Intellinet 503433 User manual

Fast
EthErnEt
OFFicE
switch
usEr
manual
MODEL 503433
INT-503433-UM-1207-01

Thank you for purchasing the INTELLINET NETWORK SOLUTIONS
™
Ethernet Media Converter, Model 503443.
Designed for high performance in an environment where network trafc
and the number of users increases continuously, this compact switch
provides smooth network migration and allows easy upgrades to match
network capacity.
Easy-to-follow instructions make installation of the switch quick and
simple, so you’ll also soon be enjoying the benets of these additional
features:
FCC Warning
This device has been tested and found to comply with the limits for a
Class B digital device, pursuant to Parts 2 and 15 of FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a commercial environment. This equipment generates,
uses and radiates radio frequency energy and, if not installed and used
in accordance with the user manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area
is likely to cause harmful interference, which the user will be required to
correct at his own expense.
CE Warning
This is a Class B product. In a domestic environment, this product may
cause radio interference, in which case the user may be required to take
adequate measures to correct.
3
• 7 10/100 auto sensing ports that
automatically detect optimal
network speeds
• 10 Mbps BNC port
• Supports any combination of
10 Mbps or 100 Mbps network
devices
• All RJ-45 ports with Auto-MDIX
& NWay auto-negotiation support
• Store and forward switching
architecture
• Full/half duplex operation
• Supports 1024 MAC address
entries
• 96 kBytes buffer memory
• Compact metal case
• LEDs for power, link/activity
• Lifetime Warranty

4
cOnnEctiOns & indicatOrs
LEDs
The front panel LED indicators provide at-a-glance network status and
real-time connectivity info, as detailed in the chart below.
Ports
The auto-negotiation feature of the Fast Ethernet Ofce Switch provides
automatic crossover detection functionality for any port, making it easy
to uplink to another switch without the need for special crossover cable.
LED Status Operation
Power Green The switch is on.
Off Power is disconnected.
Link/Act Green Valid port connection; ready to transmit/receive.
Flashing Data is being transmitted or received.
Off Port is disconnected.
Right: An example of uplinking
the Fast Ethernet Ofce Switch
to another device.
Above: The rear panel of the
Fast Ethernet Ofce Switch:
10/100 Mbps RJ-45 ports (1-7)
and 10 Mbps BNC (coax) port (8).

Power
Power is supplied
to the Fast
Ethernet Ofce
Switch through an
external 7.5 V DC power
adapter that connects to the
device through the side panel.
installatiOn
The Fast Ethernet Ofce Switch can be placed on a desktop or other
appropriate at surface. Prior to installation, check that:
• the device will have adequate ventilation and room for cable and power
adapter connections. A minimum clearance of 25 mm (1 inch) on all
sides is recommended.
• the location is fairly cool and dry. (See Specications for the acceptable
temperature and humidity operating ranges.)
• the location is free from electrical noise from radios, transmitters,
broadband ampliers and such.
5

spEciFicatiOns
6
Standards
• IEEE 802.3 (10Base-2 Ethernet)
• IEEE 802.3 (10Base-T Ethernet)
• IEEE 802.3u (100Base-TX Fast Ethernet)
• IEEE 802.3x (ow control for full duplex mode)
General
• Media support:
- 10Base-2 RG-58 A/U 50 Ohms coaxial cable
- 10Base-T Cat3, 4, 5 UTP/STP RJ-45
- 100Base-TX Cat5 UTP/STP RJ-45
• Packet lter/forwarding rate: 148,800 pps (100 Mbps); 14,880 pps (10 Mbps)
• Buffer memory: 96 kBytes
• MAC address table: 1024 entries
• Switch architecture: store and forward
• Certications: FCC Class B, CE Mark
LEDs
• Power; Link/Activity
Power
• External power adapter: 7.5 V DC
• Power consumption: 5 Watts (maximum)
Environmental
• Metal housing
• Dimensions: 130 (L) x 77 (W) x 24 (H) mm (5.1 x 3.0 x 0.9 in.)
• Weight: 320 g (0.8 lbs.)
• Operating temperature: 0 – 55°C (32 – 140°F)
• Operating humidity: 10 – 90% RH, non-condensing
• Storage temperature: -20 – 90°C (-4 – 194°F)
Package Contents
• Fast Ethernet Ofce Switch
• External power adapter
• User manual

INTELLINET NETWORK SOLUTIONS™offers a complete line
of active and passive networking products.
Ask your local computer dealer for more information or visit
www.intellinet-network.com.
Copyright © INTELLINET NETWORK SOLUTIONS
All products mentioned are trademarks or registered trademarks of their respective owners.
