Intel®Trusted Platform Module
(TPM module-AXXTPME3)
Hardware User’s Guide
Intel Order Number: G21682-003

ii Intel® Trusted Platform Module Hardware User’s Guide
DISCLAIMER
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL PRODUCTS.
NO LICENSE, EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY
INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS DOCUMENT. EXCEPT AS
PROVIDED IN INTEL'S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL
ASSUMES NO LIABILITY WHATSOEVER AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED
WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY
OR WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE,
MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER
INTELLECTUAL PROPERTY RIGHT.
UNLESS OTHERWISE AGREED IN WRITING BY INTEL, THE INTEL PRODUCTS ARE NOT
DESIGNED NOR INTENDED FOR ANY APPLICATION IN WHICH THE FAILURE OF THE INTEL
PRODUCT COULD CREATE A SITUATION WHERE PERSONAL INJURY OR DEATH MAY
OCCUR.
Intel may make changes to specifications and product descriptions at any time, without notice.
Designers must not rely on the absence or characteristics of any features or instructions marked
“reserved” or “undefined.” Intel reserves these for future definition and shall have no responsibility
whatsoever for conflicts or incompatibilities arising from future changes to them. The information
here is subject to change without notice. Do not finalize a design with this information.
The products described in this document may contain design defects or errors known as errata
which may cause the product to deviate from published specifications. Current characterized errata
are available on request.
Contact your local Intel sales office or your distributor to obtain the latest specifications and before
placing your product order.
Copies of documents which have an order number and are referenced in this document, or other
Intel literature, may be obtained by calling 1-800-548-4725, or go to:
http://www.intel.com/design/literature.htm
Intel®is a trademark or registered trademark of Intel Corporation or its subsidiaries in the United
States and other countries.
*Other names and brands may be claimed as the property of others.
Copyright © 2011 Intel Corporation. All rights reserved.

Intel® Trusted Platform Module Hardware User’s Guide iii
Preface
This is the primary hardware guide for the Intel®Trusted Platform Module (TPM
module). It contains installation instructions and specifications.
Audience
The people who benefit from this document are:
•Engineers who are designing an Intel®TPM module.
•Anyone installing an Intel®TPM module in their Intel®server system.
Organization
This document includes the following chapters and appendices:
•Chapter 1 provides a general overview of the Intel®TPM module.
•Chapter 2 describes the procedures for installing the Intel®TPM module.
•Chapter 3 provides the procedures for configuring the Intel®TPM module.
•Chapter 4 provides the characteristics and technical specifications for the Intel®
TPM module.
•Appendix A provides safety instructions to be observed during installation and
assembly.
•Appendix B provides regulatory and certification information.
Related Publication
This is the primary hardware guide for the Intel®TPM module. It contains installation
instructions and specifications.

iv Intel® Trusted Platform Module Hardware User’s Guide

Intel® Trrusted Platform Module Hardware User’s Guide v
Table of Contents
Preface ........................................................................................................................iii
Audience ............................................................................................................................... iii
Organization ......................................................................................................................... iii
Related Publication ............................................................................................................... iii
Overview ...................................................................................................................... 1
Intel®Trusted Platform Module Hardware Installation .......................................... 3
Requirements ........................................................................................................................3
Installing the TPM module .....................................................................................................4
Configuring the TPM module .................................................................................... 5
TPM Security BIOS ................................................................................................................5
Physical Presence .................................................................................................................5
TPM Security Setup Options .................................................................................................6
Security Screen .....................................................................................................................6
Intel® Trusted Execution Technology (Intel® TXT) ...............................................................7
Overview ........................................................................................................................7
Intel® TXT hardware overview ......................................................................................8
Enabling Intel® TXT on Intel® Server Board .................................................................8
Intel®Trusted Platform Module Characteristics .................................................... 11
TPM module Connector List & Pinouts ................................................................................11
A. Installation/Assembly Safety Instructions ......................................................... 13
English .................................................................................................................................15
Deutsch ................................................................................................................................16
Français ...............................................................................................................................17
Español ................................................................................................................................19
Italiano .................................................................................................................................20
B. Regulatory and Certification Information .......................................................... 23
Product Safety and EMC Compliance .................................................................................23

