EE1260 EchoStream® Passive Infrared Motion
Detector
Installation and Operation Manual - 05375B
1 Overview
The EE1260 is a low-current motion detector highly sensitive to moving heat (infrared
radiation) sources. It features increased immunity to radio frequency interference,
vibration, static, lightning, ambient temperature changes, and other common causes
of false alarms.
The EE1260 includes a range of features, including a wall tamper capability for
increased security, and a fixed or variable sleep time option for normal or high-traffic
applications.
Caution: The EE1260 needs one minute for stabilization after power up. During the
stabilization period, the LED will blink twice per second, and the EE1260 will not be
operational.
1.1 Inovonics Wireless Contact Information
If you have any problems with this procedure, contact Inovonics Wireless technical
services:
• E-mail: [email protected]
• Phone: [phone]
2 Installation and Startup
2.1 Install/Replace Battery
To install the battery:
1. Use a small Phillips screwdriver to remove the screw at the bottom of the EE1260
housing; separate the housing.
2. Install/replace the battery.
3. Press the Reset button to initialize the transmitter.
2.2 EE1260 Components
Figure 1 EE1260 components
4.
2.3 Enable EchoStream Select
To meet ETSI requirements, Inovonics has developed a new line of EE 868MHz-only
products. These new 868MHz-only products are compatible with older systems that
include EchoStream Select products. If you are using any ES products in your current
system, you will need to enable EchoStream Select compatibility on this new 868MHz-
only product.
To enable/disable EchoStream Select compatibility:
1. To enable compatibility with ES products, place a selection jumper on the ES
selection pins.
Note: The selection jumper is included in the EE1260 hardware packet.
2. If no ES products are used in your system, remove the selection jumper from the
ES selection pins.
3. Press the Reset button to initialize the transmitter.
Caution: When pressing the Reset button, make sure you don’t also touch the ES
selection pins. Touching the ES selection pins while pressing the Reset button can
inadvertently set the EE1260 to the wrong frequency band.
2.4 Select Automatic/Pulse Count
The pulse count jumper setting provides control for normal or difficult operating
environments. Automatic pulse count is recommended for reliable operation in
environments subject to temperature fluctuations that may cause false alarms. The
single pulse count mode is more sensitive to minor temperature variations, and should
be used in sites where variant heat sources will not cause false alarms.
1. Place a selection jumper on the appropriate pulse count selection pins.
• Place the jumper on the left two pins to select automatic pulse count.
• Place the jumper on the right two pins to select single pulse count.
2. Press the Reset button to complete configuration.
2.5 Select Fixed/Variable Sleep Time
The sleep time jumper setting provides control for normal or high-traffic operating
environments. When set to fixed, if the EE1260 senses motion, it will transmit an
alarm, then enter sleep mode for 180 seconds; if motion is sensed when the sleep
time has expired, the EE1260 will transmit another alarm. Fixed sleep time is
recommended for normal operating environments. When set to variable, if the EE1260
senses motion, it will transmit an alarm, then enter sleep mode for 180 seconds; if
motion is sensed before the sleep time has expired, the EE1260 will restart the 180
second interval. Variable sleep time is recommended for high-traffic operating
environments.
1. Place a selection jumper on the appropriate sleep time selection pins.
• Place the jumper on the left two pins to select fixed sleep time.
• Place the jumper on the right two pins to select variable sleep time.
2. Install the battery.
3. Press the Reset button.
2.6 Register the Transmitter
The EE1260 must be registered with the system receiver in order to be monitored and
supervised. Each EE1260 has a unique factory-programmed identification number.
Refer to the receiver, network coordinator or control panel installation instructions for
details on registering a transmitter.
1. When prompted reset the EE1260, press the EE1260 Reset button.
2. Replace the EE1260 cover.
Caution: The EE1260 should be tested after registration to ensure operation. To test
the EE1260, activate each of the conditions and ensure an appropriate response.
Note: The EE1260 retains programming data in non-volatile memory. It does not
require re-programming after loss of power.
2.7 Mount the Transmitter
Mount the transmitter.
1. Remove the EE1260 printed circuit board from the housing.
2. Use the included hardware to mount the EE1260 housing back plate to the
mounting surface.
a. If using the wall tamper function for increased security, mount the housing back
plate per Figure 2, ensuring the tamper switch is depressed..
Figure 2 EE1260 mounting back plate
b. If not using the wall tamper, mount the housing back plate using all appropriate
hardware.
