MODERN REEF READY
INSTRUCTION MANUAL
EXT-75 | EXT-100 | EXT-200

The NUVO INT has a 1 YEAR limited warranty. The NUVO INT is
warranted to the original purchaser against defective material and
workmanship for 1 YEAR from the date of original purchase. This
warranty is valid only under the following conditions: additions,
modifications, or changes made to the product by the purchaser and
not by the manufacturer shall void this warranty. Damages brought on
by abuse, misapplication, or mishandling also voids this warranty.
This warranty is limited to the repair or replacement of the product at
the discretion of the manufacturer. This warranty does not cover
personal injury, property loss, including livestock or damage (direct,
incidental, or consequential) arising out of use of this product. This
warranty gives you specific rights and you may also have other rights,
which may vary from state to state.
The Product Registration Card must be filled out completely and
returned within (14) days from the date of purchase.
Failure to do so will void this warranty. A proof of purchase from an
authorized dealer must be provided when making a warranty claim.
For Warranty Claims please contact our Customer Care Department.
866-368-7941 | [email protected]
An RMA# must be issued before sending any product back to
Innovative Marine. Products sent back to Innovative Marine without an
RMA# will not be accepted. Service on products will not extend the
original warranty period.
Email: [email protected]
LIMITED WARRANTY
Make sure your NUVO is set on a level surface to prevent undue stress
on the aquarium tank from stress and leaks.
It is not recommended that this aquarium is set upon coffee tables,end
tables, TV stands, or night stands unless the structure has been
properly tested to withstand the weight limits of the aquarium.
Please pay special attention when leveling your aquarium on carpet.
Before lifting your aquarium, make sure your stand is in position.
Lifting the glass aquarium onto its stand will require more than two
people. Please use proper lifting techniques when lifting large heavy
objects.
Lift from the bottom of the aquarium DO NOT lift using the aquarium’s
edges this will cause stress on the glass and seals and may cause
leakage.
The back of the aquarium should be flush with your stand and all four
corners are not overhanging the edges.
Once you have placed your aquarium atop your stand, make sure your
stand has not moved from its position.
Place a level on edge of tank, if necessary readjust and reposition tank
and stand.
PLACING AND LEVELING YOUR NUVO AQUARIUM

BH - Bulkhead
S - Slip
T - Threaded
ID - Inner Diameter
OD - Outer Diameter
Key Terms
Items Included:
3 - 1” Slip x Slip BulkHead [Overflow]
2 - 3/4” Threaded x Slip BulkHead [Return]
1 - 1” Diameter E-Drain Pipe [Overflow]
1 - 1” Diameter Secondary Drain Pipe [Overflow]
2 - 3/4” LOC-LINE w/ Flare Nozzles [Return]
000030
000031
000032
000033
000034
1” Bulkhead SxS
3/4” Bulkhead TxS
1” Diameter E-Drain
3/4” LOC-LINE w/ Nozzle
1” Diameter Secondary Drain
1
2
3
4
1 2 3 4
AQUARIUM
+ High Clarity Low Iron Glass
+ Laser Cut Black Acrylic Weir
+ Black Silicone
+ Rubber Leveling Mat
+ 2 - Pre-drilled 3/4”Bulkhead Return Hole
EXTERNAL LOW IRON GLASS CENTER OVERFLOW
+ Solid Glass Construction
+ Pre-drilled 3 - 1” Drain Holes
+ Silent and Safe Bean Animal Drain System
5
5

EXTERNAL OVERFLOW BOX [REAR VIEW]
1/4”
1” BH SxS
3/4” BH Thread x Slip
3/4” LOC-LINE
MODERN REEF READY
Water line
Water line
Return Hose
!NOTE: Primary Drain Pipe must be submerged a
minimum of 1” for drain pipe to siphon properly.
Primary Drain
1” BH SxS
4
2
E-Drain
3
1
1” Gate Valve is required to maintain
proper water line in overflow box.
Secondary Drain
5
1
Primary Drain
Secondary Drain
E-Drain
Plumbing
Not Included
!E-drain needs to be 1/4”
below the overflow teeth.
