USER GUIDE
Built-in 4.9 Cu. Ft.
Wine Cooler
NS-WB44SS8
NS-WB44SS8_17-0586_MAN_V1_ENG.fm Page 1 Monday, August 14, 2017 8:44 AM

www.insigniaproducts.com
2
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Important Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Control and display panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Setting up your wine cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Before using your cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Finding a suitable location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Building in your wine cooler. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Leveling your cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Reversing the door. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Grounding requirement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Connecting to power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Using your wine cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Turning on your cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Setting the temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Lighting your cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Memory function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Understanding the dual temperature zones . . . . . . . . . . . . . . . .14
Using the wine shelves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Arranging your wine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Serving and storage tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Maintaining your wine cooler. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Defrosting your cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Storing your cooler. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Moving your wine cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Tips on saving energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Error codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
ONE-YEAR LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Introduction
Congratulations on your purchase of a high-quality Insignia product. Your
NS-WB44SS8 represents the state of the art in wine cooler design and is
designed for reliable and trouble-free performance.
NS-WB44SS8_17-0586_MAN_V1_ENG.fm Page 2 Monday, August 14, 2017 8:44 AM

3
Built-in 4.9 Cu. Ft. Wine Cooler
www.insigniaproducts.com
Important Safety Instructions
WARNING
To reduce the risk of fire, electrical shock, or injury follow these basic
precautions when using your cooler.
• Read all instructions before using the cooler.
•DANGER or WARNING: Risk of child entrapment.
• To avoid the possibility of child entrapment, please take the following
precautions before throwing out the appliance:
• Remove all doors from the unit.
• Leave the shelves in place so that children may not easily climb inside.
• Never allow children to operate, play with, or crawl inside the appliance.
•Refrigerants: All refrigeration products contain refrigerants. Under the
guidelines of federal law, refrigerants must be removed before the disposal
of the product. It is the consumer’s responsibility to comply with federal
and local regulations when disposing of this product.
• Never clean the appliance parts with flammable fluids. The fumes can
create a fire hazard or explosion.
• Do not store or use gasoline or any other flammable vapors and liquids in
the vicinity of this or any other appliance. The fumes can create a fire
hazard or explosion.
SAVE THESE INSTRUCTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous voltage
constituting a risk of electric shock is present
within your cooler.
This symbol indicates that there are important
operating and maintenance instructions in the
literature accompanying your cooler.
NS-WB44SS8_17-0586_MAN_V1_ENG.fm Page 3 Monday, August 14, 2017 8:44 AM

4
NS-WB44SS8
www.insigniaproducts.com
WARNING
Electric Shock Hazard
Failure to follow these instructions can result in
electric shock, fire, or death.
1WARNING–Keep ventilation openings in the
appliance enclosure or in the built-in structure
clear of obstruction.
2WARNING–Do not touch the interior of the chiller
compartment with wet hands. This could result in
frost bite.
3WARNING–Do not use mechanical devices or other means to
accelerate the defrosting process, other than those recommended by
the manufacturer.
4WARNING–Do not damage the refrigerant circuit when handling,
moving, or using the cooler.
5WARNING–Do not use electrical appliances inside the storage
compartment of the appliance, unless they are of the type
recommended by the manufacturer.
6WARNING–DANGER—Never allow children to play with, operate, or
crawl inside the cooler.
Risk of child entrapment. Before you throw away your old cooler:
1) Take off the door
2) Leave the shelves in place so that children may not easily climb
inside
7Unplug the cooler before carrying out user maintenance on it.
8This appliance is not intended for use by persons (including children)
with reduced physical, sensory, or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible
for their safety. Children should be supervised to ensure that they do
not play with the appliance.
9If a component part is damaged, it must be replaced by the
manufacturer, its service agent, or similar qualified persons in order to
avoid a hazard.
10 Please dispose of the cooler according to local regulations as the
cooler contains flammable gas and refrigerant.
11 Follow local regulations regarding disposal of the cooler due to
flammable refrigerant and gas. All refrigeration products contain
refrigerants, which under the guidelines of federal law must be
removed before disposal. It is the consumer's responsibility to comply
with federal and local regulations when disposing of this product.
NS-WB44SS8_17-0586_MAN_V1_ENG.fm Page 4 Monday, August 14, 2017 8:44 AM

