INSTRUCTION MANUAL
MANUALE DI ISTRUZIONI
PMR 446 VERSION
16CH / 0.5W E.R.P.
MT-446W10
VHF FM VERSION
136-174 MHz
16CH / 1-5-10W
MT-174W10
UHF FM VERSION
400-470 MHz
16CH / 1-5-10W
MT-460W10
PROFESSIONAL
HANDHELD
TRANSCEIVER
PC PROGRAMMABLE
W10
SERIES

English
Index - Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Unpacking and checking parts - Supplied accessories . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Preliminary Steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Getting acquainted with the product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9
Advanced Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-10
Programmable Side Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Specifications - Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
MT-446W10 Frequency / Channels programming - User Information . . . . . . . . . . . . . . 13
MT-174W10 / MT-460W10 Frequency / Channels programming . . . . . . . . . . . . . . . . . . . 14
CTCSS / DCS Tone Frequency Charts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Declarations of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32-34
Index - Notice
- 1 -
NOTICE !
This transceiver is programmable via PC, using the dedicated software (free download at
www.intek-radios.com) and the PC interface cable (optional item). Any programming or modification
of the original default setting must be made by a specialised technician or by an authorised service
centre. Some functions of this transceiver might be programmed in violation of the technical rules in
force for the use of the VHF and UHF FM bands. It is the user’s responsibility to check that any
modification to the programming will be done in compliance with the current regulations. Any
modification to the product, alteration of the internal circuit, of the external structure of the radio or any
programming in violation of the current regulations will automatically void the product certification and
your right to use the product. INTEK S.R.L. declines any responsibility concerning any modification of
the product, made by the user or by a third party, after delivery of the product.
NOTICE !
This transceiver has been factory pre-programmed, in order for the user to test it right after
purchase. It is the user' s responsibility to re-program the radio, in accordance with the
specifications for the frequency channels assigned by the local authority.
NOTICE !
It is recommended to carefully read this owner’s manual before using the product. This will also
help the user to prevent using the radio in violation of the regulations valid in the country where
the product is used, as well as to avoid any possible interferences with other services.

Thank you !
Thank you for choosing INTEK for your two-way business radios applications. This user friendly
transceiver will provide you with clear and reliable communications and will keep your professional
activities at peak efficiency. This transceiver incorporates the latest and most advanced technology, so
you will be pleased with its quality and its technical features.
Important notice !
The use of VHF and UHF FM transceivers is subject to the regulations applied in the country where the
product has to be used. As regulations are usually subject to possible modifications, please check the
current regulations in your country with your dealer or local supplier. INTEK does not take any
responsibility for illegal use and operation of this product not in accordance with the regulation of the
country where the product is used.
Safety notice
The user must know and understand the common risks related to the use of transceivers. Do not use
the transceiver in environments at risk of explosion (where there are gas, dusts, smokes, etc.). Do not
use the transceiver in service areas or fuel stations, on board aircrafts, etc.
Cautions
Please observe the following precautions, in order to avoid causing fire, personal injuries or damage to
the radio:
It is suggested that each transmitted message lasts a few minutes only, since very long
transmissions at the maximum transmitter RF output power may overheat the transmitter.
Do not alter or modify in any way your transceiver.
Do not expose the transceiver for a long time to direct sunlight and do not place it close to
heat sources.
Do not expose the transceiver to excessively dusty or damp places, do not place it on
unstable surfaces.
In case of anomalous smell or smoke that leaks out from the transceiver, turn it off immediately
and remove the battery pack. Please contact an authorised service center.
Please do not dispose off used battery with common garbage. Please use the dedicated
disposal containers.
If your vehicle is equipped with an airbag, do not place your transceiver device or other
accessories above the airbag or in the airbag deployment area. If in-vehicle equipment is
improperly stored or installed and the airbag inflates, serious injury could result. Radio frequency
signals might affect improperly installed or inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its representative regarding your vehicle. If any
equipment has been added to your vehicle, you should also consult the manufacturer of that
equipment for information on radio frequency signals.
To assure optimal performance of the radio and in order to keep human exposure to radio frequency
electromagnetic energy within the guidelines, always adhere to the following procedures :
Two-Way Radio Operation
When using your radio, hold the radio in a vertical position with the microphone at a distance of
approximately 20 to 25 centimetres away from the lips. For PTT devices, the TX duty cycle is 30%.
- 2 -
General Information
English

