Intellinet 560559 User manual

Web Smart Managed Switches
User Manual
Models 560559, 561167, 561198, 561341, 561426, 508834
intellinet-network.com

2
CHAPTER 1 - PRODUCT INTRODUCTION ........................................................................................................5
1.1 PRODUCT OVERVIEW............................................................................................................ 5
1.2 FEATURES.............................................................................................................................. 5
1.3 EXTERNAL COMPONENT DESCRIPTION................................................................................ 6
1.3.1 FRONT PANEL (EXAMPLE SHOWN FROM 560559).......................................................... 6
1.3.2 REAR PANEL (19 RACKMOUNT/DESKTOP EXAMPLE SHOWN) ........................................ 7
1.4 ENVIRONMENT ..................................................................................................................... 8
1.5 PACKAGE CONTENTS ............................................................................................................ 8
CHAPTER 2 - INSTALLING AND CONNECTING THE SWITCH..............................................................................9
2.1 INSTALLATION (19 RACKMOUNT & DESKTOP VERSION)...................................................... 9
2.1.1 INSTALLATION IN A 19-INCH RACK / CABINET................................................................. 9
2.1.2 DESKTOP INSTALLATION................................................................................................ 10
2.1.3 DIN RAIL INSTALLATION................................................................................................. 11
2.1.4 POWER ON THE SWITCH................................................................................................ 11
2.2 CONNECT COMPUTER (NIC) TO THE SWITCH..................................................................... 12
2.3 SWITCH CONNECTION TO THE PD (EXCLUDING 508834)................................................... 12
CHAPTER 3 - HOW TO LOG INTO THE SWITCH..............................................................................................13
3.1 SWITCH TO END NODE ....................................................................................................... 13
3.2LOGIN INFORMATION......................................................................................................... 13
CHAPTER 4 - WEB CONFIGURATION GUIDE .................................................................................................15
4.1 BASIC SETTING .................................................................................................................... 15
4.1.1 SYSTEM INFO.................................................................................................................. 16
4.1.2 GENERAL SETUP............................................................................................................. 17
4.1.3 IP SETUP......................................................................................................................... 18
4.1.3.1 VLAN INTERFACE..................................................................................................................18
4.1.3.2 VLAN INTERFACE CONFIG....................................................................................................19
4.1.4 PORT SETUP ................................................................................................................... 21
4.1.5 DHCP SERVER................................................................................................................. 23
4.1.5.1 DHCP SERVER POOL SET ......................................................................................................24
4.1.5.2 DHCP SERVER GROUP SET ...................................................................................................25
4.1.6 DHCP-RELAY................................................................................................................... 25
4.1.7 PORT INFORMATION...................................................................................................... 26
4.2 ADVANCED APPLICATION ................................................................................................... 27
4.2.1 VLAN............................................................................................................................... 28
4.2.1.1 VLAN STATUS.......................................................................................................................29
4.2.1.2 VLAN PORT SETTINGS..........................................................................................................30

