Reference Number: 322821-002
Intel®Itanium®Processor 9300
Series and 9500 Series
Intel®Itanium®Processor Quad-Core 1.86-1.73 GHz with 24 MB L3 Cache 9350
Intel®Itanium®Processor Quad-Core 1.73-1.60 GHz with 20 MB L3 Cache 9340
Intel®Itanium®Processor Quad-Core 1.60-1.46 GHz with 20 MB L3 Cache 9330
Intel®Itanium®Processor Quad-Core 1.46-1.33 GHz with 16 MB L3 Cache 9320
Intel®Itanium®Processor Dual-Core 1.60 GHz Fixed Frequency with 10 MB L3 Cache 9310
Intel®Itanium®Processor Eight-Core 2.53 GHz with 32 MB LLC Cache 9560
Intel®Itanium®Processor Four-Core 2.40 GHz with 32 MB LLC Cache 9550
Intel®Itanium®Processor Eight-Core 2.13 GHz with 24 MB LLC Cache 9540
Intel®Itanium®Processor Four-Core 1.73 GHz with 20 MB LLC Cache 9520
Datasheet
November 2012

2Intel®Itanium® Processor 9300 Series and 9500 Series Datasheet
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL PRODUCTS. NO LICENSE, EXPRESS OR IMPLIED,
BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS DOCUMENT. EXCEPT AS
PROVIDED IN INTEL'S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER
AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING
LIABILITY OR WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY
PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT.
A “Mission Critical Application” is any application in which failure of the Intel Product could result, directly or indirectly, in personal
injury or death. SHOULD YOU PURCHASE OR USE INTEL'S PRODUCTS FOR ANY SUCH MISSION CRITICAL APPLICATION, YOU
SHALL INDEMNIFY AND HOLD INTEL AND ITS SUBSIDIARIES, SUBCONTRACTORS AND AFFILIATES, AND THE DIRECTORS,
OFFICERS, AND EMPLOYEES OF EACH, HARMLESS AGAINST ALL CLAIMS COSTS, DAMAGES, AND EXPENSES AND REASONABLE
ATTORNEYS' FEES ARISING OUT OF, DIRECTLY OR INDIRECTLY, ANY CLAIM OF PRODUCT LIABILITY, PERSONAL INJURY, OR DEATH
ARISING IN ANY WAY OUT OF SUCH MISSION CRITICAL APPLICATION, WHETHER OR NOT INTEL OR ITS SUBCONTRACTOR WAS
NEGLIGENT IN THE DESIGN, MANUFACTURE, OR WARNING OF THE INTEL PRODUCT OR ANY OF ITS PARTS.
Intel may make changes to specifications and product descriptions at any time, without notice. Designers must not rely on the
absence or characteristics of any features or instructions marked “reserved” or “undefined”. Intel reserves these for future
definition and shall have no responsibility whatsoever for conflicts or incompatibilities arising from future changes to them. The
information here is subject to change without notice. Do not finalize a design with this information.
The products described in this document may contain design defects or errors known as errata which may cause the product to
deviate from published specifications. Current characterized errata are available on request.
Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.
Copies of documents which have an order number and are referenced in this document, or other Intel literature, may be obtained
by calling 1-800-548-4725, or go to: http://www.intel.com/design/literature.htm%20
I2C is a two-wire communication bus /protocol developed by Phillips. SMBus is a subset of the I2C bus/protocol developed by Intel.
Implementation of the I2C bus/protocol or the SMBus bus/protocol may require licenses from various entities, including Phillips
Electronics, N.V. and North American Phillips Corporation.
Intel® Virtualization Technology requires a computer system with an enabled Intel® processor, BIOS, virtual machine monitor
(VMM) and, for some uses, certain computer system software enabled for it. Functionality, performance or other benefits will vary
depending on hardware and software configurations and may require a BIOS update. Software applications may not be compatible
with all operating systems. Please check with your application vendor.
Intel, Itanium, and the Intel logo are trademarks of Intel Corporation in the U. S. and\or other countries.
*Other names and brands may be claimed as the property of others.
Copyright © 2012, Intel Corporation. All Rights Reserved.

Intel®Itanium® Processor 9300 Series and 9500 Series Datasheet 3
Contents
1Introduction..............................................................................................................9
1.1 Overview ...........................................................................................................9
1.2 Architectural Overview.......................................................................................15
1.2.1 Intel®Itanium®Processor 9300 Series Overview .......................................15
1.2.2 Intel®Itanium®Processor 9500 Series Overview .......................................16
1.3 Processor Feature Comparison ............................................................................19
1.4 Processor Abstraction Layer................................................................................20
1.5 Mixing Processors of Different Frequencies and Cache Sizes ....................................20
1.6 Terminology .....................................................................................................20
1.7 State of Data....................................................................................................21
1.8 Reference Documents........................................................................................21
2 Electrical Specifications...........................................................................................23
2.1 Intel®QuickPath Interconnect and Intel®Scalable Memory Interconnect
Differential Signaling .........................................................................................23
2.2 Signal Groups...................................................................................................24
2.3 Reference Clocking Specifications ........................................................................26
2.4 Intel®QuickPath Interconnect and Intel®SMI Signaling Specifications.....................28
2.4.1 Intel® Itanium® Processor 9300 Series
Intel®QuickPath Interconnect and
Intel®SMI Specifications for 4.8 GT/s.......................................................28
2.4.2 Intel® Itanium® Processor 9500 Series Requirements for
Intel®QuickPath Interconnect for 4.8 and 6.4 GT/s ....................................32
2.4.3 Intel®Itanium®Processor 9500 Series Processor Requirements for
Intel® SMI Specifications for 6.4 GT/s.......................................................37
2.5 Processor Absolute Maximum Ratings...................................................................38
2.5.1 Intel®Itanium®Processor 9300 Series Absolute Maximum Ratings...............39
2.5.2 Intel®Itanium®Processor 9500 Series Absolute Maximum Ratings...............39
2.6 Processor DC Specifications ................................................................................39
2.6.1 Flexible Motherboard Guidelines for the Intel®Itanium®
Processor 9300 Series.............................................................................40
2.6.2 Flexible Motherboard Guidelines for the Intel®Itanium®
Processor 9500 Series.............................................................................43
2.6.3 Intel®Itanium®Processor 9300 Series Uncore, Core, and Cache Tolerances.. 44
2.6.4 Intel®Itanium®Processor 9500 Series Uncore and Core Tolerances .............49
2.6.5 Overshoot and Undershoot Guidelines.......................................................52
2.6.6 Signal DC Specifications..........................................................................53
2.6.7 Motherboard-Socket Specification for VR Sense Point..................................57
2.7 Core and Uncore Voltage Identification.................................................................57
2.7.1 Core and Uncore Voltage Identification for the
Intel® Itanium® Processor 9300 Series....................................................58
2.7.2 Core and Uncore Voltage Identification for the
Intel®Itanium®Processor 9500 Series ..................................................... 59
2.8 Cache Voltage Identification (Intel®Itanium®Processor 9300 Series only) ...............62
2.9 RSVD, Unused, and DEBUG Pins..........................................................................63
2.10 Mixing Processors..............................................................................................64
2.11 Supported Power-up Voltage Sequence ................................................................64
2.11.1 Supported Power-up Voltage Sequence for the
Intel® Itanium® Processor 9300 Series....................................................66
2.11.2 Supported Power-up Voltage Sequence for the
Intel®Itanium®Processor 9500 Series ..................................................... 67
2.11.3 Power-up Voltage Sequence Timing Requirements......................................68
2.12 Supported Power-down Voltage Sequence ............................................................68
2.13 Timing Relationship Between RESET_N and SKTID.................................................69

