1 System Overview
This manual provides instructions for installation, cabling, power supply evaluation for BCR-SD G2
and describe service procedures.
1.1 Parts List
Supplied:
I. BCR-SD G2 1 pcs
II. Connector 1 pcs
III. Wall tamper springs 2 pcs
IV. Box tamper springs 2 pcs
V. Quick Installation Guide 1 pcs
VI. Drilling pattern 1 pcs
VII. Opening Tool xCR-SD/S (Mini) G2 1 pcs
Not supplied
I. Instructions for other devices that will be connected to the BCR-SD G2.
1.2 Technical specifications
Power supply Typical/Min/Max 24V DC/20VDC/30VDC
Power consumption Typical/Max at 24V 35 mA/170 mA
Enclosure IP 54
Operating temperature -25oto +70oC
Dimensions NET (L/W/H) 123.5/88/20 mm
Weight NET 150 g
Color NCS 8500-N
NCS 6502-B
Communication RS485

1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 5
SystemHouse Solutions
1.3 Article numbers
44 28 03 70 BCR-SD G2
1.3.1 Accessories
There are several accessories types available:
44 28 02 70 Installation plate for xCR-SD G2
44 28 02 71 Installation angle 15 Degrees xCR-SD G2
44 28 02 72 Installation angle 30 Degrees xCR-SD G2
44 28 02 73 Weather hood plastic for xCR-SD G2
44 28 02 74 Weather hood metal for xCR-SD G2
44 28 02 75 Opening Tool xCR-SD/S (Mini) G2
44 28 50 21 Flashcable for xCR G2

1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 6
SystemHouse Solutions
2 Safety Instructions
The following safety instructions should observed during installation, maintenance and standard
use.
•Installation and service should only be performed by qualified personnel.
•If there exist local regulations, these must be followed. This safety information is
supplement to local regulations.
•Reader must be disconnected from voltage before installation and service.
•Do not modify any components or part of device.
•All reparation should be performed only by the manufacturer.

1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 7
SystemHouse Solutions
3 Installation Procedure
Installation procedure consist of evaluation of power requirements, mounting accessories, power
and communication lines wiring to S-Node G2, C-Node G2, Moveo, Moveo XL, mounting,
connecting cables, setting switches and verification.
Evaluate optional accessories that will be used.
If the reader shall be mounted outdoors and there is risk for that it can be exposed to rain,
proper protective housing must be used.
Evaluate power requirements as described in section 4 Power Supply. Same time evaluate
required power cables determined by required power and length of the cables.
Select cables used for communication lines as described in section 5 Communication and
address.
Determine an appropriate mounting position for the device. The card reader is supported to be
installed on walls, mounting column, mounting brackets. The back plate of the unit contain
rubber sealing so it SHALL BE NOT used as a template for drilling. Use attached drilling
pattern instead.
Route the interface cables to S-Node G2, C-Node G2, Moveo or Moveo XL or to the other reader
if the actual reader is in the middle of the bus. Route cables to other accessories to be
connected.
Install the bottom part of BCR-SD G2 box to the wall. Feed all cables inside the box to
appropriate position and fix them to the box with cable ties.
Connect all cables to the terminals as required.
Set termination jumper SW1 to enabled (default setting) if the actual reader is placed at the end
of the bus, otherwise disable termination.
After wiring the BCR-SD G2 and accessories, device is ready to be tested. If the card reader
have been properly installed, connect terminal PL1 to the BCR-SD G2. The card reader will
beep for 1 second and starts working after short while (this is valid only in case that system was
already configured at PC level and that the parent node is up and running). This indicates that
unit is working properly.
Set the device address according requirements. Default address is “1”. For setting follow
procedure in the section Setting address
Assemble the unit by pressing the top part down on the back plate. Ensure correct positioning
in the top before it is pressed into place.

1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 8
SystemHouse Solutions
3.1 Device overview

1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 9
SystemHouse Solutions
3.2 Opening device
To open device always use proper opening tool. Using other tools can cause scratches and damages
of the box that will cause warranty refusal.
For opening device follow instructions in Quick Installation Guide (part of device delivery) or look
in section in this document.
Opening tool:
3.3 Maximum torque for box installation
When device is installed by using an electrical screwdriver the maximum torque used shall be 2.5
N/m.

1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 10
SystemHouse Solutions
3.5 Installation on metal surfaces
When device is installed on metal surface is strongly recommended to use proper accessory
44282070 Installation plate for xCR-SD G2.
This will minimize problems with low reading distance caused by interfering with metal surface.
3.6 EN 50131 Grade 3 - Wall tamper
When installing reader in an intruder alarm grade 3 installation it is required to use wall tamper
and wall tamper springs must be installed.
Note: wall tamper springs are not possible to use together with mounting angles or the distance
plate. The springs (for wall tamper) do not detect removal from the wall if you use mounting angle
or a distance plate.
Installation procedure:
1. Open device using opening tool.
2. Cut tamper activators placed at bottom cover at plastic level.
3. Install springs from bottom side.
4. Fix bottom cover with screws at installation place. Surface level needs to be even.