Unpacking and Checking Parts - Supplied Accessories
- 3 -
Unpacking and checking parts
Carefully unpack the product. Please identify all the parts listed below, before wasting the packaging. If
any part is missing or if the packaging shows any damage, please contact your dealer immediately.
Supplied accessories
Rubber flexible antenna with SMA connector (only models MT-174W10 and MT-460W10)
7.4V 2500mAh Li-Poly Rechargeable Battery Pack
Electronic Quick Desk Charger
Belt Clip
Handstrap
Speaker-microphone Jack Cover
User Manual
Quick Desk ChargerRubber flexible antenna
with SMA connector
(except model MT-446W10)
Li-Poly Battery Pack
Belt ClipAC Adaptor Handstrap User Manual
English

Preliminary Steps
- 4 -
Battery charging
Connect the 230VAC adaptor charger to the desk type battery charger and to a 230VAC outlet. The
Red Led will flash for 1 second then go out, to confirm that the charger is powered.
Insert the empty battery or the transceiver with the battery pack in the battery charger. Please make
sure that the charging contacts of the radio are connected with the charging contacts of the charger
cradle. The Red Led will light then the device is ready to begin the charging process. The charging time
depends on the battery condition and capacity. When the charging process has finished, the Led lights
in Green color. Remove the battery pack or the transceiver from the battery charger and disconnect it
from the AC outlet. When the battery capacity is using out, the radio's red LED (5) will flash in red color
and the radio will keep reporting "Please charge the battery".
Warning !
The battery is supplied empty and it has to be fully recharged before use.
Some complete cycles of charge/discharge will be necessary in order for the battery to reach a
peak efficiency level.
Please do not charge the battery again when it has just been charged. Otherwise, you may
damage the battery or reduce its life.
The battery charger does not switch OFF automatically when charging is complete, therefore
please remove battery or radio from the charger cradle and disconnect it from the AC outlet.
Do not recharge battery for more than 8 hours, in order to avoid battery overheating.
Please do not waste used batteries into the environment and do not trash them with the common
garbage. Please use the dedicated case for the collection of used up batteries at your supplier.
Do not attempt to open or remove the battery casing.
Do not short the battery terminals or throw the used batteries into fire.
English
Charger Status LED Indicators Remarks
Power ON Red LED flashes for 1 second
then lights OFF
Standby Mode Green LED lights ON
Charging Mode Red LED lights ON
Full Charging Green LED lights ON
Battery Fault Red LED flashes Battery voltage is lower than 6V
or battery pack is damaged

English
To install the battery pack
Place the battery pack on the radio as showed in the drawing
(item 1). Push the battery pack forward (item 2) until it is
locked on the radio (item 3).
To remove the battery pack
To remove the battery pack, slide the battery locker on the
bottom of the radio (item 1) and push back the battery pack, as
showed in the drawing (item 2).
Installing the antenna (only for models MT-174W10 and MT-460W10)
Connect the antenna to the antenna connector located on the top panel of
the radio. Gently turn the antenna clockwise until locked.
Warning : Do not touch the antenna and do not move it close to a
microphone cable during transmission, as this might cause malfunction
and damage to the radio.
(FOR MODEL MT-446W10)
WARNING !
THE RUBBER FLEXIBLE ANTENNA IS FIXED AND NOT
REMOVABLE. DO NOT TRY TO TURN OR REMOVE IT, OTHERWISE
ANTENNA MAY BE BROKEN.
Preliminary Steps
- 5 -
1
2
1
2
3

