FT-65R/FT-65E
Quick Manual
Speaker V/M key
Microphone LED Flash-Light
LCD (Liquid Crystal Display)  key
Quick Recall key BAND key
Alphabet / Numeric keys 0 / zero-set key
*The circled numbers in the table correspond to the circled numbers
in the procedures of this manual.
Basic Operation
Turn the Power ON and OFF
Rotate the PWR/VOL knob out of the click-stop to turn the transceiver
ON. The current DC supply voltage will be shown on the display for two
seconds. After the two second interval, the display will commence the
normal operating frequency indication.
Changing between VFO mode and Memory mode
Press the [V/M] key repeatedly to toggle the frequency control between
the VFO mode and the Memory mode.
For details on Memory channels, see “Setting the Memory Channels“ on the
back page.
Selecting the Operating Band
Press the [#BAND] key repeatedly to change the operating frequency
between the 144 MHz Band, the 430 MHz Band, and the 95 MHz (FM
Radio Broadcast) Band. Frequency ranges are shown in the table.
Frequency Range (MHz)
RX TX RX TX
USA version 136-174 144-148 400-480 430-450
EU version 136-174 144-146 400-480 430-440
Asian version 136-174 136-174 400-480 400-480
Frequency Navigation
1.Tuning Frequency
Pressing the [] key tunes the FT-65R/E toward a higher frequency,
while pressing the [] key will lower the operating frequency, in steps
preprogrammed for the current operating band.
2.Direct Keypad Frequency Entry
The operating frequency may be entered directly from the keypad by
pressing the numbered digits on the keypad in the proper sequence.
Example:
To enter 145.000 MHz*, press [1] [4] [5] [0] [0] [0]
*There is a short-cut to enter frequencies ending in zeros - after the last non-
zero digit, press and hold the to enter the remaining zeros.
3.Scanning
Manual VFO Scan:
To manually initiate VFO scanning, press and hold either the [] or []
key to begin upward or downward scanning, respectively.
Programmed Mode VFO Scan:
To begin scanning within a limited sub-band range from the VFO mode,
press and hold the [#BAND] key to select the bandwidth for the
Programmed Mode (VFO) scanner. Then press the Fkey and the
[#BAND] key to start scanning.
Transmission
To transmit, press the PTT switch, and speak into the front panel
microphone (located in the lower left-hand corner of the speaker grille)
in a normal voice level. The TX/BUSY indicator will glow red during
transmission.
Activating the Set Mode
Use the following procedure to activate the Set Mode and configure the
transceiver parameters.
1. Press and hold the F key to enter the Set mode.
2. Repeatedly press the [▲] or [▼] key to select the Set Mode Item to be adjusted.
3. Press the F key momentarily to enable adjustment of the Set Mode Item.
4. Press the [▲] or [▼] key to adjust the level, or choose the parameter, of the
selected Set Mode Item.
5. After completing the selection and adjustment, press the PTT switch to save the new
setting and exit to normal operation.
Antenna Jack TX/BUSY Indicator Lamp
EMERGENCY Key PWR/VOL Knob
PTT (Push To Talk) Switch F key
MONI/T.CALL Key
(Function is selectable from Set mode)
SP Jack
MIC Jack
EH066M551

Changing the Transmit Power Level
1. Press the Fkey and then press the [P2] key.
• The present TX power output level will appear on the display.
• To adjust the TX power in the Set Mode, press and hold the Fkey.
Then repeatedly press the [▲] or [▼] key to select Set Mode item “32 TX PWR”
and then press the Fkey.
2. Press the [▲] or [▼] key to select the desired power output level.
Available selections are “HI” (5 W), “MID” (2.5 W), and “LOW” (0.5 W).
3. Press the PTT switch to save the new setting and return to normal operation.
Setting the Preferred Operating Mode
The following reset or preferred operating modes may be selected.
Menu Description
F1:SET RESET Reset the Set Mode settings to factory defaults.
F2:MEM RESET Clear the Memory settings to factory defaults.
F3:BANK RESET Clear the Memory Bank assignments.
F4:ALL RESET Clear the All memories and other settings to factory defaults.
F5:MEM-ONLY Operation on the Memory mode only.
F6:VHF-ONLY Operation on the VHF Band only.
F7:UHF-ONLY Operation on the UHF Band only.
F8:DUAL DISP Display both VFO-A and VFO-B.
F9:CLONE Clone mode.
1. Turn the radio OFF.
2. Press and hold the MONI/T.CALL key and the PTT switch simultaneously, while
turning the radio ON.
3. When the LCD backlight comes on, release the MONI/T.CALL key and the PTT
switch.
