IS300 Series Servo Drive User Manual Preface
- 1 -
Preface
The IS300 series servo drive is specially designed for the permanent magnet synchronous
motor (PMSM). It provides wide coverage of capacity (rated current 2.1–725 A, rated power
400 W–400 kW).
In addition to standard servo drive functions, IS300 can also implement the control of
pumps. It is a cost effective servo drive in the middle to high power range of the existing
market.
This manual is a guideline for the selection, installation, parameter setting, on-site
commissioning and troubleshooting of the IS300 servo drive.
Before using the servo drive, please read this manual carefully so that you fully comprehend
the features of the product. Please ensure that the manual is kept safely before forwarding
to the end user.
Upon Unpacking, Please Ensure That:
1. The nameplate model and ratings of the servo drive match your order. The box contains
the product, the certificate of conformity, the manual and warranty.
2. The product is not damaged. If you find any omission or damage, please contact
Inovance or our agent immediately.
First-time Use
The person who uses this product for the first time must read the manual carefully. If they
have any doubt concerning some functions or performance, please contact our technical
support personnel for advice, thereby ensuring the correct use of our product.
With our commitment to constant improvement of the servo drive, our company may change
the information without further notice.
The IS300 series servo drive complies with the following international standards:
•IEC/EN 61800-5-1: 2003, Adjustable speed electrical power drive systems - Safety
requirements
•IEC/EN 61800-3: 2004, Adjustable speed electrical power drive systems – Part 3: EMC
requirements and specific test methods
Some products have passed the CE certification.

Contents
Preface ………………………………………………………………………………… 1
Chapter 1 Product Information ……………………………………………………… 6
1.1 IS300 Servo Drive Designation Rules ……………………………………………………… 6
1.2 IS300 Models and Technical Data …………………………………………………………… 6
1.3 Selection of IS300 Brake Parts ……………………………………………………………… 9
1.4 Selection of IS300 Peripheral Electrical Parts …………………………………………… 12
1.5 Physical Dimensions and Mounting Dimensions ………………………………………… 15
Chapter 2 Wiring ………………………………………………………………………24
2.1 Wiring Method ……………………………………………………………………………… 24
2.2 Description of Main Circuit Terminals
……………………………………………………… 24
2.3 Description of Control Circuit Terminals
…………………………………………………… 24
2.4 Description of Jumpers of IS300
…………………………………………………………… 26
2.5 Description of Terminals of PG Card of IS300 …………………………………………… 27
2.6 Wiring of External Braking Unit ……………………………………………………… 27
Chapter 3 Commissioning Procedure ………………………………………………30
3.1 Servo Pump Commissioning Flow Chart ………………………………………………… 30
3.2 Motor Trial RUN ……………………………………………………………………………… 30
3.3 Servo Pump Application Trail Run ………………………………………………………… 31
Chapter 4 Operation and Display ……………………………………………………36
4.1 Operation Panel
……………………………………………………………………………… 36
4.2 How to Query and Modify Function Codes ……………………………………………… 38
4.3 QUICK Operation …………………………………………………………………………… 39
4.4 Querying Status Parameters ……………………………………………………………… 40
4.5 Password Setting …………………………………………………………………………… 41
4.6 Motor Tuning ………………………………………………………………………………… 41
Chapter 5 Troubleshooting ……………………………………………………………44
5.1 Faults and Solutions ………………………………………………………………………… 44
5.2 Common Faults and Solutions …………………………………………………………… 55
Chapter 6 ISMG Servo Motor (Voltage Class: 400V)
………………………………58
6.1 ISMG Servo Motor Designation Rules …………………………………………………… 58

6.2 ISMG Servo Motor Specification Parameters …………………………………………… 59
6.3 ISMG Servo Motor Appearance and Mounting Dimensions …………………………… 63
6.4 Description of Supporting Board of ISMG Servo Motor Base ………………………… 66
6.5 Wiring of ISMG Servo Motor ……………………………………………………………… 67
Appendix ………………………………………………………………………………70
Appendix 1 Function Code Table ……………………………………………………………… 70
Appendix 2 Servo Motor Code Table ……………………………………………………… 94
Appendix 3 Configuration Examples of Servo Pump System ……………………………… 95

