch. 7
12. Mounting screw 6,5 x__
Article nr: 100-65__
For type see annex ch. 7
13. Module clamping plate
Article nr: 100-3020
8. Mounting bracket
Article nr: 100-2060
14. End cap Black (optional)
Article nr: 100-3030
15. Color cap Black (optional)
Article nr: 100-6500
4.2 Bill of materials
04
Rev. 10.06.15 MANUAL MOUNTING SYSTEM FOR PITCHED ROOF WITH BITUMEN
11A. End clamp Black (optional)
End clamp CFA Black
Article nr: 100-3950
End clamp CFB Black
Article nr: 100-3951
For type see annex ch. 7
13A. Module clamping plate
Black (optional)
Article nr: 100-3952
6A. Mounting screw 6,5 x 19
Article nr: 100-6519
7. Chip board screw 5,0 x 40
Article nr: 100-3540
8A. Increment block 15 mm
(optional)
Article nr: 100-3065
16. Tixophalte kit
Article nr: 100-3900
17. Self-adhesive EPDM
sealing tape 30 mm
(optional)
Article nr: 100-0005
9. RVS Hex bolt M8 x 20 (optional)
Article nr: 100-0820
10. RVS Hex ange bolt M8 (optional)
Article nr: 100-0721

1
2
3
4
5
6
5. Mounting preparation
5.1 Monitoring tools and accessories
and/
or
S10 / S13 S8 PZ2
Here is a list of necessary tools / utilities:
Measuring tape Brush Ratchet with hex cap Cordless Screwdriver
Marker / chalk Kit gun
05
Rev. 10.06.15 MANUAL MOUNTING SYSTEM FOR PITCHED ROOF WITH BITUMEN
Scaffold or stable safe
ladder
Knife

5.2 Determining position of solar panels and measuring
In the determination of the position of the solar panels on the bitumen roof, it is very important to pay attention to the sunlight
coming in throughout the day and throughout the year. Place the panels on a roof surface which has no shadow. Shadow
of a chimney, dormer, trees and nearby buildings have an adverse effect on the amount of energy generated by the solar
panels.
Measuring and marking
For the placing of the solar panel, you need approximately an area of 160x80 cm or 160x100 cm or 200x100 cm per panel
(depending on the type of solar panel).
Make sure that on the roof around the solar panels 30 cm is kept free. In other words,
30 cm from the ridge and the gutter and 30 cm from the sides in connection with wind load.
Mark the contours of the panel eld on the bitumen roof eld with chalk or a marker. Mark the lines where the mounting rails
are coming (on 1 / 4th of the top panel and bottom panel). Mark then where the mounting brackets must be placed ie on the
ends of the mounting rail up to 30 cm apart and furthermore up to 120 cm
apart (See calculator for distance).
06
Rev. 10.06.15 MANUAL MOUNTING SYSTEM FOR PITCHED ROOF WITH BITUMEN
5.3 Cleaning roof
Clean the bitumen / EPDM roof with a brush.
Remove algae, moss, etc. to reduce imperfections to a minimum during installation!
min. 30 cm
min. 30 cm
min. 30 cm
min. 30 cm

6. Installation
6.1 Preinstall suspension on solar panels (only with portrait)
Install per solar panel 2 suspension sockets at the rear of the solar panel (= same side as the connection box). First insert
the RVS hex bolts M6x20 in the available holes in the frame and afx thereon the suspension sockets. Then install the M6
nuts.
6.2 Preinstall connecting strips
You can attach the mounting rails to each other with the supplied connection strips.
Slide the connection strip in the side of the mounting rail and x this using the supplied mounting screws 6,5x19.
The tightening torque of the screw connections is 4,5Nm.
When the total length of the coupled mounting rails is longer than 20m, a dilation of a number of mm is advisable.
07
Rev. 10.06.15 MANUAL MOUNTING SYSTEM FOR PITCHED ROOF WITH BITUMEN

6.3 Attaching mounting brackets
On the basis of the position of the solar panels on the roof, you determine the position of the mounting brackets.
With solar panels in portrait setup the mounting brackets are xed on 1/4 H of the top panel and panel-bottom edge, at
a mutual distance 2/4 H. Divide the mounting brackets proportionally in the assembly line where the rails will be. The
mounting brackets may be positioned up to 120 cm apart (see calculator for distance). Place on the ends an additional
mounting bracket at a mutual distance of about 30 cm.
1. Mark with chalk or marker on the roof in a straight line the place where the mounting brackets should come.
2. Apply with a kit gun, the Tixophalte kit on the underside of the mounting brackets in a closed circle in order to prevent the
screw hole from leaking. (See processing instructions Tixophalte kit)
2A. Optionally, you can also use self-adhesive EPDM sealing tape instead of the Tixophalte kit for example with EPDM
roofs (see annex on page 14)
3. Ensure that the 2 screw holes of the mounting bracket are completely enclosed.
4. Place the mounting brackets along the marked line on the roof. Always place the mounting brackets parallel to each
other. Make sure that the mounting brackets are never placed on the transition seam of the roof sheets, but place them at
least 5 cm from this seam. Screw the mounting bracket to the eaves with the chipboard screw 5,0x40mm.
For this step only screw the top screw. This allows the mounting bracket to still move something, which makes clicking the
mounting rail easier. Use a cordless screwdriver with bit PZ2 until the bracket is tightened and the kit visibly ows out under
the bracket.
5. Make sure that the mounting brackets are mutually aligned.
Be aware: Differences in height in the roof can easily be lled by means of a special increment
block (optional).
With solar panels in landscape setup you go through the same steps above, the only mounting brackets are rotated
90 degrees and the mounting rails are placed vertically and secured on top. (see annex on page 14)
08
Rev. 10.06.15 MANUAL MOUNTING SYSTEM FOR PITCHED ROOF WITH BITUMEN
1
2
3
4
5
6
See Calculator
2
3
4
5
Click !
OPTION
Increment block 15 mm
2/4 H
2/4 H
1/4 H
1
2/4 H
1/4 H

