Intermec IF61 User manual

IF61 Fixed Reader
User’s Manual

ii IF61 Fixed Reader User’s Manual
Intermec Technologies Corporation
Worldwide Headquarters
6001 36th Ave.W.
Everett, WA 98203
U.S.A.
www.intermec.com
The information contained herein is provided solely for the purpose of allowing customers to
operate and service Intermec-manufactured equipment and is not to be released, reproduced, or
used for any other purpose without written permission of Intermec Technologies Corporation.
Information and specifications contained in this document are subject to change without prior
noticed and do not represent a commitment on the part of Intermec Technologies Corporation.
© 2007-2008 by Intermec Technologies Corporation. All rights reserved.
The word Intermec, the Intermec logo, Norand, ArciTech, Beverage Routebook, CrossBar,
dcBrowser, Duratherm, EasyADC, EasyCoder, EasySet, Fingerprint, i-gistics, INCA (under
license), Intellitag, Intellitag Gen2, JANUS, LabelShop, MobileLAN, Picolink, Ready-to-Work,
RoutePower, Sabre, ScanPlus, ShopScan, Smart Mobile Computing, SmartSystems, TE 2000,
Trakker Antares, and Vista Powered are either trademarks or registered trademarks of Intermec
Technologies Corporation.
There are U.S. and foreign patents as well as U.S. and foreign patents pending.
Wi-Fi is a registered certification mark of the Wi-Fi Alliance.
Microsoft, Windows, and the Windows logo are registered trademarks of Microsoft Corporation
in the United States and/or other countries.
This product includes software developed by the OpenSSL Project for use in the OpenSSL
Toolkit (www.openssl.org).
This product includes cryptographic software written by Eric Young ([e-mail]).
Part of the software embedded in this product is gSOAP software.
Portions created by gSOAP are Copyright (C) 2001-2004 Robert A. van Engelen, Genivia inc.
All Rights Reserved.
In no event shall the author be liable for any direct, indirect, incidental, special, exemplary, or
consequential damages (including, but not limited to, procurement of substitute goods or
services; loss of use, data, or profits; or business interruption) however caused and on any theory
of liability, whether in contract, strict liability, or tort (including negligence or otherwise) arising
in any way out of the use of this software, even if advised of the possibility of such damage.
ACE(TM), TAO(TM), CIAO(TM), and CoSMIC(TM) (henceforth referred to as “DOC
software”) are copyrighted by Douglas C. Schmidt and his research group at Washington
University, University of California, Irvine, and Vanderbilt University, Copyright (c) 1993-2006,
all rights reserved.

IF61 Fixed Reader User’s Manual iii
Document Change Record
This page records changes to this document. The document was
originally released as Revision 001.
Revision Date Description of Change
003 4/2008 Manual was revised to support IF61 firmware
version 2.1x.
Moved edgeware application information to new
documents:
• SAP Device Controller information,
previously in Appendix B, is now in the IF61
SAP Device Controller User’s Guide
(P/N 934-025-xxx).
• Application Level Engine (ALE) information,
previously in Chapter 3, is now in the IF61
Application Level Engine (ALE) User’s Guide
(P/N 934-026-xxx).
Added new information for RFID services,
including BRI and LLRP configuration settings,
and the Device Configuration web service.
002 11/2007 Added information and procedures for
configuring, using, and troubleshooting the
802.11a/b/g radio.
Updated screenshots to match the revised web
browser interface.
Minor revisions made to RFID application
development sections.