1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 11
SystemHouse Solutions
4 Power Supply
BCR-SD G2 does not use its own power supply, instead it is powered from S-Node G2, central unit
C-Node G2 or Moveo/XL. The S-Node G2 is normally powered from central unit where power
supply and communication line are distributed together to door environments.
S-Node G2, C-Node G2 and Moveo/XL are equipped with fused terminals to supply power to card
readers.
4.1 Power requirements
Before starting installation, power requirements needs to be evaluated.
Typical power consumption is 45 mA, but increases to 170 mA when the embedded heating element
is turned on at low ambient temperatures. When calculating power consumption for the entire
installation, it must be calculated that readers mounted outdoors consume up to 170 mA.
4.1.1 Power supply
The device is powered by terminal PL1. Connector for power supply and communication line is
fixed to bottom cover and it’s released from electronics while opening device.
PL1 24VDC/RS485

1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 12
SystemHouse Solutions
5 Communication and address
There is one RS485 communication line to/from the BCR-SD G2.
5.1 Setting address
For proper communication on RS485 device needs to have proper address assigned. All devices
have from production address 1. If another address is required default address must be changed by
following next steps:
1. Open device to disconnect it from power supply. Hold “Menu button”while closing
device to enter extended information screen.
2. Press “0” to enter address configuration screen.
Current address and new address fields are shown.

1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 13
SystemHouse Solutions
3. Enter new address in range 01-08.
Until the new address is confirmed you can change address any time.
4. Press “Menu button”to confirm new address.
If you want to leave address configuration menu without change press “Back
button”.

1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 14
SystemHouse Solutions
5.2 RS485 communication line
The RS485 bus must be configured as a bus with no branches. The bus needs to be terminated at
each end. Jumpers are provided on each device (Moveo, Moveo XL, C-Node G2 or S-Node G2 and
card readers) to enable or disable termination. Up to two card readers can be connected to the same
S-Node G2, in-reader and out-reader.
Since together with communication line is distributed also power line we do use mixed cable to
supply both in one.
5.2.1 Line installation
PL1 24VDC/RS485

1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 15
SystemHouse Solutions
5.2.2 Line termination
SW1 CR RS485 termination
RS485 bus terminated
No termination
For RS485 termination must be On at beginning and end of line only, all other devices must have it
Off.
SW1 RS485 Termination
5.2.3 Recommended cable
Maximum length of RS485 line can be up to 1000 meters from the first to last unit on the bus.
Always use twisted pair cables, and we always recommend the use of shielded cable for connecting
card readers.
NOTE:
ALWAYS calculate total power consumption and choose a cable with conductor cross-sectional
area designed for that total power consumption.
ALWAYS calculate voltage drop before selecting cable.
5.2.3.1 PTS-HF-2x2x0.6
We always recommend screened, twisted pair cables, type PTS-HF-2x2x0.6 for RS485 lines.
A screened cable is considerably more difficult to wiretap than an unscreened cable.

1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 16
SystemHouse Solutions
Higher cable cross-sectional areas may be necessary in the case of long lines, as voltage drops can
be expected.
5.2.4 RS485 network topology and termination principles
•Linear double terminated bus
•Linear double terminated cascade bus with S-Node G2 in the middle.
Star formation in the wiring from S-Node G2
•Two linear double terminated cascade buses on C-Node G2.
RS485 lines from C-Node G2 can have bus formation although wiring is performed as a star
network. This can be done by using two cable pairs for the bus, "RS485 out" and "RS485 in".
C-Node G2 can be equipped with an optional connection block for this, CG2-VDE

1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 17
SystemHouse Solutions
6 Service routines
6.1 Periodical service check
Periodical service check consist of from several steps.
•When approaching keypad intensity of display must be increased and keypad light must
be activated
Minimum distance for activation is 25 cm
•Visual inspection - check mechanical damage of the box
There shall be no visible damage on the box.
•Visual inspection - check scratches on display glass
There shall be no visible scratches on display glass.
•Evaluate every key on keypad
Press every key and you must feel tactile feedback while pressing and beep from
internal buzzer.
• Apply valid card
Green light stripe must be activated together with single beep from buzzer. The
screen shall present this picture:
•Apply not valid card
Red light stripe must be activated together with two beeps from buzzer. The
screen shall present this picture:
•Open box and check wiring
Every wire must be properly inserted and fixed in screw terminal.
•Check visually electronics for any possible damages.
There shall be no damage on electronics.
•Check both parts – bottom and lid for traces of water or humidity.
There shall be no water drops or signs of humidity. If there are any signs device
must be evaluated for possible source of water leakage. In most of cases cable is
not properly sealed inside back sealing and its leading water inside device. In this
case bottom part must be exchanged.
•Measure voltage on screw terminal and compare it against level on used power supply.
Voltage must be within range 20-30 V DC.

1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 18
SystemHouse Solutions
6.2 Fixing common issues with the reader
6.2.1 No communication with the Reader
Check display, if next picture is presented there is no RS485 communication between reader and
master device.
Solution:
1. Check wires for RS485 if they are properly attached to screw terminal.
2. Check polarity for wires.
3. Check setting of switch SW1 – termination of RS485 according position of reader on the
line.
4. Compare device address with address set in the system.
6.2.2 Reader is not working
Solution:
1. Check wiring of the connectors, check polarity.
2. Check power supply if it’s within range 20-30 V DC.
3. Check setting of switch SW1 – termination of RS485 according position of reader on the
line.
4. Check setting inside system if device has proper address set.

1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 19
SystemHouse Solutions
7 Attachments
7.1 Construction
The Card Reader is equipped with a built-in antenna for card reading, a clearly visible keypad, LED
indication, internal buzzer and convenient display for graphic symbols.
The Card Reader is sabotage protected in a sturdy case with RS485 interface.
The smart card reader use technology in the 13.56 MHz frequency range.
7.2 Functions
The Card Reader is used for contactless smart card access cards in a 50 mm range, status
indications of the door environment and access requests. Integrated management (Set, Unset and
Acknowledge) of alarm areas is also included.
Display guided operation. The display provides for certain functions such as alarm areas, menu-
based interface.
LED’s for indication of door status, etc.
Built in buzzer for warning and button press indication etc.
Integrated heater is activated at low ambient temperatures.

1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 20
SystemHouse Solutions
7.3 BCR-SD G2 as a part of door
environment