- 6 -
Preliminary Steps
To install the belt clip
If necessary, install the belt clip, located on the rear side of the radio.
Do not use any kind of glue to fix the screws on the belt clip. The glue
may damage the back cover of the radio.
Remove / install the external earset-microphone jack cover.
If an external earset-microphone may be used, please remove the
earset-microphone jack cover, by unfixing the screw (item 1).
Install the earset-microphone jack cover as showed on the drawing.
Fix the cover with the supplied screw (item 1).
If the earset-microphone jack cover is removed, radio will not be
splash proof.
To install the external microphone (optional)
To install the external microphone, remove the protection cover of the
external microphone/speaker jack. This cover ensures the watertight
integrity of the transceiver (spray-guard) that will not be ensured after
its removing. Insert the connector of the external microphone into the
right jack.
In order to avoid mulfunction or damage to the transceiver, use only
original microphones. Using non original accessories will
authomatically void the warranty.
Warning !
If an external earset-microphone is used, radio will not be splash proof.
1
English

GETTING ACQUAINTED WITH THE PRODUCT
1. Antenna
Fixed non removable rubber flexible antenna on model MT-446W10.
Rubber flexible antenna with SMA connector on models MT-174W10 and MT-460W10.
2. Speaker
Built-in speaker.
3. Channel Selector
Turn the selector to select the desired channel from 1 to 16.
4. Power ON switch and volume control
Switch on the transceiver turning the knob clockwise or counterclockwise to switch it off.
To increase the volume, turn the knob clockwise or counterclockwise to decrease it.
5. LED Indicator
The LED indicator will light in green colour when the radio is receiving a signal, in red colour
during transmission and it will flash in red colour when, during transmission, the battery level is
low or empty.
6. Microphone
Built-in microphone.
7. PTT key (Push-To-Talk)
To transmit, press and keep pressed the PTT key (7), then speak into the microphone (6) with your
normal voice. To receive release the PTT key (7).
PF3 4
5
3
1
2
6
English
Getting Acquainted with the Product
- 7 -
8
9
PF1
7
PF2

- 8 -
Getting Acquainted with the Product - Getting Started
8. External earset-microphone jack cover
This cover protects the external earset-microphone jack and makes the radio splash proof.
9. Battery Pack / Desktop Charger Contacts
PF1 / PF2 / PF3 (Programmable Side Keys)
These keys are programmable by using dedicated software (free download at www.intek-radios.com).
Please refer to the funcions list chart at page 11.
GETTING STARTED
Power ON
Switch on the transceiver turning the Power/Volume knob (4)
clockwise until you hear a click. A beep will be heard and the
transceiver now is in stand-by mode. If the Voice Announcement
function is enabled by software, radio will automatically report the
channel number. To switch OFF the radio, turn the knob anti-
clockwise.
Volume adjustment
To adjust the volume, turn the volume knob (4) while using the PF1
key to temporarily open the Squelch and listen to the background
noise of the channels.
Channels selection
Turn the channels selector (3) to select the channels. If the Voice
Announcement function is enabled by software, radio will
automatically report the channel number.
English

