Intel NUC 12 Pro User manual

1
Intel® NUC 12 Pro Mini PC NUC12WSK
User Guide –August 2022
Intel® NUC 12 Pro Mini PC NUC12WSKi3
Intel® NUC 12 Pro Mini PC NUC12WSKi5
Intel® NUC 12 Pro Mini PC NUC12WSKi7
User Guide
August 2022

2
Intel® NUC 12 Pro Mini PC NUC12WSK
User Guide –August 2022
You may not use or facilitate the use of this document in connection with any infringement or other legal analysis concerning Intel products
described herein. You agree to grant Intel a non-exclusive, royalty-free license to any patent claim thereafter drafted which includes subject
matter disclosed herein.
No license (express or implied, by estoppel or otherwise) to any intellectual property rights is granted by this document.
All information provided here is subject to change without notice. Contact your Intel representative to obtain the latest Intel product
specifications and roadmaps.
The products described may contain design defects or errors known as errata which may cause the product to deviate from published
specifications. Current characterized errata are available on request.
Copies of documents which have an order number and are referenced in this document may be obtained by calling 1-800-548-4725 or by
visiting: http://www.intel.com/design/literature.htm.
Intel technologies' features and benefits depend on system configuration and may require enabled hardware, software or service activation.
Performance varies depending on system configuration. No computer system can be absolutely secure.
Intel and the Intel logo are trademarks of Intel Corporation or its subsidiaries in the U.S. and/or other countries.
*Other names and brands may be claimed as the property of others.
Copyright © 2022, Intel Corporation. All rights reserved.

3
Intel® NUC 12 Pro Mini PC NUC12WSK
User Guide –August 2022
Contents
1.0 Introduction.......................................................................................................................................................5
1.1 Before You Begin ...........................................................................................................................................5
1.2 Installation Precautions.............................................................................................................................5
1.3 Observe Safety and Regulatory Requirements.........................................................................6
2.0 Open the Chassis...........................................................................................................................................7
3.0 Upgrade System Memory ........................................................................................................................8
3.1 Upgrade to Different Memory ...............................................................................................................8
3.2 Install Additional Memory........................................................................................................................9
4.0 Changing the M.2 SSD............................................................................................................................ 10
5.0 Close the Chassis........................................................................................................................................ 12
6.0 Use the VESA Bracket (Optional) .................................................................................................... 13
7.0 Connect Power.............................................................................................................................................. 15
8.0 Set Up Microsoft® Windows 11........................................................................................................ 16
9.0 Install the Latest Device Drivers and Software..................................................................... 17
10.0 Operating System Recovery ............................................................................................................... 18

4
Intel® NUC 12 Pro Mini PC NUC12WSK
User Guide –August 2022
Revision History
Date
Revision
Description
August 2022
1.0
Initial release.

5
Intel® NUC 12 Pro Mini PC NUC12WSK
User Guide –August 2022
1.0 Introduction
This User Guide provides step-by-step installation instructions for these products:
•Intel® NUC 12 Pro Mini PC NUC12WSKi3
•Intel® NUC 12 Pro Mini PC NUC12WSKi5
•Intel® NUC 12 Pro Mini PC NUC12WSKi7
1.1 Before You Begin
CAUTIONS
The steps in this guide assume you’re familiar with computer terminology and
with the safety practices and regulatory compliance required for using and
modifying computer equipment.
Disconnect the computer from its power source and from any network before
performing any of the steps described in this guide.
Failure to disconnect power, telecommunications links, or networks before you open
the computer or perform any procedures can result in personal injury or equipment
damage. Some circuitry on the board can continue to operate even though the front
panel power button is off.
Follow these guidelines before you begin:
•Always follow the steps in each procedure in the correct order.
•Create a log to record information about your computer, such as model,
serial numbers, installed options, and configuration information.
•Electrostatic discharge (ESD) can damage components. Perform the
procedures described in this chapter only at an ESD workstation using an
antistatic wrist strap and a conductive foam pad. If such a station isn’t
available, you can provide some ESD protection by wearing an antistatic wrist
strap and attaching it to a metal part of the computer chassis.
1.2 Installation Precautions
When you install and test the Intel NUC, observe all warnings and cautions in the
installation instructions.
To avoid injury, be careful of:

6
Intel® NUC 12 Pro Mini PC NUC12WSK
User Guide –August 2022
•Sharp pins on connectors
•Sharp pins on circuit boards
•Rough edges and sharp corners on the chassis
•Hot components (such as SSDs, processors, voltage regulators, and heat sinks)
•Damage to wires that could cause a short circuit
Observe all warnings and cautions that instruct you to refer computer servicing
to qualified technical personnel.
1.3 Observe Safety and Regulatory Requirements
If you don’t follow these instructions, you increase your safety risk and the possibility
of noncompliance with regional laws and regulations.