4Intel®Itanium® Processor 9300 Series and 9500 Series Datasheet
2.14 Test Access Port (TAP) Connection.......................................................................71
3 Pin Listing................................................................................................................73
3.1 Processor Package Bottom Pin Assignments...........................................................73
3.1.1 Package Bottom Pin Listing by Pin Name....................................................73
3.1.2 Pin Listing by Pin Number ........................................................................89
3.2 Processor Package Top Pin Assignments..............................................................105
3.2.1 Top-Side J1 Connector Two-Dimensional Table .........................................105
3.2.2 Top-Side J2 Connector Two-Dimensional Table .........................................108
3.2.3 Top-Side J3 Connector Two-Dimensional Table .........................................111
3.2.4 Top-Side J4 Connector Two-Dimensional Table .........................................114
4 Mechanical Specifications ......................................................................................119
4.1 Package Mechanical Drawing.............................................................................120
4.2 Intel®Itanium®Processor 9300 Series...............................................................121
4.3 Processor Component Keepout Zones.................................................................129
4.4 Package Loading Specifications..........................................................................129
4.5 Package Handling Guidelines.............................................................................129
4.6 Processor Mass Specifications............................................................................130
4.7 Processor Materials..........................................................................................130
4.8 Package Markings............................................................................................130
5 Thermal Specifications...........................................................................................133
5.1 Thermal Features.............................................................................................133
5.1.1 Digital Thermometer .............................................................................134
5.1.2 Thermal Management............................................................................135
5.1.3 Thermal Alert.......................................................................................136
5.1.4 TCONTROL...........................................................................................137
5.1.5 Thermal Warning..................................................................................137
5.1.6 Thermal Trip ........................................................................................137
5.1.7 PROCHOT ............................................................................................138
5.1.8 FORCEPR_N Signal Pin...........................................................................138
5.1.9 Ararat Voltage Regulator Thermal Signals ................................................138
5.2 Package Thermal Specifications and Considerations..............................................139
5.3 Storage Conditions Specifications.......................................................................140
6 System Management Bus Interface........................................................................143
6.1 Introduction....................................................................................................143
6.2 SMBus Memory Component...............................................................................144
6.2.1 Processor Information ROM (PIROM) .......................................................144
6.2.2 Scratch EEPROM...................................................................................149
6.2.3 PIROM and Scratch EEPROM Supported SMBus Transactions.......................150
6.3 Memory Component Addressing.........................................................................150
6.4 PIROM Field Definitions.....................................................................................152
6.4.1 General...............................................................................................152
6.4.2 Processor Data.....................................................................................152
6.4.3 Processor Core Data..............................................................................152
6.4.4 Processor Uncore Data ..........................................................................153
6.4.5 Cache Data..........................................................................................154
6.4.6 Package Data.......................................................................................155
6.4.7 Part Number Data.................................................................................155
6.4.8 Thermal Reference Data ........................................................................155
6.4.9 Feature Data........................................................................................156
6.4.10 Other Data ..........................................................................................157
6.4.11 Checksums ..........................................................................................157
7SignalDefinitions...................................................................................................159

Intel®Itanium® Processor 9300 Series and 9500 Series Datasheet 5
Figures
1-1 Intel®Itanium®Processor 9300 Series Processor Block Diagram.............................16
1-2 Intel®Itanium®Processor 9500 Series Processor Block Diagram.............................17
1-3 Intel®Itanium®Processor 9500 Series Firmware Diagram......................................18
2-1 Active ODT for a Differential Link Example............................................................23
2-2 Single-ended Maximum and Minimum Levels and Vcross Levels...............................27
2-3 Vcross-delta Definition.......................................................................................27
2-4 Differential Edge Rate Definition..........................................................................28
2-5 VRB and TStable Definitions................................................................................28
2-6 TX Equalization Diagram ....................................................................................31
2-7 TX Return Loss .................................................................................................32
2-8 RX Return Loss .................................................................................................32
2-9 Processor ICC_CORE Load Current versus Time........................................................42
2-10 VCCUNCORE Static and Transient Tolerance for
Intel®Itanium®Processor 9300 Series ................................................................45
2-11 VCCCORE Static and Transient Tolerance for
Intel®Itanium®Processor 9300 Series ................................................................47
2-12 VCCCACHE Static and Transient Tolerance for
Intel®Itanium®Processor 9300 Series ................................................................48
2-13 VCCUNCORE Static and Transient Tolerance for the
Intel®Itanium®Processor 9500 Series ................................................................50
2-14 VCCUNCORE Load Line for the Intel®Itanium®Processor 9500 Series .....................50
2-15 VCCCORE Load Line for the Intel®Itanium®Processor 9500 Series ......................... 51
2-16 VR Sense Point (Representation).........................................................................57
2-17 Supported Power-up Voltage Sequence Timing Requirements for the
Intel® Itanium® Processor 9300 Series...............................................................66
2-18 Supported Power-up Sequence Timing Requirements for
Intel® Itanium® Processor 9500 Series...............................................................67
2-19 Supported Power-down Voltage Sequence Timing Requirements..............................69
2-20 RESET_N and SKITID Timing for Warm and Cold Resets .........................................70
4-1 Processor Package Assembly Sketch .................................................................. 119
4-2 Intel®Itanium®Processor 9300 Series Package Drawing (Sheet 1 of 4)................. 121
4-3 Intel®Itanium®Processor 9300 Series Processor Package Drawing (Sheet 2 of 4)... 122
4-4 Intel®Itanium®Processor 9300 Series Package Drawing (Sheet 3 of 4)................. 123
4-5 Intel®Itanium®Processor 9300 Series Package Drawing (Sheet 4 of 4)................. 124
4-6 Intel®Itanium®Processor 9500 Series Package Drawing (Sheet 1 of 4)................ 125
4-7 Intel®Itanium®Processor 9500 Series Package Drawing (Sheet 2 of 4)................. 126
4-8 Intel®Itanium®Processor 9500 Series Package Drawing (Sheet 3 of 4)................. 127
4-9 Intel®Itanium®Processor 9500 Series Package Drawing (Sheet 4 of 4)................. 128
4-10 Processor Marking Zones.................................................................................. 131
5-1 Intel®Itanium®Processor 9300 Series and
Intel®Itanium®Processor 9500 Series’ Thermal States ....................................... 134
5-2 Intel®Itanium®Processor 9300 Series and
Intel®Itanium®Processor 9500 Series Package Thermocouple Location................. 140
6-1 Intel® Itanium® Processor 9300 Series and
Intel® Itanium® Processor 9500 Series Package................................................. 151