vi Intel® Trrusted Platform Module Hardware User’s Guide

Intel® Trusted Platform Module Hardware User’s Guide vii
List of Figures
Figure 1. TPM module............................................................................................................... 1
Figure 2. TPM module Dimensioned Drawing........................................................................... 3
Figure 3. Setup Utility – TPM Configuration Screen.................................................................. 6

viii Intel® Trusted Platform Module Hardware User’s Guide

Intel® Trusted Platform Module Hardware User’s Guide ix
List of Tables
Table 1. TPM Setup Utility – Security Configuration Screen Fields ..........................................7
Table 2. TPM module Connector Pin-out ................................................................................11

xIntel® Trusted Platform Module Hardware User’s Guide

Intel® Trusted Platform Module Hardware User’s Guide 1
1Overview
The Intel®Trusted Platform Module (TPM) is a hardware-based security device that
addresses the growing concern on boot process integrity and offers better data protection.
TPM protects the system start-up process by ensuring it is tamper-free before releasing
system control to the operating system. A TPM device provides secured storage to store
data, such as security keys and passwords. In addition, a TPM device has encryption and
hash functions. The Intel®TPM module implements TPM as per TPM PC Client
specifications revision 1.2 by the Trusted Computing Group (TCG).
A TPM device is affixed to the motherboard of the server and is secured from external
software attacks and physical theft. A pre-boot environment, such as the BIOS and
operating system loader, uses the TPM to collect and store unique measurements from
multiple factors within the boot process to create a system fingerprint. This unique
fingerprint remains the same unless the pre-boot environment is tampered with.
Therefore, it is used to compare to future measurements to verify the integrity of the
boot process.
After the BIOS complete the measurement of its boot process, it hands off control to the
operating system loader and in turn to the operating system. If the operating system is
TPM-enabled, it compares the BIOS TPM measurements to those of previous boots to
make sure the system was not tampered with before continuing the operating system boot
process. Once the operating system is in operation, it optionally uses TPM to provide
additional system and data security (for example, Microsoft Vista* supports Bitlocker
drive encryption).
The Intel®TPM module is a common board across the series of Intel®servers and
baseboards (for a list of supported servers and baseboards, please refer:
http://www.intel.com/support/motherboards/server/sb/CS-032301.htm). The TPM module
is a small board that provides hardware level security for the server. The TPM module
docks into a connector on the baseboard and is retained by a tamper
resistant screw.
Figure 1. TPM module

2Intel® Trusted Platform Module Hardware User’s Guide

Intel® Trusted Platform Module Hardware User’s Guide 3
2Intel®Trusted Platform Module
Hardware Installation
Requirements
•Intel®Trusted Platform Module , with the provided standoffs
•A host system/board with the TPM connector on the board
The TPM module docks into a connector on the baseboard and is retained by a tamper
resistant screw. Below is a drawing of the physical dimension of the TPM module.
Note: Measurements are in millimeters.
Figure 2. TPM module Dimensioned Drawing

4Intel® Trusted Platform Module Hardware User’s Guide
Installing the TPM module
To install the TPM module, follow these steps:
1. Turn off the power to the system, all drives, enclosures, and system components.
Remove the power cord(s).
2. Remove the server cover. For instructions, see your server system documentation.
3. Insert the standoff into the hole in the server/workstation board and insert the TPM
module connector into the connector in the board. To locate the TPM module
connector and the hole on your server/workstation board, see your
server/workstation board documentation.
4. Press down gently but firmly to ensure that the module is properly seated in the
connectors, and then tighten the tamper resistant screw.