5
Built-in 4.9 Cu. Ft. Wine Cooler
www.insigniaproducts.com
12 This cooler is intended to be used in household and similar
environments.
13 Do not store or use gasoline or any flammable liquids inside or in the
vicinity of this cooler.
14 Do not use extension cords or ungrounded (two prong) adapters with
this cooler. If the power cord is too short, have a qualified electrician
install an outlet near the cooler.
15 If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified person in order to
avoid a hazard.
Features
• 4.9 Cu. Ft. capacity
• Dual-zone cooling
• Electronic temperature control with LED Display
• Glass door with single-layer Low-E and lock
•InteriorLEDlight
• Adjustable leveling feet (2)
Package contents
• 4.9 Cu. Ft. wine bottle/beverage cooler
•Keys
•Doorstopper
• Wooden shelves
•UserGuide
NS-WB44SS8_17-0586_MAN_V1_ENG.fm Page 5 Monday, August 14, 2017 8:44 AM

6
NS-WB44SS8
www.insigniaproducts.com
Components
Notes
• For your cooler to operate normally, avoid placing it in areas
with high magnetic fields or high humidity.
• When you put a lot of wines in the cooler at one time, the
temperature in the cooler may rise temporarily.
• To prolong the service life of the compressor, wait for at
least five minutes before restarting the wine cooler after a
power failure.
Tempered glass
door
Control panel
and display
Partition
gasket
Interior
light
Electric
fan
Zone
partition
Wood
shelves
NS-WB44SS8_17-0586_MAN_V1_ENG.fm Page 6 Monday, August 14, 2017 8:44 AM

7
Built-in 4.9 Cu. Ft. Wine Cooler
www.insigniaproducts.com
Control and display panel
BUTTON FUNCTION
Press to turn the interior light on or off.
Left side - press to raise the temperature in the upper zone.
Right side - press to raise the temperature in the lower zone.
Left side - press to lower the temperature in the upper zone.
Right side - press to lower the temperature in the lower zone.
Press both (upper zone temperature) buttons simultaneously to change
the display from F° to C° or back again.
Press both (lower zone temperature) buttons simultaneously to lock or
unlock the cooler.
Press to turn the power on or off.
Notes
• Touch the control panel lightly when pressing the keys.
• To avoid scratching the control panel, do not touch it with
sharp objects.
Lower zone
display
Upper zone
temperature
buttons
Light button
Lower zone
temperature
buttons
Upper zone
display Power button
Upper zone
indicator Lower zone
indicator
NS-WB44SS8_17-0586_MAN_V1_ENG.fm Page 7 Monday, August 14, 2017 8:44 AM

8
NS-WB44SS8
www.insigniaproducts.com
Setting up your wine cooler
Before using your cooler
• Remove the exterior and interior packing.
• Let the cooler stand upright for approximately four hours before
connecting it to power. This reduces the possibility of a malfunction in
the cooling system from improper handling during transportation.
• Clean the interior surface with lukewarm water using a soft cloth.
Finding a suitable location
• This cooler is designed to be built-in or free standing.
• Place your cooler on a floor, countertop, or cabinet that is strong
enough to support the cooler when it is fully loaded.
• Locate the cooler away from direct sunlight and sources of heat (stove,
heater, radiator, and so on). Direct sunlight may affect the acrylic
coating and heat sources may increase electrical consumption.
Ambient temperature below 55°F (12.8°C) or above 90°F (32°C) will
hinder the performance of this cooler. This cooler is not designed for
use in a garage or any other outside installation.
• Avoid locating the cooler in moist areas.
• This unit is not designed to be installed in an RV or used with an
inverter.
•Donotstackyourcooler.
NS-WB44SS8_17-0586_MAN_V1_ENG.fm Page 8 Monday, August 14, 2017 8:44 AM