6Intel®Itanium® Processor 9300 Series and 9500 Series Datasheet
Tables
1-1 Intel®Itanium®Processor 9300 Series and
Intel®Itanium®Processor 9500 Series Feature Comparison....................................19
2-1 Signals with RTT................................................................................................24
2-2 Signal Groups ...................................................................................................24
2-3 Intel®QuickPath Interconnect/Intel®Scalable Memory
‘Interconnect Reference Clock Specifications26
2-4 Intel®Itanium®Processor 9300 Series Clock Frequency Table.................................29
2-5 Intel®Itanium®Processor 9300 Series Transmitter Parameter Values for Intel®
QuickPath Interconnect and Intel SMI Channels @ 4.8 GT/s ....................................29
2-6 Intel®Itanium®Processor 9300 Series Receiver Parameter
Values for Intel®QuickPath Interconnect and Intel®SMI Channels @ 4.8 GT.............30
2-7 Intel®Itanium®Processor 9500 Series Clock Frequency Table.................................33
2-8 Intel®Itanium®Processor 9500 Series Link Speed Independent Specifications ..........33
2-9 Intel®Itanium®Processor 9500 Series Transmitter and
Receiver Parameter Values for Intel®QPI Channel at 4.8 GT/s.................................34
2-10 Intel®Itanium®Processor 9500 Series Transmitter and
Receiver Parameter Values for Intel®QPI at 6.4 GT/s.............................................35
2-11 Intel®Itanium®Processor 9500 Series Transmitter and
Receiver Parameter Values for Intel®SMI at 6.4 GT/s and lower..............................37
2-12 PLL Specification for TX and RX ...........................................................................38
2-13 Intel®Itanium®Processor 9300 Series Absolute Maximum Ratings ..........................39
2-14 Intel®Itanium®Processor 9500 Series Processor Absolute Maximum Ratings............39
2-15 FMB Voltage Specifications for the Intel®Itanium®Processor 9300 Series ................40
2-16 FMB 130W Current Specifications for the Intel®Itanium®Processor 9300 Series .......41
2-17 FMB 155W/185W Current Specifications for the
Intel®Itanium®Processor 9300 Series.................................................................42
2-18 FMB Voltage Specifications for the Intel®Itanium®Processor 9500 Series ................43
2-19 FMB 170W and 130W Current Specifications for the
Intel®Itanium®Processor 9500 Series.................................................................44
2-20 VCCUNCORE Static and Transient Tolerance for
Intel®Itanium®Processor 9300 Series.................................................................45
2-21 VCCCORE Static and Transient Tolerance for
Intel®Itanium®Processor 9300 Series.................................................................46
2-22 VCCCACHE Static and Transient Tolerance for
Intel®Itanium®Processor 9300 Series.................................................................48
2-23 VCCUNCORE Static and Transient Tolerance for the
Intel®Itanium®Processor 9500 Series.................................................................49
2-24 VCCCORE Static and Transient Tolerance for the
Intel®Itanium®Processor 9500 Series.................................................................51
2-25 Overshoot and Undershoot Specifications For Differential
Intel®QuickPath Interconnect and Intel®SMI and Single-Ended Signals
for the Intel®Itanium®Processor 9300 Series ......................................................52
2-26 Overshoot and Undershoot Specifications For Differential
Intel®QuickPath Interconnect and Intel®SMI and Single-Ended
Signals for the Intel®Itanium®Processor 9500 Series ...........................................53
2-27 Voltage Regulator Signal Group DC Specifications ..................................................53
2-28 Voltage Regulator Control Group DC Specification ..................................................54
2-29 TAP and System Management Group DC Specifications ...........................................54
2-30 Error, FLASHROM, Power-Up, Setup, and Thermal Group DC Specifications................54
2-31 VID_VCCCORE[6:0], VID_VCCUNCORE[6:0] and VID_VCCCACHE[5:0] DC
Specifications for the Intel®Itanium®Processor 9300 Series...................................55
2-32 SVID Group DC Specifications for the Intel®Itanium®Processor 9500 Series ............55