Web Smart Managed PoE Switches User Manual
3
4.2.1.3 STATIC VLAN ........................................................................................................................32
4.2.2 MAC ADDRESS FORWARDING........................................................................................ 33
4.2.3 LOOPBACK DETECTION (PART OF OUR SELF-HEALING NETWORK SUITE OF FEATURES)
35
4.2.4 SPANNING TREE PROTOCOL (PART OF OUR SELF-HEALING NETWORK SUITE OF
FEATURES) .................................................................................................................................... 36
4.2.4.1 SPANNING TREE PROTOCOL STATUS...................................................................................37
4.2.4.2 SPANNING TREE CONFIGURATION......................................................................................38
4.2.4.3 COMPATIBLE/RAPID SPANNING TREE PROTOCOL..............................................................39
4.2.4.4 MULTIPLE SPANNING TREE PROTOCOL...............................................................................41
4.2.5 BANDWIDTH CONTROL.................................................................................................. 42
4.2.6 BROADCAST STORM CONTROL...................................................................................... 43
4.2.7 MIRRORING.................................................................................................................... 45
4.2.8 LINK AGGREGATION....................................................................................................... 47
4.2.8.1 LINK AGGREGATION STATUS...............................................................................................47
4.2.8.2 LINK AGGREGATION SETTING..............................................................................................48
4.2.8.3 LINK AGGREGATION CONTROL PROTOCOL.........................................................................49
4.2.9 POE SETTINGS (EXCLUDES 508834, WHERE POE IS NOT SUPPORTED) ......................... 50
4.2.9.1 POE SETTINGS......................................................................................................................50
4.2.9.2 POE PORT SETTINGS ............................................................................................................51
4.2.10 POE SCHEDULING (PART OF OUR SELF-HEALING NETWORK SUITE OF FEATURES) . 52
4.2.10.1 POE SCHEDULING ................................................................................................................52
4.2.10.2 CONFIGURE PORT POE SCHEDULING ..................................................................................53
4.2.11 PDM (PART OF OUR SELF-HEALING NETWORK SUITE OF FEATURES) ...................... 54
4.2.12 CLASSIFIER................................................................................................................. 55
4.2.13 POLICY RULE.............................................................................................................. 56
4.2.14 QUEUING METHOD................................................................................................... 57
4.2.15 MULTICAST................................................................................................................ 59
4.2.15.1 MULTICAST STATUS.............................................................................................................59
4.2.15.2 MULTICAST SETTINGS..........................................................................................................60
4.2.15.3 IGMP SNOOPING DENY VLAN..............................................................................................61
4.2.15.4 IGMP FILTERING PROFILE ....................................................................................................62
4.2.16 IPV6 MULTICAST........................................................................................................ 63
4.2.16.1 IPV6 MULTICAST STATUS.....................................................................................................63
4.2.16.2 IPV6 MULTICAST SETTING ...................................................................................................64
4.2.16.3 MLD SNOOPING DENY VLAN ...............................................................................................66
4.2.17 DOS ATTACK PROTECT .............................................................................................. 67
4.2.18 DHCP SNOOPING SETTING........................................................................................ 68
4.2.18.1 DHCP SNOOPING SETTING...................................................................................................68
4.2.18.2 IP SOURCE GUARD...............................................................................................................70
4.2.19 SNTP SETTING............................................................................................................ 71
4.2.20 LLDP PROTOCOL........................................................................................................ 73

Web Smart Managed PoE Switches User Manual
4
4.2.20.1 LLDP STATUS........................................................................................................................73
4.2.20.2 LLDP SETTING.......................................................................................................................74
4.2.21 AAA............................................................................................................................ 74
4.2.21.1 802.1X ..................................................................................................................................75
4.2.21.2 DOMAIN...............................................................................................................................77
4.2.21.3 SET AUTHENTICATION.........................................................................................................78
4.2.21.4 TACACS+ SERVER SETUP......................................................................................................78
4.2.21.5 RADIUS SERVER SETUP ........................................................................................................79
4.2.22 EEE (PART OF OUR SELF-HEALING NETWORK SUITE OF FEATURES) ........................ 80
4.2.23 ARP SAFEGUARDING ................................................................................................. 80
4.2.24 PORT ISOLATION ....................................................................................................... 81
4.2.25 MTU........................................................................................................................... 81
4.2.26 WATCH DOG (PART OF OUR SELF-HEALING NETWORK SUITE OF FEATURES) ......... 82
4.3 MANAGEMENT ................................................................................................................... 83
4.3.1 MANAGEMENT AND MAINTENANCE............................................................................. 83
4.3.2 ACCESS CONTROL........................................................................................................... 84
4.3.2.1 SNMP ...................................................................................................................................84
4.3.2.2 USER INFORMATION............................................................................................................85
4.3.2.3 LOGINS.................................................................................................................................86
4.3.2.4 SUPER PASSWORD...............................................................................................................88
4.3.3 DIAGNOSTIC................................................................................................................... 88
4.3.4 SYSLOG........................................................................................................................... 89
4.3.4.1 SYSLOG SETUP .....................................................................................................................89
4.3.4.2 SYSLOG SERVER SETUP ........................................................................................................90
CHAPTER 5 - APPENDIX..............................................................................................................................92
5.1 TECHNICAL SPECIFICATIONS............................................................................................... 92
5.1.1 HARDWARE SPECIFICATIONS......................................................................................... 92
5.1.2 SOFTWARE SPECIFICATION............................................................................................ 94
5.2 FEATURES AND TERMS EXPLAINED .................................................................................... 95
CHAPTER 6 - ADDITIONAL INFORMATION ...................................................................................................97
6.1 WASTE ELECTRICAL & ELECTRONIC EQUIPMENT............................................................... 97
6.2 WARRANTY ......................................................................................................................... 98
6.3 REGULATORY STATEMENTS................................................................................................ 98

