INNO A3 User manual

SPLICING OPERATION
HOW TO USE KEYPAD
•Turning splicer on
Select splice mode
The default mode is SM mode, the splicing effect is the best, you can also choose the QUICK mode
to save time.
Check splicing and heater modes
Cleaning bers
Place the sleeve on the ber
Stripping ber
Cleaning ber
Cleaving ber
Install ber onto splicer
Start splicing by closing wind proof cover
Visual inspection on LCD during splice
Remove the spliced ber
Centering protection sleeve on spliced ber
Put the sleeved ber into heater
Start heating by closing heater cover
Completed
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Quick Reference Guide
•
•
•
Use only 99% or better purity alcohol.
Make sure the stripped fiber is free of coating debris or dust. •Keep the bare fiber and cleaved fiber end faces in
a clean condition.
•Place the fiber ends between the edge of V-grooves
and the electrode ends.
Insert fiber into the
protection sleeve
Cleaning fiber
Clean by clean wipes (dustproof)
Hold the fiber at edge of splicer body
Gently pull the fiber
V-groove
edge
Electrode
center
BATTERY PACK
How to recharge battery
How to check remaining battery
capacity on ready screen
Battery Pack
AC Charger
•Connect battery pack (LBT-3000-02) with AC charger, power cable.
•Do not stack battery pack on top of charger while recharging.
•Recharging temperature: 0~40°C (32~104°F).
ON/OFF Key
Power ON/OFF
Back Key
Return to
previous screen
OK Key
Enter
HEAT Key
Heater ON/OFF
when auto heating is off
LED
Turn ON Press key until green led turns on
Turn OFF Press key until green led blank
SET Key
Execute splice when
auto start is off •
•
When ARC discharge is not stable. Electrodes should be stabilized and calibrated toreform the arc discharge.
Install prepared SM fibers onto splicer to operate stabilize electrodes and arc calibration. After installation SM fibers,
splice fibers again.
250um
8~16mm
1/3"~2/3"
8~16mm
1/3”~2/3"
900um
13mm
1/2"
Less than 3mm
1/8"
Fiber Holder
Description
Confirm power saving function is working when using battery pack.
RESET Key
Stop and back to ready
Ver. 1.0
ARC FUSION SPLICER
CLAD ALIGNMENT
CAUTION
!
CAUTION
!
Hold
Splicing Position
Open the heat oven lid
Move into heat oven clamp
A 3

Maintenance
01. Always use SM fiber only
02. To keep in best splice condition,
following the procedure.
V-grooves
Fiber clamp slot White LEDObjective lens
When lens is dirty, clean it.
Prepare SM fiber and go to “Main Menu”
Important:
During cleaning,
· Do not contact the electrode tips.
· Use only 99% or better purity alcohol.
· Clean by clean wipes (dustproof)
Objective lens
If lens is dirty, clean it periodically, with alcohol moistened thin cotton swab. Otherwise, the lens can
make trouble.
Electrodes
When “Replace Electrodes” message appears, or when the tip is damaged, replace electrodes.
·Execute [Replace Electrodes]
· Press “SET”,then automatically turns off
· Loosen screws
· Take out electrodes
· Put new electrodes
· Reassemble the electrode cover
· Tighten screws
· Turn splicer on
· Install prepared fibers
· Execute [Stabilize Electrodes]
· Execute [Arc Calibration]
Battery pack
•Discharge battery pack completely every 3 months before recharging.
•When storing battery pack in long term;
•Storing temperature should be -20~30°C (-4~86°F)
•Recharge battery pack every 6 months, not to be empty.
ARC Calibration
A2 ARC Fusion Splicer
Select [Maintenance] in [Maintenance Menu]
Execute [Maintenance], then the following checks will be made.
LED calibration
Measure and adjust the brightness of the LED.
Dust check
Check the optical path for dust or dirt and judges whether they disturb ber observation. If contamination
exists, press the return button twice to display the location.
Adjust Position
Automatic ber adjustment
Motor Calibration
Automatically calibrate the speed of 4 motors.
Stabilize Electrodes
Accurately measure the position of the electrodes by ARC discharge.
Arc Calibration
Automatically calibrate the arc power factor and ber splicing position.
Upon completion of all checks and adjustments, a list of results is displayed. If the dust check result
is not good, clean the objective lenses. If the cleaning cannot eliminate contamination, there is a possibility
that the contamination may be in the inside of the optical path. Please contact your sales agency for
additional instructions.
•
Note : Before you start test, remove the fibers from the splicer. When the above item No. 2 (dust check)
is completed, prepare and load the fibers onto the splicer and press “SET”
•
•
•
•
•
MAINTENANCE MENU
MAINTENANCE
PERIODIC MAINTENANCE
CLEANING BEFORE SPLICING
BELIEVE YOUR EYES
CAUTION !