Intel®Itanium® Processor 9300 Series and 9500 Series Datasheet 7
2-33 SMBus and Serial Presence Detect (SPD) Bus Signal Group DC Specifications............55
2-34 Debug Signal Group DC Specifications..................................................................56
2-35 PIROM Signal Group DC Specifications .................................................................56
2-36 Intel® Itanium® Processor 9300 Series VCCCORE (VID_VCCCORE) and
VCCUNCORE and (VID_VCCUNCORE) Voltage Identification Definition for Ararat........58
2-37 Intel® Itanium® Processor 9500 Series VCCCORE (VID_VCCCORE)
and VCCUNCORE and (VID_VCCUNCORE) Voltage Identification
Definition for Ararat II .......................................................................................59
2-38 Cache (VID_VCCCACHE) Voltage Identification Definition for Ararat .........................63
2-39 Power-up Voltage Sequence Timing Requirements .................................................68
2-40 RESET_N and SKTID Timing ...............................................................................70
3-1 Pin List by Pin Name..........................................................................................73
3-2 Pin List by Pin Number.......................................................................................89
3-3 Top-Side J1 Connector Two-Dimensional Table
(Intel®Itanium®Processor 9300 Series)............................................................ 105
3-4 Top-Side J1 Connector Two-Dimensional Table
(Intel®Itanium®Processor 9500 Series)............................................................ 106
3-5 Top-Side J2 Connector Two-Dimensional Table
(Intel®Itanium®Processor 9300 Series)............................................................ 108
3-6 Top-Side J2 Connector Two-Dimensional Table
(Intel®Itanium®Processor 9500 Series)............................................................ 110
3-7 Top-Side J3 Connector Two-Dimensional Table
(Intel®Itanium®Processor 9300 Series)............................................................ 111
3-8 Top-Side J3 Connector Two-Dimensional Table
(Intel®Itanium®Processor 9500 Series)............................................................ 113
3-9 Top-Side J4 Connector Two-Dimensional Table
(Intel®Itanium®Processor 9300 Series)............................................................ 114
3-10 Top-Side J4 Connector Two-Dimensional Table
(Intel®Itanium®Processor 9500 Series)............................................................ 116
4-1 Processor Loading Specifications ....................................................................... 129
4-2 Package Handling Guidelines............................................................................. 129
4-3 Processor Package Insertion Specification........................................................... 130
4-4 Package Materials............................................................................................ 130
4-5 1248 FCLGA Package Marking Zones.................................................................. 130
5-1 Thermal Sensor Accuracy Distribution for the
Intel®Itanium®Processor 9300 Series .............................................................. 134
5-2 Thermal Sensor Accuracy Distribution for the
Intel® Itanium® Processor 9500 Series............................................................. 135
5-3 Thermal Specification for the Intel®Itanium®Processor 9300 Series ..................... 139
5-4 Thermal Specification for the Intel®Itanium®Processor 9500 Series Processor....... 139
5-5 Storage Condition Ratings ................................................................................ 141
6-1 Processor Information ROM Data....................................................................... 144
6-2 Read Byte SMBus Packet.................................................................................. 150
6-3 Write Byte SMBus Packet ................................................................................. 150
6-4 Offset 78h/79h Definitions................................................................................ 156
6-5 128 Byte PIROM Checksum Values .................................................................... 157
7-1 Signal Definitions for the Intel®Itanium®Processor 9300
Series and Intel®Itanium®9500 Series............................................................. 159

8Intel®Itanium® Processor 9300 Series and 9500 Series Datasheet
Revision History
§
Document
Number Revision Number Description Date
322821 -002 • Initial release of the 9300/9500 document. November 2012
322821 -001 • Initial release of the document. February 2010

Intel®Itanium®Processor 9300 Series and 9500 Series Datasheet 9
Introduction
1Introduction
1.1 Overview
The Intel®Itanium®Processor 9300 Series and Intel®Itanium®Processor 9500 Series
employ Explicitly Parallel Instruction Computing (EPIC) design concepts for a tighter
coupling between hardware and software. In this design style, the interface between
hardware and software is designed to enable the software to exploit all available
compile-time information, and efficiently deliver this information to the hardware. It
addresses several fundamental performance bottlenecks in modern computers, such as
memory latency, memory address disambiguation, and control flow dependencies. The
EPIC constructs provide powerful architectural semantics, and enable the software to
make global optimizations across a large scheduling scope, thereby exposing available
Instruction Level Parallelism (ILP) to the hardware. The hardware takes advantage of
this enhanced ILP, and provides abundant execution resources. Additionally, it focuses
on dynamic run-time optimizations to enable the compiled code schedule to flow at
high throughput. This strategy increases the synergy between hardware and software,
and leads to greater overall performance.
The Intel®Itanium®Processor 9300 Series and Intel®Itanium®Processor 9500 Series
system interface, with its 4 full width and 2 half width Intel®QuickPath Interconnects,
enables each processor to directly connect to other system components, thus can be
used as an effective building block for very large systems. The balanced core and
memory subsystem provide high performance for a wide range of applications ranging
from commercial workloads to high performance technical computing.
The Intel®Itanium®Processor 9300 Series and Intel®Itanium®Processor 9500 Series
are pin compatible and support a range of computing needs and configurations from a
2-way to large SMP servers (although OEM field upgrade methodologies vary). This
document provides the electrical, mechanical and thermal specifications that must be
met when using the Intel®Itanium®Processor 9300 Series and Intel®Itanium®
Processor 9500 Series in your systems.