iv IF61 Fixed Reader User’s Manual

Contents
IF61 Fixed Reader User’s Manual v
Contents
Before You Begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
Global Services and Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
Web Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
Telephone Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
Service Location Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
Who Should Read This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii
Related Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii
Patent Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xiv
1 Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Overview of the IF61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Understanding the Network and Power Ports . . . . . . . . . . . . . . . . . . . . . . . . 4
Understanding the LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
About the Intermec Ready-To-Work Indicator . . . . . . . . . . . . . . . . . . . . . . . 7
Understanding the Top Panel Ports. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Connecting to the IF61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Assigning an Initial IP Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Using the Web Browser Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Saving Configuration Changes. . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Disabling Help in the Web Browser Interface . . . . . . . . . . . . . . . 14
Installing the IF61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Choosing a Mounting Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Connecting the IF61 to Your Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Setting the Date and Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Using the IF61 Securely . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2 Configuring Network Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Configuring Settings for Your Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Configuring Ethernet Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Configuring the 802.11 Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Setting the 802.11 Network Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Configuring Common Network Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Contents
vi IF61 Fixed Reader User’s Manual
Configuring Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Controlling Access Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Setting Up Logins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Configuring the IF61 to Use a Password Server . . . . . . . . . . . . . 33
Changing the Default Login . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Disabling Access Via the Serial Port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Configuring Wireless Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Configuring WEP Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Configuring Dynamic WEP/802.1x Security . . . . . . . . . . . . . . . . . . . . . . 39
Configuring WPA Personal (PSK) Security . . . . . . . . . . . . . . . . . . . . . . . . 41
Configuring WPA Enterprise (802.1x) Security. . . . . . . . . . . . . . . . . . . . . 43
Configuring WPA2 Personal (PSK) Security . . . . . . . . . . . . . . . . . . . . . . . 45
Configuring WPA2 Enterprise (802.1x) Security. . . . . . . . . . . . . . . . . . . . 47
Managing Certificates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Viewing Certificates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Installing and Uninstalling Certificates . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
3 Developing and Using RFID Applications. . . . . . . . . . . . . . . . . 53
RFID Applications and the IF61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Using the RFID Resource Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Creating RFID Applications for the IF61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Delivering Applications to the IF61. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
About Configuration Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Auto-Starting Applications at Boot Time. . . . . . . . . . . . . . . . . . . . . . . . . . 57
IF61 .NET Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
IF61 Java Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Executing Java Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Java Support for Microsoft SQL Server and Sybase . . . . . . . . . . . 58
IF61 JavaScript Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Installing RFID Applications on the IF61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Managing Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
About the IF61 Edgeware Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Upgrading or Installing Edgeware Applications . . . . . . . . . . . . . . . . . . . . . 62
About RFID Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Configuring BRI Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Changing BRI Attribute Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
About BRI Attribute Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Contents
IF61 Fixed Reader User’s Manual vii
Tag Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Read Tries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Write Tries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Lock Tries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Field Separator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
ID Report . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
No Tag Report. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Report Timeout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Timeout Configuration Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Select Tries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Unselect Tries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Session . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Initial Q. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Initialization Tries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
ID Tries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
ID Timeout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Antenna Tries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Antenna Timeout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Dense Reader Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
LBT Scan Enable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
LBT Channel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Field Strength 1 to 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Antenna Sequence: First through Eighth . . . . . . . . . . . . . . . . . . . 69
Configuring the BRI Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Viewing the BRI Server Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Configuring LLRP Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
About the Developer Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Testing the GPIO Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Sending BRI Commands and Running Scripts . . . . . . . . . . . . . . . . . . . . . . 74
Using the Workbench. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Configuring a JavaScript File to Auto-Run at Boot Time . . . . . . . . . . . . . . 77
Editing Remote Startup Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
4 Managing, Troubleshooting, and Upgrading the IF61 . . 81
Managing the IF61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Using the Device Configuration Web Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Using Simple Network Management Protocol (SNMP) . . . . . . . . . . . . . . . . . . . . . . 84
Using SmartSystems Foundation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Configuring the IF61 with Intermec Settings . . . . . . . . . . . . . . . . . . . . . . . 88

