Intel SE7525RP2 User manual

Intel® Server Board
SE7320EP2 / Intel® Server
Board SE7525RP2
Technical Product Specification
Intel order number D24635-001
Revision 1.0
April 29, 2005
Enterprise Platforms and Services Division - Marketing

Revision History Intel® Server Board SE7320EP2 / Intel® Server Board SE7525RP2
Revision 1.0
Intel order number D24635-001
ii
Revision History
Date Revision Number Modifications
2/01/2005 0.5 Initial release
4/29/2005 0.95
Added BIOS section information, updated HW information to include
latest product developments.
Disclaimers
Information in this document is provided in connection with Intel®products. No license, express
or implied, by estoppel or otherwise, to any intellectual property rights is granted by this
document. Except as provided in Intel's Terms and Conditions of Sale for such products, Intel
assumes no liability whatsoever, and Intel disclaims any express or implied warranty, relating to
sale and/or use of Intel products including liability or warranties relating to fitness for a particular
purpose, merchantability, or infringement of any patent, copyright or other intellectual property
right. Intel products are not intended for use in medical, life saving, or life sustaining
applications. Intel may make changes to specifications and product descriptions at any time,
without notice.
Designers must not rely on the absence or characteristics of any features or instructions marked
"reserved" or "undefined." Intel reserves these for future definition and shall have no
responsibility whatsoever for conflicts or incompatibilities arising from future changes to them.
The Intel® Server Board SE7320EP2 / Intel® Server Board SE7525RP2 may contain design
defects or errors known as errata which may cause the product to deviate from published
specifications. Current characterized errata are available on request.
Intel, Pentium, Itanium, and Xeon are trademarks or registered trademarks of Intel Corporation.
*Other brands and names may be claimed as the property of others.
Copyright © Intel Corporation 2005. All rights reserved.

Intel® Server Board SE7320EP2 / Intel® Server Board SE7525RP2 Table of Contents
Revision 1.0
Intel order number D24635-001 iii
Table of Contents
1. Introduction ........................................................................................................................11
1.1 Server Board Use Disclaimer ................................................................................ 11
2. Intel® Server Board SE7320EP2 / SE7525RP2 Overview ...............................................12
2.1 Intel® Server Boards SE7320EP2 and SE7525RP2 Feature Set .........................12
3. Functional Architecture.....................................................................................................14
3.1 Processor and Memory Subsystem....................................................................... 14
3.1.1 Processor Support ................................................................................................. 14
3.1.2 Memory Subsystem ............................................................................................... 17
3.2 Intel® E7320 / E7525 Chipset ............................................................................... 20
3.2.1 MCH Memory Architecture Overview..................................................................... 21
3.2.2 Memory Controller Hub (MCH) .............................................................................. 22
3.2.3 6300ESB ICH ........................................................................................................ 22
3.3 Super I/O ............................................................................................................... 25
3.3.1 GPIOs .................................................................................................................... 26
3.3.2 Serial Ports ............................................................................................................ 27
3.4 BIOS Flash ............................................................................................................ 27
3.5 SM Bus Block Diagram.......................................................................................... 28
4. Clock Generation and Distribution...................................................................................29
5. PCI I/O Subsystem .............................................................................................................31
5.1 PCI Subsystem ...................................................................................................... 31
5.1.1 P32-A: 32-bit/33-MHz PCI Subsystem................................................................... 31
5.1.2 P64-B 66-MHz PCI-X Subsystem.......................................................................... 32
5.1.3 PCI Express x8 ...................................................................................................... 33
5.1.4 PCI Express x16 (E7525 MCH support only)......................................................... 33
5.2 Video Controller ..................................................................................................... 34
5.2.1 Video Modes.......................................................................................................... 34
5.2.2 Video Memory Interface......................................................................................... 35
5.2.3 Host Bus Interface ................................................................................................. 35
5.3 Network Interface Controller (NIC) ........................................................................ 36
5.3.1 NIC Connector and Status LEDs ........................................................................... 36
5.4 Interrupt Routing .................................................................................................... 36
5.4.1 Legacy Interrupt Routing .......................................................................................36