Introduction
10 Intel®Itanium®Processor 9300 Series and 9500 Series Datasheet

Intel®Itanium®Processor 9300 Series and 9500 Series Datasheet 11
Introduction
Intel®Itanium®Processor 9300 SeriesIntel®Itanium®Processor 9300 Series
Intel®Itanium®Processor Quad-Core 1.86-1.73 GHz with 24 MB L3 Cache 9350
Intel®Itanium®Processor Quad-Core 1.73-1.60 GHz with 20 MB L3 Cache 9340
Intel®Itanium®Processor Quad-Core 1.60-1.46 GHz with 20 MB L3 Cache 9330
Intel®Itanium®Processor Quad-Core 1.46-1.33 GHz with 16 MB L3 Cache 9320
Intel®Itanium®Processor Dual-Core 1.60 GHz Fixed Frequency with 10 MB L3 Cache 9310
Product Features
Quad Core
— Four complete 64-bit processing cores on one
processor.
— Includes Dynamic Domain Partitioning.
Advanced EPIC (Explicitly Parallel Instruction
Computing) Architecture for current and future
requirements of high-end enterprise and technical
workloads.
— Provide a variety of advanced implementations of
parallelism, predication, and speculation,
resulting in superior Instruction-Level Parallelism
(ILP).
Intel®Hyper-Threading Technology
— Two times the number of OS threads per core.
Wide, parallel hardware based on Intel®Itanium®
architecture for high performance:
— Integrated on-die L3 cache of up to 24 MB; cache
hints for L1, L2, and L3 caches for reduced
memory latency.
— 128 general and 128 floating-point registers
supporting register rotation.
— Register stack engine for effective management
of processor resources.
— Support for predication and speculation.
Extensive RAS features for business-critical
applications, for example:
— Machine check architecture with extensive ECC
and parity protection.
— On-chip thermal management.
— Built-in processor information ROM (PIROM).
— Built-in programmable EEPROM.
—Hot-PlugSocket
— Hot-add and hot removal.
— Double Device Data Correction (DDDC) for x4
DRAMs, plus correction of a single bit error.
— Single Device Data Correction (SDDC) for x8
DRAMs, plus correction of a single bit error.
—Intel
®QuickPath Interconnect Dynamic Link
Width Reduction.
—Intel
®QuickPath Interconnect Clock Fail-Safe
Feature.
— Intel QuickPath Interconnect (Intel®QPI) Hot-
Add and Removal.
— DIMM Sparing, Memory Scrubbing, Memory
Mirroring, and Memory Migration.
— Architected firmware stack, including PAL and
SAL support.
— Directory-based and source-based coherency
protocol.
— Intel QPI poisoning, viral containment and
cleanup.
On-die Memory Controller
— Each memory controller supports two Intel®
Scalable Memory Interconnects.
— Support for one Scalable Memory Buffer per Intel
Scalable Memory Interconnect; four Scalable
Memory Buffers per processor.
— High memory bandwidth, thus improved
performance.
— 4.8 GT/s for the Intel®7500 Scalable Memory
Buffer.
Intel®Virtualization Technology for virtualization for
data-intensive applications.
— Reduce virtualization complexity.
— Improve virtualization performance.
— Increase operating system compatibility.
Intel®Cache Safe Technology ensures mainframe-
caliber availability.
— Minimize L3 cache errors.
— Disable cache entries that have become hard
errors.
— Improve availability.
High bandwidth Intel®QuickPath Interconnect for
multiprocessor scalability:
— 4 full and 2 half width Intel QPI Links
— 4.8GT/s transfer rate.
— Systems are easily scaled without sacrificing
performance.
Features to support flexible platform environments:
— IA-32 Execution Layer supports IA-32 application
binaries.
— Bi-endian support.
— Processor abstraction layer eliminates processor
dependencies.

Introduction
12 Intel®Itanium®Processor 9300 Series and 9500 Series Datasheet
The Intel®Itanium®Processor 9300 Series delivers new levels of flexibility, reliability,
performance, and cost-effective scalability for your most data-intensive business and
technical applications. It provides 24 megabytes L3 cache accessed at core speed,
Hyper-Threading Technology for increased performance, Intel®Virtualization
Technology for improved virtualization, Intel®Cache Safe Technology for increased
availability.
The Intel®Itanium®Processor 9300 Series consists of up to 4 core processors and a
system interface unit. Each processor core provides a 6-wide, 8-stage deep execution
pipeline. The resources consist of six integer units, six multimedia units, two load and
two store units, three branch units and two floating-point units each capable of
extended, double and single precision arithmetic. The hardware employs dynamic
prefetch, branch prediction, a register scoreboard, and non-blocking caches to optimize
for compile-time non-determinism. Each core provides duplication of all architectural
state to support hardware multithreading, thus enabling greater throughput. Three
levels of on-die cache minimize overall memory latency. It interfaces with the Ararat
“1” Voltage Regulator Module, which used exclusively with the Intel®Itanium®
Processor 9300 Series.

Intel®Itanium®Processor 9300 Series and 9500 Series Datasheet 13
Introduction
Intel®Itanium®Processor 9500 Series
Intel®Itanium®Processor Eight-Core 2.53 GHz with 32 MB LLC Cache 9560
Intel®Itanium®Processor Four-Core 2.40 GHz with 32 MB LLC Cache 9550
Intel®Itanium®Processor Eight-Core 2.13 GHz with 24 MB LLC Cache 9540
Intel®Itanium®Processor Four-Core 1.73 GHz with 20 MB LLC Cache 9520
Product Features
Eight Core
— Eight complete 64-bit processing cores on one
processor, with two threads per core.
— Each core provides in-order issue and execution
of up to twelve instructions per cycle.
— Includes dynamic domain partitioning and static
hard partitioning.
Advanced EPIC (Explicitly Parallel Instruction
Computing) Architecture for current and future
requirements of high-end enterprise and technical
workloads.
— Provide a variety of advanced implementations of
parallelism, predication, and speculation,
resulting in superior Instruction-Level Parallelism
(ILP).
Intel®Hyper-Threading Technology
— Dual Domain Multithreading with independent
front end and back end thread domains providing
hardware support for 2 threads per core.
— Support for Intel®Itanium®Processor New-
Instructions.
Wide, parallel hardware based on Intel®Itanium®
architecture for high performance:
— Integrated on-die LLC cache of up to 32MB;
cache hints for FLC, MLC, and LLC caches for
reduced memory latency.
— 160 general and 128 floating-point registers
supporting register rotation.
— Register stack engine for effective management
of processor resources.
— Support for predication and speculation.
Extensive RAS features for business-critical
applications, for example:
— Machine check architecture with extensive ECC
and parity protection with firmware first error
handling.
— End-to-end error detection.
— On-chip thermal management and power
management.
— Built-in processor information ROM (PIROM).
— Built-in programmable EEPROM.
—HotPlugSocket.
— Hot-add and hot removal support.
— Double Device Data Correction (DDDC) for x4
DRAMs, plus correction support of a single bit
error.
— Single Device Data Correction (SDDC) for x8 and
x4 DRAMs, plus correction of a single bit error.
—Intel
®QuickPath Interconnect Dynamic Link
Width Reduction.
—Intel
®QuickPath Interconnect Clock Fail-Safe
Feature.
—Intel
®QuickPath Interconnect Hot-Add and
Removal.
— Memory DIMM and Rank Sparing, Memory
Scrubbing, Memory Mirroring, and Memory
Migration.
—Intel
®Turbo Boost Technology, featuring
sustained boost.
— Architected firmware stack, including PAL and
SAL support.
— Directory-based and source-based coherency
protocol.
— Intel QPI poisoning, viral containment and
cleanup.
Two On-die Memory Controllers
— Each memory controller supports two Intel®
Scalable Memory Interconnects that operate in
lockstep.
— Support for one Scalable Memory Buffer per Intel
Scalable Memory Interconnect; four Scalable
Memory Buffers per processor.
— High memory bandwidth, thus improved
performance.
— 4.8 GT/s for the Intel®7500 Scalable Memory
Buffer.
— 6.4 GT/s for the Intel®7510 Scalable Memory
Buffer.
Intel®Instruction Replay Technology to replay core
pipeline for pipeline management and core RAS.
Intel®Virtualization Technology (Intel® VT) for
Intel®64 or Itanium ®architecture (Intel ® Vt-i) 3 -
Virtualization Support Extensions for Intel®
Virtualization Technology.
— Reduce virtualization complexity.
— Improve virtualization performance via hardware
optimization.
— Increase operating system compatibility.
Intel®Cache Safe Technology ensure mainframe-
caliber availability.
— Minimize LLC cache errors.
— Disable cache entries that have become hard
errors.
— Directory Cache covers 33% more cache lines.
— Improve availability.
High bandwidth Intel®QuickPath Interconnect for
multiprocessor scalability:
— 4 full and 2 half width Intel QPI Links
— 6.4GT/s transfer rate with aggregate data
bandwidth of 28.8 GB/s.
— Systems are easily scaled without sacrificing
performance.
Features to support flexible platform environments:
— Fully compatible with binaries for the Intel
Itanium processor family with Instruction level
advancements.
— LGA1248 Socket Level compatible with the Intel®
Itanium®Processor 9300 Series.
— Bi-endian support.
— Processor abstraction layer eliminates processor
dependencies.