3 Test the EE1260
3.1 Perform a Walk Test
The walk test is performed to test the PIR, ensuring motion is sensed. To perform a
walk test:
AES selection pins BReset button CPulse count selection pins
DTamper switch ETest mode reed switch FSleep time selection pins
C
A
D
B
E
F
Mount either
corner or wall
with screw only
Mount either corner
or wall with screw
and wall anchor
Mount either
corner or wall
with screw only

© Inovonics, 2011 - www.inovonics.com 2
1. Hold the magnet to the reed switch for less than one quarter of a second, The
LED will light three times to indicate the three-minute walk test has been
activated.
Note: To activate the walk test, the magnet shouldn’t remain near the reed switch for
more than one-quarter of a second.
2. Walk in front of the PIR to test the sensor. The LED will light every time the PIR
senses motion.
3. The unit will not transmit alarm signals during the three minute test period. When
the walk test ends, the LED will light six times.
3.2 Perform Transmission Test
1. Hold the magnet to the reed switch for more than four seconds. The LED will light
three times to indicate the transmission test has been activated.
2. The unit will transmit alarm and restoral cycles at regular intervals for
approximately one minute. The LED will light every time the unit transmits. Ensure
transmissions are received by your network coordinator, receiver or control panel.
4 Operation
The EE1260 transmitter signals an alarm condition when motion is detected by the
sensor.
4.1 Zone Pattern for Standard Lens
The standard wide-angle lens has a coverage pattern of 105°, and covers an area 18
m x 18 m (60 ft x 60 ft). It has a total of 52 zones: (18 long range + 16 intermediate +
ten short range + six nearest range + two creep zones). Optional lenses are available.
Contact Inovonics Wireless technical services.
4.2 Lens Options
The following optional lenses are available for the EE1260:
• ACC672CT curtain lens
• ACC672LR long range lens
• ACC672PA pet alley lens
Note: Mounting height of the EE1260 with standard lens may be anywhere within a
range of 2.1 to 2.7 meters (7 to 9 feet).
Figure 3 EE1260 zone map
5 Specifications
Dimensions: 11.4 8cm x 6.4 cm x 4.1 cm (4.5”H x 2.5”Wx 1.6”D)
Operating temperature: -4° to 60°C (-20° to 140°F)
Humidity: 0 - 90% (non-condensing)
Battery: 3V lithium (CR123A orDL123A)
Tamper: Housing and wall tamper
PIR RF interference immunity: Greater than 30 v/m 26 MHz - 1 GHz
Alarm lockout time: 3 minutes
Mounting height: 2.1 to 2.7 meters (7 to 9 feet)
6 Warranty/Disclaimer
Note: Changes or modifications to this unit not expressly approved by Inovonics
Wireless Corporation may void the installer's authority to operate the equipment as
well as the product warranty.
Inovonics Wireless Corporation ("Inovonics") warrants its EchoStream products
("Product" or "Products") to conform to its own specifications and to be free of defects
in materials and workmanship under normal use for a period of thirty-six (36) months
from the date of manufacture. Within the warranty period, Inovonics will repair or
replace, at its option, all or any part of the warranted Product. Inovonics will not be
responsible for dismantling and/or reinstallation charges. To exercise the warranty, the
User ("User", "Installer" or "Consumer") must work directly through their authorized
distributor who will be given a Return Material Authorization ("RMA") number by
Inovonics. Details of shipment will be arranged directly through the authorized
distributor.
This warranty is void in cases of improper installation, misuse, failure to follow
installation and operating instructions, alteration, accident or tampering, and repair by
anyone other than Inovonics.
This warranty is exclusive and expressly in lieu of all other warranties, obligations or
liabilities, whether written, oral, express, or implied. There is no warranty by Inovonics
that Inovonics product will be merchantable or fit for any particular purpose, nor is
there any other warranty, expressed or implied, except as such is expressly set forth
herein. In no event shall Inovonics be liable for an incidental, consequential, indirect,
special, or exemplary damages, including but not limited to loss of profit, revenue, or
contract, loss of use, cost of down time, or interruption of business, nor any claim
made by distributor's customers or any other person or entity.
This warranty will not be modified or extended. Inovonics does not authorize any
person to act on its behalf to modify or extend this warranty.
This warranty will apply only to Inovonics Products. Inovonics will not be liable for any
direct, incidental, or consequential damage or loss whatsoever, caused by the
malfunction of Product due to products, accessories, or attachments of other
manufacturers, including batteries, used in conjunction with Inovonics Products.
Note: E-mail [e-mail] for a copy of the CE Declaration of Conformity.