7
Intel® NUC 12 Pro Mini PC NUC12WSK
User Guide –August 2022
2.0 Open the Chassis
Unscrew the four corner screws on the bottom of the chassis and lift the cover.

8
Intel® NUC 12 Pro Mini PC NUC12WSK
User Guide –August 2022
3.0 Upgrade System Memory
The Intel® NUC 12 Pro Mini PC NUC12WSK has two 260-pin DDR4 SO-DIMM sockets.
Pre-installed memory
Intel® NUC 12 Pro Mini PC NUC12WSKi3
2x 4GB DDR4-3200 SODIMMs
Intel® NUC 12 Pro Mini PC NUC12WSKi5
2x 4GB DDR4-3200 SODIMMs
Intel® NUC 12 Pro Mini PC NUC12WSKi7
2x 8GB DDR4-3200 SODIMMs
To upgrade memory, be sure to select memory modules that meet these
requirements:
•1.2V low voltage memory
•2133/2400/3200 MHz SO-DIMMs
•Non-ECC
Find compatible memory modules in the Intel Product Compatibility Tool:
•Intel® NUC 12 Pro Mini PC NUC12WSKi3
•Intel® NUC 12 Pro Mini PC NUC12WSKi5
•Intel® NUC 12 Pro Mini PC NUC12WSKi7
NOTE
If you plan to install only one memory module, install it in the lower
memory socket.
3.1 Upgrade to Different Memory
1. Observe the precautions in "Before You Begin" in Section 1.1.
2. Turn off all peripheral devices connected to the computer.
3. Turn off the computer and disconnect the power cord.
4. Remove the computer’s bottom chassis cover.
5. Remove the pre-installed memory module
a. Gently spread the retaining clips at each end of the memory socket, which
causes the module to pop out of the socket (C).
b. Holding the module by the edges, lift it away from the socket, and
store it in an anti-static package.
6. Install the new memory module
a. Align the small space at the bottom edge of the memory module
with the key in the socket.
b. Insert the bottom edge of the module at a 45 degree angle into
the socket (A).
c. When the module is inserted, push down on the outer edges of

9
Intel® NUC 12 Pro Mini PC NUC12WSK
User Guide –August 2022
the module until the retaining clips snap into place (B). Make sure
the clips are firmly in place (C).
3.2 Install Additional Memory
1. Observe the precautions in "Before You Begin" in Section 1.1.
2. Turn off all peripheral devices connected to the computer.
3. Turn off the computer and disconnect the power cord.
4. Remove the computer’s bottom chassis cover.
5. Install the additional module:
a. Align the small space at the bottom edge of the memory module with the
key on the socket.
b. Insert the bottom edge of the module at a 45 degree angle into the
socket (A).
c. When the module is inserted, push down on the outer edges of
the module until the retaining clips snap into place (B). Make
sure the clips are firmly in place (C).
6. Reinstall and reconnect any parts you removed or disconnected to reach the
memory sockets.
7. Replace the computer’s cover and reconnect the power cord.

10
Intel® NUC 12 Pro Mini PC NUC12WSK
User Guide –August 2022
4.0 Changing the M.2 SSD
The Intel® NUC 12 Pro Mini PC NUC12WSK supports an 80mm and 42mm SSD.
Pre-installed M.2
Intel® NUC 12 Pro Mini PC NUC12WSKi3
500GB Gen 4 NVMe SSD
Intel® NUC 12 Pro Mini PC NUC12WSKi5
500GB Gen 4 NVMe SSD
Intel® NUC 12 Pro Mini PC NUC12WSKi7
500GB Gen 4 NVMe SSD
Find compatible M.2 SSDs in the Intel Product Compatibility Tool:
•Intel® NUC 12 Pro Mini PC NUC12WSKi3
•Intel® NUC 12 Pro Mini PC NUC12WSKi5
•Intel® NUC 12 Pro Mini PC NUC12WSKi7
To install a different M.2 SSD:
1. Remove the small silver screw from the 80mm or 42mm metal standoff on the
board (A).
2. Remove the pre-installed SSD/Intel Optane Memory from the connector.
3. Align the space at the bottom of the new M.2 SSD to the key on the connector.
4. Insert the bottom edge of the M.2 SSD into the connector (B).
5. Secure the card to the standoff with the small silver screw (C).