Table of Contents Intel® Server Board SE7320EP2 / Intel® Server Board SE7525RP2
Revision 1.0
Intel order number D24635-001
iv
5.4.2 APIC Interrupt Routing........................................................................................... 37
5.4.3 Serialized IRQ Support .......................................................................................... 38
5.5 PCI Error Handling................................................................................................. 40
6. BIOS.....................................................................................................................................41
6.1 BIOS Architecture .................................................................................................. 41
6.1.1 BIOS Identification String....................................................................................... 41
6.2 System Initialization ............................................................................................... 42
6.2.1 Processors............................................................................................................. 42
6.2.2 Memory Subsystem ............................................................................................... 45
6.2.3 PCI......................................................................................................................... 51
6.2.4 PCI Express........................................................................................................... 52
6.2.5 Keyboard/Mouse.................................................................................................... 53
6.2.6 Universal Serial Bus (USB).................................................................................... 53
6.2.7 IDE......................................................................................................................... 53
6.2.8 Removable Media Drives....................................................................................... 53
6.2.9 Flash ROM............................................................................................................. 54
6.3 BIOS POST ........................................................................................................... 54
6.3.1 User Interface ........................................................................................................ 54
6.3.2 System Diagnostic Screen..................................................................................... 55
6.3.3 Quiet Boot / OEM Splash Screen .......................................................................... 55
6.3.4 BIOS Boot Popup Menu ........................................................................................ 56
6.4 BIOS Setup Utility .................................................................................................. 56
6.4.1 Localization............................................................................................................ 56
6.4.2 Console Redirection .............................................................................................. 57
6.4.3 Configuration Reset ............................................................................................... 57
6.4.4 Keyboard Commands ............................................................................................ 57
6.4.5 Entering BIOS Setup .............................................................................................58
6.5 Security.................................................................................................................. 75
6.5.1 Operating Model .................................................................................................... 75
6.5.2 Administrator/User Passwords and F2 Setup Usage Model.................................. 76
6.5.3 Password Clear Jumper ........................................................................................77
6.6 Flash Architecture and Flash Update Utility...........................................................78
6.6.1 Flash Update Utility................................................................................................78
6.6.2 Update OEM Logo ................................................................................................. 80

Intel® Server Board SE7320EP2 / Intel® Server Board SE7525RP2 Table of Contents
Revision 1.0
Intel order number D24635-001 v
7. Hardware and System Management.................................................................................82
7.1 Hardware Management ......................................................................................... 82
7.1.1 Fan Speed Control Diagram .................................................................................. 82
7.1.2 Chassis Intrusion ................................................................................................... 83
7.2 Intel® Server Management (ISM) Software Support ............................................. 83
7.3 Additional System Management Components....................................................... 83
7.3.1 Console Redirection .............................................................................................. 83
7.3.2 Wired For Management (WFM) ............................................................................. 84
7.3.3 Vital Product Data (VPD) ....................................................................................... 84
7.3.4 PXE BIOS Support ................................................................................................ 84
7.3.5 System Management BIOS (SMBIOS) .................................................................. 84
8. Sleep Support.....................................................................................................................85
8.1 Advanced Configuration and Power Interface (ACPI) ........................................... 85
8.2 Sleep and Wake Functionality ............................................................................... 86
8.2.1 Power Switch Off to On ......................................................................................... 86
8.2.2 On to Off (operating system absent)...................................................................... 86
8.2.3 On to Off (operating system present) .................................................................... 86
8.2.4 On to Sleep (ACPI) ................................................................................................ 87
8.2.5 Sleep to On (ACPI) ................................................................................................ 87
8.2.6 System Sleep States .............................................................................................87
9. Error Logging .....................................................................................................................88
9.1 Error Sources and Types....................................................................................... 88
9.2 SMI Handler........................................................................................................... 88
9.2.1 PCI Bus Error......................................................................................................... 88
9.2.2 Processor Bus Error ..............................................................................................89
9.2.3 Memory Bus Error.................................................................................................. 89
9.2.4 Logging Format Conventions................................................................................. 89
9.3 Single-bit ECC Error Throttling Prevention ............................................................ 89
9.4 Error Messages and Error Codes .......................................................................... 89
9.4.1 POST Progress Codes and Messages.................................................................. 89
9.4.2 BIOS Messages..................................................................................................... 95
9.4.3 POST Error Messages and Handling .................................................................. 100
9.4.4 Boot Block Error Beep Codes.............................................................................. 102
9.4.5 POST Error Beep Codes ..................................................................................... 103