1
Product Information

Product Information IS300 Series Servo Drive User Manual
- 6 -
Chapter 1 Product Information
1.1 IS300 Servo Drive Designation Rules
IS300 T 030 C L
Servo drive series
Voltage class
S
2T
T
5T
Single-phase 220 V
Three -phase 220 V
Three -phase 380 V
Three -phase 480 V
Cooling method
Null
L
Forced air cooling by default
Water cooling
Rated output current
(approximate value )
Interface board type
C
With CAN communication
and motor overheat
protection PTC sensor
Note that the servo drive with the resolver
PG card is standard configuration.
1.2 IS300 Models and Technical Data
Model Power Capacity
(kVA)
Input Current
(A)
Output Current
(A)
Adapted Motor (S1)
kW HP
Single-phase 220 V, 50/60 Hz
IS300S002-C 1 5.4 2.3 0.4 0.5
IS300S003-C 1.5 8.2 4 0.75 1
IS300S004-C 3 14 7 1.5 2
IS300S005-C 4 23 9.6 2.2 3
Three-phase 220 V, 50/60 Hz
IS300-2T002-C 1.5 3.4 2.1 0.4 0.5
IS300-2T003-C 3 5 3.8 0.75 1
IS300-2T004-C 4 5.8 5.1 1.5 2
IS300-2T005-C 5.9 10.5 9 2.2 3
IS300-2T010-C 8.9 14.6 13 3.7 5
IS300-2T020-C 17 26 25 5.5 7.5
IS300-2T030-C 21 35 32 7.5 10
IS300-2T040-C 30 46.5 45 11 15

IS300 Series Servo Drive User Manual Product Information
- 7 -
Model Power Capacity
(kVA)
Input Current
(A)
Output Current
(A)
Adapted Motor (S1)
kW HP
IS300-2T050-C 40 62 60 15 20
IS300-2T070-C 57 76 75 18.5 25
IS300-2T080-C 69 92 91 22 30
IS300-2T100-C 85 113 112 30 40
IS300-2T140-C 114 157 150 37 50
IS300-2T170-C 134 180 176 45 60
IS300-2T210-C 160 214 210 55 75
IS300-2T300-C 231 307 304 75 100
IS300-2T140-C-L 114 157 150 37 50
IS300-2T170-C-L 134 180 176 45 60
IS300-2T210-C-L 160 214 210 55 75
IS300-2T300-C-L 231 307 304 75 100
Three-phase 380 V, 50/60 Hz
IS300T002-C 1.5 3.4 2.1 0.75 1
IS300T003-C 3 5 3.8 1.5 2
IS300T004-C 4 5.8 5.1 2.2 3
IS300T005-C 5.9 10.5 9 3.7 5
IS300T010-C 8.9 14.6 13 5.5 7.5
IS300T015-C 11 20.5 17 7.5 10
IS300T020-C 17 26 25 11 15
IS300T030-C 21 35 32 15 20
IS300T035-C 24 38.5 37 18.5 25
IS300T040-C 30 46.5 45 22 30
IS300T050-C 40 62 60 30 40
IS300T070-C 57 76 75 37 50
IS300T080-C 69 92 91 45 60
IS300T100-C 85 113 112 55 75
IS300T140-C 114 157 150 75 100
IS300T170-C 134 180 176 90 125
IS300T210-C 160 214 210 110 150
IS300T250-C 192 256 253 132 200
IS300T300-C 231 307 304 160 250
IS300T370-C 250 385 377 200 300