Introduction
14 Intel®Itanium®Processor 9300 Series and 9500 Series Datasheet
The Intel®Itanium®Processor 9500 Series delivers increased levels of flexibility,
reliability, performance, and cost-effective scalability for your most data-intensive
business and technical applications.
The Intel®Itanium®Processor 9500 Series processor provides up to 32 megabytes LLC
cache, Hyper-Threading Technology for increased performance, Intel®Virtualization
Technology for improved virtualization, Intel®Cache Safe Technology for increased
availability. Intel®Turbo Boost Technology, featuring sustained boost. The Intel®
Itanium®Processor 9500 Series employs advanced power monitoring and control to
deliver a higher processor frequency at all times, for maximum performance on all
workloads. The result is a higher thermal envelope utilization for more overall
performance. The Intel®Itanium®Processor 9500 Series offers large cache arrays
covered by ECC including the large LLC utilizing double correct/triple detect (DECTED)
and protecting the MLI/MLD with in-line single correct/double detect (SECDED). In
addition, the processor provides extensive parity protection and parity interleaving on
nearly all RFs, end-to-end parity protection with recovery-support on all critical internal
buses and data paths including the ring. Residue protection on Floating Point unit,
along with the adoption of radiation-hardened (RAD) sequential latching elements for
vulnerable architectural and state. The Intel®Itanium®Processor 9500 Series
processor interfaces exclusively with the Ararat II Voltage Regulator Module.
The Intel®Itanium®Processor 9500 Series consists of up to 8 core processors and a
system interface unit. Each processor core provides a 12-wide, 11-stage deep
execution pipeline. The resources consist of six integer units, one integer multiply unit,
four multimedia units, two load/store units, three branch units and two floating-point
units each capable of extended, double and single precision arithmetic. The hardware
employs dynamic prefetch, branch prediction, a register scoreboard, and non-blocking
caches to optimize for compile-time non-determinism. 32 additional stacked general
registers are provided over the Intel®Itanium®Processor 9300 Series, and hardware
support is provided for denormal, unnormal, and pseudo-normal operands for floating
point software assist offloading.
New instructions on the Intel®Itanium®Processor 9500 Series simplify common tasks.
They include: clz (count leading zeros), mpy4 and mpyshl4(unsigned integer multiply/
shift and multiply), mov-to-DAHR/mv-from-DAHR (for improved MLD/FLD prefetcher
hinting and performance), and hint@priority (used by the processor to temporarily
allocate more resources to a thread). Advanced Explicitly Parallel Instruction
Computing (EPIC) is enhanced on the Intel®Itanium®Processor 9500 Series by
increasing the capacity of retiring instructions per cycle from 6 to a maximum of 12
instructions per cycle per core.
Intel®Hyper-threading Technology is enhanced in the Intel®Itanium®Processor 9500
Series with dual domain multithreading, which enables independent front-end and
back-end pipeline execution to improve multi-thread efficiency and performance for
both new and legacy applications. It provides hardware support for two threads per
core, with a threaded 96 entry per thread Instruction Buffer and threaded MLDTLB and
FLDTLB, and a dedicated load return path from the MLD to the integer register file.
Three levels of on-die cache minimize overall memory latency, with 16 KB instruction
cache FLI/16 KB write-through data cache FLD that comprise the FLC and 512 KB MLI/
256 KB writeback data cache MLD that comprise the MLC.
The Intel®Itanium®Processor 9500 Series offers a new RAS feature: Intel®
Instruction Replay Technology. Pipeline replay resolves stall conditions that occur when
the microprocessor pipeline encounters a resource hazard that prevents immediate
execution. In a replay, the instruction that encountered the resource hazard is removed
from the pipeline, along with all the instructions that come after it. The instruction is
then read again out of the instruction buffer for replay and re-executed. To ensure a