Web Smart Managed PoE Switches User Manual
5
Chapter 1 - Product Introduction
Thank you for purchasing this Intellinet Web Smart Managed Switch. Before you
install and use this product, please read this manual carefully to benefit from the full
set of features that are available.
1.1 Product Overview
These Layer 2 switches are designed to create a high-security and high-performance
network with Self-Healing Network features. They provide from eight to 24
10/100/1000 Mbps auto-sensing RJ45 ports and 100/1000 Mbps SFP optical ports.
All ports support wire-speed forwarding and can provide you with larger network
flexibility.
Some of our newer features have been labeled as Self-Healing Network (SHN)
features. These features are designed to assist in the automated preservation of
health on the network. To assist even further, we have partnered with Domotz™to
provide the additional option of Cloud Management, which gives the ability to
administer our managed switches from any internet-connected device through an
app on your smartphone or web application hosted by Domotz (Cloud Management
is subscription-based, and information can be found at the following link:
https://www.domotz.com/residential-plan.php.)
1.2 Features
➢Compliance with IEEE 802.3i, IEEE 802.3u, IEEE802.3x, IEEE802.3ab, IEEE802.1q,
IEEE802.1p standards
➢In PoE versions, supports IEEE802.3af, IEEE802.3at standards, management of
the PoE ports, PoE port power on/off, and port output power restriction
➢Web interface management
➢Up to 24 x 10/100/1000 Mbps Auto MDI/MDI-X Ethernet ports, ports Auto
MDI/MDIX
➢8K-entry MAC address table of the Switch with auto-learning and auto-aging
➢Supports IEEE802.3x flow control for Full-duplex Mode and backpressure for
Half-duplex Mode
➢Supports QoS (quality of service), port mirroring, link aggregation protocol
➢Supports packet length 9,216 bytes jumbo frame packet forwarding at wire
speed
➢LED indicators for monitoring Link / Activity / Speed and, in PoE versions, PSE
monitoring

Web Smart Managed PoE Switches User Manual
6
1.3 External Component Description
1.3.1 Front Panel (Example shown from 560559)
Depending on your model number, the front panel of the Switch consists of up to
24 x 10/100/1000 Mbps RJ45 ports, 4 x 1000 Mbps SFP ports (and 4 x Uplink RJ45
ports), 1 x Console port, 1 x Reset button and a series of LED indicators as shown
as below.
A —10/100/1000 Mbps RJ45 ports (1 –24):
Designed to connect to a device with a bandwidth of 10 Mbps, 100 Mbps or 1000
Mbps. Each has a corresponding 10/100/1000 Mbps LED (see E —LED indicators
below).
B —SFP ports (SFP1, SFP2, 25S, etc.):
Designed to install an SFP module and connect to the device with a bandwidth of
1000 Mbps. Each has a corresponding 1000 Mbps LED.
Combo ports (25-28T) on model 561426:
The four SFP receiver slots are shared with four related RJ45 ports (25-28T). An
SFP port and a related RJ45 port are called "composite" ports, which means that
they can't be used at the same time. Either the SFP port works or the RJ45 port
works.
C —Console port (Console):
Designed to connect with the serial port of a computer or terminal for monitoring
and configuring the Switch.
D —Reset button (Reset):
With the device powered on, press down the button for about 5 seconds. The
system restores the factory default settings.
E —LED indicators:
The LED indicators will allow you to monitor, diagnose and troubleshoot any
potential problem with the Switch, connection or attached devices.
A
E
D
C
B

Web Smart Managed PoE Switches User Manual
7
The following chart shows the LED indicators of the Switch along with explanation of
each indicator.
LED
COLOR
STATUS
STATUS DESCRIPTION
Power
Green
On
Power On
Off
Power Off
LINK/ACT/
Speed
(1 –24;
25T –28T)
Orange
(10/100
Mbps)
On
A device is connected to the port
Off
No device is connected to the port
Green
(1000
Mbps)
Flashing
Sending or receiving data
LINK/ACT/
Speed
(SFP1, 2)
Green
On
A device is connected to the port
Off
No device is connected to the port
Flashing
Sending or receiving data
PoE
(1 –24)
(excluding
508834)
Yellow
On
A Powered Device is connected to the
port and is receiving power.
Off
No Powered Device is connected to the
port, or no power is supplied according to
the power limits of the port.
Flashing
The PoE power circuit may be in short or
the power current may be overloaded.
1.3.2 Rear Panel (19 Rackmount/Desktop example shown)
The rear panel of the Switch contains AC power connector and one marker shown
as below.
F —AC Power Connector:
Power is supplied through an external AC power adapter. See specifications for your
model.
G —Grounding Terminal:
The Switch already comes with a Lightning Protection Mechanism. You can also
ground the Switch through the PE (Protecting Earth) cable of an AC cord or with a
Ground Cable.
F
G