Product Information IS300 Series Servo Drive User Manual
- 8 -
Model Power Capacity
(kVA)
Input Current
(A)
Output Current
(A)
Adapted Motor (S1)
kW HP
IS300T420-C 280 430 426 220 300
IS300T460-C 355 468 465 250 400
IS300T520-C 396 525 520 280 370
IS300T580-C 445 590 585 315 500
IS300T650-C 500 665 650 355 420
IS300T720-C 565 785 725 400 530
IS300T140-C-L 114 157 150 75 100
IS300T170-C-L 134 180 176 90 125
IS300T210-C-L 160 214 210 110 150
IS300T250-C-L 192 256 253 132 200
IS300T300-C-L 231 307 304 160 250
Three-phase 480 V, 50/60 Hz
IS300-5T002-C 1.5 3.4 2.1 0.75 1
IS300-5T003-C 3 5 3.8 1.5 2
IS300-5T004-C 4 5.8 5.1 2.2 3
IS300-5T005-C 5.9 10.5 9 3.7 5
IS300-5T010-C 8.9 14.6 13 5.5 7.5
IS300-5T015-C 11 20.5 17 7.5 10
IS300-5T020-C 17 26 25 11 15
IS300-5T030-C 21 35 32 15 20
IS300-5T035-C 24 38.5 37 18.5 25
IS300-5T040-C 30 46.5 45 22 30
IS300-5T050-C 40 62 60 30 40
IS300-5T070-C 57 76 75 37 50
IS300-5T080-C 69 92 91 45 60
IS300-5T100-C 85 113 112 55 70
IS300-5T140-C 114 157 150 75 100
IS300-5T170-C 134 180 176 90 125
IS300-5T210-C 160 214 210 110 150
IS300-5T250-C 192 256 253 132 175
IS300-5T300-C 231 307 304 160 210
IS300-5T370-C 250 385 377 200 260
IS300-5T420-C 280 430 426 220 300

IS300 Series Servo Drive User Manual Product Information
- 9 -
Model Power Capacity
(kVA)
Input Current
(A)
Output Current
(A)
Adapted Motor (S1)
kW HP
IS300-5T460-C 355 468 465 250 350
IS300-5T520-C 396 525 520 280 370
IS300-5T580-C 445 590 585 315 420
IS300-5T650-C 500 665 650 355 470
IS300-5T720-C 565 785 725 400 530
IS300-5T140-C-L 114 157 150 75 100
IS300-5T170-C-L 134 180 176 90 125
IS300-5T210-C-L 160 214 210 110 150
IS300-5T250-C-L 192 256 253 132 175
IS300-5T300-C-L 231 307 304 160 210
Note
The models in grey are customized servo drives (water cooling).
1.3 Selection of IS300 Brake Parts
Model
(Braking Resistor)
Recommended
Power
(Braking Resistor)
Recommended
Resistance
Braking
Unit Remark
Single-phase 220 V
IS300S002-C 80 W ≥200 Ω
Built-in No special
description
IS300S003-C 80 W ≥150 Ω
IS300S004-C 100 W ≥100 Ω
IS300S005-C 100 W ≥70 Ω
Three-phase 220 V
IS300-2T002-C 150 W ≥150 Ω
Built-in No special
description
IS300-2T003-C 150 W ≥110 Ω
IS300-2T004-C 250 W ≥100 Ω
IS300-2T005-C 300 W ≥65 Ω
IS300-2T010-C 400 W ≥45 Ω
IS300-2T020-C 800 W ≥22 Ω
IS300-2T030-C 1000 W ≥16 Ω
IS300-2T040-C 1500 W ≥11 Ω
IS300-2T050-C 2500 W ≥8 Ω
IS300-2T070-C 3.7 kW ≥4 ΩExternal MDBU-70-A

