Intel Express 410T User manual

740604-001
Intel®Express 410T
Standalone Switch
Quick Start and User Guide
English
Français
Italiano
Deutsch
Español
*740604-001*
410T-QS-GD cover-1.p65 4/7/99, 3:10 PM1

Copyright © 1999, Intel Corporation. All rights reserved.
Intel Corporation, 5200 NE Elam Young Parkway, Hillsboro OR 97124-6497
Intel Corporation assumes no responsibility for errors or omissions in this manual. Nor does Intel make any commitment to update the
information contained herein.
* Other product and corporate names may be trademarks of other companies and are used only for explanation and
to the owners’ benefit, without intent to infringe.
First Edition May 1999 740604-001
Year 2000 Capable
An Intel product, when used in accordance with its associated documentation, is “Year 2000 Capable” when,
upon installation, it accurately stores, displays, processes, provides, and/or receives date data from, into, and
between the twentieth and twenty-first centuries, including leap year calculations, provided that all other
technology used in combination with said product properly exchanges date data with it.

1
Contents
Quick Starts 2
English...........................................................................................2
Chinese ..........................................................................................4
Korean ...........................................................................................6
French............................................................................................8
Italian.............................................................................................10
German ..........................................................................................12
Spanish ..........................................................................................14
User Guide 17
Understanding 410T Switches.......................................................18
Port LEDs...............................................................................18
Status LED .............................................................................18
Crossover Button....................................................................18
Local Management ........................................................................19
Overview ................................................................................19
Navigation ..............................................................................19
Functions ................................................................................20
Connecting to Devices ..................................................................21
Connection Guidelines ...........................................................21
Workgroup Example......................................................................22
Cabling Devices ............................................................................23
Media Requirements ..............................................................23
Straight-through vs. Crossover Cables...................................23
Testing a cable........................................................................24
FAQs/Troubleshooting ..................................................................25
Regulatory Information and Warnings ..........................................26
Limited Hardware Warranty ..........................................................29
Intel Customer Support Inside back cover

2
5678
2
Quick Start
Install the Switch
Check the
Connections
• Check the port LEDs to confirm the link
status.
• A solid green LED (on the left) indicates
a valid link.
Left (Green/Orange)
Solid Green = Link
Blinking Green = Activity
Blinking Orange = Collision
Right (Orange)
Off = 100Mbps
Solid = 10Mbps
MDI/
MDI-X
19
210
311
412
513
614
715
816
Left
Right
Link=Solid Green
Activity=BlinkingGreen
Collision=BlinkingOrange
10Mbps=Solid Orange
100Mbps=Off
Intel
®
Express 410T Standalone Switch
Status
Rack: Use the three small
screws to attach the
brackets to the switch.
Shelf: Peel off the protective
backing and attach the rubber
feet to the switch.
3
1
English
• Remove the switch and parts from the box.
• Attach the enclosed brackets if you plan
to mount the switch in a rack.
• Install the Intel®Express 410T Standalone
Switch in a rack or on a shelf.
• Plug in the power cord.
Connect
the Devices
• All ports automatically detect the speed
and duplex-mode of any connected
device.
• Connect PCs and print servers to the
switch with straight-through cables.
• Use a crossover cable to connect a switch
to another switch or hub.
• Use a straight-through cable to connect to
another switch or hub when port 1 is set
to MDI.
• Use only CAT 5 UTP cable to connect
100Mbps devices. To connect 10Mbps
devices, use CAT 3, 4, or 5 UTP cable.
10/100
10/100
Switch Hub or Switch
Switch Print Server
Switch PC/Server
straight-through
From To
Switch Hub or Switch
straight-through
when port 1 set to MDI
crossover

3
Optional Information
How to Change Port 1
from MDI-X to MDI
• All ports on the switch are MDI-X.
Press the MDI/MDI-X button to change
Port 1 to MDI so you can connect to
another switch or hub using a straight-
through cable.
1234
MDI
MDI-X
Intel®Express 410T Standal
o
4
MDI/MDI-X
button
English
MDI
MDI-X
Access the
Configuration Screen
5
• Connect your PC to the Management
module’s serial port using the null-modem
cable (included).
• Set a VT100-compatible terminalemula-
tion program (such as HyperTerminal*) to
these parameters:
- 9600 baud - 8 data bits
- No parity - 1 stop bit
- No flow control
Press Eto connect to the Configura-
tion screen.
• Navigate the menus with these keys:
TMove to next item.
BMove to previous item.
zToggle options within a field.
c +SSave changes to configuration.
c +RRepaint the screen.
• <Auto> is the default setting for the ports.
You only need to configure the port
settings if you are having difficulty
connecting to a device.
Configuration Screen: Items surrounded by angle
brackets < > indicate a toggle field. Use the z to
toggle selections.
Speed Auto = all port settings are
automatically negotiated.
100 = port set to 100Mbps.
10 = port set to 10Mbps.
Duplex Half = port set to half duplex.
Full = port set to full duplex.
– = port set to auto mode.
Flow enable = Flow control is enabled in full
Control duplex mode. Back pressure is
enabled in half duplex mode.
disable = flow control is off.
– = port set to auto mode.