- 9 -
Getting Started - Advanced Funcions
Transmission
In order to transmit, press the PTT key (7) and speak with your normal
voice, keeping the microphone at about 2.5 cm to 5 cm from your
mouth. It is important that the antenna is at 2.5 cm away from your
face. The LED indicator (5) will light in red color. Release the PTT key
(7) at the end of transmission.
If during transmission the battery voltage drops below the pre-set
minimum level, radio will automatically switch to RX mode and the
LED low battery indicator (5) will blink in red colour.
Receiving
Release the PTT key (7) and properly adjusting volume, yo will be able to receive the incoming signals.
When receiving a signal, the LED indicator (5) will light in green colour.
ADVANCED FUNCTIONS
The following functions could be programmed only by using the dedicated PC software. If these functions are
disable by factory setting, they will be effect after activation.
Time-Out-Timer
This function has two purposes:
- to allow, after a set time, to listen to other urgent calls.
- to avoid to transmit for an endless time, in order to prevent overheating or damage to the
transceiver. After a programmable preset time (1 to 255 secs.) of uninterrupted transmission, the
transceiver automatically stops the transmission emitting a warning tone (pre-set function) and
the LED indicator (5) lights in green color. To stop the warning tone, release the PTT key (7). To
restart the transmission, press again the PTT key (7).
Note : on model MT-446W10 the preset time is fixed at 180 seconds.
Battery Saving
This function reduces the battery consumption when no signal is received or when no operation is
performed (it means when no key is pressed, no switch is turned on/off). This function is automatically
enabled if no signals are received and if radio has not been operated for 10 seconds (default setting).
The time can be reset by software for 5 to 60 seconds.
Low Battery Alert
This function warns you when it is necessary to charge the battery. If the battery level goes down to a
fixed level, the Led indicator (5) will flash in red colour and radio will emit a warning tone. By pressing
the PTT Key (7), the transceiver will stop automatically the transmission and radio will continue to emit
the warning tone. So please release the PTT key (7) and charge the battery.
Note: if battery level is too low, radio may power OFF automatically.
English

- 10 -
Advanced Funcions
Squelch OFF Momentary (default setting: PF1 Key)
This function can be enabled by programming Side Keys (PF1 is default setting).
When no signal is received, the Squelch circuit automatically disables the speaker, so the background
noise desappears. To manually disable the Squelch, press the PF1 key. This function may be useful
when you want to adjust the volume, when you want to receive a weak signal or when you want to
listen to a channel screened by CTCSS/DCS. If the PF1 key is pressed, the Led indicator (5) lights in
green color.
Adjust Squelch Level (default setting: PF2 Key)
This function can be enabled by programming Side Keys (PF2 is default setting).
The Squelch threshold level is adjustable in 10 steps (0-9). Each time the Side key (PF2) is pressed,
the Squelch level will be cyclically changed. If the Voice Announcement function is enabled by software,
radio will automatically report the level number, from level 1 to level 9. If level 0 is selected, Squelch will
be open and you will hear the background noise and the Led indicator (5) lights in green color.
Local Alarm (default setting: PF3 Key)
This function can be enabled by programming Side Keys (PF3 is default setting).
When the side key (PF3) is pressed, the radio will emit local alarm sound to remind other users.
English

- 11-
Programmable Side Keys (PF1 - PF2 - PF3)
No. Function
DTMF ON / OFF (*)
Description
Enable / disable DTMF Function
Check the current Squelch Level.
The radio will un-mute only when it receives a carrier signal.
1
Monitor
Monitor Momentary
2
3
The radio will un-mute no matter there is a carrier signal or not.
Squelch OFF
Squelch OFF Momentary
4
5
Check Squelch level6
Adjust the current Squelch Level quickly.Adjust Squelch level7
Automatic channel scanning.SCAN8
Scan the Priority Channel before other channels.Priority Channel Scan9
Delete the noise channel from the current scan group
temporarily.
Nuissance Channel
Temporary Delete
10
Delete the noise channel from the current scan group.Nuissance Channel Delete11
The Rx frequency will be used in place of the Tx frequency
during transmission.
Talk Around (*)12
Reverse the transmitting frequency and receiving frequency for
Repeater function.
Reverse Frequency (*)13
Check the transmitting power level on the current channel.Check TX Power (*)14
Enable / disable VOX function.VOX ON / OFF15
To know the current battery capacity.Check battery capacity16
When you turn the Channel Selector Knob, the radio will report
the current channel position.
Voice Announcement17
For access to Repeaters1750 Hz Tone (*)18
To lock the current channel position, and the Channel Knob is
invalid.
Channel Lock19
You can speak quietly into the Microphone, and other users
still can hear clearly.
Whisper (*)20
Single Call and Group Call.Select Call (*)21
The alarm mode can be programmed via Software.Emergency Alarm (*)22
Adjust the transmitting power level on current channel.TX Power Adjustment (*)23
You can program the Side keys (PF1 - PF2 - PF3), by using the dedicated PC software.
The programmable fuctions are as follow :
Note: Your dealer may assign different functions for Side Keys (long press or short press the key).
(*) These funcions are available only on models MT-174W10 and MT-460W10
English