Table of Contents Intel® Server Board SE7320EP2 / Intel® Server Board SE7525RP2
Revision 1.0
Intel order number D24635-001
vi
9.4.6 "POST Error Pause" option.................................................................................. 103
10. Server Board SE7320EP2 and SE7525RP2 Connectors...............................................104
10.1 Main Power Connector ........................................................................................ 104
10.2 Memory Module Connector ................................................................................. 105
10.3 Processor Socket................................................................................................. 107
10.4 I2C Header ........................................................................................................... 110
10.5 PCI Slot Connector .............................................................................................. 111
10.6 Front Panel Connector......................................................................................... 114
10.7 VGA Connector.................................................................................................... 115
10.8 NIC Connector ..................................................................................................... 115
10.9 IDE Connector ..................................................................................................... 116
10.10 SATA Connector.................................................................................................. 116
10.11 USB Connector.................................................................................................... 117
10.12 Floppy Connector ................................................................................................ 118
10.13 Serial Port Connector ..........................................................................................118
10.14 Keyboard and Mouse Connector ......................................................................... 119
10.15 Miscellaneous Headers ....................................................................................... 119
10.15.1 Fan Header.......................................................................................................... 119
10.15.2 Intrusion Cable Connector ................................................................................... 120
10.15.3 System Recovery and Update Jumpers .............................................................. 120
11. General Specifications.....................................................................................................122
11.1 Absolute Maximum Ratings ................................................................................. 122
11.2 Mean Time Between Failure (MTBF)................................................................... 122
11.3 Processor Power Support.................................................................................... 123
11.4 Power Supply Specifications ...............................................................................123
11.4.1 Power Timing....................................................................................................... 123
11.4.2 Voltage Recovery Timing Specifications .............................................................126
12. Product Regulatory Compliance.....................................................................................128
12.1 Product Safety Compliance ................................................................................. 128
12.1.1 Product EMC Compliance ................................................................................... 128
12.1.2 Mandatory/Standard: Certifications, Registration, Declarations .......................... 129
12.1.3 Product Regulatory Compliance Markings .......................................................... 129
12.2 Electromagnetic Compatibility Notices ................................................................129
12.2.1 Europe (CE Declaration of Conformity) ............................................................... 129
12.2.2 Australian Communications Authority (ACA) (C-Tick Declaration of Conformity) 129

Intel® Server Board SE7320EP2 / Intel® Server Board SE7525RP2 List of Figures
Revision 1.0
Intel order number D24635-001 vii
12.2.3 Ministry of Economic Development (New Zealand) Declaration of Conformity ... 130
12.2.4 BSMI (Taiwan) ..................................................................................................... 130
12.3 Replacing the Back up Battery ............................................................................ 130
Appendix A: Integration and Usage Tips..............................................................................131
Glossary...................................................................................................................................132
List of Figures
Figure 1. Block Diagram of Intel® Server Boards SE7320EP2 and SE7525RP2....................... 13
Figure 2. CEK ‘Passive’ Component Stackup............................................................................. 16
Figure 3. Memory Sub-system Block Diagram............................................................................ 17
Figure 4. Memory Bank Label Definition..................................................................................... 19
Figure 5. Intel® Server Boards SE7320EP2 and SE7525RP2 SMBUS Block Diagram............. 28
Figure 6. Intel® Server Boards SE7320EP2 and SE7525RP2 Clock Distribution Diagram .......30
Figure 7. Video Controller PCI Bus Interface.............................................................................. 35
Figure 8. Interrupt Routing Diagram ........................................................................................... 38
Figure 9. Interrupt Routing Diagram ........................................................................................... 39
Figure 10. BIOS Identification String...........................................................................................41
Figure 11. Fan Speed Control Block Diagram ............................................................................ 82
Figure 12. System Recovery and Update Jumpers (J17) ......................................................... 120
Figure 13. Output Voltage Timing ............................................................................................. 124
Figure 14. Turn On / Turn Off Timing........................................................................................ 126

List of Tables Intel® Server Board SE7320EP2 / Intel® Server Board SE7525RP2
Revision 1.0
Intel order number D24635-001
viii
List of Tables
Table 1. Processor Support Matrix ............................................................................................. 14
Table 2. Memory Bank Labels ....................................................................................................18
Table 3. I2C Addresses for Memory Module SMB ...................................................................... 19
Table 4. Supported DDR2 Technology ....................................................................................... 21
Table 5. 6300ESB ICH GPIO Usage Table ................................................................................ 24
Table 6. Super I/O GPIO Usage Table ....................................................................................... 26
Table 7. PCI Bus Segment Characteristics................................................................................. 31
Table 8. P32-A Configuration IDs ...............................................................................................31
Table 9. P32-A Arbitration Connections......................................................................................32
Table 10. P64-B Configuration IDs ............................................................................................. 32
Table 11. P64-B Arbitration Connections....................................................................................33
Table 12. PCI Express x8 Connections ...................................................................................... 33
Table 13. PCI Express x16 (Port B) Connections....................................................................... 33
Table 14. Video Modes ............................................................................................................... 34
Table 15. PCI AND PCI-X Interrupt Routing/Sharing.................................................................. 37
Table 16. Interrupt Definitions..................................................................................................... 37
Table 17. Supported DIMM Module Capacities .......................................................................... 45
Table 18. Supported DDR2-400 DIMM Populations ................................................................... 47
Table 19. Memory Error Handling in RAS Mode......................................................................... 47
Table 20. Memory Error Handling in non-RAS Mode.................................................................. 48
Table 21. Sample BIOS Popup Menu......................................................................................... 56
Table 22. BIOS Setup Keyboard Command Bar Options ........................................................... 57
Table 23. BIOS Setup, Main Menu Options................................................................................ 58
Table 24. BIOS Setup, Advanced Menu Options........................................................................ 59
Table 25. BIOS Setup, Processor Configuration Sub-menu Options ......................................... 60
Table 26. BIOS Setup IDE Configuration Menu Options ............................................................ 61
Table 27. Mixed PATA-SATA Configuration with only Primary PATA ........................................ 63
Table 28. BIOS Setup, IDE Device Configuration Sub-menu Selections ................................... 63
Table 29. BIOS Setup, Floppy Configuration Sub-menu Selections........................................... 64
Table 30. BIOS Setup, Super I/O Configuration Sub-menu........................................................ 65
Table 31. BIOS Setup, USB Configuration Sub-menu Selections .............................................. 65
Table 32. BIOS Setup, USB Mass Storage Device Configuration Sub-menu Selections........... 66

