EN1248 Glassbreak Detector
Installation and Operation Manual
1 Overview
The EN1248 glassbreak detector is a wireless omni-directional glassbreak
detector, providing detection coverage of 180°, as measured from the
sensor to the point on the glass farthest from the sensor.
1.1 Inovonics Contact Information
If you have any problems with this procedure, contact Inovonics technical
support:
• E-mail: [email protected].
• Phone: [phone].
2 Installation and Startup
2.1 Installation Notes
• These products are designed to be maintained by professional
security technicians
• Products are tested for indoor use
• All products should be manually tested weekly
2.2 Install the Battery
Before installing the EN1248 glassbreak transmitter you will need to install
the battery. To install the battery:
1. Use a Phillips screwdriver to loosen the housing screw.
2. Tilt out the glassbreak detector to remove it from the base.
Figure 1 Remove the glassbreak detector from the base
3. Install the batteries.
Figure 2 Install the batteries
2.3 Register the Transmitter
EN1248 transmitters must be registered. Refer to receiver, network
coordinator or control panel installation instructions to register the EN1248
transmitter.
1. When prompted to register the device, remove and reinstall the
batteries.
Caution: The EN1248 should be tested after registration to ensure
operation. To test the EN1248, activate each of the conditions and ensure
an appropriate response.
2.4 Mount the EN1248
1. Choose your mounting location, considering the following:
• Coverage is measured from the detector to the point on the glass
farthest from the detector.
• The detector can be mounted as close as 3.28’ (1m) from the glass.
• Mounted on the opposite or adjoining walls, the maximum range is
26.2’ (8m) for plate or glass.
• Mounted on the ceiling, the maximum range is 19.6’ (6m) for plate,
tempered, laminated and wired glass.
• For armor-coated glass, mount sensor no more than 11.9’ (3.65m)
from glass.
2. Use the included three mounting screws to mount the EN1248 to the
wall.
Figure 3 Mount the glassbreak detector
For product and installation videos visit us at
www.inovonics.com/videos or use the QR
code below.

11.18.21 357-00048-02 Rev A © Inovonics, 2021 - www.inovonics.com 2
2.5 Test the EN1248
The EN1248 should be tested following installation. When in test mode the
red test LED will light solid when the glass is within detection range. If the
LED does not light solid, but continues blinking, reposition the detector
closer to the protected windows, and retest. To initiate test mode:
1. Press the tamper button three times within three seconds.
2. Either use a hand clap or Sentrol 5709C acoustic glassbreak sensor to
test the functionality.
Note: The test LED only lights red while in test mode.
3 Specifications
Dimensions: 2.5” x 2.5” x .9” (63mm x 63mm x 22mm).
Weight (inc. battery) 4.2 oz (120g).
Operating temperature: 32°F to 120°F (0°C to 49°C).
Humidity: 0 - 93% (non-condensing).
Detection method: Omni-directional electric microphone.
Coverage area: Up to 26.2’ (8m); 180° radius.
Battery: Two Energizer Ultimate lithium 1.5V AA batteries.
Battery life: 2 years.
4 Television and Radio Interference
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
5 FCC Part 15 and Innovation, Science and
Economic Development Canada (ISED)
Compliance
This device complies with part 15 of the FCC Rules, and ISED license-
exempt RSS standard(s). Operation is subject to the following two
conditions: (1) this device may not cause interference, and (2) this device
must accept any interference that may cause undesired operation of the
device.
Le présent appareil est conforme aux CNR Innovation, Sciences et
Développement économique Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions
suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur
de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
Caution: Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
6 Radiation Exposure Limits
6.1 FCC
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. In order to avoid the possibility of exceeding the
FCC radio frequency exposure limits, human proximity to the antenna shall
not be less than 20 cm during normal operation and must not be co-located
or operating in conjunction with any other antenna or transmitter.
6.2 ISED
This equipment complies with ISED RSS-102 radiation exposure limits set
forth for an uncontrolled environment. This transmitter must be installed to
provide a separation distance of at least 20 cm from all persons and must
not be co-located or operating in conjunction with any other antenna or
transmitter.
Cet équipement est conforme avec ISED RSS-102 des limites d'exposition
aux rayonnements définies pour un environnement non contrôlé. Cet
émetteur doit être installé à au moins 20 cm de toute personne et ne doit
pas être colocalisé ou fonctionner en association avec une autre antenne
ou émetteur.
