RHINO TR310LT User manual

© 2021 Alamo Group Inc.
RHINO®
1020 S. SangamonAve.
Gibson City, IL60936
800-446-5158
Email: [email protected]
PART'S MANUAL
An Operator's Manual was shipped with the equipment in the
Manual Canister. This Operator's Manual is an integral part of
the safe operation of this machine and must be maintained
with the unit at all times. READ, UNDERSTAND, and FOLLOW
the Safety and Operation Instructions contained in this manual
before operating the equipment. If the Operator's Manual is
not with the equipment, contact your dealer or Servis-Rhino
(800-446-5158) to obtain a Free copy before operating the
equipment.
ROTARY CUTTER
TR310LT/PT
Rev 08-2021 Part No. 00793562P

TO THE OWNER/OPERATOR/DEALER
Allimplementswithmovingparts arepotentiallyhazardous. There isnosubstitute foracautious, safe-mindedoperatorwho
recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this implement to
be used with all its safety equipment properly attached to minimize the chance of accidents.
BEFOREYOUSTART!! Read the safety messages on the implement and shown in your manual.
Observe the rules of safety and common sense!
WARRANTY INFORMATION:
ReadandunderstandthecompleteWarrantyStatementfoundinthis Manual. Fill out the Warranty Registration Form
in full and return it within 30 Days. Make certain the Serial Number of the Machine is recorded on the Warranty Card
andontheWarrantyFormthatyouretain.Theuseof"will-fit"partswillvoidyourwarrantyandcancausecatastrophic
failure with possible injury or death.

PARTS
SECTION
Parts Section – 1

Parts Section – 2
©2021 Alamo Group Inc.
For maximum safety and to guarantee optimum product reliability, always use
genuine Servis-Rhino Parts. The use of inferior replacement parts may cause
premature or catastrophic failure which could result in serious injury or death.
Direct any questions regarding parts to:
The following instructions are offered to help eliminate needless delay and error in processing
purchase orders for the equipment in this section.
1. The Parts Section is prepared in logical sequence and grouping of parts that belong to the
basic machine featured in this manual. Part Numbers and Descriptions are given to help
locate the parts and quantities required.
2. The Purchase Order must include the name and address of the person or organization
ordering the parts, who should be charged, and if possible, the serial number of the machine
for which the parts are ordered.
3. The Purchase Order must clearly list the quantity of each part, the complete and correct part
number (be sure to include all periods), and the basic name of the part.
4. The Manufacturer reserves the right to substitute parts where applicable.
5. Some parts are unlisted items which are special production items not normally stocked and
are subject to special handling. Request a quotation for such parts before sending a
Purchase Order.
6. The Manufacturer reserves the right to change prices without prior notice.
NOTE: Please refer to The Safety Section in the front of this Manual for the proper
Part Number when ordering Replacement Safety Decals.
PARTS ORDERING GUIDE
RHINO®
1020 S. Sangamon Ave.
Gibson City, IL 60936
800-446-5158
Email: [email protected]

PART NAME INDEX
AFRAME COMPONENTS........................................................................................................................................................................... 4
AXLE ASSEMBLY - PULL TYPE............................................................................................................................................................... 5
BLADE CARRIER........................................................................................................................................................................................ 7
CANISTER ASSEMBLY.............................................................................................................................................................................. 8
CHAINGUARD ASSEMBLY....................................................................................................................................................................... 9
CYLINDER ASSEMBLY - PULL TYPE................................................................................................................................................... 11
DRIVELINE - 00793198 1000RPM CAT 4 1-3/8 20 X 60.12 (LIFT TYPE)............................................................................................ 12
DRIVELINE - 00777983 (SIDE DRIVE).................................................................................................................................................... 13
DRIVELINE - 00793192 JACKSHAFT (PULL TYPE)............................................................................................................................. 14
DRIVELINE - 00793197 540RPM CAT4, 1-3/8-6 X 1-3/4-20 X 59.65 (LIFT TYPE).............................................................................. 15
DRIVELINE - 00793199 1000RPM CAT 4 1-3/4 20 SPL (LIFT TYPE)................................................................................................... 16
DRIVELINE - MAIN CV 10000RPM CAT 5 1-3/4 -20 SPLINE PULL TYPE 00791883SP................................................................... 17
DRIVELINE - MAIN CV 1000RPM CAT 5 1-3/8 21 SPLINE PULL TYPE 00791882SP...................................................................... 19
DRIVELINE - MAIN CV 540RPM CAT 5 1-3/8 6 SPLINE PULL TYPE 00791881SP.......................................................................... 21
GEARBOX ASSEMBLY - 00790700 1:1.00A 540RPM (OUTBOARD).................................................................................................. 23
GEARBOX ASSEMBLY - 00790705 1:1.22A 1000RPM (OUTBOARD)................................................................................................ 25
GEARBOX ASSEMBLY - 50075292 1:1.85 (540RPM DIVIDER).......................................................................................................... 27
GEARBOX ASSEMBLY - 50075293 1:0.82 (1000RPM DIVIDER)........................................................................................................ 29
HUB & SPINDLE ASSEMBLY - 00790220 (LIFT TYPE)....................................................................................................................... 31
LEVEL ROD ASSEMBLY - 00793407 PULL TYPE................................................................................................................................ 32
SHIELD ASSEMBLY - CENTER LIFT TYPE.......................................................................................................................................... 33
SHIELD ASSEMBLY - CENTER PULL TYPE......................................................................................................................................... 34
SHIELD ASSEMBLY - OUTBOARD........................................................................................................................................................ 35
SKID SHOES............................................................................................................................................................................................... 36
SLIPCLUTCH - 00793537........................................................................................................................................................................... 37
TAILWHEEL ASSEMBLY - LIFT TYPE.................................................................................................................................................. 38
TIRE OPTIONS........................................................................................................................................................................................... 39
TONGUE ASSEMBLY - PULL TYPE....................................................................................................................................................... 41
©2021 Alamo Group Inc. Parts Section -3
TR310LT TR310PT
TR310 DECALS ........................................................................................................................................................................................................................................... 43