4. Referring to the above table, press the [▲] or [▼] key to select the desired
preference mode.
5. Press the F key momentarily to activate the selected operating mode.
Locking the Keys and Switches
The FT-65R/E keypad may be locked to prevent accidental frequency change or inadvertent
transmissions.
Turning the Keylock Feature ON and OFF
1. Press and hold the [6] key to lock the keys and switches.
• The
icon will appear on the LCD display .
•
To unlock the keys and switches, press and hold the [6] key
again.
Change the key locking scheme
The following locking schemes may be selected.
Item Description
KEY(default setting) Only the front panel keypad is locked out
PTT The PTT switch is locked out (TX is not possible)
P+K Both the PTT switch and keypad are locked out
1. Press and hold the F key to enter the Set mode.
2. Press the [▲] or [▼] key to select Set Mode Item “15 KEY LOCK”.
3. Press the F key to enable adjustment of this Item.
4. Press the [▲] or [▼] key to choose one of the above listed locking schemes.
5. Press the PTT switch to save the new setting and return to normal operation.
Using the Flash Light / the Emergency Alarm
The Flash Light
1. Press the EMERGENCY key briefly to turn the LED Flash-Light ON.
The Emergency Alarm
1. Press and hold the EMERGENCY key for three seconds to enable the emergency
alarm function.
• Emergency Alarm will sound from the speaker and the flash-light will blink with the SOS
signal.
• VHF “Home” channel will appear on the LCD display.
2. Press the EMERGENCY key to stop the Alarm.
Setting the Memory Channels
1.Memory Storage
1. Select the desired frequency, while operating in the VFO mode.
Be sure to set up the desired CTCSS or DCS tones, as well as any desired repeater
offset. The power level may also be set at this time, if you wish to store it.
2. Press and hold the [V/M]key.
A blank memory channel will be displayed automatically.
3. If it is desired to change to another channel number, press the [▲] or [▼] key.
4. Press the Alphabet / Numeric keys and
[0/SET] key (,) to input characters and
create a “Tag” (label) for the memory channel.
If not inputting a “Tag” (label), proceed to step 5.
• To move the cursor to the next character, press the Fkey.
• To correct a mistake, press the Fkey repeatedly until the cursor returns to the
character position.
5. Press and hold the [V/M]key to store the frequency and settings into the selected
memory channel.
“MEM-IN” on the display will blink twice and the tone will sound to complete the memory
setting.
2.Memory Recall
1. While operating in the VFO mode, press the [ V/M] key to enter the Memory mode.
2. Press the [▲] or [▼] key to select the desired memory channel.
3. To return to the VFO mode, press the [V/M] key.
When the transceiver is already set to the Memory mode, an easy way to recall a
memory channel is to enter the memory channel number using the numeric keypad.
3.Deleting Memories
1. Press and hold the F key to enter the Set mode.
2. Press the [▲] or [▼] key to select Set Mode item “18: MEM DEL” and then press
the F key.
3. Press the [▲] or [▼] key to select the memory channel to be “deleted”.
4. Press the F key to delete the selected memory channel.
5. Press the PTT switch to return to normal operation.
For additional details, refer to the Operating manual and the Advanced
Manual, which may be downloaded from the Yaesu website.
Setting the Quick Recall Keys
The four keys (P1, P2, P3 & P4), are user programmable.
Quick Recall Key Press Press after pressing F key Press and hold
recall the stored or
assigned setting
HOME (Fixed setting)
store or assign a
setting to the key
TX PWR (Fixed setting)
SQL TYPE (Fixed setting)
REV (Fixed setting)
1.Assigning Set Mode Items to the Quick Recall Keys (Set Mode
Recall feature)
1. Press and hold the F key to enter the Set mode.
2. Press the [▲] or [▼] key to select the Set Mode Item to be assigned to the Quick
Recall Key as a recalled Menu item.
The Quick Recall Keys can store and recall favorite frequency settings, and are also
short-cut keys to the Set Mode menu items.
3. Press and hold the [P1], [P2], [P3] or [P4] key( ) to assign the Set Mode Item to the
Quick Recall Key.
4. Press the [P1], [P2], [P3] or [P4] key( ) to recall the assigned Set Mode Item.
2.Storing a displayed frequency and Settings to a Quick Recall Key
(Quick memory feature)
1. While operating in the VFO mode or the Memory mode, set the desired frequency and
associated settings.
2. Press and hold the [P1], [P2], [P3] or [P4] key( ) to store the frequency to a Quick
Recall key.
3. Press the [P1], [P2], [P3] or [P4] key( ) to recall the stored settings.
A Quick Recall Key may also store the frequency and associated settings in the Memory
Mode.