Intel® Server Board SE7320EP2 / Intel® Server Board SE7525RP2 List of Tables
Revision 1.0
Intel order number D24635-001 ix
Table 33. BIOS Setup, PCI Configuration Sub-menu Selections ............................................... 67
Table 34. BIOS Setup, Memory Configuration Sub-menu Selections......................................... 68
Table 35. BIOS Setup, Boot Menu Selections ............................................................................ 69
Table 36. BIOS Setup, Boot Settings Configuration Sub-menu Selections ................................ 69
Table 37. BIOS Setup, Boot Device Priority Sub-menu Selections ............................................ 70
Table 38. BIOS Setup, Hard Disk Drive Sub-Menu Selections................................................... 70
Table 39. BIOS Setup, Removable Drives Sub-menu Selections............................................... 70
Table 40. BIOS Setup, CD/DVD Drives Sub-menu Selections................................................... 71
Table 41. BIOS Setup, Security Menu Options........................................................................... 71
Table 42. BIOS Setup, Server Menu Selections......................................................................... 72
Table 43. BIOS Setup, System Management Sub-menu Selections.......................................... 72
Table 44. BIOS Setup, Serial Console Features Sub-menu Selections ..................................... 73
Table 45. BIOS Setup, Event Log Configuration Sub-menu Selections ..................................... 74
Table 46. BIOS Setup, Exit Menu Selections .............................................................................74
Table 47. Security Features Operating Model ............................................................................ 75
Table 48. Monitored Components............................................................................................... 82
Table 49. Supported Wake Events ............................................................................................. 87
Table 50. POST Code Checkpoints............................................................................................ 90
Table 51. Boot Block Initialization Code Checkpoints................................................................. 92
Table 52. Boot Block Recovery Code Checkpoints .................................................................... 93
Table 53. DIM Code Checkpoints ............................................................................................... 94
Table 54. ACPI Runtime Checkpoints ........................................................................................95
Table 55. Memory BIOS Messages ............................................................................................ 95
Table 56. Boot BIOS Messages.................................................................................................. 95
Table 57. Storage Device BIOS Messages ................................................................................96
Table 58. Virus Related BIOS Messages ...................................................................................98
Table 59. System Configuration BIOS Messages....................................................................... 98
Table 60. CMOS BIOS Messages .............................................................................................. 99
Table 61. Miscellaneous BIOS Messages .................................................................................. 99
Table 62. USB BIOS Error Messages....................................................................................... 100
Table 63. SMBIOS BIOS Error Messages ................................................................................ 100
Table 64. POST Error Messages and Handling........................................................................ 101
Table 65. Boot Block Error Beep Codes ................................................................................... 102
Table 66. POST Error Beep Codes ..........................................................................................103
Table 67. Troubleshooting BIOS Beep Codes.......................................................................... 103