AFRAME COMPONENTS
©2021 Alamo Group Inc. Parts Section -4
TR310LT TR310PT
ITEM PART NO. QTY.
1 0758550010A 2
2 0758550020A 2
3 00793424 1
4 00793423 1
5 00793425 1
6 00778651 1
7 00761267 2
8 00792430 1
9 00792429 1
10 00792431 2
11 00007800 2
12 02958757 1
13 03200782 1
14 7B16820 1
15 00748823 1
16 5JRC1680 2
17 329915H8C 3
DESCRIPTION
WDMT,A-FRAME RH LEG
WDMT,A-FRAME LH LEG
LINK, FLOATING RH
LINK, FLOATING LH
LINK, TR 10` A-FRAME
BRACKET, DRIVELINE HOLDER
SPACER
BUSHING, 1.00 X .78 X 2.53
BUSHING, 1.25 X 1.06 X 2.53
BUSHING, SHOULDER-3/4"
HEXB 3/4 NCX 3 PL5
HHCS 3/4 NC X 7" PL GR8
HEXB 1 NC 5 PL5
HEXB 1NC X 2-1/2 PL
HHCS 1/2-13 UNC X 1-1/2 GR.5 PL
NUT TOPLOCK 1 NC PL
NUT, HEX FLANGE-SPIRALOCK 3/4-10

AFRAME COMPONENTS
Continued...
ITEM PART NO. QTY.
18 00793426 2
19 00793526 2
20 00001800 2
21 02776600 2
22 02971324 1
DESCRIPTION
WDMT, TR 10` REAR A-FRAME
WDMT, REAR A-FRAME PIVOT
LOCKNUT TLM 1/2 NC PLC
HHCS 1/2-13 NC X 1 1/4 GR8 PL
NUT LOCK FLG 1/2-13 NC PL
©2021 Alamo Group Inc. Parts Section -5
TR310LT TR310PT

AXLE ASSEMBLY - PULL TYPE
©2021 Alamo Group Inc. Parts Section -5
TR310LT TR310PT
ITEM PART NO. QTY.
1 00793404 1
2 00793406 1
3 00793402 1
4 00793244 2
5 8727A 1
6 00791366 1
7 00755234 1
8 03200347 1
9 00793364 1
10 00793365 1
11 00790220 4
12 00790205 4
13 00793434 2
14 00793435 2
15 000644 6
16 4528 6
17 00793282 4
DESCRIPTION
WDMT, TR 10` LH EXT AXLE
WDMT, TR 10` RH EXT AXLE
WDMT, TR LARGE CENTER AXLE
WDMT, SUSP AXLE ARM
CYLINDER, HYD 2-1/2 X 8
CASTING, 8IN CYLINDER LOCK
KIT, CONTROL SPACER
EMBLEM, SMV
MOUNT, CANISTER SMV BRANDED
PLATE, BRANDING BACKER
ASY,HUB & SPINDLE (DEMCO)
PUCK, RUBBER SUSPENSION
DEFLECTOR, TR 10` RUBBER TAIL
BRACKET, TAIL DEFLECTOR
CARB-3/8 NCK 1-1/4 PL5
NUT, HEX LOCK 3/8-16 FLG WHIZ
WDMT, AXLE PIVOT PIN