6.4 Attaching mounting rail
1. Position the mounting rail on the mounting brackets. Make sure the mounting bracket are completely perpendicular to the
mounting rail. It is still possible to turn the mounting bracket something because it is only screwed with the top screw.
2. Make sure the tip of the mounting rail protrudes app. 5 cm against to the last mounting bracket.
3. Then click the mounting rail piece by piece to the mounting brackets. Make sure it clicks properly! The mounting brackets
can be sprayed with silicone spray in order to facilitate the clicking.
4. Make sure that the mounting rails are mutually aligned.
5. Screw the lower chipboard screw 5,0x40mm into the mounting brackets.
6. Check that all chipboard screws are tightly screwed.
Make sure the mounting rails are right above each other in connection with the alignment of the
solar panels!
09
Rev. 10.06.15 MANUAL MOUNTING SYSTEM FOR PITCHED ROOF WITH BITUMEN
1
2
3
4
5
6
Click !
min. 30 cm
4e
3e
2e
1e
1
234
5
6
5 cm

6.5 Hanging solar panels to mounting rail (only with portrait)
Temporarily hang the rst solar panel using the preinstalled suspension sockets to the upper mounting rail. This will keep
your hands free for the rest of the installation.
10
Rev. 10.06.15 MANUAL MOUNTING SYSTEM FOR PITCHED ROOF WITH BITUMEN

6.6 Mounting 1st solar panel on mounting rail
Slide the rst solar panel to the side of the mounting rail.
Then slide the end clamp onto the mounting rail. Choose the correct recess so that the end clamp connects to the solar
panel. Leave about 1 cm rail visible protrude next to the end clamp. Then tighten the end clamp with the mounting screw.
The tightening torque of the screw connections is 4,5Nm.
Option: Slide the black end caps in the side of the mounting rails and place the color caps onto the mounting screws.
11
Rev. 10.06.15 MANUAL MOUNTING SYSTEM FOR PITCHED ROOF WITH BITUMEN
X Y
1
2
OPTION
1 cm

6.7 Mounting other solar panels on the rail
Hang the second solar panel on the rail and slide it towards the rst, until a gap remains of about 7mm. Then screw the
mounting screw with a module clamping plate module into the mounting rail. The tightening torque of the screw connections
is 4,5Nm.
Make sure the solar panels are aligned before you tighten the screw! Repeat this with the remaining solar panels. Option:
Place the black color caps over the mounting screws.
12
Rev. 10.06.15 MANUAL MOUNTING SYSTEM FOR PITCHED ROOF WITH BITUMEN
7 mm
OPTION

6.8 Final assembly / multiple rows under each other
1. Slide the end clamp onto the mounting rail. Choose the correct recess so that the end clamp connects to the solar panel.
2. Then tighten the end clamp using the mounting screw. (tightening torque 4,5Nm)
3. To obtain an interconnected panel surface you slide the underlying solar panels after you hung them with the suspension
sockets onto the mounting rail against the upper row of solar panels with a gap of 1-2 cm.
Then you secure the solar panels rmly using the mounting screws, end clamps and module clamping plates to the
mounting rails.
Option: Slide the black end caps in the side of the mounting rails and place the color caps onto the mounting screws.
13
Rev. 10.06.15 MANUAL MOUNTING SYSTEM FOR PITCHED ROOF WITH BITUMEN
1 2
3
OPTION
OPTION
OPTION

7. ANNEX
14
Rev. 10.06.15 MANUAL MOUNTING SYSTEM FOR PITCHED ROOF WITH BITUMEN
Frame height End clamp Screw length
29mm CFA 55 mm
30mm CFA 55 mm
31mm CFB 55 mm
32 mm CFB 55 mm
33 mm CFA 60 mm
34 mm CFA 60 mm
35 mm CFB 60 mm
36 mm CFB 63 mm
37 mm CFA 63 mm
38 mm CFA 63 mm
39 mm CFB 63 mm
40 mm CFB 63 mm
41 mm CFA 70 mm
42 mm CFA 70 mm
43 mm CFB 70 mm
44 mm CFB 70 mm
45 mm CFA 70 mm
46 mm CFA 70 mm
47 mm CFB 75 mm
48 mm CFB 75 mm
49 mm CFA 75 mm
50 mm CFA 75 mm
51 mm CFB 75 mm
52 mm CFB 75 mm
9 cm
12
12
1. Cut with a knife the self-adhesive EPDM sealing tape into pieces
of about 9 cm. Then pull the yellow strip from the tape.
2. Stick the EPDM sealing tape onto the underside of the mounting
brackets. The 2 holes of the mounting bracket should be completely
covered.
Applying EPDM sealing tape
Secure the vertical proles to the top with the RVS hexagonal
bolt M8 x 20 and hex ange bolt M8.
Securing vertical profiles (with landscape setup)