Intel® Trusted Platform Module Hardware User’s Guide 5
3Configuring the TPM module
TPM Security BIOS
The BIOS TPM support conforms to the TPM PC Client Specific – Implementation
Specification for Conventional BIOS, version 1.2, and to the TPM Interface specification,
version 1.2. The BIOS adheres to the Microsoft Vista BitLocker* requirement. The role of
the BIOS for TPM security includes the following:
•Measures and stores the boot process in the TPM microcontroller to allow a TPM
enabled operating system to verify system boot integrity.
•Produces EFI and legacy interfaces to a TPM-enabled operating system for using
TPM.
•Produces ACPI TPM device and methods to allow a TPM-enabled operating system
to send TPM administrative command requests to the BIOS.
•Verifies operator physical presence. Confirms and executes operating system TPM
administrative command
•Provides BIOS Setup options to change TPM security states and to clear TPM
ownership.
For additional details, refer to the TCG PC Client Specific Implementation Specification,
the TCG PC Client Specific Physical Presence Interface Specification, and the Microsoft
BitLocker* requirement documents.
Physical Presence
Administrative operations to the TPM require TPM ownership or physical presence
indication by the operator to confirm the execution of administrative operations. The
BIOS implements the operator presence indication by verifying the setup Administrator
password.
A TPM administrative sequence invoked from the operating system proceeds as follows:
1. User makes a TPM administrative request through the operating system’s security
software.
2. The operating system requests the BIOS to execute the TPM administrative
command through TPM ACPI methods and then resets the system.
3. The BIOS verifies the physical presence and confirms the command with the
operator.
4. The BIOS executes TPM administrative command(s), inhibits BIOS Setup entry
and boots directly to the operating system which requested the TPM command(s).

6Intel® Trusted Platform Module Hardware User’s Guide
TPM Security Setup Options
The BIOS TPM Setup allows the operator to view the current TPM state and to carry out
rudimentary TPM administrative operations. Performing TPM administrative options
through the BIOS setup requires TPM physical presence verification.
Using BIOS TPM Setup, the operator can turn ON or OFF TPM functionality and clear
the TPM ownership contents. After the requested TPM BIOS Setup operation is carried
out, the option reverts to No Operation.
The BIOS TPM Setup also displays the current state of the TPM, whether TPM is enabled
or disabled and activated or deactivated. Note that while using TPM, a TPM-enabled
operating system or application may change the TPM state independent of the BIOS
setup. When an operating system modifies the TPM state, the BIOS Setup displays the
updated TPM state.
The BIOS Setup TPM Clear option allows the operator to clear the TPM ownership key
and allows the operator to take control of the system with TPM. You use this option to
clear security settings for a newly initialized system or to clear a system for which the
TPM ownership security key was lost.
Security Screen
The Security screen provides fields to enable and set the user and administrative
passwords and to lock out the front panel buttons so they cannot be used. The Intel®
server boards support Intel®TPM module.
To access this screen from the Main screen, select the Security option.
Figure 3. Setup Utility – TPM Configuration Screen

Intel® Trusted Platform Module Hardware User’s Guide 7
Table 1. TPM Setup Utility – Security Configuration Screen Fields
Intel® Trusted Execution Technology (Intel® TXT)
Overview
Intel®Trusted Execution Technology (Intel®TXT) for safer computing, formerly code
named LaGrande Technology, is a versatile set of hardware extensions to Intel®
processors and chipsets that enhance the platform with security capabilities such as
measured launch and protected execution. Intel®TXT provides hardware-based
mechanisms that help protect against software-based attacks and protects the
confidentiality and integrity of data stored or created on the system. It does this by
enabling an environment where applications can run within their own space, protected
from all other software on the system. These capabilities provide the protection
Setup Item Options Help Text Comments
•Enabled and
Activated
•Enabled and
Deactivated
•Disabled and
Activated
•Disabled and
Deactivated
—Information only.
•Shows the current TPM device
state.
•A disabled TPM device will not
execute commands that use TPM
functions and TPM security
operations will not be available.
•An enabled and deactivated TPM
is in the same state as a disabled
TPM except setting of TPM
ownership is allowed if not
present already.
•An enabled and activated TPM
executes all commands that use
TPM functions and TPM security
operations will be available.
TPM
Administrative
Control
•No Operation
•Tur n On
•Tur n Of f
•Clear
Ownership
•[No Operation] - No
changes to current state.
•[Turn On] - Enables and
activates TPM.
•[Turn Off] - Disables and
deactivates TPM.
•[Clear Ownership] -
Removes the TPM
ownership authentication
and returns the TPM to a
factory default state.
Note: The BIOS setting
returns to [No
Operation] on every
boot cycle by default.