AXLE ASSEMBLY - PULL TYPE
©2021 Alamo Group Inc. Parts Section -6
TR310LT TR310PT
Continued...
ITEM PART NO. QTY.
18 00748823 4
19 00752680 4
20 00037200 4
21 02959391 4
22 02675800 8
23 00695100 8
24 02959924 2
25 00021400 2
26 00764375 4
27 00001800 4
28 8354 1
29 420011 1
30 02822500 2
31 00606000 2
32 00793248 2
33 00793250 2
DESCRIPTION
HHCS 1/2-13 UNC X 1-1/2 GR.5 PL
HHCS, 1/2-13 NC X 4 GR5 PL
NUT,HEX TOPLOCK 3/4 NC GR.C PL
HHCS, 3/4 NC X 2-1/4 PL5
BOLT 5/8 NC 1-1/2 PL5
NUT, TOPLOCK 5/8 NC PLC
NUT, LOCK TLM 1/4-20 NC PLB
HEXB 1/4 NC 3/4 PL5
HHCS 1/2NC X 3-1/4 PL5
LOCKNUT TLM 1/2 NC PLC
PIN, CLEVIS, 1.00 X 3.25
PIN, CLEVIS 1 X 5 PL
FLATWASHER 1 PL STD
PIN, COTTER 3/16 X 2"
WDMT, SUSP AXLE CLAMP
WDMT, AXLE ARM PIVOT

BLADE CARRIER
ITEM PART NO. QTY. DESCRIPTION
1 00791100 1 CAST WING PAN - PARTS LISTED ARE PER CARRIER
2 00792898 2 BLADE, FAN CW, 4X20-1/2 CTR-TIP
00792899 2 BLADE, FAN CCW, 4X20-1/2 CTR-TIP (NOT SHOWN)
3 00791094 1 HUB, EZ80 FLANGED ADAPTOR
4 B571044 1 BLADE BOLT KIT/NUTS
5 571045 2 SHOULDER BOLT WASHER
6 00756077 2 WASHER,5/8 HARDENED
7 00008300 6 HHCS 5/8-11NC X 1-3/4" PL5
©2021 Alamo Group Inc. Parts Section -7
TR310LT TR310PT

CANISTER ASSEMBLY
ITEM PART NO. QTY. DESCRIPTION
1 00776031 1 CANISTER, PARTS MANUAL
2 00780878 3 RIVET, 3/16 POP X 15/32" G.R.
©2021 Alamo Group Inc. Parts Section -8
TR310LT TR310PT

CHAINGUARD ASSEMBLY
ITEM PART NO. QTY. DESCRIPTION
1 00793410 1 ASSY, REAR CENTER C.G.
00793377 1 ASSY, REAR CTR DBL C.G. (NOT SHOWN)
2 00793412 1 ASSY, REAR LH C.G.
00793378 1 ASSY, REAR LH DBL C.G. (NOT SHOWN)
3 00793414 1 ASSY, REAR RH C.G.
00793379 1 ASSY, REAR RH DBL C.G. (NOT SHOWN)
4 00793464 2 ASSY, FRONT SIDE C.G.
00793466 2 ASSY, FRONT SIDE DBL C.G. (NOT SHOWN)
5 00793322 1 ASSY, FRONT C.G.
00793371 1 ASSY, FRONT DOUBLE C.G. (NOT SHOWN)
6 00793467 1 BRACKET, TR REFLECTOR
7 00002700 19 FLATWASHER 1/2 PL STD
8 00001300 19 WASHER, LOCK 1/2 GD8 YDP
9 00748823 19 HHCS 1/2-13 UNC X 1-1/2 GR.5 PL
10 00793435 2 BRACKET, TAIL DEFLECTOR
11 00793434 2 DEFLECTOR, TR 10` RUBBER TAIL
12 000644 6 CARB-3/8 NCK 1-1/4 PL5
©2021 Alamo Group Inc. Parts Section -9
TR310LT TR310PT
13 4528 6 NUT, LOCK 3/8-16 FLG WHIZ