9
Built-in 4.9 Cu. Ft. Wine Cooler
www.insigniaproducts.com
Building in your wine cooler
The cutout dimensions shown in the following graphic allow the door to
swing open and provides access to the pull-out shelves when installed as
a built-in unit.
If you are installing the unit between frameless cabinets, a ½” wide filler
strip or side panel may be needed on the hinge side. The filler strip will act
as a spacer between the appliance case and the adjacent cabinet door
swing. The width of the opening must include the filler panels. The door
should extend at least one inch beyond the surrounding cabinets.
Leveling your cooler
• It is very important for the cooler to be level in order to function
properly. If the cooler is not leveled during installation, the door may
not close or seal properly, causing cooling, frost, or moisture problems.
• To level your cooler, you may either turn the leveling foot clockwise to
raise that side to the cooler or turn it counter-clockwise to lower that
side.
Power outlet
24-1/2” (62.2 cm)
(including door)
6” (15.2 cm) max.
34-1/2” to 35”
(87.6 to 88.9 cm)
24” (61 cm) min.
20-4/5” (52.8 cm) Cabinet only
34-2/5” (87.4 cm)
23-2/5”
(59.4 cm)
24”(61cm)
min.
NS-WB44SS8_17-0586_MAN_V1_ENG.fm Page 9 Monday, August 14, 2017 8:44 AM

10
NS-WB44SS8
www.insigniaproducts.com
Reversing the door
You will need a 10 mm socket wrench and a Phillips screw driver. Have
someone available to assist you in the process.
• Keep all of the parts you remove to reuse them later.
• Removing the door requires that the cooler be tilted backwards.
1Make sure that your wine cooler is unplugged and empty.
2Adjust the two leveling feet to their highest position.
3Remove the screw that holds the top hinge cover on your cooler, then
remove the top hinge cover.
4Remove the screws holding the top hinge of your cooler, then remove
the hinge.
5Remove the screw hole covers from the top left side of the cabinet.
6Pull the door upwards and remove it from the lower hinge.
7Remove right door stopper and hinge pin sleeve. The right door
stopper should be kept if the door hinge needs to be moved to the
right side again.
8Remove the screws for the toe kits, then remove the toe kit.
9Remove the screw holding the bottom hinge on the right side, then
remove the hinge. Reinstall the screw into the right hinge hole of the
cabinet.
Caution
Do not lay the wine cooler completely flat as that could damage
the coolant system.
Screw hole
covers
Hinge cover screw
Hinge cover
Hinge screws
Hinge
Right door
stopper
Hinge pin sleeve
Screws
Lower hinge
Screws (2)
Toe kit
Screws (2)
NS-WB44SS8_17-0586_MAN_V1_ENG.fm Page 10 Monday, August 14, 2017 8:44 AM

11
Built-in 4.9 Cu. Ft. Wine Cooler
www.insigniaproducts.com
10 Move the hinge pin from the right hole of the hinge to the left hole.
11 Remove the screw on the left side of the cabinet, this screw will be
used to attach the door hinge to the cabinet.
12 Install the bottom hinge on the left bottom of your cooler using the
screws you previously removed. Tighten the screws.
13 Take out the left stopper, found in the bag with the manual, then
attach the hinge pin sleeve and left stopper to the bottom of the left
door.
14 Align the hole at the bottom left of the wine cooler door with the
bottom hinge pin, then install the door on the hinge pin.
15 Place the top hinge pin into the top of the cooler door, then install the
top hinge on the top left of the cooler with the screws you previously
removed.
16 Check the fit and alignment (vertical and horizontal) of the door and
make sure that it opens and closes freely, then tighten the screws
holding the top hinge.
17 Install the hinge cover.
Left stopper
NS-WB44SS8_17-0586_MAN_V1_ENG.fm Page 11 Monday, August 14, 2017 8:44 AM

12
NS-WB44SS8
www.insigniaproducts.com
18 Install the screw covers previously removed from the left holes to the
right holes of the cabinet.
19 Adjust the leveling feet to level the cooler
Grounding requirement
This cooler must be grounded. This cooler is equipped with a cord having
a grounding wire with a grounding plug. The plug must be inserted into
an outlet that is properly installed and grounded.
Consult a qualified electrician or service person if the grounding
instructions are not completely understood, or if doubt exists as to
whether the cooler is properly grounded.
Connecting to power
• Plug the appliance into a dedicated, properly installed grounded wall
outlet. This appliance should be operated on a separate electrical circuit
from other operating appliances. Do not under any circumstances cut or
remove the third (ground) prong from the power cord. Any questions
concerning power and/or grounding should be directed toward a
certified electrician or an authorized service center.
• Plug in and run your cooler for three to four hours before making any
temperature adjustments and before adding wine. This allows your cooler
to reach a stable temperature.
• Do not use an extension cord with this cooler. If the power cord is too
short, have a qualified electrician install an outlet near the cooler. Use of
an extension cord can negatively affect the cooler’s performance.
Warning
• Improper use of the grounding plug can result in a risk of
electric shock.
• Do not, under any circumstances, cut or remove the third
ground prong from the supplied power cord.
Caution
This unit is not designed to be installed in an RV or used with an
inverter.
Notes
• Check your local power source. This cooler requires a
110V-120V, 60 Hz power supply.
• Use a receptacle that accepts the grounding prong. The
power cord is equipped with a 3-prong (grounding) plug
which mates with a standard 3-prong (grounding) wall
outlet to minimize the possibility of electric shock hazard
from this cooler.
NS-WB44SS8_17-0586_MAN_V1_ENG.fm Page 12 Monday, August 14, 2017 8:44 AM