Intel®Itanium®Processor 9300 Series and 9500 Series Datasheet 15
Introduction
replay can be initiated for any instruction in the pipeline that encounters a resource
hazard, a copy of each instruction is maintained in the instruction buffer until the
instruction has successfully traversed the pipeline and is no longer needed. If
necessary, an instruction can replay multiple times. As a result, Intel®Instruction
Replay Technology automatically detects and many corrects soft errors in the
instruction pipeline. With this technology, soft errors can be identified and corrected in
as few as seven clock cycles, which is fast enough to be invisible to the software
running on the platform.
1.2 Architectural Overview
The sections below give an overview of the Intel®Itanium®Processor 9300 Series and
Intel®Itanium®Processor 9500 Series.
1.2.1 Intel®Itanium®Processor 9300 Series Overview
The Intel®Itanium®Processor 9300 Series processor is a quad-core architecture. It
supports up to four processor cores, each with its own L3, L2, and L1 level cache. Also
supported are the following page sizes for purges or inserts: 4K, 8K, 16K, 64K, 256K,
1M, 4M, 16M, 64M, 256M, 1G, 4G.
The architecture interfacing the cores to the system is referred to as the System
Interface. Each processor core has it own Caching Agent (CPE). The CPE interfaces
between the processor core and the Intel QuickPath Interconnect. The Intel®Itanium®
Processor 9300 Series processor has two Home Agents (Bbox). The Bbox interfaces
between the memory controller and the Intel®QuickPath Interconnect and supports a
directory cache. Each Bbox interfaces with a memory controllers (Zbox). Each memory
controller supports two Intel SMI in lockstep. The Intel SMI are the interconnects to
Intel®7500 Scalable Memory Buffer. The processor supports six Intel QuickPath
Interconnects at the socket, four full width and two half width. The Caching Agent,
Home Agent, and Intel QuickPath Interconnects are connected via a 12-port Crossbar
Router, each port supporting the Intel QuickPath Interconnect protocol. Figure 1-1
shows the Intel®Itanium®Processor 9300 Series block diagram.
The Intel QPI viral and poison fields are used to flag corrupted system state and bad
data accordingly. Once it has “gone viral”, an Intel QPI agent will set the viral field
within all packet headers. Viral mode is entered in three ways: receiving a viral packet,
upon a detecting fatal/panic error, or when a global viral signal (from Cboxes) is
asserted. Viral is cleared on Reset. Poisoning is used to indicate bad data on a per-flit
basis. Poison does not indicate corrupted system coherency, but rather that a particular
block of data is not reliable.

Introduction
16 Intel®Itanium®Processor 9300 Series and 9500 Series Datasheet
1.2.2 Intel®Itanium®Processor 9500 Series Overview
The Intel®Itanium®Processor 9500 Series is an eight core architecture. It supports up
to eight cores, each with its own First Level Cache (FLC) and Mid Level Cache (MLC),
both of which are split into instruction and data caches (FLI/FLD and MLI/MLD,
respectively). The Last Level Cache (LLC) is shared among the cores and supports up to
32 MB. Also supported are the following page sizes for purges or inserts: 4K, 8K, 16K,
64K, 256K, 1M, 4M, 16M, 64M, 256M, 1G, 4G.
The architecture interfacing the cores to the system is referred to as the uncore. Each
Intel®Itanium®Processor 9500 Series core interfaces to the Ring. The Ring provides
connectivity to the Last Level Cache via the Cache Controllers (Cboxes). The Ring also
provides connectivity to Intel QPI via Ring/Sbox. The Sbox and Cbox provide the
supports for the two Intel QPI Caching Agents. The processor has two Home Agents
(Bbox). The Bbox interfaces between the memory controller and the Intel®QuickPath
Interconnect and supports a directory cache. Each memory controller supports two
Intel®Scalable Memory Interconnects (Intel®SMI) in lockstep. The Intel SMI are the
interconnects to Scalable Memory Buffer. The Intel®Itanium®Processor 9500 Series
processor supports six Intel®QuickPath Interconnects at the socket, four full width and
two half width. The Caching Agent, Home Agent, and Intel®QuickPath Interconnects
are connected via a 10-port Crossbar Router, each port supporting the Intel®QuickPath
Interconnect protocol. Figure 1-2 shows the processor block diagram.
Figure 1-1. Intel®Itanium®Processor 9300 Series Processor Block Diagram
Core0 Core3Core2Core1
CPE0 CPE3CPE2CPE1
RboxBbox0Zbox0 Zbox1Bbox1
Pbox
PZ1
Pb o x
PR1
Pbo x
PR 0
Pbo x
PH4
Pbo x
PH5
Pbo x
PR 3
Pb o x
PR 2
Intel® SMI Intel® SMI
Intel®
QPI
Intel®
QPI
Intel®
QPI
Intel®
QPI
Intel®
QPI
Intel®
QPI
Pbox
PZ0
Intel® SMI Intel® SMI
0xA 0
87 3
16 9 5
2
40xB

Intel®Itanium®Processor 9300 Series and 9500 Series Datasheet 17
Introduction
The Intel QPI viral and poison fields are used to flag corrupted system state and bad
data accordingly. Once it has “gone viral”, an Intel QPI agent will set the viral field
within all packet headers. Viral mode is entered in three ways: receiving a viral packet,
upon a detecting fatal/panic error, or when a global viral signal (from Cboxes) is
asserted. Viral is cleared on Reset. Poisoning is used to indicate bad data on a per-flit
basis. Poison does not indicate corrupted system coherency, but rather that a particular
block of data is not reliable.
Intel®Itanium®Processor 9500 Series PAL's Demand Based Switching (DBS) support
includes implementations of Power/Performance states (P-states) and Halt states (C-
states). For the PAL Halt state interface and architected specifications of the PAL P-
state interface, see the Intel®Itanium®Architecture Software Developer's Manual,
Volume 2, Section 11.6. PAL controls the Intel®Itanium®Processor 9500 Series
processor power through a special built-in microcontroller that manipulates voltage and
frequency. PAL communicates requested P-states to this controller through internal
registers.
As shown in Figure 1-3, Itanium architecture-based firmware consists of several major
components: Processor Abstraction Layer (PAL), System Abstraction Layer (SAL),
Unified Extensible Firmware Interface (UEFI) and Advanced Configuration and Power
Interface (ACPI). PAL, SAL, UEFI and ACPI together provide processor and system
initialization for an operating system boot. PAL and SAL provide machine check abort
handling. PAL, SAL, UEFI and ACPI provide various run-time services for system
functions which may vary across implementations. The interactions of the various
services that PAL, SAL, UEFI and ACPI provide are illustrated in Figure 1-3. In the
context of this model and throughout the rest of this chapter, the System Abstraction
Layer (SAL) is a firmware layer which isolates operating system and other higher level
software from implementation differences in the platform, while PAL is the firmware
layer that abstracts the processor implementation.
Figure 1-2. Intel®Itanium®Processor 9500 Series Processor Block Diagram

