Inlite SMART HUB-150 User manual

in-lite INSTALLATION MANUAL SMART HUB-150
www.in-lite.com 03-09-2019
INSTALLATION MANUAL
SMART HUB-150
12 V
Attention
This product may only be used within the in-lite system. If components are used
in the system that do not originate from in-lite, the warranty no longer applies.
Install the in-lite system components (fixtures, transformers, mini-connectors,
Easy-Locks and cable connectors) so that they can easily be replaced
Never use the in-lite low-voltage cable directly connected to 100-230V. This
cable is only meant for use with the components of the in-lite 12 Volt (low-
voltage) system.

in-lite INSTALLATION MANUAL SMART HUB-150
www.in-lite.com 03-09-2019
Contents
1x SMART HUB-150
INPUT : 230 V~, 50 Hz
OUTPUT HUB-150: 12 V~, 12.5 A max., 150 VA
Or,
1x SMART HUB-150
INPUT : 120 V~, 60 Hz
OUTPUT HUB-150: 12 V~, 12.5 A max., 150 VA
Dimensions 228 x 143 x 82 mm / 9.0 x 5.6 x 3.2 inches
2x screws
Optional SMART MOVE (motion sensor)
Please read the following instructions before installing. You are advised
to keep these installation instructions in a safe place. Although a 12 V
system is safe, we advise you to have a qualified electrician check the
installation.
Use
The SMART HUB-150 transformer is controlled by the in-lite app, suitable for
Android and iOS phones or tablets produced, for example, by Samsung and
Apple. The transformer is fitted with an integrated timer and an astronomical
clock. You can make use of various options whereby the lamps are activated
during the hours of darkness or for a certain time period you can set yourself.
You can also manually switch the lamps ON and OFF at any time.
Bluetooth Low Energy
The transformer connects to the phone or tablet using Bluetooth Low Energy.
BLE is a new low-energy form of Bluetooth and is more user-friendly and more
secure than, for instance Wi-Fi.
Three power lines
A total of 150 VA in fixtures can be connected to the SMART HUB-150. Three
power cables can easily be connected to the transformer using the Easy-Connect
click connectors. With one transformer you’re able to create three lighting zones
in your outdoor space. It’s not necessary to evenly divide the maxiumum of 150
VA among the three lines. It’s also possible to use only 1 or 2 of the 3 power
lines.

in-lite INSTALLATION MANUAL SMART HUB-150
www.in-lite.com 03-09-2019
Safety
The external flexible cord of this product cannot be replaced; if the cord is
damaged, the product shall be scrapped.
When the transformer is connected in a wrong way (short circuit) or it
encounters an overload, the “Off-led” will blink to signal the installer. Above a
certain level of overload the transformer will shut down and reset itself when the
touch pad is activated manually. This procedure will loop until the connection has
be done right or the load is reduced to an acceptable level.
This product has triple protection. It’s based on 3 mechanisms:
1. Current monitoring by software,
2. Voltage monitoring after PTC’s (3x 9A PTC),
3. Transformer temperature monitoring (thermal resettable fuse inside toroid
transformer).
The software protection is based on one true-RMS current measurement and two
voltage measurements. If the external load is increased, the following levels are
reached for SMART HUB-150:
•Detection levels calibrated for each product at 100% of nominal load (150
VA).
•If the current exceeds 120% for a few seconds (>180VA), the “off-Led”
(around the on/off-button) starts blinking slowly until the load is
decreased below 120%.
•If the current exceeds 140% for a few seconds (>210VA), the relay is
switched off and the “off-Led” starts blinking fast until the on/off-button is
activated (reset after overload).
•If the current exceeds 200% (>300VA), the relay is switched-off
immediately until the on/off-button is activated (reset after short-circuit).
•If the customer resets too many times during overload/short-circuit the 3
PTCs on the connection PCB become hot and the output voltage will
become too low, which is measured by the software. The output will be
disabled for 1 minute to allow cooling down.
•Finally, if all of the above protections fail the temperature sensing switch
inside the transformer will break the input current if its temperature rise is
too high. This mechanism resets automatically after cooling down.
The control of the relay is synchronized with the mains input, it switches on and
off during the zero crossing off the current to prevent induction voltages
(spikes).
If the supply voltage for the control part becomes too low (long power dips) the
output will be disabled. After restoring of the mains supply the product will start
again in the last known mode.

in-lite INSTALLATION MANUAL SMART HUB-150
www.in-lite.com 03-09-2019
Installation
The SMART HUB-150 is easy to install. After mounting the transformer and
downloading and installing the in-lite application (app), the system is ready for
connection.
All lights can be controlled with the in-lite app on a smart phone or tablet. The
app, which is suitable for an Android and iOS device, can be downloaded from
the app store and installed on your device.
The in-lite app makes it possible to communicate with the transformer by a
Bluetooth connection. The app automatically recognizes which lines are in use. In
the app you can turn light sections (total 3) “ON” and “OFF”. You can also set
different scenarios based on sunset and sunrise, time of the day and/or
movement detection (with accessory SMART MOVE).
It’s possible to share the in-lite app with other people like familiy members. The
Share function makes it possible to quickly link an extra device. The settings are
duplicated so there’s no need to set again for the linked device.

in-lite INSTALLATION MANUAL SMART HUB-150
www.in-lite.com 03-09-2019
Installation step by step
Although the transformer is designed to withstand inclement weather,
you are recommended not to place it close to a sprayer system. Place
the transformer at least 50 cm above the ground and in the immediate
vicinity of a 110V/230V electric socket.
Installing the transformer (Fig. 5)
Step 1
Open the package of the transformer. Here you will find the screws for
fixing the transformer in place and the terminal lugs for the cable. Fix the
transformer to a wall, panel or post using the screws supplied (Fig. 1).
Step 2
Split about 5-10 cm of the low-voltage cable end into 2 wires. Remove about 8
mm of insulation from both wire ends (Fig. 2).
Step 3
Remove the lid from the transformer so you get access to the 3 cable terminals.
Each terminal represents a separate light section in your garden.
Step 4
Insert the copper wires into the terminal lug (Fig. 3) and fix them firmly in place
by pressing the click mechanism down (Fig. 4).
Step 5
Put the lid back in place on the transformer to cover the cable terminals.(Fig. 5).
Step 6
Put the plug of the 110V/230V power cable into the electric socket. The
transformer will be switched on automatically. The on-off button on the side of
the transformer will light up continuously. (At any time it is possible to switch the
transformer on and off by a push on the on/off button)