Specifications - Optional Accessories
- 12 -
SPECIFICATIONS
General
Frequency 446.00625 - 446.09375 MHz (MT-446W10)
136 - 174 MHz (MT-174W10)
400 - 470 MHz (MT-460W10)
Channels 16
Channel spacing 12.5 KHz (MT-446W10)
12.5 / 25 KHz selectable (MT-174W10 and MT-460W10)
DC input voltage 7.4 VDC
Operating temperature -20/+55°
Dimensions mm 58 x 136 x 36
Weight 246 gr. (with battery pack and antenna)
Receiver
Sensitivity (12dB Sinad) 0.25 µV
Audio output 1W
Transmitter
RF output power 0.5W ERP (MT-446W10)
10W / 5W / 1W (MT-174W10) (*)
10W / 5W / 1W (MT-460W10) (*)
Modulation FM
Spurious & Harmonics in compliance with the R&TTE regulations
OPTIONAL ACCESSORIES
- KST-301M External "Heavy Duty" speaker-microphone
- KME-614M External earset-microphone with adjustable ear hook
- KME-801M External earset-microphone for security and bodyguard
- KME-315M External earset-microphone with special soft tear proof cable
- KSPL-09 PC interface USB cable
NOTICE !
(*) The transmitter RF output power levels are user programmable by PC, using the
programming software (free download at www.intek-radios.com). The power levels must be
programmed in accordance with the regulations of the country where the product is used.
English

MT-446W10 Channels Programming - User Information
- 13 -
CHANNEL FREQUENCY
TX
FREQUENCY
RX
CTCSS / DCS
TONE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
446.00625
446.01875
446.03125
446.04375
446.05625
446.06875
446.08125
446.09375
446.00625
446.01875
446.03125
446.04375
446.05625
446.06875
446.08125
-
446.00625
446.01875
446.03125
446.04375
446.05625
446.06875
446.08125
446.09375
446.00625
446.01875
446.03125
446.04375
446.05625
446.06875
446.08125
-
NO
NO
NO
107.2
110.9
114.8
118.8
123.0
127.3
131.8
136.5
141.3
146.2
123.0
156.7
-
FREQUENCY / CHANNELS PROGRAMMING (factory default programming)
User Information
in accordance with art. 13 of the Legislative Decree of 25th July 2005, no. 15 ”Implementation of Directives 2002/95/EC,
2002/96/EC and 2003/108/EC, relative to reduction of the use of hazardous substances in electrical and electronic
equipment, in addition to waste disposal”.
The crossed bin symbol shown on the equipment indicates that at the end of its working life the product must
be collected separately from other waste.
The user must therefore take the above equipment to the appropriate differentiated collection centres for
electronic and electro technical waste, or return it to the dealer when purchasing a new appliance of
equivalent type, in a ratio of one to one.
Appropriate differentiated waste collection for subsequent recycling, treatment and environment-friendly disposal of the
discarded equipment helps to prevent possible negative environmental and health effects and encourages recycling of
the component materials of the equipment.
Illegal disposal of the product by the user will be punished by application of the administrative fines provided for by the
legislative decree no. 22/1997 (article 50 and following of the legislative decree no. 22/1997).
English

MT-174W10 / MT-460W10 Channels Programming
- 14 -
CHANNEL FREQUENCY
TX
FREQUENCY
RX
CTCSS / DCS
TONE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
.....................
FREQUENCY / CHANNELS PROGRAMMING
English

