Innotech M2K04 User manual

APPROVED
JSM REVNO:A
TITLE
MODEL NO
DATE
DRAWN
M2K04USER INSTRUCTIONS
MICRO2000CONTROLLER
07-07-03
USER INSTRUCTIONS
M2K04
BUTTON FUNCTIONS
=ENTERisusedtosavesettingsandtoenteranewparameter.
=BACKallowsyoutoscrollbackto theprevioussettingorparameter.
=DELETEisusedtodeleteaTimeSchedule.
=COPYisusedtocopythepreviousTime.
SETTING THE CLOCK ‘CURRENT DAY ANDTIME’
Anytimethecontroller ispoweredup,thedisplaywill readSET CLOC.
Tosettheclock,follow theinstructionsbelow.
STEP 1
Pressandholdthe button untilthedisplaygoesblank.Pressthe and buttonstoselect
clock‘CLOC’editmodeandpressthe button.
STEP 2
Usethe and buttonstoadjustyourtimesettingsandsaveitbypressingthe button.
Thecurrentdatewillbedisplayedintheformatof01.01dd/mm.Usethe and buttonsto
adjustyourdatesettingandsaveitbypressingthe button.Thecurrentyearwillbedisplayed.
Adjustitasbefore.
STEP 3
Tosaveandexitthe ‘CLOC’ modepressandholdthe button untilthedisplaygoesblank.
Note: Ifamistakeismakeyoucanpressthe buttontoreturntotheprevioussetting.

M2K04 Setting Clock and Schedules
SETTING THE TIME CLOCK - TIME SCHEDULES
Tosettheschedule, followtheinstructionsbelow.
Step 1
Pressandholdthe buttonuntilthedisplaygoesblank.Pressthe and buttonstoselect
between‘CLOC’, ‘SCHE’and‘HOL’. Selectthe‘SCHE’modebypressingthe button.
Step 2
Oncethe schedulefunctionhas been selected,‘DAY1’isdisplayed.Youmay scrollthroughthe the
thedaysrequiringprogrammingbyusingthe and buttons.Whenthedesired dayisdisplayed
select itbypressingthe button. E.g. ‘DAY1’=Monday, ‘DAY2’ =Tuesday.
Step 3
Thedisplaywillnowread ‘SCH1’.
Notethatthis7daytimeclockiscapableof2on/offtimesperdayreferedtoas,schedule1&schedule2.
Ifonlyoneeventisrequired perdaythenenternotimes forschedule2.
Pressthe buttonandselect ‘SCH1’Thedisplaywill thenflash“ON”followedbytheon time.Usethe
and buttonstoadjusttheontimethenpressthe buttontosavethetimesetting.
‘OFF’followedby‘----’will thenbedisplayed.Setthe“OFF”timeandpressthe button.
Step 4
Thedisplaywill nowshow ‘SCH2’. Pressthe button.Eitherenteran‘ON’and‘OFF’timeor
ignoreitbypressingthe buttonagain.Note:ifnotimeisenteredfor ‘SCH2’ then ‘----’willbe
displayedforthe‘ON’time and the‘OFF’time will not bedisplayed.
Step 5
Thedisplaywillnowread‘DAY2’.Repeat steps2and 3foreach dayasrequired.If the‘DAY2’
‘ON’and ‘OFF’timeistobethesameas‘DAY1’, Thenpress whenthe‘----’isdisplayedforthe
‘ON’time.Noteifamistakeismadepress todeletetheunwantedtime.Press toreturntothe
previoussetting.Pressandholdthe buttontosaveandexit.
ENABLETHE AUTO FUNCTION
Pressingthe button‘ON’willallowtheunitto rununderthecontrolof it’sprogrammedweekly
timeclock.
SETTING THE TEMPERATURE
*Notetherangeofthisadjustmentcanberestricted.
Whenthe or buttons aredepressed. Thesetpointwillbedisplayed Continuingtopress either
the or buttonswillincreaseordecreasethesetpoint. Ifthe or buttons havenot
beendepressedfor5secondsthedisplaywillreverttothesensedtemperature.
VENT CONDITION MODE
The buttonwilltoggletheunitbetweenVentandCondition.Onstate=Condition.
AFTERHOURSMODE
The buttonwillallowtheunittorunforeitherapre-determinedtimedperiod,anadjustabletime
periodor continuouslydependingontheprogrammedoptions.Pressingthe buttonwhileinthe
afterhoursmodewilltoggletheunitto‘OFF’.

M2K04 Setting Holiday Schedules
SETTING THETIME CLOCK - HOLIDAY SCHEDULES
Tosettheschedule, followtheinstructionsbelow.
Step 1
Pressandholdthe buttonuntilthedisplaygoesblank.Pressthe and buttonstoselect
between‘CLOC’,‘SCHE’and‘HOL’.Selectthe‘HOL’ modebypressingthe button.
Step 2
Oncetheschedulefunctionhasbeenselected,‘H_01’isdisplayed. Notethatthistimeclockiscapableof
havingupto20 holidayswhich maybe anydatethat you wanttheUnitto be‘OFF’. Youmayscroll
throughtheholidaysrequiringprogrammingbyusingthe and buttons.Whenthedesireddayis
displayedselectitbypressingthe button. E.g. ‘DAY1’=Monday, ‘DAY2’ =Tuesday.
Step 3
Thedisplaywillnow read ‘OFF’followedby‘____’,Usethe and buttonstoadjusttheOFFdate.
Thedateis intheformatof01.01,dd/mm.Press button.‘ON’followedbytheondatewillthenbe
displayed.Notetheunitwillbedisabledbetween12:00amoftheoffdateand12:00oftheondate.
Setatheondateandpressthe buttontosavethisholidayschedule.
Step 4
Thedisplaywillnowshow ‘H02’. Repeatsteps2and3 foreachholidayrequired.Noteif amistake ismade,
press whenviewingtheoffdateoftheunwantedschedule.Press toreturntotheprevious
setting.
Todeleteall holidaysettings,pressandhold buttonuntil‘DEL’isdisplayed.Pressandholdthe
buttontosaveandexit.
