EcoBrite Warehouse LED Light Installation Guide Rev 1.2, Date: 07/28/11
CAUTION
Use caution when handling a power tool.
Always wear protective eyewear.
Installation Guide
For EcoBrite™ Warehouse LED Light Fixtures
WARNING
Risk of electrical shock. Disconnect power
before installing or servicing product.
BEFORE YOU BEGIN INSTALLATION
Read these instructions carefully. Failure
to follow these instructions will invalidate
the warranty on this product.

2
EcoBrite Warehouse LED Light Installation Guide Rev 1.2, Date: 07/28/11
Thank you for purchasing EcoBrite Warehouse LED Light Fixtures. There are multiple methods for mounting the
fixtures based on the available structure. Please read the instructions completely before installation.
Standard Surface Mount
Required tools and components
1. #8 x 1/2” sheet metal screws
-pan head or hex head
2. Tape measure
3. Pencil
4. Drill
5. Phillips screw bit or screwdriver
6. 1/8” drill bit
7. Regulated 12VDC Class 2 Power Supply
100-240V input, 60W (PN 750-9990)
100-240V input, 60W, Low Profile (PN 750-9995)
100-277V input, 60W, (PN 740-9990)
8. Wire nuts / connectors
Procedure:
1. Mark locations of holes
a. 2 Mounting clips are required for each EcoBrite Lamp. A 3rd
mounting clip is optional.
b. Mounting clips should be about 50” – 60” apart (when using 2).
c. Be sure that the holes are all in-line with each other
2. Drill pilot holes with 1/8” drill bit
3. Use Phillips driver to fasten the clips in place
4. Snap the light fixture in place
*Note: Drilling holes in “I” beams or any other load-bearing structure is not
recommended
Included Parts
Warehouse LED Light Fixture HB (PN 740-XXXX)
or
Warehouse LED Light Fixture Super HB(PN 742-XXXX)
Accessories
Mounting Clips
(PN 750-9910)

3
EcoBrite Warehouse LED Light Installation Guide Rev 1.2, Date: 07/28/11
I Beam/ Hanging Mount:
*Note: This is one of several mounting methods. This and other mounting hardware can be
found through these manufacturers:
http://www.rize-enterprises.com/
http://www.gripple.com/
http://www.erico.com/
Included Parts
Warehouse Light Fixture
(PN 740-XXXX)
Accessories
Mounting Clips
(PN 750-9910)
Required tools and components
1. 7/16” wrench
2. Pliers
3. Tape measure
4. Studded Cables (one per mounting clip)
5. Cable Hangers (one per mounting clip)
6. Beam Clamps (one per mounting clip)
7. 3/16” X 2” Clevis Pin (one per mounting clip)
8. Regulated 12VDC Class 2 Power Supply (PN 750-9990)
9. Wire nuts / connectors
10. 12 gauge wire
Procedure:
1. Insert Clevis Pin into mounting clip hole
2 beam hanger assemblies are required for each EcoBrite
Lamp.
Beam hanger assemblies should be about 50” – 60” apart.
2. Thread the free end of the cable hanger through the hole in
the clevis pin. Secure the cable end in the clasp according to
the manufacturer’s instructions.
3. Fasten the other end of the cable hanger to the beam clamp
then fasten the beam clamp to the beam according to the
manufacturer’s instructions.
4. Repeat steps 1-3 for the second beam hanger assembly and
snap the light fixture to both mounting clips.
Beam hanger assemblies should be hung
vertically. If suspended at an angle, load capacity
will be reduced.