CTCSS Tone Frequency Chart - DCS Tone Frequency Chart
- 15 -
67.0 82.5 100.0 123.0 15 1.4 171.3 18 9.9 210.7 250.3
69.3 85.4 103.5 127.3 15 6.7 173.8 192.8 218 .1 254.1
71.9 88.5 107.2 131.8 159.8 177.3 196 .6 225.7
74.4 91.5 110.9 136.5 16 2.2 179.9 199.5 229.1
77.0 94.8 114.8 141.3 16 5.5 183.5 203.5 233.6
79.7 97.4 118.8 146.2 16 7.9 186.2 206.5 241.8
CTCSS - TONE FREQUENCY CHART (50 TONES)
DCS - TONE FREQUENCY CHART (105 TONES)
English
D023N/I
D025N/I
D026N/I
D031N/I
D032N/I
D036N/I
D043N/I
D047N/I
D051N/I
D053N/I
D054N/I
D065N/I
D071N/I
D072N/I
D073N/I
D074N/I
D114N/I
D115N/I
D116N/I
D122N/I
D125N/I
D131N/I
D132N/I
D134N/I
D143N/I
D145N/I
D152N/I
D155N/I
D156N/I
D162N/I
D165N/I
D172N/I
D174N/I
D205N/I
D212N/I
D223N/I
D225N/I
D226N/I
D243N/I
D244N/I
D245N/I
D246N/I
D251N/I
D252N/I
D255N/I
D261N/I
D263N/I
D265N/I
D266N/I
D271N/I
D274N/I
D306N/I
D311N/I
D315N/I
D325N/I
D331N/I
D332N/I
D343N/I
D346N/I
D351N/I
D356N/I
D364N/I
D365N/I
D371N/I
D411N/I
D412N/I
D413N/I
D423N/I
D431N/I
D432N/I
D445N/I
D446N/I
D452N/I
D454N/I
D455N/I
D462N/I
D464N/I
D465N/I
D624N/I
D503N/I
D506N/I
D516N/I
D523N/I
D526N/I
D532N/I
D546N/I
D565N/I
D606N/I
D612N/I
D624N/I
D627N/I
D631N/I
D632N/I
D645N/I
D654N/I
D662N/I
D664N/I
D703N/I
D712N/I
D723N/I
D731N/I
D732N/I
D734N/I
D743N/I
D754N/I

Indice - Importante . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Informazioni per l' utente . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Disimballaggio e verifica delle parti - Accessori forniti . . . . . . . . . . . . . . . . . . . . . . . . . 18
Preparazione . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19-21
Familiarizzare con il prodotto . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-23
Operazioni di base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23-24
Funzioni supplementari . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24-25
Programmazione tasti laterali (PF1 - PF2 - PF3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Specifiche tecniche - Accessori opzionali . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Programmazione canali MT-446W10 - Avviso agli utenti . . . . . . . . . . . . . . . . . . . . . . . . 28
Programmazione canali MT-174W10 / MT-460W10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Tabelle toni CTCSS / DCS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Avvertenze importanti / Garanzia limitata . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Dichiarazioni di Conformità . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32-34
Indice - Introduzione
- 16 -
IMPORTANTE !
Questo ricetrasmettitore è programmabile tramite PC, utilizzando l’apposito software
(liberamente scaricabile dal sito www-intek-radios.com) e cavetto di interfaccia (opzionali).
L’eventuale programmazione o modifica della programmazione esistente deve essere eseguita
da un tecnico specializzato o da un centro di assistenza autorizzato. Alcune funzioni del
ricetrasmettitore potrebbero essere programmate in violazione delle norme tecniche in vigore
per l’utilizzo delle bande VHF e UHF FM. E’ responsabilità dell’utente verificare che eventuali
modifiche nella programmazione delle funzioni del ricetrasmettitore siano conformi a quanto
previsto dalle norme tecniche in vigore. Modifiche al prodotto, manomissioni, alterazione delle
regolazioni interne o delle strutture esterne della radio e programmazioni in violazione delle
norme di legge fanno decadere le certificazioni e omologazioni del prodotto ed il diritto
all’utilizzo dello stesso.
INTEK s.r.l. declina qualsiasi responsabilità relativamente a modifiche della programmazione
del ricetrasmettitore, eseguite dall’utente o da terzi, dopo la consegna del prodotto.
IMPORTANTE !
Questo ricetrasmettitore è stato pre-programmato in origine, al fine di consentire un test del
prodotto dopo l’acquisto. E' responsabilità dell' utente riprogrammare la radio, nel rispetto delle
norme tecniche in vigore per l’ utilizzo sulle frequenze assegnate dalla autorizzazione ministeriale.
IMPORTANTE !
Si raccomanda di leggere attentamente questo manuale prima di utilizzare il prodotto. Ciò aiuterà
l' utente anche ad impedire di utilizzare la radio in violazione delle norme di legge in vigore nel
paese dove il prodotto viene utilizzato e di evitare ogni possibile interferenza con altri servizi.
Italiano