List of Tables Intel® Server Board SE7320EP2 / Intel® Server Board SE7525RP2
Revision 1.0
Intel order number D24635-001
x
Table 68. Power Connector Pin-out (J12)................................................................................. 104
Table 69. Auxiliary Signal Connector (J5)................................................................................. 104
Table 70. Auxiliary CPU Power Connector Pin-out (J22) ......................................................... 105
Table 71. DIMM Connectors (J16,J18,J20,J21) .......................................................................105
Table 72. Socket 604 Processor Socket Pin-out (J36, J37) ..................................................... 107
Table 73. HSBP Header Pin-out (J30,J54) ............................................................................... 110
Table 74. OEM RMC Header Pin-out (J33) .............................................................................. 110
Table 75. P32-A 5V 32-bit/33-MHz PCI Slot Pin-out (J10, J11) ............................................... 111
Table 76. P64-B 3.3V 64-bit/66-MHz PCI-X Slot Pin-out (J8, J9)............................................. 112
Table 77. PCI Express Slot Pin-out (J13 for x8, J14 for x16) ................................................... 113
Table 78. Front Panel 34-Pin Header Pin-out (J38).................................................................. 114
Table 79. VGA Connector Pin-out (J4) ..................................................................................... 115
Table 80. NIC1-82541PI(10/100/1000) Connector Pin-out (JA1,JA2) ...................................... 115
Table 81. ATA 40-pin Connector Pin-out (J43)......................................................................... 116
Table 82. SATA Connector Pin-out (J28, J32).......................................................................... 116
Table 83. USB Connectors Pin-out (J55).................................................................................. 117
Table 84. Optional USB Connection Header Pin-out (J31)....................................................... 117
Table 85. Legacy 34-pin Floppy Connector Pin-out (J47) ........................................................118
Table 86. 9-pin Header Serial B Port Pin-out (J15) ..................................................................118
Table 87. Keyboard and Mouse PS/2 Connectors Pin-out (J2) ................................................ 119
Table 88. 3-pin Fan Headers Pin-out (J1, J48)......................................................................... 119
Table 89. 4-pin Fan Headers Pin-out (J7, J44, J45, J46) ......................................................... 119
Table 90. 6-pin Fan Headers Pin-out (J50)...............................................................................120
Table 91. IntruSuper IOn Cable Connector (J19)Pin-Out ......................................................... 120
Table 92. System Recovery and Update Jumper Options........................................................ 121
Table 93. Absolute Maximum Ratings ...................................................................................... 122
Table 94. MTBF Calculation ..................................................................................................... 122
Table 95. Intel® Xeon™ Processor DP TDP Guidelines .......................................................... 123
Table 96. Power Supply Voltage Specification ......................................................................... 123
Table 97. Voltage Timing Parameters ......................................................................................124
Table 98. Turn On / Off Timing .................................................................................................125
Table 99. Transient Load Requirements...................................................................................127

Intel® Server Board SE7320EP2 / Intel® Server Board SE7525RP2 TPS
Introduction
Revision 1.0
Intel order number D24635-001 11
1. Introduction
The Intel® Server Board SE7320EP2 / SE7525RP2 Technical Product Specification provides
technical details for the server board’s functional architecture and feature set. It also provides a
high-level detail of some of the board’s functional sub-systems.
This document is intended to be the technical reference for this board. Updates to this
document will be made via the Specification Update that is published monthly following the date
of the product launch.
1.1 Server Board Use Disclaimer
Intel Corporation server boards contain a number of high-density VLSI and power delivery
components that need adequate airflow to cool. Intel ensures through its own chassis
development and testing that when Intel server building blocks are used together, the fully
integrated system will meet the intended thermal requirements of these components. It is the
responsibility of the system integrator who chooses not to use Intel developed server building
blocks to consult vendor datasheets and operating parameters to determine the amount of air
flow required for their specific application and environmental conditions. Intel Corporation
cannot be held responsible if components fail or the server board does not operate correctly
when used outside any of their published operating or non-operating limits.

Intel® Server Board SE7320EP2 / Intel® Server Board SE7525RP2 TPS
Intel® Server Board SE7320EP2 / SE7525RP2 Overview
Revision 1.0
Intel order number D24635-001
12
2. Intel® Server Board SE7320EP2 / SE7525RP2
Overview
The Intel® Server Boards SE7320EP2 and SE7525RP2 are monolithic printed circuit boards
with features that were designed to support the general purpose, pedestal server market. The
Intel Server Board SE7525RP2 also meets the needs of a high-end workstation system. The
architecture is based around the Intel® E7320/E7525 chipset and is capable of supporting one
or two Intel® Xeon™ processors with 1MB or 2MB L2 cache and up to 8GB of memory.
2.1 Intel® Server Boards SE7320EP2 and SE7525RP2 Feature Set
The Intel Server Boards SE7320EP2 and SE7525RP2 support the following feature set:
Processor/FSB support
-Dual Intel Xeon processors with 1MB or 2MB L2 cache using the 604-pin FCPGA
processor package
-800 MHz FSB
-6.4 GB/sec bus bandwidth
-One version 10.1 compliant VRD to supply each CPU core voltage
Intel E7320/E7525 chipset components
-MCH memory controller
-6300ESB ICH I/O controller
Support for up to four DDR2-400 compliant ECC DDR2 DIMMs providing up to 8GB
memory support.
Three separate and independent PCI buses:
-Segment A: Two PCI 32-bit/33-MHz, 5 V connectors supporting full-length PCI add-
in cards and two embedded devices:
2D/3D graphics controller: ATI* Rage* XL video controller with 8 MB of SDRAM
One Intel 10/100/1000 82541PI Fast Ethernet Controller
-Segment B: Two PCI-X* 64-bit/66-MHz, 3.3 V slots supporting full-length PCI / PCI-X
add-in cards
-Segment C:
One x4 PCI Express* slot supporting x1/x2/x4/x8 PCI Express add-in card (up to
x 4 connection)
One x16 PCI Express (Server Board SE7525RP2 only) supporting
x1/x2/x4/x8/x16 PCI Express add-in card.
One x1 PCI Express bus supporting the Marvell* Yukon* 88E8050 10/100/1000
gigabit Ethernet controller
LPC (Low Pin Count) bus segment with one embedded devices:
-Super I/O (Super I/O) controller chip, National Semiconductor* PC8374L, providing
all PC-compatible I/O (floppy, serial, keyboard, mouse) and integrated hardware
monitoring
Two external Universal Serial Bus (USB) ports with an additional internal header
providing two optional USB ports for front panel support

