Instruo Cs-L User manual

MOD
LINK
LFO
SYNCSYNC
MOD BUTTON
USED TO SET INTERNAL ROUTING
THROUGH INDEX VCA TO PWM CV INPUTS
RING
AM
RECT RING/AM/RECT BUTTON
DETERMINES THE
AMPLITUDE MODULATION MODE
FOR MULTIPLY MODULATOR INPUT
UNILLUMINATED -
ROUTING DISABLED
UNILLUMINATED -
BIPOLAR MODULATION
UNILLUMINATED - LINKING IS DISABLED
ILLUMINATED WHITE - 1V/OCT INPUTS CONTROL
BOTH OSC A AND OSC B
(IF BOTH PATCHED, OSC WILL TRACK INDEPENTENTLY)
ILLUMINATED WHITE -
OSC A SINEWAVE >
OSC B PWM CV INPUT
OSC B SINEWAVE >
OSC A PWM CV INPUT
ILLUMINATED WHITE -
HALF WAVE RECTIFICATION
ILLUMINATED AMBER -
FULL WAVE RECTIFICATION
ILLUMINATED AMBER -
OSC A SINEWAVE >
OSC B PWM CV INPUT
OSC A HARD SYNC
FROM OSC B
OSC B SOFT SYNC
FROM OSC A
ILLUMINATED WHITE -
OSC A OUTPUTS
SUB AUDIO
FREQUENCIES
Cš-L
PWM
WAVEFOLD
WAVEFOLD
FINAL
MULTIPLY
FINAL
COARSE
COARSE
1V/OCT
LINK
1V/OCT
LFO
FINE
SYNC
CV
CV
DEPTH
RING
MOD
AM
RECT
SYNC
FM
FM
FINE
CV
INDEX
PWM
SUB
LIN EXP
+
–
+
–
+
–
+
–
+
–
OSC A
OSC B
OSC A
OSC B
OSC A
OSC B
OSC A
OSC B
Cš-L
Complex Oscillator
-əz- proverb (derivative)
“complex sauce-later” (see Tš-L )

INDEX
THE INDEX BUTTON FUNCTIONS AS A “SHIFT” CONTROL. WHEN PRESSED THE CORRESPONDING BUTTONS
ILLUMINATE TO DISPLAY THE ROUTING CURRENTLY ENABLED.
ROUTING CAN BE ENABLED / DISABLED BY TOGGLING THE ASSOCIATED BUTTON.
THE INDEX CONTROLLED SINE WAVEFORMS ARE USED FOR INTERNAL MODULATION (OSC A CAN MODULATE THE
PARAMETERS OF OSC B, AND VISE VERSA).
THE RING/AM/RECT
BUTTON IS USED
TO ENABLE / DISABLE
THE MODULATION
ROUTING TO THE FM INPUT
OF OSC A.
(WHEN DISABLED, THE SINE
WAVEFORM OF OSC B IS
DIRECTLY NORMALLED TO
THIS DESTINATION AND
NOT CONTROLLED BY THE
INDEX PARAMETER).
THE SYNC BUTTON IS
USED TO ENABLE /
DISABLE THE MODULATION
ROUTING TO THE FM INPUT
OF OSC B.
(WHEN DISABLED, THE SINE
WAVEFORM OF OSC A IS
DIRECTLY NORMALLED TO
THIS DESTINATION AND
NOT CONTROLLED BY THE
INDEX PARAMETER).
Cš-L
PWM
WAVEFOLD
WAVEFOLD
FINAL
MULTIPLY
FINAL
COARSE
COARSE
1V/OCT
LINK
1V/OCT
LFO
FINE
SYNC
CV
CV
DEPTH
RING
MOD
AM
RECT
SYNC
FM
FM
FINE
CV
INDEX
PWM
SUB
LIN EXP
+
–
+
–
+
–
+
–
+
–
RING
AM
RECT
SYNC
INTERNAL MODULATION ROUTING
PRESS & HOLD
RING
AM
RECT
SYNC
FM
FM
INDEX
LIN EXP

Cš-L
PWM
WAVEFOLD
WAVEFOLD
FINAL
MULTIPLY
FINAL
COARSE
COARSE
1V/OCT
LINK
1V/OCT
LFO
FINE
SYNC
CV
CV
DEPTH
RING
MOD
AM
RECT
SYNC
FM
FM
FINE
CV
INDEX
PWM
SUB
LIN EXP
+
–
+
–
+
–
+
–
+
–
LFO
THE LFO BUTTON IS USED TO ENABLE / DISABLE
MODULATION ROUTING TO THE SYMMETRY BIAS
INPUT OF OSC A.
THE MODULATION SIGNAL REPLACES THE DEFAULT
REFERENCE VOLTAGE. THE SYMMETRY BIAS
ATTENUVERTER WILL CONTROL THE INVERSION AND
DEPTH OF THE INDEX MODULATION SIGNAL.
LINK
THE LINK BUTTON IS USED TO ENABLE / DISABLE
MODULATION ROUTING TO THE SYMMETRY BIAS
INPUT OF OSC B.
THE MODULATION SIGNAL REPLACES THE DEFAULT
REFERENCE VOLTAGE. THE SYMMETRY BIAS
ATTENUVERTER WILL CONTROL THE INVERSION AND
DEPTH OF THE INDEX MODULATION SIGNAL.
MOD
THE MOD BUTTON IS
USED TO ENABLE /
DISABLE THE MODULATION
ROUTING TO THE
WAVEFOLD CV INPUT OF
OSC A
SUB
THE SUB BUTTON IS
USED TO ENABLE /
DISABLE THE MODULATION
ROUTING TO THE
WAVEFOLD CV INPUT OF
OSC B
INTERNAL MODULATION ROUTING
PRESS & HOLD
LINK
LFO
CV
CV
MOD
INDEX
SUB
+
–
+
–
+
–
+
–