4
5678
kable
Hub
10/100
10/100
MDI/
MDI-X
19
210
311
412
513
614
715
816
Left
Right
Link=Solid Green
Activity= BlinkingGreen
Collision=BlinkingOrange
10Mbps=Solid Orange
100Mbps=Off
Intel
®
Express 410T Standalone Switch
Status
2
•LED
• LED
=
=
=
= 100 Mbps
= 10 Mbps
( Rack ) ( switch )
( Shelf ) ( switch )
3
1
•
•
•Intel®Express 410T
Standalone Switch
•
•
•PC
•
•1 MDI
•CAT 5 UTP 100 Mbps
10 Mbps
CAT 3 4 5 UTP
( Switch ) ( Hub or Switch )
( Switch )
PC/
( Switch )
( Switch ) ( Hub or Switch )
1 MDI
Sch_410TQS_Emb.p65 99-4-6, 16:124

5
1234
MDI
MDI-X
Intel
®
Express 410T Standal
o
1 MDI-X
MDI
•MDI-X
MDI/MDI-X 1
MDI
4
MDI/MDI-X
Switch )
MDI
MDI-X
5
•PC
•VT100
*
- 9600 - 8
- - 1
-
E
•
T
B
z
c +S
c +R
•< >
< >
z
(Auto) =
(Speed)
100 = 100 Mbps
10 = 10 Mbps
(Half) =
(Duplex) (Full) =
– =
(Enable) =
(Flow Control)
(Disable) =
– =
Sch_410TQS_Emb.p65 99-4-6, 16:135

6
45678
9
Module A
ackable Hub
10/100
10/100
MDI/
MDI-X
19
210
311
412
513
614
715
816
Left
Right
Link=SolidGreen
Activity=BlinkingGreen
Collision=BlinkingOrange
10Mbps=SolidOrange
100Mbps=Off
Intel
®
Express410TStandaloneSwitch
Status
2


3
1


®






Kr_410TQS.Emb.p65 99-04-06, ¿ÀÈÄ 5:376

7
12345
MDI
MDI-X
Intel
®
Express 410T Standalone
S
MDI
MDI-X

4
5


E

T
B
z
c +S
c +R

z
Kr_410TQS.Emb.p65 99-04-06, ¿ÀÈÄ 5:387

8
Français
45678
9
Module A
ackable Hub
10/100
10/100
MDI/
MDI-X
19
210
311
412
513
614
715
816
Left
Right
Link=SolidGreen
Activity= BlinkingGreen
Collision=BlinkingOrange
10Mbps=Solid Orange
100Mbps=Off
Intel
®
Express 410T Standalone Switch
Status
Démarrage rapide
2
Installez le switch
Vérifiez les
connexions
• Vérifiez les diodes du port pour confirmer
l’état de la liaison.
• Une lumière verte continue (sur le côté
gauche) indique une liaison valable.
Gauche (vert/orange)
Vert continu = Liaison
Vert clignotant = Activité
Orange clignotant = Collision
Droite (orange)
Éteint = 100 Mbps
Continu = 10 Mbps
Armoire : utilisez trois petites
vis pour fixer les supports
au switch.
Étagère : enlevez la pellicule
adhésive et placez les supports
en caoutchouc sous le switch.
3
1
• Retirez le switch et les pièces de la boîte.
• Fixez les supports livrés avec l’appareil si vous
envisagez de le monter dans une armoire.
• Installez Intel®Express 410T Standalone Switch
dans une armoire ou sur une étagère.
• Branchez l’alimentation électrique.
Connectez les
périphériques
• Tous les ports sont configurés de manière
à détecter automatiquement la vitesse et le
mode duplex du périphérique connecté.
• Connectez les PC et les serveurs d’impression
au switch à l’aide de câbles directs.
• Utilisez un câble croisé pour connecter
le switch à un autre switch ou
à un hub.
• Utilisez un câble direct pour vous connecter
à un autre switch ou à un hub lorsque
le port 1 est défini sur MDI.
• Utilisez uniquement un câble CAT 5 UTP pour
connecter des périphériques 100 Mbps. Pour
connecter des périphériques 10 Mbps, utilisez
un câble CAT 3, 4 ou 5 UTP.
Switch Hub ou Switch
Switch Serveur d’impression
Switch PC/Serveur
Direct
De À
Switch Hub ou Switch
Direct
Lorsque le port 1 est défini sur
MDI
Croisé
410T-QS-FIGS.p65 4/7/99, 3:26 PM8