Intel® Server Board SE7320EP2 / Intel® Server Board SE7525RP2 TPS
Intel® Server Board SE7320EP2 / SE7525RP2 Overview
Revision 1.0
Intel order number D24635-001 13
One IDE connector, supporting up to two ATA-100 compatible devices
Two SATA connectors, supporting up to two SATA devices and RAID 0/1
Support for up to five system fans and two processor fans
SSI-compliant connectors for SSI interface support: front panel and power connectors
The following figure below shows the functional blocks of the server boards and the plug-in
modules that they support.
Figure 1. Block Diagram of Intel® Server Boards SE7320EP2 and SE7525RP2

Intel® Server Board SE7320EP2 / Intel® Server Board SE7525RP2 TPS
Functional Architecture
Revision 1.0
Intel order number D24635-001
14
3. Functional Architecture
This chapter provides a high-level description of the functionality distributed between the
architectural blocks of the Intel® Server Boards SE7320EP2 and SE7525RP2.
3.1 Processor and Memory Subsystem
The Intel® chipset E7320 / E7525 provides a 36-bit address, 64-bit data processor host bus
interface, operating at 800 MHz in the AGTL+ signaling environment. The MCH component of
the chipset provides an integrated memory controller, an 8-bit hub interface, one x8 PCI
Express interface (programmable into separate x 4 interface), and a x16 PCI Express interface
(E7525 MCH only).
The x4 PCI Express interface provides
The interface to x8 PCI Express slot (Lane 0-3)
The interface to Marvell (Lane 4)
The x16 PCI Express interface provides
The interface to x16 PCI Express slot
The 32-bit/33-MHz PCI buses via the 6300ESB ICH
The board directly supports up to 8GB of ECC memory, using four DDR2-400 compliant ECC
DIMMs. The ECC implementation in the MCH can detect and correct single-bit errors (SBE),
detect multiple-bit errors (MBE), and supports Intel® x4 Single Data Device Correction (Intel®
x4 SDDC) feature with x4 DIMMs.
3.1.1 Processor Support
The Intel Server Boards SE7320EP2 and SE7525RP2 support one or two processors in the
604-pin FCPGA package. When two processors are installed, both must be of identical revision,
core voltage, and bus/core speed. When only one processor is installed, it must be in the socket
labeled CPU0. The other socket must be empty. The support circuitry on the server boards
consist of the following:
Dual 604-pin processor sockets supporting 800MHz FSB Intel® Xeon™ processors.
Processor host bus AGTL+ support circuitry.
Table 1. Processor Support Matrix
Processor Family Package Type Frequency Cache Size Front Side Bus Speed
Intel® Xeon™ MPGA604 2.8~3.6GHz 1 MB 800MHz
Intel® Xeon™ MPGA604 3.0~3.6GHz 2 MB 800MHz

