Integral LED ILRC032 User manual

RF Single Color Remote Controller 70010015
All on
Note:Before the first use, please remove the protective film on the battery.
Function introduction
Important: Read All Instructions Prior to Installation
Output RF signal
Operation Frequency
868/869.5/916.5/434MHz
Operating temperature 0-40°C
Relative humidity 8% to 80%
Dimensions 136.3x38.9x10.7mm
Front side
Back side
• Compatible with all universal series RF receivers
• Control 4 zones of receivers separately
• Single color controller
• 1 receiver can be paired by max 8 different remote controls.
• Waterproof grade: IP20
Product Data
• This device contains a button lithium battery that shall be stored and disposed properly.
• DO NOT expose the device to moisture.
Safety & Warnings
Power Supply 3V(1xCR2025 battery)
Zone 1:Short press to turn on,
Press and hold down to increase
light intensity
Zone 2:Short press to turn on,
Press and hold down to increase
light intensity
Zone 3:Short press to turn on,
Press and hold down to increase
light intensity
Zone 4:Short press to turn on,
Press and hold down to increase
light intensity
All off
Zone 1:Short press to turn off,
Press and hold down to decrease
light intensity
Zone 2:Short press to turn off,
Press and hold down to decrease
light intensity
Zone 3:Short press to turn off,
Press and hold down to decrease
light intensity
Zone 4:Short press to turn off,
Press and hold down to decrease
light intensity
Pair with RF receiver
Step 3:Choose one zone and Short press or of the zone(e.g. zone 4),
The LED lights connected with the receiver will flicker once which means the
receiver is paired with zone 4 successfully.
Step 2: Short press the “Learning Key” button on RF receiver or re-power on the
receiver three times continuously to set it into pairing status
Note: one receiver can be paired with max 8 remote controls.
Learning Key
RF LED Receiver
After pairing, Short press or hold or of 1/2/3/4 to control each zone separately
Step 1: Wire the strip to the receiver and set the dip switches of the
receiver according to the strip type. Please see instructions of the
receiver for more info.
Remove the protective film from the battery compartment of the remote.

If you use multiple receivers, you have two choices:
Option 1: have all the receivers in the same zone, like zone 1
Learning Key
RF LED Receiv er
Zone 1
O
WARNING: This product contains a button battery and should be kept out of reach of children.
ption 2: have each receiver in a different zone, like zone 1, 2, 3 or 4
Zone 1 Zone 2 Zone 3
RF remote
RF remote
Learning Key
RF LED Rec eiv er
Learning Key
RF LED Receiv er
Learning Key
RF LED Rec eiv er
Learning Key
RF LED Receiv er
Shenzhen Sunricher
Technology Co. Ltd
Add: 3F, Bldg. E, Qihang
Industrial Park, 1008
Songbai Road, Nanshan
Dis., Shenzhen 518108