8Intel® Trusted Platform Module Hardware User’s Guide
mechanisms, rooted in hardware, that are necessary to provide trust in the application's
execution environment. In turn, this can help to protect vital data and processes from
being compromised by malicious software running on the platform. Long available on
client platforms, Intel is now enabling Intel TXT on selected server platforms as well.
Intel® TXT hardware overview
Implementation of a Trusted Execution Technology-enabled platform requires a number
of hardware enhancements. Key hardware elements of this platform are:
1. Processor: Extensions to the IA-32 architecture allow for the creation of multiple
execution environments, or partitions. This allows for the coexistence of a standard
(legacy) partition and protected partition, where software can run in isolation in the
protected partition, free from being observed or compromised by other software
running on the platform. Access to hardware resources (such as memory) is
hardened by enhancements in the processor and chipset hardware. Other processor
enhancements include: (1) event handling, to reduce the vulnerability of data
exposed through system events, (2) instructions to manage the protected execution
environment, (3) and instructions to establish a more secure software stack.
2. Chipset: Extensions to the chipset deliver support for key elements of this new,
more protected platform. They include: (1) the capability to enforce memory
protection policy, (2) enhancements to protect data access from memory, (3)
protected channels to graphics and input/output devices, (4) and interfaces to the
Trusted Platform Module [Version 1.2].
3. Keyboard and Mouse: Enhancements to the keyboard and mouse enable
communication between these input devices and applications running in a protected
partition to take place without being observed or compromised by unauthorized
software running on the platform.
4. Graphics: Enhancements to the graphic subsystem enable applications running
within a protected partition to send display information to the graphics frame buffer
without being observed or compromised by unauthorized software running on
the platform.
5. The TPM v. 1.2 device: Also called the Fixed Token, is bound to the platform and
connected to the PC’s LPC bus. The TPM provides the hardware-based mechanism
to store or ‘seal’ keys and other data to the platform. It also provides the hardware
mechanism to report platform attestations.
Note: For a list of servers and baseboards support Intel®TXT, please refer:
http://www.intel.com/support/motherboards/server/sb/CS-032301.htm.
Enabling Intel® TXT on Intel® Server Board
The following steps describe how to set up Intel®TXT feature:

Intel® Trusted Platform Module Hardware User’s Guide 9
Intel®TXT Setup:
1. Go to BIOS Setup Menu, Advanced > Processor Configuration, set Intel®VT
for directed I/O and Intel®TXT option as Enabled.
2. Press F10 to save and exit. Now Intel®TXT is successfully enabled.
Intel®TPM Setup:
1. Enable TPM module: Go to BIOS setup Menu page, Security Tab, set
administrator password.
2. After administrator password is setup, press F10 to save and exit BIOS setup.
3. System will automatically reboot, go to BIOS setup Menu page, Security tab, set
TPM Administrative Control as Turn ON, press F10 to save and exit
BIOS setup.
4. Go to BIOS setup Menu, Security Tab, TPM State should be
Enabled & Activated.

10 Intel® Trusted Platform Module Hardware User’s Guide