13
Built-in 4.9 Cu. Ft. Wine Cooler
www.insigniaproducts.com
Using your wine cooler
Turning on your cooler
Press the button to turn your cooler on. The display screen and
indicators blink for three seconds and an audible beep will be heard, then
the compressor starts working.
You can manually set your unit to “Standby” mode by touching the
button for approximately three seconds, provided that the control keys
are unlocked and no other setting is in effect (the display is not blinking).
Repeating this action restarts the unit.
Setting the temperature
The screen display always shows the set temperature. When adjusting the
temperature, the temperature display blinks to indicate that the
temperature is being adjusted.
The temperature in the upper and lower zones can be set independently
by touching the or buttons for the selected zone. The temperature
range of both zones can be set between 39° F to 64° F (4° C to 18° C).
When the or buttons are pressed, the temperature will increase or
decrease in increments of one degree. If the or buttons are pressed
and held for two seconds, the temperature will increase or decrease at a
speed of one degree per half second.
After you have adjusted the upper and/or lower zone to the temperature
you want, release the button. The temperature display will blink for
approximately three seconds to confirm the selected temperature.
Changing the temperature display
The temperature display can be exchanged between Celsius and
Fahrenheit by simultaneously pressing and holding the buttons for
approximately three seconds.
Note
The temperature may vary ± 5° F (± 3° C) from the temperature
set.
Notes
• A large number of bottles will lower the cooling efficiency
of the cooler.
• Adjust the thermostat setting by one increment at a time.
Allow several hours for the temperature to stabilize
between adjustments.
NS-WB44SS8_17-0586_MAN_V1_ENG.fm Page 13 Monday, August 14, 2017 8:44 AM

14
NS-WB44SS8
www.insigniaproducts.com
Understanding the dual temperature zones
There are two temperature zones in this appliance. They are divided by a
partition.
• Each zone has its own independent temperature control and display.
• Each zone can be used to store wine bottles.
• The upper zone can hold up to 16 bottles.
• The lower zone can hold up to 28 bottles.
The temperature after a power failure will be the temperature previously
set.
Upper Zone
• There are two wine shelves of full depth in the upper zone. Each shelf
can hold up to eight bottles, with the necks of the bottles alternating
front to back. Fewer bottles can be accomodated if larger bottles are
also included.
• You can move the shelf to the second supporting guide if you want to
store cans there.
Lower Zone
• There are two full-depth wine shelves in the lower zone. Each shelf can
hold up to eight bottles, with the necks of the bottles alternating front
to back.
• There is one wood shelf at the bottom of the lower zone. A total of 12
bottles can be stored on this shelf, in two layers, with six bottles in
each layer.
Second supporting
guide - for beverage
cans only
NS-WB44SS8_17-0586_MAN_V1_ENG.fm Page 14 Monday, August 14, 2017 8:44 AM