Intel® Server Board SE7320EP2 / Intel® Server Board SE7525RP2 TPS
Functional Architecture
Revision 1.0
Intel order number D24635-001 15
Notes:
Processors must be populated in sequential order. Processor socket 1 must be
populated before processor socket 2.
The board is designed to provide up to 105A of current per processor. Processors with
higher current requirements are not supported.
No terminator is required in the second processor socket when using a uni-processor
configuration.
In addition to the circuitry described above, the processor subsystem contains the following:
Reset configuration logic
Processor module presence detection logic
Server management registers and sensors
3.1.1.1 Processor VRD
The Intel Server Boards SE7320EP2 and SE7525RP2 have two Voltage Regulator Downs
(VRDs) to support two processors. This is compliant with the VRM 10.1 specification and
provides a maximum of 210 Amps, which is capable of supporting the requirements for two
Intel® Xeon™ processors.
The board hardware must monitor the processor VTTEN (Output enable for VTT) pin for each
processor before turning on the VRD. If the VTTEN pin of the two processors are not identical,
then the Power on Logic will not turn on the VRD.
3.1.1.2 Reset Configuration Logic
The BIOS determines the processor stepping, cache size, and other information through the
CPUID instruction. The requirements are as follows:
All processors in the system must operate at the same frequency, have the same cache
sizes, and same VID. No mixing of product families is supported.
Processors run at a fixed speed and cannot be programmed to operate at a lower or
higher speed.
The processor information is read at every system power-on.
Note: The processor speed is the processor power on reset default value. No manual processor
speed setting options exist either in the form of a BIOS setup option or jumpers.
3.1.1.3 Processor Module Presence Detection
Logic is provided on the server boards to detect the presence and identity of installed
processors. The Power On logic checks the logic and will not turn on the system DC power
unless the VTTENs of both the processors match in a DP configuration.

Intel® Server Board SE7320EP2 / Intel® Server Board SE7525RP2 TPS
Functional Architecture
Revision 1.0
Intel order number D24635-001
16
3.1.1.4 Interrupts and APIC
Interrupt generation and notification to the processors is done by the APICs in the 6300ESB ICH
using messages on the front side bus.
3.1.1.5 Common Enabling Kit (CEK) Design Support
The server boards have been designed to comply with the Intel® Common Enabling Kit (CEK)
processor mounting and thermal solution. The server boards ship from Intel’s factory with a CEK
spring snapped onto the underside of the board, beneath each processor socket. The CEK
spring is removable to allow the use of non-Intel heat sink retention solutions.
Note: When installing either of these server boards into an Intel® Server Chassis SC5300, the
passive heatsink solution (no fan) must be used.
Figure 2. CEK ‘Passive’ Component Stackup
Heatsink assembly
with integrated
hardware
TIM
Server Board
CEK Spring
Chassis

Intel® Server Board SE7320EP2 / Intel® Server Board SE7525RP2 TPS
Functional Architecture
Revision 1.0
Intel order number D24635-001 17
3.1.2 Memory Subsystem
The server boards supports up to four DIMM slots for a maximum memory capacity of 8 GB. The
DIMM organization is x72, which includes eight ECC check bits. The memory interface runs at
400MT/s. The memory controller supports memory scrubbing, single-bit error correction and
multiple-bit error detection and Intel x4 SDDC support with x4 DIMMs. Memory can be
implemented with either single-sided (one row) or double-sided (two row) DIMMs.
The figure below provides a block diagram of the memory sub-system implemented on the
board.
Figure 3. Memory Sub-system Block Diagram
3.1.2.1 Memory DIMM Support
The board supports DDR2-400 compliant ECC DIMMS operating at 400MT/s. Only DIMMs
tested and qualified by Intel or a designated memory test vendor are supported on this board.
All DIMMs are supported by design, but only fully qualified DIMMs will be supported on the
board.
The minimum supported DIMM size is 256MB. Therefore, the minimum main memory
configuration is 1 x 256MB or 256MB. The largest size DIMM supported is a 2GB registered
DDR2-400 ECC DIMM based on 1Gb technology. Therefore, the maximum main memory
configuration is 4 x 2GB or 8GB.
Only registered DDR2-400 compliant, ECC, DDR2 memory DIMMs are supported
ECC single-bit errors (SBE) are corrected and multiple-bit error (MBE) are detected.
The server boards support Intel® x4 SDDC with x4 DIMMs.
The maximum memory capacity is 8GB
The minimum memory capacity is 256MB

Intel® Server Board SE7320EP2 / Intel® Server Board SE7525RP2 TPS
Functional Architecture
Revision 1.0
Intel order number D24635-001
18
3.1.2.2 Memory Configuration
The memory interface between the MCH and the DIMMs is 144 bits wide (72 bits for each
bank).
There are two banks of DIMMs, Bank 1 and Bank 2. Bank 1 contains DIMM socket locations 1A
and 1B. Bank 2 contains 2A and 2B. The sockets associated with each bank are located next to
each other and the DIMM socket identifiers are marked on the server board silkscreen, near the
DIMM socket.
For designs that require a lower price point, a single 256MB DIMM can be populated in the
DIMM 1B socket. When a single DIMM is installed, interleaving and Intel x4 SDDC are not
available. Bank 2 will only operate with two DIMMs installed.
The server boards’ signal integrity and cooling are optimized when memory banks are
populated in order. Before populating either DIMM socket in Bank 2, both DIMMs in Bank 1
must be populated. No empty DIMM sockets are allowed between populated DIMMs.
DIMM and memory configurations must adhere to the following:
DDR2-400 ECC, registered DIMM modules
DIMM organization: x72 with ECC
Pin count: 240
DIMM capacity: 256 MB, 512 MB, 1 GB, 2 GB DIMMs
Serial PD: JEDEC Rev 2.0
Voltage options: 1.8 V (VDD/VDDQ)
Interface: SSTL-1.8
Table 2. Memory Bank Labels
Memory DIMM Bank
J18 (DIMM 1A), J16 (DIMM 1B) 1
J21 (DIMM 2A), J20 (DIMM 2B) 2