Web Smart Managed PoE Switches User Manual
8
1.4 Environment
➢Operating Temperature: 0°C –45°C
➢Storage Temperature: -40°C –70°C
➢Operating Humidity: 10% –90% non-condensing
➢Storage humidity: 5% –90% non-condensing
1.5 Package Contents
Before installing the Switch, make sure that the following the packing list matches
the items in the packaging. If any part is lost and damaged, please contact your local
agent immediately. In addition, make sure that you have the tools to install switches
and cables on hand.
➢ One Managed Ethernet Switch
➢ Four rubber feet, two mounting ears and eights screws (except for Industrial
version 508834, which is for DIN Rail mounting)
➢ One AC power cord (except for Industrial version 508834, which is designed
to receive power from an Industrial power source)
➢ Quick Install Guide

Web Smart Managed PoE Switches User Manual
9
Chapter 2 - Installing and Connecting the Switch
This part describes how to install this Switch and make connections to it. Please read
the following topics and perform the procedures in the order being presented.
2.1 Installation (19 Rackmount & Desktop version)
Please follow these instructions to avoid incorrect installation, cause device damage
or security threats.
➢Put the Switch on stable place or desktop to prevent damage from falling.
➢Make sure the Switch works in the proper AC input range and matches the
voltage labeled on the Switch.
➢To prevent electrical shocks, do not open the Switch’s housing, even in power
failure or if disconnected from a power source.
➢Make sure that there is proper heat dissipation from and adequate ventilation
around the Switch.
➢Make sure the cabinet can hold the weight of the Switch and its accessories.
2.1.1 Installation in a 19-inch Rack / Cabinet
The Switch can be mounted in an EIA standard-sized, 19-inch rack, which can be
placed in a wiring closet with other equipment. To install the Switch, follow these
steps:
a. Attach the mounting brackets on the Switch’s side panels (one on each side)
and secure them with the screws provided.
Bracket Installation
b. Use the screws provided with the equipment rack to mount the Switch on the
rack and tighten it.

Web Smart Managed PoE Switches User Manual
10
Rack Installation
2.1.2 Desktop Installation
If users are not equipped with a 19-inch standard cabinet, install the Switch on a
desktop. Attach the included rubber feet on the bottom of the Switch at each corner
to minimize external vibration. Allow adequate space for ventilation between the
device and the objects around it.
Desktop Installation

Web Smart Managed PoE Switches User Manual
11
2.1.3 DIN Rail Installation
For Industrial Models, the Switch can be installed onto a DIN rail. Follow these
instructions:
1. With the DIN-rail bracket attached to the device with screws, angle the
bracket onto the DIN rail.
2. Push in the device until it clicks into place.
1. 2.
2.1.4 Power on the Switch
The Switch is powered on by the AC 100 –240 V 50/60 Hz internal high-
performance power supply. Please follow the next tips to connect:
AC Electrical Outlet:
It is recommended to use single-phase three-wire receptacle with neutral outlet or
multifunctional computer professional receptacle. Please make sure to connect the
metal ground connector to the grounding source on the outlet.
AC Power Cord Connection:
Connect the AC power connector in the back panel of the Switch to external
receptacle with the included power cord, and check the power indicator is ON.
When it is ON, it indicates the power connection is OK.
DC Terminal Block Installation (for Industrial models)
NOTE: Ensure all power is off/disconnected before beginning!
1. Loosen appropriate screws.
2. Insert bare power-supply wires into appropriate terminal slots (positive wire
into positive slot; negative wire into negative slot).
3. Tighten appropriate screws to secure wires. (If desired, repeat steps 1 –3 on
second input pair.)
4. Install block into the device and tighten screws.
Example —Your model may be different.
1. 2. 3. 4.

Web Smart Managed PoE Switches User Manual
12
2.2 Connect Computer (NIC) to the Switch
After installing the network card driver, insert the NIC into the computer. Connect
one end of the twisted pair to the RJ45 jack on your computer, and connect the
other end to any RJ45 port of the Switch, with a maximum distance of 100 meters
between the Switch and the computer. Once the connection is OK and the devices
power on normally, the LINK/ACT/Speed status indicator lights, corresponding to
ports on the Switch.
2.3 Switch connection to the PD (excluding 508834)
On PoE models, any ports that have a PoE indicator also have the PoE power supply
function, which makes it possible to provide power to PD devices such as VoIP
phones, network cameras, wireless access points and more. You only need to
connect the Switch PoE port directly to the PD with a network cable.