Contents
viii IF61 Fixed Reader User’s Manual
Using Wavelink Avalanche. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Importing and Exporting Files. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Using the IF61 FTP Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Using CIFS File Sharing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Accessing the IF61 via the Linux Shell . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Opening a Secure Shell (SSH) Connection . . . . . . . . . . . . . . . . . . . . . . . . 93
Opening a Telnet Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Using a Communications Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Opening a Serial Connection to the IF61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Maintaining the IF61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Viewing the System Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Viewing the About Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Using the LEDs to Locate the IF61. . . . . . . . . . . . . . . . . . . . . . . 99
Restoring the IF61 to the Default Configuration. . . . . . . . . . . . . . . . . . . 100
Rebooting the IF61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Managing USB Devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Troubleshooting the IF61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Problems While Working With RFID. . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Connecting Directly to the RFID Module . . . . . . . . . . . . . . . . . . . . . . . 104
Problems With Connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Calling Intermec Product Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Accessing Intermec Web Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Upgrading Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
Configuring the Firmware Upgrade. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
Installing the Firmware Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
Upgrading from the Web Browser Interface . . . . . . . . . . . . . . . 110
Upgrading with SmartSystems Server . . . . . . . . . . . . . . . . . . . . 111
Upgrading with a USB Drive . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Upgrading with an Avalanche Package . . . . . . . . . . . . . . . . . . . 112
5 Using the IF61 GPIO Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
About the GPIO Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Accessing the Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

Contents
IF61 Fixed Reader User’s Manual ix
Using the Input Interfaces. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
IF61 Powered Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Isolated Input Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Open Collector Input Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Using the Output Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Switching the High Side Using IF61 Power . . . . . . . . . . . . . . . . . . . . . . . 118
Switching the Low Side Using IF61 Power . . . . . . . . . . . . . . . . . . . . . . . . 118
Switching the High Side Using External Power. . . . . . . . . . . . . . . . . . . . . 119
Driving a DC Relay to Control an AC Load. . . . . . . . . . . . . . . . . . . . . . . 119
Using the Power Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
A Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
IF61 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
RFID Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Port Pin Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
GPIO Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Serial Ports (COM1, COM2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
Ethernet Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
I Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127

Contents
x IF61 Fixed Reader User’s Manual

Before You Begin
IF61 Fixed Reader User’s Manual xi
Before You Begin
This section provides you with safety information, technical
support information, and sources for additional product
information.
Safety Information
Your safety is extremely important. Read and follow all cautions
in this document before handling and operating Intermec
equipment. Your equipment and data can be damaged if you do
not follow the safety cautions.
This section explains how to identify and understand cautions
and notes that are in this document.
Global Services and Support
Warranty Information
To understand the warranty for your Intermec product, visit the
Intermec web site at www.intermec.com, click Support >
Returns and Repairs, then click Warranty.
Disclaimer of warranties: The sample code included in this
document is presented for reference only. The code does not
necessarily represent complete, tested programs. The code is
provided “as is with all faults.” All warranties are expressly
disclaimed, including the implied warranties of merchantability
and fitness for a particular purpose.
Web Support
Visit the Intermec technical knowledge base (Knowledge
Central) at intermec.custhelp.com to review technical
information or to request technical support for your Intermec
product.
A caution alerts you to an operating procedure, practice,
condition, or statement that must be strictly observed to
prevent equipment damage or destruction, or corruption or
loss of data.
Note: Notes either provide extra information about a topic or
contain special instructions for handling a particular condition or
set of circumstances.

