injen SES9300AB User manual

STAINLESS STEEL EXHAUST SYSTEM
Part Number: SES9300ABInstallation Instructions
YEAR MAKE MODEL ENGINE
20212023FORD BRONCO 2DR & 4DR L42.3L TURBO
20212023FORD BRONCO 2DR & 4DR V62.7L TWIN TURBO

PAGE 1
PARTS INCLUDED
TOOLS REQUIRED
Ratcheting Wrench 10mm socket 15mm socket
A
C
D
B
E
ITEM QTY PART NO. DESCRIPTION
A 1 W-SES9300AB-1 Axle back
B 2 W-SES9300AB-2 Tip extension
C 2 X-17176C Black Ceramic �p 101mm
D 1 M-20121 SS Exhaust hanger bracket
(2.3L models only)
E 2 X-4015 76mm SS Slip fit torsion clamp

PAGE 2
BEFORE YOU BEGIN
Please check the list of parts included and report any defective or missing parts to the authorized Injen dealer you purchased
this product from. Before installing any parts of this system, please read the instructions thoroughly. If you have any questions
regarding installation, please contact your Injen Technology dealer. Installation DOES require some mechanical skills. A
qualied mechanic is always recommended.
This product includes a Limited Lifetime Warranty to the original purchaser against defects in material and workmanship on all
Injen exhaust systems Any and all warranty coverage is limited to the repair or replacement of the defective part only, at Injen
Technology’s discretion. The warranty does not cover incidental or consequential damages, nor does it cover the cost of
installation or removal of the defective part or its replacement. Proof of purchase is required.
Do not attempt to install the exhaust system while the engine is hot. Severe burn could result from touching hot engine
components.
WARNING: Failure to follow installation instructions and not using the provided hardware may damage the exhaust system,
engine, or components of either.
Note: It is always recommended to disconnect your battery before disconnecting any sensors.

PAGE 3
12. If necessary loosen the factory clamp
and adjust the tment of the exhaust.
11. OPTIONAL: Attach exhaust tips to the
tip extension.
10. OPTIONAL: Attach the tip extensions
to the muer section. Secure using the
provided 76mm clamps.
9. Insert the passenger side hanger into
the rubber insulator.
8. Insert the driver side hanger into the
rubber insulator.
7. Connect the muer section to the mid
pipe. Secure with the OEM clamp.
6. 2.3L MODELS ONLY: Insert the rubber
insulator onto the exhaust hanger bracket.
5. 2.3L MODELS ONLY: Slide the injen
bracket into place. Then secure the two
bolts.
4. 2.3L MODELS ONLY: Install the two
factory bolts to the injen hanger bracket.
Leave 1/4”distance between the bolt head
and the bracket plate.
3. 2.3L MODELS ONLY: Remove the two
bolts and rubber insulator from the
exhaust bracket.
2. 2.3L MODELS ONLY: Remove the OEM
hanger by loosening the two bolts and
then sliding it out. The bolts can be
accessed from the rear of the subframe.
slide out
1. Remove the stock muer by loosening
the mid pipe clamp and detaching the
muer from the rubber insulators
clamp
hanger
hanger

PAGE 4
CONGRATULATIONS! You have just completed the
installation of this exhaut system. Periodically, check the
alignment of the exhaust, normal wear and tear can cause
nuts and bolts to come loose. Note: Check clearance and
adjust if needed! Failure to check the alignment and
adjust the exhaust can cause damage that will void the
warranty. Injen Technology is not responsible for any
damages caused by/from improper installation.
13. Ensure all bolts and clamps are
properly secured.