15
Built-in 4.9 Cu. Ft. Wine Cooler
www.insigniaproducts.com
Arranging bottles for maximum storage
If you will only be storing smaller bottles, we suggest that you use the “All
small bottles” layout shown above.
If you will be storing a combination of large and small bottles, the “Large
and small bottles” layout suggested above may help. Due to the wide
range of bottle sizes available, we suggest that you begin by placing the
large bottles (over 2 31/32”) on the top shelf, then place the smaller
bottles (2 31/32” or smaller) in the available space remaining. The second
shelf will only accomodate smaller bottles. If you need to accomodate
additional larger bottles, we suggest removing the third shelf, then begin
by placing the smaller bottles on the fourth shelf, then place the larger
bottles on top of them. The bottom shelf should be reserved for smaller
bottles only. The following information should help you plan your storage
layout:
Shelf spacing from top to bottom
• Top to first shelf - 4 1/3” (11 cm)
• Between first and second shelf - 2 31/32" (7.55 cm)
• Between the control panel and the third shelf - 3 1/5” (8.18 cm)
• Between the third and fourth shelves - 2 31/32" (7.55 cm)
• Between the fourth and fifth shelves - 6 2/32" (15.4 cm)
Bottle size chart
Use this chart to determine if the bottle type you want will fit:
Note
The compressor takes up some space above the 5th shelf, so
some bottles may not fit.
Standard Racking Bottle width Will it fit?
Split (375 ml) 2 3/8” Yes
Bordeaux 2 7/8” Yes
All small bottles (2 31/32“ or smaller) Large (over 2 31/32”) and small bottles
NS-WB44SS8_17-0586_MAN_V1_ENG.fm Page 15 Monday, August 14, 2017 8:44 AM

16
NS-WB44SS8
www.insigniaproducts.com
Lighting your cooler
Each zone has its own interior light, which can be switched on or off by
pressing the button on the control panel. Energy-efficient LEDs are
used for long-term durability.
Memory function
If you experience a power outage, when your cooler is turned on again it
resumes the same temperature that was set when the power went off.
Using the wine shelves
• All of the shelves have tabs to engage the cabinet on both sides.
• Any of the shelves can be removed to accommodate larger bottles.
To remove a shelf
1Remove all bottles from the shelves.
2Lift the shelf upward and then gently pull out the shelf.
To replace a shelf
• Place the sides of the shelf back onto the supporting guides of the
cabinet and push back until the shelf tabs slide into place.
Cabernet (750 ml Boutique) 3 1/8” Yes
Small Champagne 3 3/16” Yes
Burgundy 3 1/4” Yes
Pinot Noir (Large Pinot) 3 3/8” Yes
Champagne Racking Bottle width Will it fit?
Bordeaux 2 7/8” Yes
Cabernet (750 ml Boutique) 3 1/8” Yes
Small Champagne 3 3/16” Yes
Burgundy 3 1/4” Yes
Pinot Noir (Large Pinot) 3 3/8” Yes
Turley 3 9/16” Yes
Magnum Racking Bottle width Will it fit?
Turley 3 9/16” Yes
Big Champagne 3 7/8” Yes
Magnum (1.5 L) 4” Yes
Caution
Make sure that the tabs are firmly engaged in the supporting
guides before storing any bottles.
NS-WB44SS8_17-0586_MAN_V1_ENG.fm Page 16 Monday, August 14, 2017 8:44 AM

17
Built-in 4.9 Cu. Ft. Wine Cooler
www.insigniaproducts.com
Arranging your wine
In order to maintain good air circulation in the cooler, do not let the
bottles touch the back of the cooler.
Serving and storage tips
We suggest that you pour wine at a temperature below the ideal serving
temperature, because the wine warms up quickly after it’s been poured
into a glass.
• Strong beers (like barleywines, tripels, dark ales) will be their happiest at
room temperature (55-60° F or 12.8-15.5° C). Most of your standard ales
(like bitters, IPAs, dobbelbocks, lambics, stouts, etc.) should be at cellar
temperature (50-55° F or 10-12.8° C). Lighter beers (like lagers, pilsners,
wheat beers, milds, etc.) should be at a refrigerated temperature (45-50° F
or 7.2-10° C).
• Do not store bottled wine by the box or case in the cooler.
• The cork of an opened bottle should always be moistened when returning
it to the bottle.
• Red wine should be allowed to breath (oxygenate) before drinking. We
suggest that you put pink/rose type wines onto the table two to five hours
before drinking and red wine four to five hours before drinking. That also
allows them to reach the suitable serving temperature. White wine, on the
other hand, can be served right away.
• Champagne should always be stored in the cooler and taken out
immediately before drinking.
WINE TYPE IDEAL SERVING TEMP
Red Bordeaux 64.4° F (18° C)
Côtes du Rhône red/Barolo Louis Family
dry red wine/Barolo
62.6° F (17° C)
Burgundy red 60.8° F (16° C)
Port 59° F (15° C)
Young Burgundy Red 57.2° F (14° C)
Young Red Wine 53.6° F (12° C )
Young Beaujolais/All White Wines (low
sugar)
51.8° F (11° C)
Old White Wines/Chardonnay 50° F (10° C)
Sherry 48.2° F (9° C)
Young White Wines (late vintage) 46.4° F (8° C)
White Wines Loire/Entre-deux-Mers 44.6° F (7° C)
NS-WB44SS8_17-0586_MAN_V1_ENG.fm Page 17 Monday, August 14, 2017 8:44 AM