Before You Begin
xii IF61 Fixed Reader User’s Manual
Telephone Support
These services are available from Intermec Technologies
Corporation.
Outside the U.S.A. and Canada, contact your local Intermec
representative. To search for your local representative, visit
www.intermec.com and choose About Us > Contact Us.
Service Location Support
For the most current listing of service locations, click Support >
Returns and Repairs > Repair Locations.
For technical support in South Korea, use the after service
locations listed below:
AWOO Systems
102-1304 SK Ventium
522 Dangjung-dong
Gunpo-si, Gyeonggi-do Korea, South 435-776
Contact: Mr. Sinbum Kang
Telephone: [phone]
E-mail: [email protected].kr
Services Description
In the USA and
Canada call 1-800-
755-5505 and
choose this option
Order Intermec
products
• Place an order.
• Ask about an existing
order.
1 and then choose 2
Order Intermec
media
Order printer labels and
ribbons.
1 and then choose 1
Order spare
parts
Order spare parts. 1 or 2 and then
choose 4
Product
Support
Talk to technical support
about your Intermec product.
2 and then choose 2.
Service • Get a return authorization
number for authorized
service center repair.
• Request an on-site repair
technician.
2 and then choose 1

Before You Begin
IF61 Fixed Reader User’s Manual xiii
IN Information System PTD LTD
6th Floor
Daegu Venture Center Bldg 95
Shinchun 3 Dong
Donggu, Daegu City, Korea
E-mail: [email protected] or [e-mail]
Who Should Read This Manual
This user’s manual is for the person who is responsible for
installing, configuring, and maintaining the IF61 Fixed Reader.
This manual provides you with information about the features of
the IF61, and how to install, configure, operate, maintain, and
troubleshoot it.
Before you work with the IF61, you should be familiar with your
network and general networking terms, such as IP address. You
should also be familiar with your RFID system.
This revision of the manual supports the IF61 with firmware
version 2.1x.
Related Documents
This table contains a list of related Intermec documents and their
part numbers.
The Intermec web site at www.intermec.com contains our
documents (as PDF files) that you can download for free.
Document Title Part Number
IF61 Fixed Reader Quick Reference Guide 930-190-xxx
IF61 Compliance Insert 933-089-xxx
Important BRCM1017 Radio Information 933-125-xxx
Important IM5 Information 075231-xxx
Basic Reader Interface Programmer’s Reference Manual 937-000-xxx
IF61 SAP Device Controller User’s Guide 934-025-xxx
IF61 Application Level Events (ALE) Engine User’s
Guide
934-026-xxx
ALE Store and Forward User’s Guide 934-034-xxx
Device Configuration Web Services Command Reference
Manual
937-012-xxx

Before You Begin
xiv IF61 Fixed Reader User’s Manual
To download documents
1Visit the Intermec web site at www.intermec.com.
2Click Support > Manuals.
3In the Select a Product field, choose the product whose
documentation you want to download.
To order printed versions of the Intermec manuals, contact your
local Intermec representative or distributor.
Patent Information
Product is covered by one or more of the following patents:
4,739,328; 4,786,907; 4,864,158; 4,888,591; 4,910,794;
4,999,636; 5,030,807; 5,055,659; 5,070,536; 5,280,159;
5,295,154; 5,349,678; 5,394,436; 5,425,051; 5,428,636;
5,483,676; 5,504,485; 5,504,746; 5,521,601; 5,546,397;
5,550,547; 5,574,979; 5,592,512; 5,673,037; 5,680,633;
5,682,299; 5,696,903; 5,740,366; 5,763,867; 5,777,561;
5,790,536; 5,825,045; 5,828,318; 5,828,693; 5,844,893;
5,850,181; 5,850,187; 5,862,171; 5,940,771; 5,942,987;
5,960,344; 5,995,019; 6,078,251; 6,121,878; 6,122,329;
6,172,596; 6,195,053; 6,249,227; 6,280,544; 6,286,762;
6,286,763; 6,288,629; 6,360,208; 6,384,712; 6,404,325;
6,429,775; 6,486,769; 6,501,807; 6,525,648; 6,639,509;
6,645,327; 6,677,852; 6,768,414; 6,784,789; 6,816,063;
6,830,181; 6,838,989; 6,859,190; 6,906,615; 6,919,793;
6,944,424; 7,075,413; 7,103,087; 7,106,196; 7,117,374;
7,121,467; 7,123,129; 7,158,046; 7,158,091.
There may be other U.S. and foreign patents pending.