Italiano
Grazie !
Vi ringraziamo per aver scelto INTEK per applicazioni civili. Siamo certi che questo ricetrasmettitore di
facile uso vi consentirà di comunicare in modo affidabile e di svolgere le vostre attività professionali con
la massima efficienza. Questo ricetrasmettitore incorpora la più avanzata tecnologia e sarete soddisfatti
del suo livello di qualità e delle sue caratteristiche tecniche.
Avviso importante per l' utente !
L’utilizzo dei ricetrasmettitori VHF e UHF FM è regolato dalle norme di legge in vigore. Poiché le norme
stesse sono soggette a possibili variazioni, prima di utilizzare gli apparecchi, si raccomanda di
informarsi presso il proprio rivenditore o fornitore verificando gli eventuali adempimenti da osservare.
INTEK declina qualsiasi responsabilità relativamente ad un uso degli apparecchi non autorizzato o non
conforme alle norme di legge.
Sicurezza
L’utente deve conoscere e comprendere i rischi comuni legati all’uso di apparecchi ricetrasmittenti. Non
utilizzate mai il ricetrasmettitore in ambienti a rischio di esplosione (in presenza di gas, polveri, fumi,
etc.). Non utilizzare inoltre il ricetrasmettitore nelle aree di servizio o distributori di carburante.
Precauzioni
Si consiglia di osservare le seguenti precauzioni, al fine di evitare incendi, ferite personali e danni al
ricetrasmettitore:
Si suggerisce di trasmettere per alcuni minuti in quanto trasmissioni molto lunghe o alla massima
potenza del trasmettitore potrebbero surriscaldare lo stesso.
Non manomettere o modificare in alcun modo il ricetrasmettitore.
Non esporre il ricetrasmettitore per lungo tempo alla luce solare diretta e non porlo vicino a fonti di calore.
Non porre il ricetrasmettitore in luoghi eccessivamente polverosi o umidi, inoltre non porlo su
superfici instabili.
Se sentite un odore anomalo o se vedete del fumo fuoriuscire dal ricetrasmettitore, spegnetelo
immediatamente e rimuovete il pacco batteria. Quindi contattate un centro di assistenza autorizzato.
Non gettate batterie usate nella spazzatura. Utilizzate solo gli appositi contenitori per lo
smaltimento.
Se il veicolo è dotato di airbag, non posizionare il ricetrasmettittore o altri accessori in prossimità
o nell'area di espansione dell'airbag. Se l'apparecchio presente nel veicolo è posizionato o
installato in modo non corretto e l'airbag si attiva, possono verificarsi danni gravi. I segnali di
radiofrequenza possono avere effetto sui sistemi elettronici delle autovetture installati in modo
non corretto o non completamente schermati. Verificare le condizioni del veicolo presso il
costruttore o un concessionario. Per informazioni sui segnali di radiofrequenza, consultare il
costruttore di eventuali apparecchiature installate sul veicolo.
Al fine di ottenere prestazioni ottimali della radio e di assicurare che l’esposizione del corpo alle
onde elettromagnetiche a radiofrequenza sia conforme ai limiti previsti, osservare sempre le
istruzioni indicate qui di seguito :
Utilizzo Della Radio Ricetrasmittente
Quando si utilizza l’unità come una tradizionale radio ricetrasmittente, mantenerla nell’assetto
verticale e ad una distanza di circa 20 – 25 centimetri dalle labbra. La percentuale del ciclo di
trasmissione è del 30%.
- 17 -
Informazioni per l' utente