CYLINDER ASSEMBLY - PULL TYPE
©2021 Alamo Group Inc. Parts Section -11
TR310LT TR310PT
ITEM PART NO. QTY. DESCRIPTION
8727A - COMPLETE ASSEMBLY
1 00774729 1
2 00774734 1
3 00774730 1
4 00774753 1
5 3047111 1
6 3047112 4
9 00774760 1
15 3047117 1
16 1917140 1
17 00774740 1
18 33003H5C 8
19 5JRC12160 1
20 1917132 1
21 2417154 1
651132 2
94514 2
0652141311 2
8354 2
CLEVIS CAP
ROD CAP
PISTON
ROD
TUBE
TIE ROD
SEAL KIT
NYLON THREAD PROTECTOR
ROD CLEVIS
SET SCREW
TIE ROD NUT
PISTON NUT
PORT PLUG
BREATHER
HOSE (NOT SHOWN)
ELBOW (NOT SHOWN)
ADAPTER (NOT SHOWN)
PIN (NOT SHOWN)
00606000 2 COTTER PIN (NOT SHOWN)

DRIVELINE - 00793198 1000RPM CAT 4 1-3/8 20 X 60.12 (LIFT TYPE)
ITEM PART NO. QTY. DESCRIPTION
00793198 1 1000RPM CAT 4 1-3/8 20 X 60.12 (LIFT TYPE)
1 00793538 1 YOKE,1-3/8 - 21 SPLINE
2 00793536 2 KIT,CROSS & BEARING 75MM
3 8982 1 INBOARD YOKE 2400 SERIES
4 00756934 2 PIN,ROLL 10 X 80
5 7413 1 INNER PROFILE
6 00775377 1 PROFILE & SLEEVE W.A.
7 8387 1 YOKE, INBOARD
8 00793537 1 ASY,FRICTION CLUTCH, 4-PLATE
9 8393 2 BEARING SUPPORT RING SC25
10 00759217 2 SCREW 1/2 LG #8 PAN
11 00756005 1 DECAL,ROTATING DRIVELINE
12 00756004 1 DECAL,DANGER - GUARD MISSING
13 8974 1 SUPPORT BEARING WAL
14 00771813 1 GREASE FTG, STGHT
15 00767954 1 YOKE.Q.D.KIT - PLASTIC
16 00793539 1 KIT,COMPLETE GUARD
©2021 Alamo Group Inc. Parts Section -12
TR310LT TR310PT

DRIVELINE - 00777983 (SIDE DRIVE)
©2021 Alamo Group Inc. Parts Section -13
TR310LT TR310PT
ITEM PART NO. QTY.
0 00777983 1
1 00778169 1
2 00785557 4
3 00766475A 48
4 00771287 24
5 00762216A 2
6 00765902 12
7 00765962 12
8 00764386 2
DESCRIPTION
DRIVELINE COMPLETE
DOUBLE FLEX YOKE&TUBE ASY
DISC,RUBBER - 7" OD
WASHER,BEADED D/L COUPLER
BUSHING,RUBBER DISK
D/L SPIDER 1-3/4 20 SPL.
HHCS M16-P2.0 X 90MM PL8.8
NUT MET TLE 16MM-P2.0 PL
GREASE FITTING,8MMX1 STRAIGHT

DRIVELINE - 00793192 JACKSHAFT (PULL TYPE)
ITEM PART NO. QTY. DESCRIPTION
00793192 1 JACKSHAFT (PULL TYPE)
1 00756934 1 SPRING PIN, 10X80
2 00775310 1 INBOARD YOKE S5
3 00793590 1 STUB + PROF ILE W .A.
4 00756004 1 DECAL INNER-IN ITEM 3
5 00793536 1 CROSS+ BRG KIT
6 00793537 1 FRICTION CLUTCH
©2021 Alamo Group Inc. Parts Section -14
TR310LT TR310PT

DRIVELINE - 00793197 540RPM CAT4, 1-3/8-6 X 1-3/4-20 X 59.65 (LIFT TYPE)
ITEM PART NO. QTY. DESCRIPTION
00793197 - 540RPM CAT4, 1-3/8-6 X 1-3/4-20 X 59.65
1 00779516 1 YOKE,1-3/8 - 6 SPLINE
2 00793536 2 KIT,CROSS & BEARING 75MM
3 8982 1 INBOARD YOKE 2400 SERIES
4 00756934 2 PIN,ROLL 10 X 80
5 7413 1 INNER PROFILE
6 00775377 1 PROFILE & SLEEVE W.A.
7 8387 1 YOKE, INBOARD
8 00793537 1 ASY,FRICTION CLUTCH, 4-PLATE
9 8393 2 BEARING SUPPORT RING SC25
10 00759217 2 SCREW 1/2 LG #8 PAN
11 00756005 1 DECAL,ROTATING DRIVELINE
12 00756004 1 DECAL,DANGER - GUARD MISSING
13 8974 1 SUPPORT BEARING WAL
14 00771813 1 GREASE FTG, STGHT
15 00767954 1 YOKE.Q.D.KIT - PLASTIC
16 00793539 1 KIT,COMPLETE GUARD
©2021 Alamo Group Inc. Parts Section -15
TR310LT TR310PT

