Inovance SV670P Series Installation instructions

‑1‑
Preface
Preface
Introduction
Thank you for purchasing the SV670P series servo drive developed by Inovance.
The SV670P series servo drive is a high‑end servo drive designed based on global‑
leading standards and high‑end application needs. It is featured with high speed, high
precision, high performance, and tuning‑free Function.
The servo drive covers a power range from 0.05 kW to 7.5 kW and carries Modbus
communication interfaces to work with the host controller for a networked operation
of multiple servo drives. The drive comes with the ITune function which supports
adaptive stiffness level setting, inertia auto‑tuning, and vibration suppression for easy
use. The servo drive, together with an MS1 series high‑response servo motor (with
ultra‑low, low or medium inertia) equipped with a 23‑bit single‑turn/multi‑turn
absolute encoder, serve to deliver a quiet and stable operation and accurate process
control through the fully closed‑loop function and internal process segment function.
The drive also offers dynamic braking. The drive aims to achieve quick and accurate
position control, speed control, and torque control through high‑performance
solutions for automation equipment in such industries as electronic manufacturing,
lithium batteries, manipulators, packaging, and machine tools.
This guide presents the servo drive electrical design guidance, terminal introduction,
certification and standard requirements, and suggestions for solving common EMC
problems.
More Documents
Name Data Code Description
SV670P Series Servo Drive
Selection Guide 19011852
Provides instructions on product
selection, including the list of supporting
components, technical data on the drive
and motor, and the selection guide of
cables.
SV670P Series Servo Drive
installation Guide 19011868
Presents installation of the servo drive,
including installation steps, , mechanical
installation, and electrical installation.
SV670P Series Servo Drive
Hardware Guide 19011854
Presents electrical design guidance of the
equipment, description of terminals,
required certificates and standards and
solutions to common EMC problems.
SV670P Series Servo Drive
Commissioning Guide 19011856
Presents servo commissioning, parameter
descriptions, including the operating
panel, commissioning software,
commissioning procedure and a
parameter list.

‑2‑
Preface
Name Data Code Description
SV670P Series Servo Drive
Function Guide 19011866
Presents functions and parameters,
including function overview, basic servo
functions, adjustment and parameter list.
SV670P Series Servo Drive
Communication Guide 19011871
Presents functions and parameters of the
servo drive, including Modbus
communication configuration, parameter
descriptions, and communication
application cases.
SV670P Series Servo Drive
Troubleshooting Guide 19011869
Introduces faults and fault levels, the
troubleshooting process, warning codes
and fault codes.
SV670P Series Servo Drive
Maintenance Guide 19011870 Provides instructions on maintenance
and repair of the equipment.
SV670P Series Servo Drive Safety
Guide 19011867
Presents the safety function and related
certifications and standards, wiring,
commissioning process, troubleshooting,
and functions.
SV670P Series Servo Drive Manual
Package PS00005526
Provides information on selection,
installation, commissioning, function,
troubleshooting and parameters of the
equipment.
Revision History
Date of Revision Version Description
2022‑08 A04 Modified the recommendations for the main circuit
cable.
2022‑07 A03
●Updated the schematic diagram of the drive.
●Deleted information on the CN8 terminal.
●Modified the recommended specifications of the main
circuit cable lug.
2022‑05 A02
●Changed the CN3/CN4 terminals in the system
connection diagram.
●Modified the wiring diagram for torque control mode.
●Modified the terminal layout diagram in section 4.4.
●Modified the connection diagram of the CN2 absolute
encoder.
2022‑05 A01 Modified the analog input wiring diagram.
2022‑04 A00 First release.
Document Acquisition
This manual is not delivered with the product. You can obtain the PDF version by
visiting:
●
http://www.inovance.com
.

‑3‑
Preface
●Scan the QR code on the equipment to acquire more.

‑4‑