Product Information IS300 Series Servo Drive User Manual
- 10 -
Model
(Braking Resistor)
Recommended
Power
(Braking Resistor)
Recommended
Resistance
Braking
Unit Remark
IS300-2T080-C 4.5 kW ≥4 ΩExternal MDBU-70-A
IS300-2T100-C 5.5 kW ≥4 ΩExternal MDBU-70-A
IS300-2T140-C 7.5 kW ≥4 ΩExternal MDBU-70-A
IS300-2T170-C 4.5 kW x2 ≥4 Ωx2 External MDBU-70-A x2
IS300-2T210-C 5.5 kW x2 ≥4 Ωx2 External MDBU-70-A x2
IS300-2T300-C 16 kW ≥1.2 ΩExternal MDBU-200-A
IS300-2T140-C-L 7.5 kW ≥4 ΩExternal MDBU-70-A
IS300-2T170-C-L 4.5 kW x2 ≥4 Ωx2 External MDBU-70-A x2
IS300-2T210-C-L 5.5 kW x2 ≥4 Ωx2 External MDBU-70-A x2
IS300-2T300-C-L 16 kW ≥1.2 ΩExternal MDBU-200-A
Three-phase 380 V
IS300T002-C 150 W ≥300 Ω
Built-in No special
description
IS300T003-C 150 W ≥220 Ω
IS300T004-C 250 W ≥200 Ω
IS300T005-C 300 W ≥130 Ω
IS300T010-C 400 W ≥90 Ω
IS300T015-C 500 W ≥65 Ω
IS300T020-C 800 W ≥43 Ω
IS300T030-C 1000 W ≥32 Ω
IS300T035-C 1300 W ≥25 Ω
IS300T040-C 1500 W ≥22 Ω
IS300T050-C 2500 W ≥16 Ω
IS300T070-C 3.7 kW ≥8 ΩExternal MDBU-70-B
IS300T080-C 4.5 kW ≥8 ΩExternal MDBU-70-B
IS300T100-C 5.5 kW ≥8 ΩExternal MDBU-70-B
IS300T140-C 7.5 kW ≥8 ΩExternal MDBU-70-B
IS300T170-C 4.5 kW x2 ≥8 Ωx2 External MDBU-70-B x2
IS300T210-C 5.5 kW x2 ≥8 Ωx2 External MDBU-70-B x2
IS300T250-C 6.5 kW x2 ≥8 Ωx2 External MDBU-70-B x2
IS300T300-C 16 kW ≥2.5 ΩExternal MDBU-200-B
IS300T370-C 20 kW ≥2.5 ΩExternal MDBU-200-B
IS300T420-C 22 kW ≥2.5 ΩExternal MDBU-200-B
IS300T460-C 12.5 kW x2 ≥2.5 Ωx2 External MDBU-200-B x2
IS300T520-C 14 kW x2 ≥2.5 Ωx2 External MDBU-200-B x2
IS300T580-C 16 kW x2 ≥2.5 Ωx2 External MDBU-200-B x2
IS300T650-C 17 kW x2 ≥2.5 Ωx2 External MDBU-200-B x2

IS300 Series Servo Drive User Manual Product Information
- 11 -
Model
(Braking Resistor)
Recommended
Power
(Braking Resistor)
Recommended
Resistance
Braking
Unit Remark
IS300T720-C 14 kW x3 ≥2.5 Ωx3 External MDBU-200-B x3
IS300T140-C-L 7.5 kW ≥8 ΩExternal MDBU-70-B
IS300T170-C-L 4.5 kW x2 ≥8 Ωx2 External MDBU-70-B x2
IS300T210-C-L 5.5 kW x2 ≥8 Ωx2 External MDBU-70-B x2
IS300T250-C-L 6.5 kW x2 ≥8 Ωx2 External MDBU-70-B x2
IS300T300-C-L 16 kW ≥2.5 ΩExternal MDBU-200-B
Three-phase 480 V
IS300-5T002-C 150 W ≥300 Ω
Built-in No special
description
IS300-5T003-C 150 W ≥220 Ω
IS300-5T004-C 250 W ≥200 Ω
IS300-5T005-C 300 W ≥130 Ω
IS300-5T010-C 400 W ≥90 Ω
IS300-5T015-C 500 W ≥65 Ω
IS300-5T020-C 800 W ≥43 Ω
IS300-5T030-C 1000 W ≥32 Ω
IS300-5T035-C 1300 W ≥25 Ω
IS300-5T040-C 1500 W ≥22 Ω
IS300-5T050-C 2500 W ≥16 Ω
IS300-5T070-C 3.7 kW ≥16.0 ΩExternal MDBU-70-D
IS300-5T080-C 4.5 kW ≥16 ΩExternal MDBU-70-D
IS300-5T100-C 5.5 kW ≥8 ΩExternal MDBU-70-D
IS300-5T140-C 7.5 kW ≥8 ΩExternal MDBU-70-D
IS300-5T170-C 4.5 kW x2 ≥8 Ωx2 External MDBU-70-D x2
IS300-5T210-C 5.5 kW x2 ≥8 Ωx2 External MDBU-70-D x2
IS300-5T250-C 6.5 kW x2 ≥8 Ωx2 External MDBU-70-D x2
IS300-5T300-C 16 kW ≥2.5 ΩExternal MDBU-200-D
IS300-5T370-C 20 kW ≥2.5 ΩExternal MDBU-200-D
IS300-5T420-C 22 kW ≥2.5 ΩExternal MDBU-200-D
IS300-5T460-C 12.5 kW x2 ≥2.5 Ωx2 External MDBU-200-D x2
IS300-5T520-C 14 kW x2 ≥2.5 Ωx2 External MDBU-200-D x2
IS300-5T580-C 16 kW x2 ≥2.5 Ωx2 External MDBU-200-D x2
IS300-5T650-C 17 kW x2 ≥2.5 Ωx2 External MDBU-200-D x2
IS300-5T720-C 14 kW x3 ≥2.5 Ωx3 External MDBU-200-D x3
IS300-5T140-C-L 7.5 kW ≥8 ΩExternal MDBU-70-D
IS300-5T170-C-L 4.5 kW x2 ≥8 Ωx2 External MDBU-70-D x2
IS300-5T210-C-L 5.5 kW x2 ≥8 Ωx2 External MDBU-70-D x2