Intel® Server Board SE7320EP2 / Intel® Server Board SE7525RP2 TPS
Functional Architecture
Revision 1.0
Intel order number D24635-001 19
Figure 4. Memory Bank Label Definition
3.1.2.3 I2C Bus
The I2C bus is used by the system BIOS to retrieve DIMM information needed to program the
MCH memory registers, which are required to boot the system. The following table provides the
I2C addresses for each DIMM slot.
Table 3. I2C Addresses for Memory Module SMB
Device Address
DIMM 1A 0xA6
DIMM 1B 0xAE
DIMM 2A 0xA4
DIMM 2B 0xAC
Bank
1
Bank 2
J16 J18 J20 J21
1B 2B1A 2A

Intel® Server Board SE7320EP2 / Intel® Server Board SE7525RP2 TPS
Functional Architecture
Revision 1.0
Intel order number D24635-001
20
3.1.2.4 DRAM ECC
The ECC used for DRAM provides Intel® x4 SDDC technology for x4 SDRAMs. DRAMs that
are x8 use the same algorithm but will not have Intel x4 SDDC technology, since at most only
four bits can be corrected with this ECC.
The method provides more ECC bits so each ECC word can correct more than a single-bit
failure. This is possible because different mathematical algorithms provide multiple-bit
correction with the right number of data bits and ECC bits. For example, a 144-bit ECC word
that consists of 128 data bits and 16 ECC bits can be used to correct up to 4-bit errors within
certain bit fields of data. These four bits must be adjacent, not random. Even though the ratio of
the ECC bits to data bits is the same as the previous example (16/128 vs. 8/64), the longer ECC
word allows for a correction and detection algorithm that is more efficient.
3.2 Intel® E7320 / E7525 Chipset
The Intel Server Boards SE7320EP2 and SE7525RP2 are designed around the Intel E7320 /
E7525 chipset. The chipset provides an integrated I/O bridge and memory controller, and a
flexible I/O subsystem core (PCI Express). This is targeted for multiprocessor systems and
standard high-volume servers. The chipset consists of two components:
MCH: Memory Control Hub. The MCH accepts access requests from the host
(processor) bus and directs those accesses to memory or to one of the PCI buses. The
MCH monitors the host bus, examining addresses for each request. Accesses may be
directed to a memory request queue for subsequent forwarding to the memory
subsystem, or to an outbound request queue for subsequent forwarding to one of the
PCI buses. The MCH also accepts inbound requests from the 6300ESB ICH. The MCH
is responsible for generating the appropriate controls to control data transfer to and from
memory.
6300ESB ICH: The 6300ESB ICH controller has several components. It provides the
interface for a 32-bit/33-MHz PCI bus and the interface for a 64-bit/66MHz PCI-X bus.
The 6300ESB ICH can be both a master and a target on that PCI bus. The 6300ESB
ICH also includes a USB 2.0 controller and an IDE controller. The 6300ESB ICH is also
responsible for much of the power management functions, with ACPI control registers
built in. The 6300ESB ICH also provides a number of GPIO pins and has the LPC bus to
support low speed legacy I/O.
The MCH and 6300ESB ICH chips provide the pathway between processor and I/O systems.
The MCH is responsible for accepting access requests from the host (processor) bus, and
directing all I/O accesses to one of the PCI buses or legacy I/O locations. If the cycle is directed
to one of the PCI Express segments, the MCH communicates with the PCI Express Devices
(add-in card, on board devices) through the PCI Express interface. If the cycle is directed to the
6300ESB ICH, the cycle is output on the MCH’s 8-bit HI 1.5 bus.
The E7320 MCH supports one x8 port configuration PCI Express interface. The E7525MCH
supports one x8 port and one x16 port configuration PCI Express interface. The x8 interface is
capable of logically dividing into separate x4 interface. Each with half the bandwidth of x8
interface and fully compliant to the specification. Maximum theoretical peak bandwidth on each
x8 PCI Express interfaces of 2.5Gb/s in each direction simultaneously, for 5 Gb/s per port.