Disimballaggio e verifica delle parti - Accessori forniti
- 18 -
Disimballaggio e verifica delle parti
Disimballate accuratamente il ricetrasmettitore. Si raccomanda di identificare tutte le parti elencate nella
tabella seguente, prima di eliminare l’imballo. Se vi sono stati danni o mancanze durante la spedizione,
contattate immediatamente il vostro fornitore.
Accessori forniti
Antenna in gomma con connettore SMA (solo nei modelli MT-174W10 e MT-460W10)
Pacco batteria Li-Poly 7.4V 2500mAh
Caricabatterie rapido elettronico da tavolo 230VAC
Clip da cintura
Cinghietta
Chiusura per presa earset-mic
Manuale d' uso
Italiano
Caricabatterie rapido
da tavolo
Antenne in gomme
con connettore SMA
(tranne modello MT-446W10)
Pacco batterie Li-Poly
Clip da cinturaAdattatore 230VAC Cinghietta Manuale d' uso

Italiano
Preparazione
- 19 -
Ricarica della batteria
Collegare l’adattatore 230V alla presa posta sul retro del caricatore da tavolo, come mostrato dal
disegno. Collegare l' adattatore alla presa 230VAC. Il LED lampeggerà in colore rosso per 1 secondo
poi si spegnerà, a conferma che il caricabatterie è alimentato. Inserire la batteria scarica o il
ricetrasmettitore con la batteria installata nel caricabatteria. Assicurarsi che i terminali della batteria
siano a contatto con quelli dei caricatore. Il LED rimarrà acceso in colore rosso, quindi l’apparecchio si
predispone per iniziare la ricarica automatica della batteria. Il tempo di ricarica dipende dallo stato di
carica e dalla capacità della batteria. Quando la ricarica è stata completata, il LED sarà acceso in
colore verde. A questo punto rimuovere la batteria o il ricetrasmettitore dal caricatore e scollegare
quest’ultimo dalla rete elettrica. Se la capacità della batteria è esaurita, il LED della radio (6) inizia a
lampeggiare in colore rosso e si udirà il messaggio sonoro "Please charge the battery".
Avvertenze !
La batteria viene fornita scarica e deve essere quindi ricaricata prima dell’uso.
Sono necessari alcuni cicli completi di carica/scarica affinché la batteria raggiunga il massimo
livello di efficienza.
La batteria non deve essere ricaricata nuovamente se è già stata completamente caricata.
Diversamente, la vita della batteria può diminuire o la stessa essere danneggiata.
Il caricabatterie non si spegne automaticamente dopo la ricarica pertanto rimuovere la batteria o il
ricetrasmettitore dal caricatore e scollegare quest’ultimo dalla rete elettrica.
Non superare le 8 ore di ricarica, per evitare il danneggiamento della batteria.
Non disperdere batterie esaurite nell’ambiente e non gettarle tra i rifiuti ordinari. Utilizzate gli appositi
contenitori per la raccolta delle batterie usate o restituite le batterie da eliminare al vostro fornitore.
Non tentare mai di rimuovere l’involucro della batteria.
Non cortocircuitare i teminali della batteria e non gettare quest' ultima nel fuoco.
Stato di carica Indicatori LED Note
Caricatore acceso LED rosso lampeggiante per 1
secondo poi spento
Modo Standby LED verde acceso
In ricarica LED rosso acceso
Carica ultimata LED verde acceso
Errore batteria LED rosso lampeggiante Voltaggio batteria inferiore a 6V
o pacco batterie guasto