18
NS-WB44SS8
www.insigniaproducts.com
Locking and unlocking your wine cooler
The lock is designed to prevent the settings of your wine cooler from
being changed accidentally. With the lock engaged, in order to adjust any
of the settings you must unlock the control panel by pressing and holding
the buttons simultaneously for approximately three seconds. The
whole display lights and an audible beep will be heard. Repeating this
action locks the display panel and the display becomes dim.
NS-WB44SS8_17-0586_MAN_V1_ENG.fm Page 18 Monday, August 14, 2017 8:44 AM

19
Built-in 4.9 Cu. Ft. Wine Cooler
www.insigniaproducts.com
Maintaining your wine cooler
Your cooler is designed for year-round use with only minimal cleaning and
maintenance.
When you first receive it, wipe the cabinet with a mild detergent and
warm water, then wipe dry with a dry cloth. Do this periodically to keep
your cooler looking new.
Cleaning the interior of your cooler:
1Turn off the cooler and unplug it from the wall outlet.
2Remove all wine/beverages.
3Wash the inside with a damp warm cloth soaked in a solution of one
quart of lukewarm water to two tablespoons of baking soda solution.
4Be sure to keep the door gasket (seal) clean to keep the unit running
efficiently.
5Dry the interior and exterior with a soft cloth.
Defrosting your cooler
The ice build-up on the inner back wall of your cooler will automatically
be defrosted in a compressor-off cycle.
When you press the button, the compressor and circulation fans for
both zones stop running while defrosting is in process.
Defrost water will drain out of the cooler, passing through the drain outlet
in the inner back wall into a drain pan located above the compressor. The
water will evaporate from the drain pan on its own.
Storing your cooler
1Turn off the cooler and unplug it from the wall outlet.
2Remove all wine/beverages.
3Clean the cooler.
4Leave the door open slightly to avoid possible formation of
condensation, mold, or odor.
Caution
To prevent damage to the finish, do not use:
• Gasoline, benzine, thinner, or other similar solvents.
• Abrasive cleaners.
Caution
Use extreme caution with children. The unit should not be
accessible to child's play.
NS-WB44SS8_17-0586_MAN_V1_ENG.fm Page 19 Monday, August 14, 2017 8:44 AM

20
NS-WB44SS8
www.insigniaproducts.com
Moving your wine cooler
1Turn off the cooler and unplug it from the wall outlet.
2Remove all wine/beverages.
3Securely tape down all loose items inside your cooler.
4Tape the door shut.
Make sure that the cooler stays in the upright position during
transportation.
Tips on saving energy
• Locate your cooler in the coolest area of the room, away from heat
producing appliances or heating ducts and out of the direct sunlight.
• Do not overload the cooler. It forces the compressor to run longer.
• Do not open the door too often, especially if the weather is very hot. Close
the door as soon as possible to prevent cool air from escaping.
• Make sure that the appliance is sufficiently ventilated, with adequate air
circulation behind it.
Troubleshooting
Error codes
If a fault is detected, the display shows one of the following codes:
If any of these error codes appears on the display, please contact your
local dealer or service center. Do not try to repair the cooler yourself.
Caution
Do not try to repair your cooler yourself. Doing so invalidates the
warranty.
Fault Code E1 E2 E3 E4
Description Temperature
sensor error in
the upper zone
Temperature
sensor error in the
lower zone
DC electric fan
error in the upper
zone
DC electric fan
error in the lower
zone
PROBLEM SOLUTION
The cooler does not operate. • Make sure that the cooler is plugged in and that the
plug is pushed completely into the outlet.
• Check the house fuse/circuit breaker box and replace
the fuse or reset the circuit breaker.
• If a power failure occurs, the cooler turns off. Wait until
the power is restored, then turn it on again.
NS-WB44SS8_17-0586_MAN_V1_ENG.fm Page 20 Monday, August 14, 2017 8:44 AM
