Intelix INT-HDX100-RXWP User manual

Rev 190412 Phone: 719-260-0061
Toll-Free: 800-530-8998
Fax: 719-260-0075
INT-HDX100-RXWP Owners Manual
11675 Ridgeline Drive
Colorado Springs, CO
80921

INT-HDX100-RXWP Owners Manual
2
Important Safety Instrucons
»Please completely read and verify you understand all instrucons in this manual before operang this equipment.
»Keep these instrucons in a safe, accessible place for future reference.
»Heed all warnings.
»Follow all instrucons.
»Do not use this apparatus near water.
»Clean only with a dry cloth.
»Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliers)
that produce heat.
»Use only accessories specied or recommended by Intelix.
»Explanaon of graphical symbols:
◊ Lightning bolt/ash symbol: the lightning bolt/ash and arrowhead within an equilateral triangle
symbol is intended to alert the user to the presence of uninsulated “dangerous voltage” within the
product enclosure which may be of sucient magnitude to constute a risk of shock to a person or
persons.
◊ Exclamaon point symbol: the exclamaon point within an equilateral triangle symbol is intended
to alert the user to the presence of important operang and maintenance (servicing) instrucons
in the literature accompanying the product.
»WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR
MOISTURE AND OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHOULD NOT BE PLACED ON THIS APPARATUS.
»Use the mains plug to disconnect the apparatus from the mains.
»THE MAINS PLUG OF THE POWER CORD MUST REMAIN READILY ACCESSIBLE.
»Do not defeat the safety purpose polarized or grounding-type plug. A polarized plug has two blades with one wider
than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong
is provided for your safety. If the provided plug does not t into your outlet, consult an electrician for replacement of
your obsolete outlet. Cauon! To reduce the risk of electrical shock, grounding of the center pin of this plug must be
maintained.
»Protect the power cord from being walked on or pinched parcularly at the plugs, convenience receptacles, and the
point where they exit from the apparatus.
»Do not block the air venlaon openings. Only mount the equipment per Intelix’s instrucons.
»Use only with the cart, stand, table, or rack specied by Intelix or sold with the equipment. When/if a
cart is used, use cauon when moving the cart/equipment combinaon to avoid injury from p-over.
»Unplug this apparatus during lightning storms or when unused for long periods of me.
»Cauon! Shock Hazard. Do not open the unit.
»Refer to qualied service personnel. Servicing is required when the apparatus has been damaged in any way, such as
power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate normally, or has been dropped.

INT-HDX100-RXWP Owners Manual
3
Table of Contents
Product Overview ��������������������������������������������������������������������������������������������������������������������������������������� 4
Product Contents ���������������������������������������������������������������������������������������������������������������������������������������� 4
Receiver View ��������������������������������������������������������������������������������������������������������������������������������������������� 5
Front and Back Panel ������������������������������������������������������������������������������������������������������������������������������������ 5
Installaon Instrucons������������������������������������������������������������������������������������������������������������������������������ 6
Quick Start ���������������������������������������������������������������������������������������������������������������������������������������������������� 6
Connecng a Video Source ��������������������������������������������������������������������������������������������������������������������������� 6
HDMI Input (Transmier not included) ..................................................................................................6
Connecng a Display������������������������������������������������������������������������������������������������������������������������������������� 6
HDMI Output (Receiver) ......................................................................................................................... 6
HDBaseT Connecon������������������������������������������������������������������������������������������������������������������������������������� 7
Connecng RS232 Control����������������������������������������������������������������������������������������������������������������������������� 7
Connecng IR Control ����������������������������������������������������������������������������������������������������������������������������������� 8
Device Control from Control System ...................................................................................................... 8
Apply Power �������������������������������������������������������������������������������������������������������������������������������������������������� 8
Applicaon Diagram ���������������������������������������������������������������������������������������������������������������������������������� 9

INT-HDX100-RXWP Owners Manual
4
The Intelix INT-HDX100-RXWP receives HDMI, IR, Ethernet and RS232 over a single solid core shielded
Category cable. The INT-HDX100-RXWP supports 1080p video signal up to 100m and 4K signals up
to 4K@60Hz / 4:2:0 / 8 bit color up to 70m. The INT-HDX100-RXWP supports CEC pass through and
is HDCP 2.2 compliant. 48V PoH built in allows the receiver to be powered from a compable Intelix
transmier.
The INT-HDX100-RXWP is compable with all Intelix HDBaseT product oerings and any product that
meets the HDBaseT specicaons.
Product Overview
Product Contents
• INT-HDX100-RXWP HDBaseT Wall Plate Transmier
• Quick Install Guide
• 2 gang decorator plate cover
• RS232 to DB9 breakout cable
• 2-pin phoenix connector
• (4) Mounng Screws
• 24V DC Power supply with US, EU, UK and AU power adapters.