DRIVELINE - 00793199 1000RPM CAT 4 1-3/4 20 SPL (LIFT TYPE)
©2021 Alamo Group Inc. Parts Section -16
TR310LT TR310PT
ITEM PART NO. QTY.
00793199 1
1 7455 1
2 00793536 2
3 8982 1
4 00756934 2
5 7413 1
6 00775377 1
7 8387 1
8 00793537 1
9 8983 2
10 00759217 2
11 00756005 1
12 00756004 1
13 8974 1
14 00771813 1
15 00773505 1
16 00793539 1
17 00759556 1
18 00774208 1
DESCRIPTION
COMPLETE DRIVELINE
YOKE SLIDE COLLAR,20 SPLINE
KIT,CROSS & BEARING 75MM
INBOARD YOKE 2400 SERIES
PIN,ROLL 10 X 80
INNER PROFILE
PROFILE & SLEEVE W.A.
YOKE, INBOARD
ASY,FRICTION CLUTCH, 4-PLATE
YOKE,1-3/8-6 SLD COL
SCREW 1/2 LG #8 PAN
DECAL,ROTATING DRIVELINE
DECAL,DANGER - GUARD MISSING
SUPPORT BEARING WAL
GREASE FTG, STGHT
MANUAL, DRIVELINE SAFETY - NOT SHOWN
KIT, COMPLETE GUARD - NOT SHOWN
Q.D. COLLAR KIT W/3 BALLS (IN ITEM #1)
LOCK ASY CC YOKE (IN ITEM #8)

DRIVELINE - MAIN CV 10000RPM CAT 5 1-3/4 -20 SPLINE PULL TYPE 00791883SP
©2021 Alamo Group Inc. Parts Section -17
TR310LT TR310PT
ITEM PART NO. QTY.
0 00791883SP 1
1 00791901 1
2 00791891 2
3 8381 1
4 00775309 1
5 703624W 1
6 00791902 1
7 00791903 1
8 8489 1
9 8486 1
10 00786369 1
11 00791894 1
12 8384 1
13 00791904 1
14 00791896 1
15 00771813 1
DESCRIPTION
ASY,CV,DRIVELINE,CAT 5,1000RPM 1-3/4-20SPL
YOKE,SLIDE COLLAR-1-3/4-20 SPL
KIT,CROSS & BEARING
DOUBLE YOKE
YOKE INBOARD S4
M10 X 75 ROLL PIN
PROFILE, INNER S4GA
PROFILE, OUTER S5GL
YOKE,INBOARD S5
KIT, CROSS BEARING
YOKE,D/L 1-3/4 - 20 SPL. - IC
ASSY, CV GUARD AND BEARING
SPRING PIN 10MM X 90MM
KIT, COMPLETE GUARD
KIT, Q.D. COLLAR 1-3/8 SPLINE
GREASE FTG, STGHT (NOT SHOWN)

DRIVELINE - MAIN CV 1000RPM CAT 5 1-3/8 21 SPLINE PULL TYPE 00791882SP
©2021 Alamo Group Inc. Parts Section -19
TR310LT TR310PT
ITEM PART NO. QTY.
0 00791882SP 1
1 00791901 1
2 00791891 2
3 8381 1
4 00775309 1
5 703624W 1
6 00791902 1
7 00791903 1
8 8489 1
9 8486 1
10 00786369 1
11 00791894 1
12 8384 1
13 00791904 1
14 00791896 1
15 00771813 1
DESCRIPTION
ASY,CV,DRIVELINE,CAT 5,1000RPM 1-3/8-21SPL
YOKE,SLIDE COLLAR-1-3/8-21 SPL
KIT,CROSS & BEARING
DOUBLE YOKE
YOKE INBOARD S4
M10 X 75 ROLL PIN
PROFILE, INNER S4GA
PROFILE, OUTER S5GL
YOKE,INBOARD S5
KIT, CROSS BEARING
YOKE,D/L 1-3/4 - 20 SPL. - IC
ASSY, CV GUARD AND BEARING
SPRING PIN 10MM X 90MM
KIT, COMPLETE GUARD
KIT, Q.D. COLLAR 1-3/8 SPLINE
GREASE FTG, STGHT (NOT SHOWN)