Product Information IS300 Series Servo Drive User Manual
- 12 -
Model
(Braking Resistor)
Recommended
Power
(Braking Resistor)
Recommended
Resistance
Braking
Unit Remark
IS300-5T250-C-L 6.5 kW x2 ≥8 Ωx2 External MDBU-70-D x2
IS300-5T300-C-L 16 kW ≥2.5 ΩExternal MDBU-200-D
Note
•"x2" indicates that two braking units with respective braking resistor are connected in
parallel. "x3" has the same indication.
•The models in grey are customized servo drives (water cooling).
1.4 Selection of IS300 Peripheral Electrical Parts
Model MCCB
(A)
Recommended
Contactor (A)
Recommended
Main Circuit
Cable at Input
Side (mm2)
Recommended
Main Circuit
Cable at Output
Side (mm2)
Recommended
Control Circuit
Cable (mm2)
Single-phase 220 V
IS300S002-C 16 10 2.5 2.5 1.0
IS300S003-C 16 10 2.5 2.5 1.0
IS300S004-C 20 16 4.0 2.5 1.0
IS300S005-C 32 20 6.0 4.0 1.0
Three-phase 220 V
IS300-2T002-C 10 10 2.5 2.5 1.0
IS300-2T003-C 16 10 2.5 2.5 1.0
IS300-2T004-C 16 10 2.5 2.5 1.0
IS300-2T005-C 25 16 4.0 4.0 1.0
IS300-2T010-C 32 25 4.0 4.0 1.0
IS300-2T020-C 63 40 4.0 4.0 1.0
IS300-2T030-C 63 40 6.0 6.0 1.0
IS300-2T040-C 100 63 10 10 1.5
IS300-2T050-C 125 100 16 10 1.5
IS300-2T070-C 160 100 16 16 1.5
IS300-2T080-C 200 125 25 25 1.5
IS300-2T100-C 200 125 35 25 1.5
IS300-2T140-C 250 160 50 35 1.5
IS300-2T170-C 250 160 70 35 1.5
IS300-2T210-C 350 350 120 120 1.5
IS300-2T300-C 500 400 185 185 1.5
IS300-2T140-C-L 250 160 50 35 1.5
IS300-2T170-C-L 250 160 70 35 1.5