INT-HDX100-RXWP Owners Manual
5
Receiver View
Front and Back Panel
FRONT BACK
15
6
7
3
8
9
4
2
1. DIAGNOSTIC LED’S
POWER (RED) - Solid when device is powered ON
LINK (GREEN) - Solid when successful link between transmier and
receiver is established; o or blinking indicates a physical link error
HDCP (GREEN) - Solid when HDMI signal is encrypted; blinking when
non -HDCP protected content is transmied; OFF when no content is
being transmied
2. IR IN -3.5mm connecon for IR receiver
3. IR OUT -3.5mm connecon for IR emier
4. HDMI OUT - HDMI output port for connecon to HDMI display
5. ETHERNET - RJ45 port for passing Ethernet to receiver / display locaon from transmier
/ source locaon
6. RS232 - 3 pin terminal block for RS232 pass through control of connected display or 3rd
party device
7. DC24V - DC connector for power supply
8. HDBT IN / POH IN - HDBaseT input; RJ45 connecon. Supports 48V PoH
9. DC12V - 2-pin terminal block for external power supply

INT-HDX100-RXWP Owners Manual
6
Installaon Instrucons
Quick Start
1. Connect video source to transmier (not included) HDMI IN
2. Connect display technology to receiver HDMI OUT
3. Connect transmier and receiver together with a shielded Category 6 cable
4. Connect control (oponal)
5. Apply power to receiver to power enre circuit
Connect an HDMI source device to the HDMI input on a compable transmier using an HDMI cable that is less
than or equal to 5 meters in total length for 1080p signals and 1.5 meters for 4K@60 signals.
Connecng a Video Source
HDMI Input (Transmier not included)
Connecng a Display
HDMI Output (Receiver)
Connect a display to the HDMI output on the INT-HDX100-RXWP labeled HDMI OUT using an HDMI cable that is
less than or equal to 5 meters total length for 1080p signals and 1.5 meters for 4K@60 signals. It is recommended
to keep the HDBaseT receiver near the display input as it is not recommended that an acve HDMI cable be used
on the HDMI output on the HDBaseT receiver.

INT-HDX100-RXWP Owners Manual
7
Connect one end of a Category cable to the INT-HDX100-RXWP receiver labeled HDBT IN, then connect the
other end of the Category cable to a compable HDBaseT Intelix transmier labeled HDBT OUT
HDBaseT Connecon
TIA/EIA-568B
Orange/White
Orange
Green/White
Blue
Blue/White
Green
Brown/White
Brown
Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
Pin 7
Pin 8
1 8 Twisted Pair Wiring
Use TIA/EIA-568B wiring for Category 6
connecon between send and receive
units.
To ensure proper performance of the INT-HDX100-RXWP, it is recommended that you use solid core, shielded Category 6
F/UTP cabling at a minimum. Category 5e F/UTP may perform well up to a certain length but may not support power over
HDBaseT reliably longer distances.
For opmized performance use the following Liberty Wire and Cable branded cabling;
Category 6 plenum; 24-4P-P-L6SH
Category 6A plenum; 24-4P-P-L6ASH
Category 6 NON-plenum; 24-4P-L6SH
Category 6A NON -plenum; 24-4P-L6ASH
When using shielded category cabling ALWAYS...
....use shielded connectors
....properly ground the category cable
Connecng RS232 Control
RS232 Wiring
Connect the controller or device RX signal
to TX on the INT-HDX100-RXWP extender.
Connect the controller or device TX signal
to RX on the INT-HDX100-RXWP extender.
INT-HDX100-RXWP
RS232 PORT
Controller or
Display Pin out
RS232 control signals can be transmied through the INT-HDX100-RXWP from/to a compable HDBaseT Intelix
transmier using the RS232 connecon port on the back of the wall plate receiver
TX G RX
RX G TX

INT-HDX100-RXWP Owners Manual
8
Connecng IR Control
The INT-HDX100-RXWP is capable of transming a bi-direcon IR signals through the HDBaseT circuit.
An IR emier (Intelix DIGIB-EMT sold seperately) can be connected to the IR OUT on the back of the wall
plate to transmit IR signals from a compable Intelix HDBaseT transmier. An IR receiver (Intelix DIGIB-EYE
sold seperately) can also be connected to the IR IN on the back of the wall plate to transmit IR signals to a
compable Intelix HDBaseT transmier.
To pass 3rd party IR system signals through the INT-HDX100-RXWP, such as a control system, connect the TS
connector of the IR-AC coupling cable (purchased seperately) to the IR output port of the control system and
connect the TRS connector of the IR-AC cable to the IR IN port of the INT-HDX100-RXWP.
Device Control from Control System
Passing IR Signals:
The INT-HDX100-RXWP is capable of passing IR signals between 33 and 55 KHz. To prevent dam-
age to any of the electronics, the extenders should be powered o while inserng or removing any
IR components.
Apply Power
Connect the included power supply to the Intelix HDBaseT transmiiter or receiver and lock the power supply to
the power connector by twisng the locking collar clockwise.
NOTE: Only Intelix transmiers with 24V power supplies can supply power to the INT-HDX100-RXWP, the wall
plate receiver cannot be powered by Intelix wall plate transmiers with 12V power. When using Intelix wall
plate transmiers you must power both transmier and receiver (INT-HDX100-RXWP) to operate normally.

INT-HDX100-RXWP Owners Manual
9
Applicaon Diagram
MEDIA PLAYER
IR REMOTE 1
FRONT BACK
IR REMOTE 2
CONTROL SYSTEM
HDMI
CATx
AUDIO
RS232
IR
PROJECTOR
up to 100m / 330’
Intelix INT-HDX100-TX
(NOT INCLUDED)

Thank you for your purchase.
For Technical Support please call our toll
free number at 800-530-8998 or email us at
supportlibav@libav.com
www.libav.com
Intelix is a brand of:
