Interface 9870 User manual

Interface, Inc. • 7418 East Helm Drive • Scottsdale, Arizona 85260 USA • Phone: [phone] • Fax: [phone]
www.interfaceforce.com
Interface 9870 Quick Start Guide
Set Up:
Start by inserting the sensor wires into the Sensor Signal Input Connector. The Signal Input Terminals are
indicated in (Figure 1) below:
(Figure 1)
Insert a flat bladed micro screwdriver into the square hole above or below the round wire insertion hole as
shown in (Figure 2). This will open the metal cover over the round wire insertion hole. After you have
inserted the wire, remove the flat bladed micro screwdriver to secure the wire in its position. Once all of the
necessary wires have been attached to the Signal Input Connector, plug the connector into the 9870
indicator and secure it with the screws located on each side.
(Figure2)

2
Plug the supplied DC power adaptor into the 9870 DC input, then plug the DC power adaptor into a
standard wall socket. You will see the 9870 Standard Home Screen appear on the display.
Remote Sense / TEDS:
If you are using a six-wire configuration TEDS enabled load cell or SENS enabled loadcell, you will need to
adjust the Remote Sense/TEDS parameter. If you are using a four-wire configuration load cell without
TEDS or SENS, skip ahead to the Calibration section.
To begin Remote Sense / TEDS Enabling from the Standard Home Screen, press the Function button.
This will bring you to the Function Menu:
From the Function Menu, use the Arrow buttons to highlight Calibration, then press the Enter button. This
will bring you to the Calibration Menu:

3
From the Calibration Menu use the Arrow buttons to highlight Remote Sense / TEDS, then press the Enter
button. This will take you to the Remote Sense / TEDS Menu:
At the Remote Sense / TEDS Menu, use the Arrow buttons to select the appropriate option depending on
the type of load cell you are using. For this example, we will choose SENS enabled. If you are using a
TEDS enabled load cell, then choose TEDS enabled. Once you have made a selection, press the Enter
button. The option you have selected will be highlighted in Green. Press the Enter button again to confirm
your selection:
This will bring you back to the calibration menu, the Remote Sense / TEDS parameter has been set. Press
the Escape button two times to return to the Standard Home Screen:

4
If you are using a TEDS enabled load cell, skip ahead to the Digital Zero section. Otherwise, proceed with
Calibration.
Calibration:
From the Standard Home Screen, press the Function button. This will bring you to the Function Menu:
From the Function Menu use the Arrow buttons to highlight Calibration, then press the Enter button:
From the Calibration Menu use the Arrow buttons to highlight Equivalent Input Calibration, then press the
Enter button:

5
Use the Arrow buttons to select the Excitation Voltage indicated on the sensors corresponding Calibration
Certification, then press the Enter button. The selected Excitation Voltage will be highlighted Green. Press
the Enter button again to confirm the selected Excitation Voltage:
This will bring you to the Rated Output and Rated Capacity parameters. The Rated Output will be
highlighted in White. Use the Arrow buttons to select the Rated Output indicated on the sensors
corresponding Calibration Certification, then press the Enter button:
The Rated Capacity will now be highlighted in White. Use the Arrow buttons to select the Rated Capacity
indicated on the sensors corresponding Calibration Certification, then press the Enter button:

6
The Rated Output and the Rated Capacity are now highlighted in Green. Press the Enterbutton again to
confirm the Rated Output and Rated Capacity values:
This will bring you to the Zero Balancing function. For the purpose of this Quick Start guide, it will not be
necessary to execute the Zero Balancing function. For further information on the Zero Balancing function,
see (Page 37) of the Interface 9870 User Manual. To proceed, use the Arrow buttons to highlight Skip and
then press the Enter button:
Next you will see the D/A Output Mode parameter. The Analog Output can be set to Voltage or Current
depending on the requirements of the application. For this example, we will select Voltage. Use the Arrow
buttons to highlight Voltage and then press the Enter button. Voltage will be highlighted in Green. Press the
Enter button again to confirm the D/A Output Mode parameter:

7
This will bring you to the D/A Max. Voltage parameter. For this example, we will set the D/A Max. Voltage to
10v. Use the Arrow buttons to input 10v, then press the Enter button. 10v will be highlighted in Green,
press the Enter button again to confirm the D/A Max Voltage parameter:
Next select the desired Engineering Units from the Select EU menu. Use the Arrow buttons to highlight the
appropriate Engineering Units, then press the Enter button. The selection will be highlighted in Green,
press the Enter button again to confirm the selected Engineering Units:
After you have confirmed the Engineering Units, you will see the Cal. Value Lock parameter. This can be
used to lock the Calibration Value if necessary. For this example, it will not be necessary to lock the
Calibration Value. Use the Arrow buttons to highlight OFF and then press the Enter button. The OFF
selection will be highlighted in Green. Press the Enter button again to confirm the selection:

8
This will bring you back to the Function Menu. From the Function Menu, press the Escape button to return
to the Standard Home Screen:
The load cell is now calibrated, proceed to Digital Zero.
Digital Zero:
To set Zero from the Standard Home Screen, Hold down the Zero Button. When the Interface 9870 has
completed setting Zero, the Zero value will be displayed on the Standard Home Screen:
The Interface 9870 is now is now calibrated and ready to use. For more detailed information regarding the
full range options and functions available within the Interface 9870, please refer to the Interface 9870 User
Manual.