IS300 Series Servo Drive User Manual Product Information
- 13 -
Model MCCB
(A)
Recommended
Contactor (A)
Recommended
Main Circuit
Cable at Input
Side (mm2)
Recommended
Main Circuit
Cable at Output
Side (mm2)
Recommended
Control Circuit
Cable (mm2)
IS300-2T210-C-L 350 350 120 120 1.5
IS300-2T300-C-L 500 400 185 185 1.5
Three-phase 380 V
IS300T002-C 10 10 2.5 2.5 1.0
IS300T003-C 16 10 2.5 2.5 1.0
IS300T004-C 16 10 2.5 2.5 1.0
IS300T005-C 25 16 4.0 4.0 1.0
IS300T010-C 32 25 4.0 4.0 1.0
IS300T015-C 40 32 4.0 4.0 1.0
IS300T020-C 63 40 4.0 4.0 1.0
IS300T030-C 63 40 6.0 6.0 1.0
IS300T035-C 100 63 6 6 1.5
IS300T040-C 100 63 10 10 1.5
IS300T050-C 125 100 16 10 1.5
IS300T070-C 160 100 16 16 1.5
IS300T080-C 200 125 25 25 1.5
IS300T100-C 200 125 35 25 1.5
IS300T140-C 250 160 50 35 1.5
IS300T170-C 250 160 70 35 1.5
IS300T210-C 350 350 120 120 1.5
IS300T250-C 400 400 150 150 1.5
IS300T300-C 500 400 185 185 1.5
IS300T370-C 600 600 150 x2 150 x2 1.5
IS300T420-C 600 600 150 x2 150 x2 1.5
IS300T460-C 800 600 185 x2 185 x2 1.5
IS300T520-C 800 800 185 x2 185 x2 1.5
IS300T580-C 800 800 150 x3 150 x3 1.5
IS300T650-C 800 800 150 x4 150 x4 1.5
IS300T720-C 1000 1000 150 x4 150 x4 1.5
IS300T140-C-L 250 160 50 35 1.5
IS300T170-C-L 250 160 70 35 1.5
IS300T210-C-L 350 350 120 120 1.5
IS300T250-C-L 400 400 150 150 1.5
IS300T300-C-L 500 400 185 185 1.5
Three-phase 480 V
IS300-5T002-C 10 10 2.5 2.5 1.0

Product Information IS300 Series Servo Drive User Manual
- 14 -
Model MCCB
(A)
Recommended
Contactor (A)
Recommended
Main Circuit
Cable at Input
Side (mm2)
Recommended
Main Circuit
Cable at Output
Side (mm2)
Recommended
Control Circuit
Cable (mm2)
IS300-5T003-C 16 10 2.5 2.5 1.0
IS300-5T004-C 16 10 2.5 2.5 1.0
IS300-5T005-C 25 16 4.0 4.0 1.0
IS300-5T010-C 32 25 4.0 4.0 1.0
IS300-5T015-C 40 32 4.0 4.0 1.0
IS300-5T020-C 63 40 4.0 4.0 1.0
IS300-5T030-C 63 40 6.0 6.0 1.0
IS300-5T035-C 100 63 6 6 1.5
IS300-5T040-C 100 63 10 10 1.5
IS300-5T050-C 125 100 16 10 1.5
IS300-5T070-C 160 100 16 16 1.5
IS300-5T080-C 200 125 25 25 1.5
IS300-5T100-C 200 125 35 25 1.5
IS300-5T140-C 250 160 50 35 1.5
IS300-5T170-C 250 160 70 35 1.5
IS300-5T210-C 350 350 120 120 1.5
IS300-5T250-C 400 400 150 150 1.5
IS300-5T300-C 500 400 185 185 1.5
IS300-5T370-C 600 600 150 x2 150 x2 1.5
IS300-5T420-C 600 600 150 x2 150 x2 1.5
IS300-5T460-C 800 600 185 x2 185 x2 1.5
IS300-5T520-C 800 800 185 x2 185 x2 1.5
IS300-5T580-C 800 800 150 x3 150 x3 1.5
IS300-5T650-C 800 800 150 x4 150 x4 1.5
IS300-5T720-C 1000 1000 150 x4 150 x4 1.5
IS300-5T140-C-L 250 160 50 35 1.5
IS300-5T170-C-L 250 160 70 35 1.5
IS300-5T210-C-L 350 350 120 120 1.5
IS300-5T250-C-L 400 400 150 150 1.5
IS300-5T300-C-L 500 400 185 185 1.5
Note
The models in grey are customized servo drives (water cooling).

IS300 Series Servo Drive User Manual Product Information
- 15 -
1.5 Physical Dimensions and Mounting Dimensions
1.5.1 IS300 (Forced Air Cooling)
■IS300(*)002-C-IS300(*)030-C Physical Dimensions & Mounting Dimensions
■IS300(*)035-C-IS300(*)720-C Physical Dimensions & Mounting Dimensions