Web Smart Managed PoE Switches User Manual
13
Chapter 3 - How to Log into the Switch
3.1 Switch to End Node
Use standard Cat5 and higher Ethernet cable (UTP/STP) to connect the Switch to
end nodes as described below. Switch ports will automatically adjust to the
characteristics (MDI/MDI-X, speed, duplex) of the device to which is connected.
Please refer to the LED Indicator table shown above. The LNK/ACT/Speed LEDs for
each port lights when the link is available.
3.2 Login Information
As the Switch provides Web-based management login, configure your computer’s IP
address manually to log onto the Switch. The default settings of the Switch are
shown below.
Parameter
Default Value
Default IP address
192.168.2.1
Default Username
admin
Default Password
SERIAL NUMBER (S/N; found on
the bottom of the switch)
You can log into the configuration window of the Switch through following steps:
1. Connect the Switch with the computer NIC interface.
2. Power on the Switch.

Web Smart Managed PoE Switches User Manual
14
3. Check whether the IP address of the computer is within this network
segment: 192.168.2.xxx (xxx ranges 2 –254), for example, 192.168.2.100.
4. Open the browser and enter http://192.168.2.1 and then press Enter. The
Switch login window appears with the following picture:
Enter the Username and Password. The factory default Username is admin and the
initial Password is the same as the serial number found on the bottom of the switch.
Then click Login to log into the Switch configuration window.

Web Smart Managed PoE Switches User Manual
15
Chapter 4 - Web Configuration Guide
The Switch configuration interface consists of three main areas: the status bar at the
top, the left function menu bar, and the main configuration window. Select the
different functions in the function menu bar to modify all settings in the main
configuration window.
4.1 Basic Setting
Choose Basic Setting, and the following page appears. There are configuration web
pages for System Info, General Setup, IP Setup, Port Setup, DHCP server, DHCP-
Relay, and Port Information.

Web Smart Managed PoE Switches User Manual
16
4.1.1 System Info
To view the basic information of System and configure the IP address and System
name, select Basic Setting>System Information settings in the function menu bar.
【Parameter Description】
Parameter
Description
Product description
Brief description of device type
Software version
Show switch’s current software version.
MAC address
Show switch’s physical address.
IP Address
The management IP of Switch
Subnet Mask
Configure the corresponding subnet mask of the
IP address specified above. The default is
255.255.255.0.
Default Gateway
Specify a gateway address for the switch.
System name
System name.
System Location
Specify the system location.
【Information】
You can view and configure Running System status.

Web Smart Managed PoE Switches User Manual
17
4.1.2 General Setup
To view the basic information of Switch, such as System Description and so on,
select Basic Setting>General Setup in the function menu bar. You can also modify
the System name, System contact and System location.
【Parameter Description】
Parameter
Description
System name
System name
System Location
Specify the system location
System contact
Including company or related URL
Product description
Brief description of device type.
【Configuration example】
To configure general system information:
1. Click Basic Setting > General Setup.
2. Specify the system name as Switch, location as office, and contact
information as admin for the system administrator.
3. Click Apply.

Web Smart Managed PoE Switches User Manual
18
4.1.3 IP Setup
To configure the IP, select Basic Setting>IP Setup in the function menu bar.
4.1.3.1 VLAN interface
To configure the VLAN Interface, select Basic Setting>IP Setup>Vlan interface in the
function menu bar.
【Parameter Description】
Parameter
Description
Interface
Select the interface:
vlan-interface
Supervlan-interface
Vlan ID
Specify the vlan ID
Name
The name of interface

Web Smart Managed PoE Switches User Manual
19
4.1.3.2 VLAN Interface Config
To adjust settings to the VLAN Interface Configuration, select Basic Setting>IP
Setup>Vlan Interface Config in the function menu bar.
【Parameter Description】
Parameter
Description
Interface name
Name of interface
Vlan ID
Specify the VLAN ID
IP Address
The IP address to log into the Switch
Override
You can override former original primary IP or not
【Configuration example】
To configure general system information:
1. Click Basic Setting > IP Setup >Vlan interface Config.
2. Specify the IP Address as 192.168.2.1.
3. Click Add.

Web Smart Managed PoE Switches User Manual
20