4
EcoBrite Warehouse LED Light Installation Guide Rev 1.2, Date: 07/28/11
Wiring Information:
Lights must be connected to a Regulated, 12V DC, Class 2 power supply
to operate. Use wire nuts or appropriate wire connectors.
Two 6’ 740-XXXX light fixtures or one 6’742-XXXX light fixture may
be powered by one power supply.
12 gauge wire is recommended for extended wiring. Do not exceed 60 ft.
If 18 gage wire is used, do not exceed 15 ft.
Red Wire - Connect to (+) positive output of the 12V DC power supply.
Green/Yellow wire - Connect to (-) negative output of the 12V DC power supply.
Optional Dimming Control:
Connect the Blue wire to the output of a “Normally Closed” isolated relay controlled by
an occupancy sensor. Connect the input of this relay to the (+) positive output of the
12V DC power supply. The light is dimmed when the blue wire receives +12V DC with
respect to the green/yellow wire. Protect wire end with a wire nut if not in use.
Removal Information
If you need to remove the light fixture, place a slotted screwdriver between the rail and the side of the clip.
Gently press the screwdriver handle towards the light to release the light. Do this for all clips. Refer to the
image below.
Cleaning
If the lights require cleaning, follow the procedure bellow.
-Switch off or disconnect the power to the EcoBrite™ lights.
-Remove the EcoBrite™ lights from the mounting clips if necessary.
-Wipe surfaces with a clean, soft cloth lightly dampened in a mixture of warm water and mild dish soap.
-Wipe surfaces again with a clean, soft cloth lightly dampened in warm water.
-Dry all surfaces completely with a clean, soft cloth.
-Reattach the lamp to the mounting clips and switch on/reconnect power.
All wiring must be in compliance with NEC and local codes. This light
fixture is suitable for damp locations. When used in a damp location,
ensure that all connection points are sealed for damp location using
the appropriate method per the NEC or local electrical code.
Do not use abrasive cleaners, scouring pads, or paper towels to clean or dry
the lamp. Do not use bleach, alcohol, or other chemicals to clean the lamp.
Some chemicals and abrasive products may scratch and damage the surfaces.
Do not submerge the lamp or use overly wet cloths as it may cause damage to
internal electrical components.

5
EcoBrite Warehouse LED Light Installation Guide Rev 1.2, Date: 07/28/11
Purchase Date: ________________________
Warranty Expiration Date: _______________
Thank you for your purchase of EcoBrite™ LED Light Fixtures. Please keep the top portion of this page
for your records and mail the bottom portion to the address provided to register your product.
WARRANTY INFORMATION
Innovative Lighting Inc. (ILC) Limited Product Warranty is FIVE (5) YEARS from date of purchase on
EcoBrite™ LED Light Fixtures and their components. Any product developing such defect in material or
workmanship within this period will be repaired or replaced with a like product, at our option (ILC)
providing it is sent to us, transportation charges prepaid. Proof-of-Purchase date must accompany
return to ILC at our Roland, Iowa facility. ILC does not warrant contractor’s installation work or
performance.
This warranty is void if the product warranted has been damaged by accident or unreasonable use,
neglect, improper installation or service, or other cause not arising out of defects in material or
workmanship.
This FIVE (5) YEAR limited product warranty is not transferable and applies to the original installation of
the EcoBrite™ LED Lighting System for as long as the original purchaser owns them.
SHIPPING DAMAGE
EcoBrite™LED Light Fixtures should be examined for shipping damage upon receipt. These fixtures have
been carefully inspected before shipment. Any claim for loss or damage must be made to the carrier.
The carrier will provide any necessary inspection reports and/or claim forms.
PRODUCT REGISTRATION
PRODUCT INFORMATION
EcoBrite™ LED Light Fixture Model: _______________
EcoBrite™ LED Light Fixture Date Code: ____________
Date of Purchase: _______
Number of units purchased:_______
OWNER INFORMATION
Name: _________________________________________
Company: ______________________________________
Address: _______________________________________
City: __________________________________________
State: ___________________________ Zip: __________
Phone: _________________________________________
Fax: ___________________________________________
E-mail: ________________________________________
Mail to: Innovative Lighting, Inc., P.O. Box 366, Roland, Iowa 50236
