interion 695729 User manual

Part List
Key Description Qty. Part
A5
B1
C 1
D 1
E 1
6
F
G
1
H
4
I
1
J
3
K
1
L
1
ATTENTION: Make certain that all screws are fully tightened before using chair.
Lubricate all moving parts and tighten all screws every 6 months or as needed.
Step 1
Turn Base “B” upside down.
Insert Casters “A” into Base “B”.
Step 2
Attach Right Armrest “D” to Seat Cushion “C” with
Armrest Screws “F” and Flat Washers “G”. Repeat for
Left Armrest “E”. NOTE: Arrows on armrests point to
front of seat cushion and fully tighten all screws.
Step 3
Attach Mechanism “H” to Seat Cushion “C” with
Mechanism Screws “I”.
NOTE: Fully tighten all screws.
Step 4
Attach Backrest “J” to the rear of Mechanism “H”
with Backrest Screws “K”.
NOTE: Fully tighten all screws.
Step 5
Insert Gas Lift “M” into hole on Base “B”.
Step 6
Place seat assembly onto Gas Lift “M”. Push firmly
on the chair seat to securely attach seat assembly to
seat post.
x 5
A
B
M
D
E
ITEM NO.: 695729
ASSEMBLY INSTRUCTIONS
x 3
F
C
L
I
H
C
L
x 4
M
B
x 3
J
K
H
M
6
L
x 3
G
x 3
F
x 3
G

CONTROL INSTRUCTIONS
ITEM NO.: 695729
ARM HEIGHT ADJUSTMENT
SEAT HEIGHT ADJUSTMENT
TILT TENSION
To adjust arm height, push button (1) in to allow the arms
to move up or down freely, release button (1) once the desired
height is reached.
BACK ANGLE ADJUSTMENT
To lock, return the back to the upright position and push lever (2) in.
To unlock, pull lever (2) out.
To raise seat height, remove pressure from the seat and lift lever (2).
To lower seat height, sit on the chair and lift lever (2).
Turn knob (3) clockwise to increase tension and counter-clockwise to
decrease or ease the tension.
Be careful not to loose the knob completely.
1