Introduction
18 Intel®Itanium®Processor 9300 Series and 9500 Series Datasheet
Protection Keys provide a method to restrict permission by tagging each virtual page
with a unique protection domain identifier. The Protection Key Registers (PKR)
represent a register cache of all protection keys required by a process. The operating
system is responsible for management and replacement polices of the protection key
cache. Before a memory access (including IA-32) is permitted, the processor compares
a translation’s key value against all keys contained in the PKRs. If a matching key is not
found, the processor raises a Key Miss fault. If a matching Key is found, access to the
page is qualified by additional read, write and execute protection checks specified by
the matching protection key register. If these checks fail, a Key Permission fault is
raised. Upon receipt of a Key Miss or Key Permission fault, software can implement the
desired security policy for the protection domain. Some processor models may
implement additional protection key registers and protection key bits. Unimplemented
bits and registers are reserved. Please see the processor-specific documentation for
further information on the number of protection key registers and protection key bits
implemented on the processor.
Figure 1-3. Intel®Itanium®Processor 9500 Series Firmware Diagram

Intel®Itanium®Processor 9300 Series and 9500 Series Datasheet 19
Introduction
1.3 Processor Feature Comparison
The Intel®Itanium®Processor 9300 Series processor and Intel®Itanium®Processor
9500 Series processor features are compared below in Table 1-1.
Table 1-1. Intel®Itanium®Processor 9300 Series and
Intel®Itanium®Processor 9500 Series Feature Comparison
Description Intel®Itanium®Processor 9300
Series Intel®Itanium®Processor 9500 Series
Socket LG1248 LG1248
Transistors 2 billion 3.1 billion
Cores/Threads up to 4/8 up to 8/16
Clock speeds up to 1.86 GHz via Intel®Turbo Boost
with sustained boost 1.73 - 2.53 GHz
Integrated on-die cache L1 (L1I 16K/L1D 16K),
L2 (L2I 512K, L2D 256K),
inclusive L3 (6 MB per core,
up to 24 MB)
FLC (FLI 16K/FLD 16K),
MLC (MLI 512K, MLD 256K),
LLC (shared, up to 32 MB)
Ararat Voltage Regulator Module Support Ararat “I” Ararat II
Supported speeds DDR3-800 DDR3-800 and DDR3-1067
Intel QPI links 6
(4 full/2 half width at up to 4.8 GT/s) 6 (4 full/2 half width at up to 6.4 GT/s)
Intel QPI Hot-plug Supported Supported
Intel QPI Link self-healing Supported Supported
Intel QPI Clock fail-safe Supported Supported
Intel QPI Data scrambling Supported Required
Intel QPI Periodic retraining Not Supported Required1
Integrated memory controllers 2 2
Intel®SMI Interface Intel® 7500 Scalable Memory Buffer
(4.8 GT/s) Intel® 7500 Scalable Memory Buffer
(4.8 GT/s)
Intel® 7510 Scalable Memory Buffer
(6.4 GT/s)
Intel®SMI Hot-plug Supported Supported
Physical address space/virtual address
space 50 physical/64 virtual 50 physical/64 virtual
Caching agent architecture four caching agents per socket where
each agent is responsible for all of the
address space and dedicated to a core
two caching agents per socket are
responsible for half the address space
and shared among the cores
Home agents per socket 2 2
Directory Cache Supported Supported
Intel®Virtualization Technology (Intel® VT) Intel® Vt-i 2 Intel® Vt-i 3
Hot add/hot removal at Intel QPI link and
DIMM memory interface Supported Supported
Hot add CPU Supported2,3 Supported2,3
Hot add memory Supported2,3 Supported2,3
Hot remove/hot replace memory Supported2,3 Supported2,3
Memory sparing technique DIMM DIMM and Rank
Memory scrubbing Supported Supported
Memory mirroring Supported Supported

Introduction
20 Intel®Itanium®Processor 9300 Series and 9500 Series Datasheet
1.4 Processor Abstraction Layer
The Intel®Itanium®Processor 9300 Series and Intel®Itanium®Processor 9500 Series
require implementation-specific Processor Abstraction Layer (PAL) firmware. PAL
firmware supports processor initialization, error recovery, and other functionality. It
provides a consistent interface to system firmware and operating systems across
processor hardware implementations. The Intel®Itanium®Architecture Software
Developer’s Manual, Volume 2: System Architecture, describes PAL. Platforms must
provide access to the firmware address space and PAL at reset to allow the processors
to initialize.
The System Abstraction Layer (SAL) firmware contains platform-specific firmware to
initialize the platform, boot to an operating system, and provide runtime functionality.
Further information about SAL is available in the Intel® Itanium® Processor Family
System Abstraction Layer Specification.
1.5 Mixing Processors of Different Frequencies and
Cache Sizes
All Intel®Itanium®Processor 9300 Series processors and Intel®Itanium®Processor
9500 Series in the same system partition are required to have the same last level
cache size and identical core frequency. Mixing processors of different core frequencies,
cache sizes, and mixing Intel®Itanium®Processor 9300 Series with Intel®Itanium®
Processor 9500 Series is not supported and has not been validated by Intel. Operating
system support for multiprocessing with mixed components should also be considered.
1.6 Terminology
In this document, “the processor” refers to the Intel®Itanium®Processor 9300 Series
and/or Intel®Itanium®Processor 9500 Series, unless otherwise indicated.
An ‘_N’ notation after a signal name refers to an active low signal. This means that a
signal is in the active state (based on the name of the signal) when driven to a low
level. For example, when RESET_N is low, a processor reset has been requested. When
NMI is high, a non-maskable interrupt has occurred. In the case of lines where the
name does not imply an active state but describes part of a binary sequence (such as
Memory patrolling Supported Supported
Memory migration Supported Supported
Support for mixing of x4 and x8 on the
same DDR channel Not Supported Supported
Online/Offline CPU (OS assisted) Supported Supported
Online/Offline Memory (OS assisted) Supported Supported
Online/Offline I/O Hub Supported Supported
Thermal Design Power (TDP) SKUs 130W, 155W, 185W 130W and 170W
Notes:
1. OEM responsible for specifying platform-specific retraining interval.
2. Electrical isolation only, no physical add/remove supported.
3. Assume spare is installed.
Description Intel®Itanium®Processor 9300
Series Intel®Itanium®Processor 9500 Series