Product Information IS300 Series Servo Drive User Manual
- 16 -
■Table of IS300 Physical Dimensions and Mounting Dimensions
Model Mounting Hole (mm) Physical Dimensions (mm) Mounting Hole
Diameter (mm)
Weight
(kg)
A B H H1 W D
Single-phase 220 V
IS300S002-C
113 172 186 / 125 164 Ø5.0 1.1
IS300S003-C
IS300S004-C
IS300S005-C
Three-phase 220 V
IS300-2T002-C
113 172 186 / 125 164 Ø5.0 1.1IS300-2T003-C
IS300-2T004-C
IS300-2T005-C 148 236 248 / 160 183 Ø5.0 2.5
IS300-2T010-C
IS300-2T020-C 190 305 322 / 208 192 Ø6 6.5
IS300-2T030-C
IS300-2T040-C 235 447 432 463 285 228 Ø6.5 20
IS300-2T050-C
IS300-2T070-C
260 580 549 600 385 265 Ø10 32IS300-2T080-C
IS300-2T100-C
IS300-2T140-C 343 678 660 700 473 307 Ø10 47
IS300-2T170-C
IS300-2T210-C 449 903 880 930 579 380 Ø10 90
IS300-2T300-C
Three-phase 380 V
IS300T002-C
113 172 186 / 125 164 Ø5.0 1.1IS300T003-C
IS300T004-C
IS300T005-C 148 236 248 / 160 183 Ø5.0 2.5
IS300T010-C
IS300T015-C
190 305 322 / 208 192 Ø6 6.5IS300T020-C
IS300T030-C

IS300 Series Servo Drive User Manual Product Information
- 17 -
Model Mounting Hole (mm) Physical Dimensions (mm) Mounting Hole
Diameter (mm)
Weight
(kg)
A B H H1 W D
IS300T035-C
235 447 432 463 285 228 Ø6.5 20IS300T040-C
IS300T050-C
IS300T070-C
260 580 549 600 385 265 Ø10 32IS300T080-C
IS300T100-C
IS300T140-C 343 678 660 700 473 307 Ø10 47
IS300T170-C
IS300T210-C
449 903 880 930 579 380 Ø10 90IS300T250-C
IS300T300-C
IS300T370-C
420 1030 983 1060 650 377 Ø12 130
IS300T420-C
IS300T460-C
IS300T520-C
IS300T580-C
520 1300 1203 1358 800 400 Ø16 200IS300T650-C
IS300T720-C
Three-phase 480 V
IS300-5T002-C
113 172 186 / 125 164 Ø5.0 1.1
IS300-5T003-C
IS300-5T004-C
IS300-5T005-C 148 236 248 / 160 183 Ø5.0 2.5
IS300-5T010-C
IS300-5T015-C
190 305 322 / 208 192 Ø6 6.5
IS300-5T020-C
IS300-5T030-C
IS300-5T035-C
235 447 432 463 285 228 Ø6.5 20IS300-5T040-C
IS300-5T050-C
IS300-5T070-C
260 580 549 600 385 265 Ø10 32IS300-5T080-C
IS300-5T100-C

Product Information IS300 Series Servo Drive User Manual
- 18 -
Model Mounting Hole (mm) Physical Dimensions (mm) Mounting Hole
Diameter (mm)
Weight
(kg)
A B H H1 W D
IS300-5T140-C
343 678 660 700 473 307 Ø10 47
IS300-5T170-C
IS300-5T210-C
449 903 880 930 579 380 Ø10 90
IS300-5T250-C
IS300-5T300-C
IS300-5T370-C
420 1030 983 1060 650 377 Ø12 130
IS300-5T420-C
IS300-5T460-C
IS300-5T520-C
IS300-5T580-C
520 1300 1203 1358 800 400 Ø16 200IS300-5T650-C
IS300-5T720-C
1.5.2 IS300 (Water Cooling)
■Physical Dimensions & Mounting Dimensions of IS300(*)140-C-L and IS300(*)170-C-L
541.5
31.5
51
590
208 ¼ pipe thread
347
242.4 237.6
Mounting
hole
218
10
541.5

IS300 Series Servo Drive User Manual Product Information
- 19 -
■Physical Dimensions & Mounting Dimensions of IS300T210(*)-C-L, IS300T250(*)-C-L
and IS300T300(*)-C-L
698.5
650
27.5
272.5 161 ¼ pipe thread
284.8
280
450
675
370
Mounting
hole
1.5.3 Mounting Hole Dimensions of Operation Panel
Φ4.00/typ 2
9.75
95.00
4.70
99.30
63.75
73.50