IF61 Fixed Reader User’s Manual 1
1Getting Started
This chapter introduces the IF61 Fixed Reader, explains the ports
and LEDs, and explains how the reader fits into your network. It
contains these topics:
•OverviewoftheIF61
• Connecting to the IF61
• Installing the IF61
• Setting the Date and Time
• Using the IF61 Securely

Chapter 1 — Getting Started
2 IF61 Fixed Reader User’s Manual
Overview of the IF61
The IF61 Fixed Reader is an RFID reader that provides
connectivity between tag data and an enterprise system.
IF61 Fixed Reader
In general, the reader forwards RFID tag data to the Ethernet or
wireless network as shown in the next illustrations.
The IF61 Fixed Reader uses an EPCglobal Gen 2-certified IM5
Module (86x MHz RFID frequency band).
The IF61 Fixed Reader uses an EPCglobal Gen 2-certified IM5
Module (915 MHz RFID frequency band).
Note: The IF61 does not ship with RFID antennas. For more
information on these accessories, contact your Intermec sales
representative.

Chapter 1 — Getting Started
IF61 Fixed Reader User’s Manual 3
IF61 in a Wired Ethernet Network
This illustration shows the IF61 in a wired Ethernet network. The IF61 sends
tag data to the RFID application server through the wired network.
IF61 in a Wireless Network
This illustration shows how the IF61 connects to your 802.11a/b/g network.
The reader communicates with the access point as it sends tag data to the
RFID application server.
Container
with RFID tag
RFID
antenna
IF61
Container
with RFID tag
RFID
antenna
IF61
Access
point

Chapter 1 — Getting Started
4 IF61 Fixed Reader User’s Manual
Understanding the Network and Power Ports
The IF61 network and power ports are located under the
removable cable cover.
To remove the cable cover
• Unscrew the four screws on the cable cover to remove it.
Removing the IF61 Cable Cover
IF61 Network and Power Ports
COM 1
COM 2
Ethernet port
USB ports
AC power port
GPIO port

Chapter 1 — Getting Started
IF61 Fixed Reader User’s Manual 5
For more information, see “Port Pin Assignments” on page 124.
IF61 Port Descriptions
Port Description
AC power Connects the reader to an AC power source.
GPIO General purpose input/output (GPIO) port that
connects the IF61 to industrial controls such as relays
or indicators.
For more information on the IF61 GPIO interfaces,
see “About the GPIO Interfaces” on page 114.
COM1 Connects the IF61 to a desktop PC for configuration.
Use an RS-232 null modem cable (P/N 059167).
COM2 Pass-through serial port for developer-level access to a
serial device.
Ethernet 10BaseT/100BaseTx port that connects the reader to
your Ethernet network. The reader auto-negotiates
with the server to set the best data rate. This port uses
MDI/MDI-X auto-switching so you can connect either
a standard Ethernet cable or a crossover cable.
USB Connect USB devices to the IF61. For more
information, see “Managing USB Devices” on
page 101.

Chapter 1 — Getting Started
6 IF61 Fixed Reader User’s Manual
Understanding the LEDs
The IF61 has six LEDs that indicate the status of the reader
during operation.
IF61 LED Descriptions
Icon Name Description
Intermec
Ready-to-Work™
Indicator
Blue LED remains on when an
application is communicating with the
IF61 BRI server. Blinks when no
application is communicating with the
IF61. For more information, see the next
section.
Power Remains on when the IF61 has power.
Wired LAN Flashes when there is activity on the
wired Ethernet network.
Wireless LAN Flashes when there is activity on the
wireless 802.11 network.
Intermec
Ready-to-Work
Indicator
Wireless LAN
Wired LAN
Power
Tag ID
RFID transmit
